Makita

Makita EX2650LH 4-stroke Brushcutter Parts

SKU: Makita EX2650LHRH
€4.02
VAT included

Makita EX2650LH 4-stroke Petrol Brush Cutter 25.4cc Spare Parts

We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Makita EX2650LH 4-stroke Petrol Brush Cutter 25.4cc.
Makita EX2650LH 4-stroke Brushcutter Parts
  • Makita EX2650LH 4-stroke Brushcutter Parts
  • Makita EX2650LH 4-stroke Brushcutter Parts - Drawing
  • Makita EX2650LH 4-stroke Brushcutter Parts - Drawing 1
  • Makita EX2650LH 4-stroke Brushcutter Parts - Drawing 2
  • Makita EX2650LH 4-stroke Brushcutter Parts - Drawing 3
Makita

Makita EX2650LH 4-stroke Brushcutter Parts

SKU: Makita EX2650LHRH Condition: New
€4.02
VAT included

Makita EX2650LH 4-stroke Petrol Brush Cutter 25.4cc Spare Parts

We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Makita EX2650LH 4-stroke Petrol Brush Cutter 25.4cc.
settings 205 spare parts
description 5 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
198 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
Pos. Item Price Buy
2
 photo_cameraImage coming soon 451601-1 SPACER EBH252L €4.02
3
 photo_cameraImage coming soon 141238-9 SHAFT B CPL EX2650LH CS246.4C €24.78
4
 photo_cameraImage coming soon 195143-2 HOOK EBH252L €6.22
5
 photo_cameraImage coming soon 911233-1 HEAD SCREW M5X20 3600H €1.46
6
 photo_cameraImage coming soon 141008-6 ROD B CPL EX2650LH CS246.4C €41.13
7
 photo_cameraImage coming soon 266034-5 SCREW CT 4X16 €3.76
8
 photo_cameraImage coming soon 452840-6 COVER FOR UNLOCKING KNOB UX360D €2.13
9
 photo_cameraImage coming soon 452839-1 BLOCK KEY UX360D EX2650L €2.13
10
 photo_cameraImage coming soon 265596-0 SCREW M6X40 UX360D- EX2650LH €1.42
11
 photo_cameraImage coming soon 312D49-5 JOINT 24 UX360D EX2650LH €20.17
12
 photo_cameraImage coming soon 922211-6 SCREW 5 X 12 X AN250HC €1.46
13
 photo_cameraImage coming soon 922342-1 SCREW M6X25 EX2650LH €1.44
14
 photo_cameraImage coming soon 252273-3 HEX FULL NUT M6 LF1000/DST111 €2.13
15
 photo_cameraImage coming soon 272268-0 LEVER 94 UC360D- EX2650LH €3.19
16
 photo_cameraImage coming soon 253332-6 FLAT WASHER 6 €1.42
17
 photo_cameraImage coming soon 213105-9 SEAL 11 43 / 65SB / HP201N €1.42
18
 photo_cameraImage coming soon 252159-1 HEX NUT XM6 X 5621RDW €3.28
19
 photo_cameraImage coming soon 961014-3 RETAINING RING E-8 €1.46
20
 Retaining Ring S12 for Power Tools Makita 961052-5 Retaining Ring S12 for Power Tools Makita €1.40
Page 2 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 2
Pos. Item Price Buy
38
 photo_cameraImage coming soon 125776-9 CONTROL LEVER EX2650LH €41.13
39
 photo_cameraImage coming soon 266130-9 SCREW 3X16 X 6203/13 / 6313DW €1.46
40
 photo_cameraImage coming soon 451595-0 SWITCH COVER MS335.4C €2.18
41
 photo_cameraImage coming soon 451594-2 SWITCH LEVER MS335.4C €2.18
42
 photo_cameraImage coming soon 232251-9 LEAF SPRING EBH341U/EM2651LH €1.46
43
 photo_cameraImage coming soon 188832-6 HOUSING CONTROL LEVER EX2650LH €17.14
44
 photo_cameraImage coming soon 346248-3 CLAMP 24 EX2650LH €1.44
45
 photo_cameraImage coming soon 922218-2 SCREW M5x14 EBH341U €1.53
46
 photo_cameraImage coming soon 451593-4 BLOCK LEVER MS335.4C €2.18
47
 photo_cameraImage coming soon 233541-3 TORSION SPRING 7 EBH341U €2.18
48
 photo_cameraImage coming soon 168571-4 CABLE EX2650LH €3.95
49
 photo_cameraImage coming soon 233540-5 SPRING TWIST 11 EBH341U €1.46
50
 photo_cameraImage coming soon 451592-6 THROTTLE LEVER MS335.4C P04 €3.28
51
 photo_cameraImage coming soon 638714-7 WIRE EX2650LH €2.14
52
 photo_cameraImage coming soon 638713-9 WIRE EX2650LH €2.14
53
 photo_cameraImage coming soon 452071-7 SHEATH EX2650LH €2.77
54
 photo_cameraImage coming soon 265620-9 TAPPING SCREW 4X18 €1.44
Page 3 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 3
Pos. Item Price Buy
photo_cameraImage coming soon 922211-6 SCREW 5 X 12 X AN250HC €1.46
photo_cameraImage coming soon 922218-2 SCREW M5x14 EBH341U €1.53
Retaining Ring S12 for Power Tools Makita 961052-5 Retaining Ring S12 for Power Tools Makita €1.40
60
 photo_cameraImage coming soon 123499-3 AIR FILTER CASE EX2650LH €7.72
61
 photo_cameraImage coming soon 265791-2 SCREW M4 X EH7500S €1.44
62
 photo_cameraImage coming soon 443171-4 AIR FILTER EX2650LH €2.14
63
 photo_cameraImage coming soon 443169-1 AIR FILTER EX2650LH €10.18
64
 photo_cameraImage coming soon 266618-9 SCREW M5X60 EX2650LH €1.44
65
 photo_cameraImage coming soon 123501-2 FILTER PLATE €36.83
66
 photo_cameraImage coming soon 162346-3 SEPARATOR EX2650LH €11.40
67
 photo_cameraImage coming soon 213540-1 O RING 15 EM2651LH/EBH253L/341 €1.46
68
 photo_cameraImage coming soon 424316-3 VALVE EBH341U €5.38
69
 photo_cameraImage coming soon 422099-9 BREATHER TUBE EX2650LH €3.22
70
 photo_cameraImage coming soon 325665-0 FITTING EX2650LH €1.44
71
 photo_cameraImage coming soon 442153-3 CARBURETTOR GASKET EX2650 €1.44
72
 photo_cameraImage coming soon 266787-6 SCREW M5X18 EX2650LH €1.44
73
 photo_cameraImage coming soon 451825-9 CLAMP EX2650LH €1.44
74
 photo_cameraImage coming soon 451729-5 INSULATING PLATE EX2650LH €3.22
75
 photo_cameraImage coming soon 213547-7 RING 12 EX2650LH €1.44
76
 photo_cameraImage coming soon 422109-2 EBREATHER TUBE X2650LH €10.18
77
 photo_cameraImage coming soon 345918-1 CLAMP EBH341U €1.46
78
 photo_cameraImage coming soon 318745-9 COVER HEAD CIL EX2650LH €8.75
79
 photo_cameraImage coming soon 922222-1 SCREW M5X16 €1.46
80
 photo_cameraImage coming soon 453860-3 CYLINDER HEAD EX2650LH €1.44
81
 photo_cameraImage coming soon 162304-9 GASKET HEAD CIL EX2650LH €2.14
82
 photo_cameraImage coming soon 424302-4 SPARK CAP EH7500S €3.22
83
 Spark Plug Boot Spring Terminal for Brushcutter Makita EBH341U 324891-8 Spark Plug Boot Spring Terminal for Brushcutter Makita EBH341U €1.62
84
 photo_cameraImage coming soon 168534-0 SPARK PLUG EM2651LH/EBH341U/25 €12.23
85
 photo_cameraImage coming soon 125554-7 ROCKET ARM ASSY EM2651LH/EBH34 €6.22
86
 photo_cameraImage coming soon 256200-2 PIN 5 PER 2704 €1.46
87
 photo_cameraImage coming soon 256865-0 ROD 2,5 EBH252L €1.46
88
 photo_cameraImage coming soon 424200-2 SPACKER EM2651LH/EBH251L/341U €1.46
89
 photo_cameraImage coming soon 143823-4 CLUTCH CASE €14.59
90
 photo_cameraImage coming soon 922228-9 SCREW M5X18 EBH341U €1.44
91
 photo_cameraImage coming soon 450569-8 SPACER EBH252L €1.46
93
 photo_cameraImage coming soon 210111-5 BEARING 6201LLU EBH252L €6.95
94
 Retaining Ring R32 for Powertools Makita 962151-6 Retaining Ring R32 for Powertools Makita €1.43
95
 photo_cameraImage coming soon 161588-6 CLUTCH DRUM €33.32
96
 photo_cameraImage coming soon 266864-4 SHOULDER HEX. BOLT M6X25 €2.14
97
 photo_cameraImage coming soon 267817-6 WASHER 8 EBH252L €1.46
98
 photo_cameraImage coming soon 126135-0 CLUTCH CPL EX2650LH €10.18
99
 photo_cameraImage coming soon 161332-1 CLUTCH GEAR X MH-246.4DF €6.95
100
 photo_cameraImage coming soon 231881-3 TENSION SPRING 7 EX2650LH €4.56
101
 photo_cameraImage coming soon 267812-6 WASHER 6 EBH252L €1.46
102
 photo_cameraImage coming soon 264039-9 FLANGED NUT EX2650LH €1.44
103
 photo_cameraImage coming soon 318569-3 FLYER EX2650LH €22.18
104
 photo_cameraImage coming soon 444021-6 GROMMET EX2650LH €1.44
105
 photo_cameraImage coming soon 266602-4 SCREW M4X20 EX2650LH €1.44
106
 photo_cameraImage coming soon 452049-0 SPACER EX2650LH €1.44
107
 photo_cameraImage coming soon 161483-0 IGNITION COIL €51.71
108
 photo_cameraImage coming soon 5923500501 CAM SHAFT MS251.4 €3.68
109
 photo_cameraImage coming soon 125552-1 CAM GEAR ASSY EM2651LH/EBH341/ €17.46
110
 photo_cameraImage coming soon 313169-4 CAM LIFTER EM2651LH/EBH251L €4.64
112
 photo_cameraImage coming soon 268239-3 PIN 4 EM2651LH/EBH €1.46
113
 Cam Gear Cover Gasket for Brushcutter Makita EBH341L 162274-2 Cam Gear Cover Gasket for Brushcutter Makita EBH341L €2.76
114
 photo_cameraImage coming soon 318443-5 CAM GEAR COVER EM2651LH/EBH251 €5.38
116
 photo_cameraImage coming soon 135478-9 CYLINDER EX2650LH €159.68
118
 photo_cameraImage coming soon 424201-0 CONTROL VALVE EBH341U €3.28
119
 photo_cameraImage coming soon 346331-6 MUFFLER GASKET EX2650LH €5.28
120
 photo_cameraImage coming soon 168554-4 MUFFLER EX2650LH €10.18
121
 photo_cameraImage coming soon 266440-4 HEX SOCKET HD BOLT M5X40 EM265 €1.46
122
 photo_cameraImage coming soon 168483-1 STARTER PULLEY EBH252L €2.18
123
 photo_cameraImage coming soon 451731-8 PROTECTION EX2650LH €2.14
125
 photo_cameraImage coming soon 638707-4 WIRE EX2650LH €2.14
126
 photo_cameraImage coming soon 638708-2 GROUND WIRE EX2650LH €2.77
129
 photo_cameraImage coming soon 453266-5 CYLINDER COVER EX2650LH €11.27
131
 photo_cameraImage coming soon 424082-2 UPPER SPACER DBC260U €2.77
133
 photo_cameraImage coming soon 922226-3 SCREW M 5 X 18 X 4341FCT €3.76
134
 photo_cameraImage coming soon 318249-1 SEMI UPPER CASE X DBC260U €3.95
135
 photo_cameraImage coming soon 318250-6 SEMI LOWER CASE X DBC260U €3.95
136
 photo_cameraImage coming soon 424083-0 LOWER SPACER X DBC260U €2.77
137
 photo_cameraImage coming soon 325668-4 SPRING BLOCK EBH252L VALVE €2.82
138
 photo_cameraImage coming soon 234108-0 COMPRESSION SPRING 9 EBH252L €1.83
140
 photo_cameraImage coming soon 326366-3 EBH252L DISCHARGE VALVE €7.94
143
 photo_cameraImage coming soon 326367-1 SUCTION VALVE EBH252L €7.94
144
 Piston Ring Top for Brushcutter Dolmar CS246.4C 257298-2 Piston Ring Top for Brushcutter Dolmar CS246.4C €6.73
145
 photo_cameraImage coming soon 195145-8 EBH252L PISTON RING €22.58
147
 Dolmar Blower PB252.4 Piston Set 197453-3 Dolmar Blower PB252.4 Piston Set €21.97
148
 photo_cameraImage coming soon 254040-2 WOODRUFF KEY 3 EM2651LH/EBH341 €4.02
149
 photo_cameraImage coming soon 123774-7 CRANKSHAFT €63.46
150
 Oil Seal 10 for Brushcutter Dolmar MS335.4C 213769-9 Oil Seal 10 for Brushcutter Dolmar MS335.4C €3.20
151
 photo_cameraImage coming soon 267400-9 WASHER 23 €1.46
152
 photo_cameraImage coming soon 213089-1 SEAL 12 EBH252L €4.02
153
 photo_cameraImage coming soon 257781-9 PISTON PIN EBH252L €1.46
154
 Piston Pin Circlip for Brushcutter Makita RBC310 233976-8 Piston Pin Circlip for Brushcutter Makita RBC310 €6.01
155
 photo_cameraImage coming soon 162345-5 GASKET OIL CUP EX2650L €3.22
156
 photo_cameraImage coming soon 346083-9 PLATE EBH341U €2.82
157
 photo_cameraImage coming soon 318910-0 CHECK PLATE EX2650LH €2.77
158
 photo_cameraImage coming soon 922112-8 SCREW M4X10 BPT350 €1.46
159
 photo_cameraImage coming soon 318588-9 OIL CUP EX2650LH €33.70
161
 photo_cameraImage coming soon 424344-8 DAMPER EBH2650LH €1.44
162
 photo_cameraImage coming soon 346305-7 GASKET EX2650LH €1.44
163
 photo_cameraImage coming soon 266611-3 SCREW M6X8 EX2650LH €1.44
164
 photo_cameraImage coming soon 213548-5 RING 20 EX2650LH €1.44
166
 photo_cameraImage coming soon 282020-8 HOSE CLAMP EM2651LH/EBH251L/ €1.44
167
 photo_cameraImage coming soon 5926500300 FITTING X MS251.4 €4.30
168
 photo_cameraImage coming soon 424301-6 OIL TUBE EX2650LH €4.56
169
 photo_cameraImage coming soon 452047-4 OIL TANK CAP BHX2501 €2.14
170
 photo_cameraImage coming soon 424343-0 GASKET X BHX2501 €1.44
171
 photo_cameraImage coming soon 452048-2 OIL FITTING EX2650LH €2.14
173
 photo_cameraImage coming soon 127112-5 FUEL TANK CAP €19.54
175
 photo_cameraImage coming soon 168755-4 FUEL TUBE EX2650LH €7.81
177
 photo_cameraImage coming soon 163518-3 FUEL FILTER EX2650LH €5.28
178
 Makita Tank for Brushcutter EM2651UH 451736-8 Makita Tank for Brushcutter EM2651UH €18.02
179
 Makita Rubber for Brushcutter EM2651UH 424080-6 Makita Rubber for Brushcutter EM2651UH €1.65
180
 photo_cameraImage coming soon 424081-4 GROMMET X DBC260U €1.44
181
 photo_cameraImage coming soon 451737-6 TANK PROTECTION EX2650LH €3.22
183
 photo_cameraImage coming soon 195308-6 RECOIL STARTER CPL EX2650LH €29.16
184
 photo_cameraImage coming soon 424319-7 STARTER KNOB EBH252L €3.28
185
 photo_cameraImage coming soon 424359-5 RUBBER RING EX2650LH €1.44
187
 photo_cameraImage coming soon 266585-8 SCREW 5X12 EBH252L €2.18
188
 photo_cameraImage coming soon 325923-4 SWING ARM EBH252L €1.46
189
 photo_cameraImage coming soon 451938-6 COLLAR EBH252L €1.46
190
 photo_cameraImage coming soon 451937-8 STARTER SPRING EBH252L €6.95
191
 photo_cameraImage coming soon 232258-5 SPRING AVVIAMENTO EBH252L €10.36
192
 photo_cameraImage coming soon 444023-2 STARTER ROPE EX2650LH €13.07
193
 photo_cameraImage coming soon 451733-4 STARTER CASE EX2650LH €33.70
194
 photo_cameraImage coming soon 922223-9 SCREW M5X16 EBH341U EX2650LH €1.46
215
 photo_cameraImage coming soon 810455-9 CAUTION PLATE EM2651LH/EBH253L €2.18
217
 photo_cameraImage coming soon 941152-7 FLAT WASHER 6 €1.46
223
 photo_cameraImage coming soon 266427-6 SCREW 4X12 MT923 €1.46
224
 photo_cameraImage coming soon 452219-1 AIR LEVER PLATE EX2650LH €2.14
231
 photo_cameraImage coming soon 452220-6 AIR LEVER EX2650LH €2.77
232
 Tapping Screw Bind M3X10 for Percussion Drill Makita HP2030 266007-8 Tapping Screw Bind M3X10 for Percussion Drill Makita HP2030 €2.07
233
 photo_cameraImage coming soon 352020-3 SEPARATOR EX2650LH €6.11
234
 photo_cameraImage coming soon 453865-3 SEPARATOR BOX EX2650LH €3.95
235
 photo_cameraImage coming soon 453862-9 OIL CUP EX2650LH €2.77
Page 4 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 4
Pos. Item Price Buy
Tapping Screw Bind M3X10 for Percussion Drill Makita HP2030 266007-8 Tapping Screw Bind M3X10 for Percussion Drill Makita HP2030 €2.07
photo_cameraImage coming soon 266427-6 SCREW 4X12 MT923 €1.46
photo_cameraImage coming soon 352020-3 SEPARATOR EX2650LH €6.11
photo_cameraImage coming soon 452219-1 AIR LEVER PLATE EX2650LH €2.14
photo_cameraImage coming soon 452220-6 AIR LEVER EX2650LH €2.77
photo_cameraImage coming soon 453862-9 OIL CUP EX2650LH €2.77
photo_cameraImage coming soon 453865-3 SEPARATOR BOX EX2650LH €3.95
photo_cameraImage coming soon 810455-9 CAUTION PLATE EM2651LH/EBH253L €2.18
photo_cameraImage coming soon 941152-7 FLAT WASHER 6 €1.46
197
 photo_cameraImage coming soon 168762-7 CARBURATOR EX2650LH CS246.4C €78.10
198
 photo_cameraImage coming soon 325922-6 SCREW CARBURATOR EBH341U €6.95
199
 photo_cameraImage coming soon 413140-9 WASHER EBH341U €2.18
200
 photo_cameraImage coming soon 266581-6 SCREW M3X8 EBH341U €2.18
201
 photo_cameraImage coming soon 257964-1 RETAINING RING E3 EBH341U €4.02
202
 photo_cameraImage coming soon 213538-8 RING 2 EBH341U €4.02
203
 photo_cameraImage coming soon 325985-2 JET EX2650LH €11.40
204
 photo_cameraImage coming soon 234183-6 SPRING 65-9 EBH341U €4.02
205
 Makita EBH341U Pump Gasket 442155-9 Makita EBH341U Pump Gasket €4.06
206
 photo_cameraImage coming soon 168575-6 DIAPHRAGM PUMP EBH341U €8.90
207
 photo_cameraImage coming soon 141737-1 PUMP BODY EX2650LH CS246.4C €22.18
208
 photo_cameraImage coming soon 352010-6 EBH252L FILTER €2.82
209
 photo_cameraImage coming soon 442154-1 SEAL IRIS EBH341U €4.64
210
 Makita Diaphragm for EM2651UH 168620-7 Makita Diaphragm for EM2651UH €23.70
211
 photo_cameraImage coming soon 140438-8 CAM GEAR COVER GASKET EM2651LH €19.90
212
 Primer Bulb for Blower Makita BHX2501 424314-7 Primer Bulb for Blower Makita BHX2501 €6.90
213
 photo_cameraImage coming soon 346270-0 PUMP COVER EBH341U €6.22
214
 photo_cameraImage coming soon 266582-4 SCREW 3x24 EBH341U €2.18
Page 5 local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Pos. Item Price Buy
500
 Makita Band Assembly 125516-5 Makita Band Assembly €6.50
502
 photo_cameraImage coming soon 195515-1 LOOP HANDLE SET €24.78
503
 photo_cameraImage coming soon 346467-1 CLAMP 24 ER2650LH/ER2550/BUR36 €2.13
504
 photo_cameraImage coming soon 346468-9 CLAMP 33 BUX360Z €1.42
505
 photo_cameraImage coming soon 452842-2 CLAMP COVER A €6.75
506
 photo_cameraImage coming soon 922244-1 SCREW M5X25 €2.74
509
 photo_cameraImage coming soon 831304-7 ACCESSORY BAG €2.18
512
 photo_cameraImage coming soon 195638-5 TOOL BAG SET €75.27

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita EX2650LH 4-stroke Petrol Brush Cutter 25.4cc Spare Parts

We are MAKITA original spare parts Worldwide Dealers

at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Makita EX2650LH 4-stroke Petrol Brush Cutter 25.4cc.

In the following table, look for the model of Brusch Cutter and the respective parts of the code.
Makita EX2650LH 4-stroke Petrol Brush Cutter 25.4cc

Makita EX2650LH 4-stroke Petrol Brush Cutter 25.4cc Spare Parts Pag.1
# Part Num. Description
2 451601-1 SPACER EBH252L
3 141238-9 SHAFT B CPL EX2650LH CS246.4C
4 195143-2 HOOK EBH252L
5 911233-1 PAN HEAD SCREW M5X20 3600H
6 141008-6 SHAFT B CPL EX2650LH CS246.4C
7 266034-5 CT SCREW M4X16
8 452840-6 RELEASE BUTTON COVER UX360D
9 452839-1 RELEASE BUTTON UX360D EX2650L
10 265596-0 HEX.BOLT M6X40 UX360D- EX2650LH
11 312D49-5 JOINT 24 UX360D EX2650LH
12 922211-6 HS HEAD BOLT M5X12 EM2651LH - AN250HC
13 922342-1 CAP HD SCREW M6X25 BUX360* EX2650LH
14 252273-3 HEX FULL NUT M6
15 272268-0 LEVER 94 UC360D- EX2650LH
16 253332-6 THIN WASHER 6 6791D
17 213105-9 O RING 11 HR2000/6835DWA/6833- 43/65SB/HP201N
18 252159-1 HEX NUT M6 BPJ140 / BPJ180 / BSS500 - 5621RDW
19 961014-3 EXT E-RING JIS JE-8
20 961052-5 EXT DIN 471 CIRCLIP-12
Makita EX2650LH 4-stroke Petrol Brush Cutter 25.4cc Spare Parts Pag.2
# Part NUm. Description
38 125776-9 CONTROL LEVER ASSY ER2650LH
39 266130-9 TAPPING SCREW BIND 3X 16 6203/13/6313DW
40 451595-0 SWITCH COVER ER2650LH/ER2550
41 451594-2 SWITCH LEVER ER2650LH/ER2550
42 232251-9 LEAF SPRING ER2650LH/ER2550
43 188832-6 LEVER CASE SET ER2650LH/ER2550
44 346248-3 CLAMP 24 ER2650LH/ER2550
45 922218-2 HEX BOLT M5X14 ER2550/EBH341U
46 451593-4 LOCK LEVER ER2650LH/ER2550
47 233541-3 TORSION SPRING 7 ER2650LH/ER25
48 168571-4 CONTROL CABLE ER260LH
49 233540-5 TORSION SPRING 11 ER2650LH/ER
50 451592-6 THROTTLE LEVER ER2650LH/ER2550
51 638714-7 LEAD UNIT ER2650LH
52 638713-9 LEAD UNIT ER260LH
53 452071-7 CORRUGATE TUBE ER2650LH
54 265620-9 TAPPING SCREW M4X18 BHR2*
55 188832-6 LEVER CASE SET ER2650LH/ER2550
Makita EX2650LH 4-stroke Petrol Brush Cutter 25.4cc Spare Parts Pag.3
# Part Num. Description
60 123499-3 CLEANER COVER ASSY ER2650LH
61 265791-2 THUMB SCREW M4 EH7500/ER2650LH
62 443171-4 AIR CLEANER ELEMENT EBH/ELM
63 443169-1 AIR CLEANER ELEMENT EBH/ELM
64 266618-9 HS BUTTON HD BOLT M5X60 ER2650
65 123501-2 CLEANER PLATE ASSY ER2650LH
66 162346-3 SEPARATOR PLATE ER2650LH
67 213540-1 O RING 15 ER2550/BHX2501/EBH
68 424316-3 CHECK VALVE EBH341U
69 422099-9 BREATHER PIPE EX2650LH
70 325665-0 JOINT PIPE ER2650LH/EM2651LH
71 442153-3 CARBURETOR GASKET EX2650
72 266787-6 H.S.H BOLT M5X18 ER2650LH
73 451825-9 CLAMP EX2650LH
74 451729-5 INSULATOR ER2650LH/EM2651LH
75 213547-7 O-RING 12 ER2650LH/EM2651LH
76 422109-2 BREATHER PIPE EX2650LH CS246.4C
77 345918-1 HOSE CLAMP ER2550/ER2650LH
78 318745-9 ROCKER COVER OUTER ER2650LH
79 922222-1 CAP HD SCREW M5X16 HM1200
80 453860-3 ROCKER COVER INNER ER2650LH
81 162304-9 ROCKER COVER GASKET ER2650LH
82 424302-4 PLUG CAP EH7500S
83 324891-8 PLUG CAP SPRING EBH341
84 168534-0 SPARK PLUG NGKCMR4A EBH341U
85 125554-7 ROCKET ARM ASSY ER2550LH/EM26 - EBH341U
86 256200-2 PIN 5 FOR 2704
87 256865-0 ROD 2.5 EBH252L
88 424200-2 SPRING RETAINER ER2650L/EBH253 - EBH341U
89 143823-4 CLUTCH CASE ER2650LH/EM2651LH
90 922228-9 HEX BOLT M5X18 EM2651LH/RBH253
91 450569-8 SPACER EBH252L
92 961052-5 EXT DIN 471 CIRCLIP-12
93 210111-5 BALL BEARING 6201DDU ER2650LH - EBH252L
94 962151-6 RETAINING RING R32
95 161588-6 CLUTCH DRUM
96 266864-4 SHOULDER HEX BOLT M6X25EM2651L
97 267817-6 WASHER 8 EBH252L
98 126135-0 CLUTCH ASSY ER2650LH
99 161332-1 CLUTCH SHOE MH-246.4DF
100 231881-3 TENSION SPRING 7 EX2650LH
101 267812-6 WASHER 6 EBH252L
102 264039-9 FLANGE NUT EX2650LH
103 318569-3 FLYWHEEL EX2650LH
104 444021-6 TUBE EX2650LH
105 266602-4 HEX SOCKET HD BOLT M4X2 EM2651 - EX2650LH
106 452049-0 SPACER EX2650LH
107 161483-0 IGNITION COIL EM2651LH/ER2650L
108 5923500501 CAM SHAFT MS251.4
109 125552-1 CAM GEAR ASSY EM2651LH/ER2650 EBH341U
110 313169-4 CAM LIFTER ER2650LH/EM2651LH EBH341U
112 268239-3 PIN 4 EBH341U
113 162274-2 CAM GEAR COVER GASKET ER2650LH EBH341
114 318443-5 CAM GEAR COVERER2550/ER2650LH EBH341U
115 922222-1 CAP HD SCREW M5X16 HM1200
116 135478-9 CYLINDER BLOCK ASSY ER2650LH
117 922222-1 CAP HD SCREW M5X16 HM1200
118 424201-0 CHECK VALVE EBH341U
119 346331-6 MUFFLER GASKET EX2650LH
120 168554-4 EXHAUST MUFFLER ER2650LH/EM
121 266440-4 HEX SOCKET HD BOLT M5X40 BHX25 EBH341U
122 168483-1 STARTER PULLEY EBH252L
123 451731-8 MUFFLER PLATE EM2651LH/ER2650L
124 922218-2 HEX BOLT M5X14 ER2550/EBH341U EBH341U
125 638707-4 LEAD UNIT EM2651LH/ER2650LH
126 638708-2 LEAD UNIT EM2651LH/ER2650LH
128 922218-2 HEX BOLT M5X14 ER2550/EBH341U EBH341U
129 453266-5 CYLINER COVER EM2651LH/ER2650L
130 922218-2 HEX BOLT M5X14 ER2550/EBH341U
131 424082-2 BUFFER RUBBER ER2650LH/RBC260L DBC260U
132 922211-6 HS HEAD BOLT M5X12 EM2651LH AN250HC
133 922226-3 HEX SOCKET HD BOLT M5X18 EBH25 4341FCT
134 318249-1 PIPE HOLDER ER2650LH/RBC260L/U DBC260U
135 318250-6 PIPE HOLDER ER2650LH/RBC260L/U
136 424083-0 BUFFER RUBBER ER2650LH/EM2651L
137 325668-4 SPACKER ER2650LH/EM2651LH EBH252L
138 234108-0 COMPRESSION SPRING 9 EBH252L
140 326366-3 EXHAUST VALVE EBH252L
143 326367-1 INTAKE VALVE EBH252L
144 257298-2 PISTON RING TOP EX2650LH
145 195145-8 PISTON RING SECOND EBH252L
146 195145-8 PISTON RING EBH252L
147 197453-3 PISTON CPL
148 254040-2 WOODRUFF KEY 3 ER2650LH/EM2651 EBH341U
149 123774-7 CRANK SHAFT ASSY ER2650LH/EM26
150 213769-9 OIL SEAL 10 ER2650LH/EM2651LH
151 267400-9 FLAT WAHSER 23 ER2650LH/EM2651
152 213089-1 OIL SEAL 12 ER2650LH/EM2651LH
153 257781-9 PISTON PIN EBH252L
154 233976-8 CLIP ER2650LH/EM2651LH/EBH253L EBH252L
155 162345-5 OIL CASE GASKET ER2650LH
156 346083-9 LEAD VALVE ER2650LH/EM2651LH EBH341U
157 318910-0 RETAINER PLATE ER2650LH
158 922112-8 CAP HD SCREW M4X10 BPT350
159 318588-9 OIL CASE EM2651LH/ER2650LH
160 922222-1 CAP HD SCREW M5X16 HM1200
161 424344-8 DAMPER EM2651LH/ER2650LH
162 346305-7 GASKET EX2650LH
163 266611-3 HEX BOLT M6X8 EM2651LH/ER2650L
164 213548-5 O-RING 20 EM2651LH/ER2650LH
165 325665-0 JOINT PIPE ER2650LH/EM2651LH
166 282020-8 HOSE CLAMP ER2650LH/EM2651LH EBH341U
167 5926500300 JOINT MS251.4
168 424301-6 OIL TUBE EX2650LH
169 452047-4 OIL TANK CAP FOR BHX2501
170 424343-0 GASKET BHX2501
171 452048-2 OIL PIPE EX2650LH
172 922218-2 HEX BOLT M5X14 ER2550/EBH341U
173 127112-5 FUEL TANK CAP ASSY ER2650LH
174 451739-2 FUEL TANK CAP
175 168755-4 TUBE COMP EX2650LH
176 282020-8 HOSE CLAMP ER2650LH/EM2651LH EBH341U
177 163518-3 GASOLINE FILTER EX2650LH
178 451736-8 FUEL TANK EX2650LH
179 424080-6 BUFFER RUBBER ER2650LH/DBC260 DBC260U
180 424081-4 BUFFER RUBBER ER2650LH/RBX260L DBC260U
181 451737-6 TANK GUARD EX2650LH
182 922218-2 HEX BOLT M5X14 ER2550/EBH341U
183 195308-6 RECOIL STARTER SET EX2650LH
184 424319-7 STARTER KNOB EBH252L
185 424359-5 DAMPER EM2651LH/ER2650LH
187 266585-8 TAPPING SCREW M5X12 ER2650LH
188 325923-4 SWING ARM ER2650LH/ER2550
189 451938-6 COLLAR ER2650LH/ER2550
190 451937-8 REEL ER2550/BHX2501/ER2650LH
191 232258-5 SPRIAL SPRING ER2650LH/EM2651L
192 444023-2 STARTER ROPE EX2650LH
193 451733-4 STARTER CASE EX2650LH
194 922223-9 HSH BOLT M5X16 BHX2501/EBH251
215 810455-9 CAUTION PLATE ER2650LH/EM2651L EBH341U
217 941152-7 FLAT WASHER 6
223 266427-6 SCREW 4X12 MT923
224 452219-1 CHOKE LEVER PLATE EX2650LH
231 452220-6 CHOKE LEVER EX2650LH
232 266007-8 TAPPING SCREW M3 X10 HP2030
233 352020-3 EPARATOR MESH ER2650LH
234 453865-3 SEPARATOR CASE ER2650LH
235 453862-9 OIL CASE PLATE ER2650LH
Makita EX2650LH 4-stroke Petrol Brush Cutter 25.4cc Spare Parts Pag.4
# Part Num. Description
197 168762-7 CARBRETTOR EX2650LH CS246.4C
198 325922-6 SWIVEL ER2650LH/341U/BHX2501 EBH341U
199 413140-9 WASHER EBH341U
200 266581-6 PAN HD SCREW M3X8 ER2650LH/EBH EBH341U
201 257964-1 STOP RING E3 EBH341U
202 213538-8 O RING 2 ER2650LH/EBH253L/ EBH341U
203 325985-2 JET EX2650LH
204 234183-6 CONICAL COMP SPRING 5-9ER2650L EBH341U
205 442155-9 PUMP GASKET EBH341U
205 168575-6 PUMP DIAPHRAGM ER2650LH/BHX250
207 141737-1 PUMP BODY EX2650LH CS246.4C
208 352010-6 INLET SCREEN ER2650LH/BHX2501
209 442154-1 METERING DIAPHRAGM GASET EBH EBH341U
210 168620-7 METERING DIAPHRAGM ER2650LH BHX2501
211 140438-8 CAM GEAR COVER GASKET ER2650LH EBH341U
212 424314-7 PRIMER PUMP ER2650LH/BHX2501 EBH341
213 346270-0 PRIMER PUMP COVER ER2650LH EBH341U
214 266582-4 TAPPING SREW M3X24 ER2550/EBH
215 810455-9 CAUTION PLATE ER2650LH/EM2651L
216 800F73-7 INDICATION LABEL
217 941152-7 FLAT WASHER 6 DIN125-A
223 266427-6 TAPPING SCREW 4X12 ER2650LH
224 452219-1 CHOKE PLATE ER2650LH
231 452220-6 CHOKE LEVER ER2650LH
232 266007-8 PT SCREW 3X10 TRIBULAR
233 352020-3 SEPARATOR MESH ER2650LH
234 453865-3 SEPARATOR CASE ER2650LH
235 453862-9 OIL CASE PLATE ER2650LH
Accessories Pag.5
500 125516-5 BAND ASSEMBLY
501 195500-4 OIL SET
502 195515-1 LOOP HANDLE SET
503 346467-1 CLAMP 24 ER2650LH/ER2550/BUR36
504 346468-9 CLAMP 33 ER2650LH/2550/BUR360/
505 452842-2 CLAMP COVER A
506 922244-1 H.S.H.BOLT M5X25 WITH WG
507 783013-3 BOX DRIVER 16-17
508 783202-0 HEX. WRENCH 4
509 831304-7 ACCESSORY BAG
510 122936-4 CUTTER ASSEMBLY
511 783217-7 HEX. WRENCH 5
512 195638-5 TOOL BAG SET
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita EX2650LHRH
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Makita EX2650LHRH Drawing

Makita EX2650LHRH Drawing

Download (1.08MB)

You might also like

Retaining Ring R32 for Powertools Makita
Makita SKU: 962151-6
Retaining Ring R32 for Powertools Makita
Retaining Ring R32 for Powertools Makita Genuine part Makita, Retaining Ring R32 for Powertools Makita. Parts for the following products: - Angle Grinder115 mm 710w-9554 NB - Angle Grinder115 mm 840w-9557 HN - Angle Grinder115 mm...
AVAILABLE €1.43
Details
Gasoline Primer Pump for Chainsaw Makita DCS230T
Makita SKU: 168398-2
Gasoline Primer Pump for Chainsaw Makita DCS230T
Gasoline Primer Pump for Chainsaw Makita DCS230T Genuine parts for Makita, Gasoline Primer Pump for Chainsaws DCS230T - DCS230TC -DCS231T -  DCS231TC - DCS232TC  Part for the following products: - DCS230T - CHAINSAW 22,2cc MAKITA...
AVAILABLE €6.24
Details
Tapping Screw Bind M3X10 for Percussion Drill Makita HP2030
Makita SKU: 266007-8
Tapping Screw Bind M3X10 for Percussion Drill Makita HP2030
Tapping Screw Bind M3X10 for Percussion Drill Makita HP2030 Original spare part Makita, Tapping Screw Bind M3X10 for Percussion Drills HP2030 - HP2031 - HP2032 - HP2033 Part for the following products: - 9523NB Grinder - 9524NB...
Last items in stock €2.07
Details
Cleaner Plate Assy for Petrol Blower Makita BHX2500
Makita SKU: 125468-0
Cleaner Plate Assy for Petrol Blower Makita BHX2500
Cleaner Plate Assy for Petrol Blower Makita BHX2500 Original replacement part Makita, Cleaner Plate Assy for Petrol Blower BHX2500 - BHX2501 - Dolmar PB250.4 - PB252.4. Part for...
on 10 Business Days Approx €21.00
Details
Air Cleaner Element for Petrol Blower Makita BHX2500
Makita SKU: 443140-5
Air Cleaner Element for Petrol Blower Makita BHX2500
Air Cleaner Element for Petrol Blower Makita BHX2500 Original replacement part Makita, Air Cleaner Element for Petrol Blower BHX2500 - BHX2501 - Dolmar PB250.4 - PB252.4. Part for the...
Usually Ships in: 7/10 Business Days Approx. €2.14
Details
Spark Plug Cap for Brushcutter Makita EBH341U
Makita SKU: 424105-6
Spark Plug Cap for Brushcutter Makita EBH341U
Spark Plug Cap for Brushcutter Makita EBH341U Genuine replacement part Makita, Spark Plug Cap for Brushcutters EBH252L - EBH252U - EBH341L - EBH341R - EM4340 - EM4340L - EBH341U. Part for the following products: - EBH252L -...
AVAILABLE €1.62
Details
Lower Flange for Brushcutter Dolmar MS-4300.4R
Makita SKU: 332114-0
Lower Flange for Brushcutter Dolmar MS-4300.4R
Lower Flange for Brushcutter Dolmar MS-4300.4R Genuine replacement part Dolmar, Lower Flange for Brushcutters MS-430.4C - MS-430.4U - MS-4300.4R - MS-4300.4U - MS335.4C - MS335.4U. Part for the following products: -  MS-430.4U -...
Last items in stock €10.70
Details
Piston Pin Circlip for Brushcutter Makita RBC410
Makita SKU: 233983-1
Piston Pin Circlip for Brushcutter Makita RBC410
Piston Pin Circlip for Brushcutter Makita RBC410 Genuine replacement part Makita, Piston Pin Circlip for Brushcutters RBC410 - RBK410 - RBC420 - RBC421 - RBC421L - MS4200 - MS4200E. Part for the following products: - RBC410 -...
AVAILABLE €1.55
Details
Separator Gasket for Blower Makita BHX2501
Makita SKU: 168577-2
Separator Gasket for Blower Makita BHX2501
Separator Gasket for Blower Makita BHX2501 Genuine replacement part Makita, Separator Gasket for Blowers BHX2501 - Dolmar PB252.4. Part for the following products: - BHX2501 - BLOWER 24,5CC 4T...
AVAILABLE €1.62
Details
Retaining Ring S12 for Power Tools Makita
Makita SKU: 961052-5
Retaining Ring S12 for Power Tools Makita
Retaining Ring S12 for Power Tools Makita Genuine replacement part Makita, Retaining Ring S12 for Power Tools Makita. Part for the following products: - 2012 12" PLANER - 2030 12" PLANER-JOINTER - 2030N 12-1/2" PLANER-JOINTER WITH...
AVAILABLE €1.40
Details
Gear Case Ass'y for Brushcutter Dolmar MS335.4C
Makita SKU: 123835-3
Gear Case Ass'y for Brushcutter Dolmar MS335.4C
Gear Case Ass'y for Brushcutter Dolmar MS335.4C Genuine replacement part Dolmar, Gear Case Assembly for Brushcutters MS335.4C - MS335.4U - MS-4300.4R - MS-430.4U. Part for the following products: -  MS-4300.4R - BACKPACK BRUSHCUTTER...
Last items in stock €79.05
Details
Cam Gear Cover Gasket for Brushcutter Makita EBH341L
Makita SKU: 162274-2
Cam Gear Cover Gasket for Brushcutter Makita EBH341L
Cam Gear Cover Gasket for Brushcutter Makita EBH341L Genuine spare part Makita, Cam Gear Cover Gasket for Brushcutters 4 STOKE EBH341L - EBH341U - Dolmar MS335.4C - MS335.4U. Part for the following products: -  EBH341L - BRUSHCUTTER...
on 7/10 Business Days Approx €2.76
Details
Choke Lever for Brushcutter Makita EBH341L
Makita SKU: 451925-5
Choke Lever for Brushcutter Makita EBH341L
Choke Lever for Brushcutter Makita EBH341L Genuine spare part Makita, Choke Lever for Brushcutters 4 STOKE EBH341L - EBH341U - Dolmar MS335.4C - MS335.4U. Part for the following products: - ...
Usually Ships in: 7/10 Business Days Approx. €2.33
Details
Oil Seal 10 for Brushcutter Dolmar MS335.4C
Makita SKU: 213769-9
Oil Seal 10 for Brushcutter Dolmar MS335.4C
Oil Seal 10 for Brushcutter Dolmar MS335.4C Genuine replacement part Dolmar, Oil Seal 10 for Brushcutters MS335.4C - MS335.4U - MS-4300.4R - MS-430.4U. Part for the following products: -  MS335.4C - BRUSHCUTTER 33,5cc 4T -  MS335.4U...
on 7/10 Business Days Approx €3.20
Details
Carburetor Walbro for Brushcutter Dolmar MS-430.4U
Makita SKU: 123301-0
Carburetor Walbro for Brushcutter Dolmar MS-430.4U
Carburetor Walbro for Brushcutter Dolmar MS-430.4U Genuine part Dolmar, Carburetor Walbro for Brushcutter MS-430.4U - MS-430.4C - MS-4300.4U - Makita EM4350LH - EM4350UH - EM4351UH. Part for the following products: -  EM4350LH -...
on 7/10 Business Days Approx. €111.50
Details
Piston Set for Brushcutter Dolmar MS-4300.4R
Makita SKU: 197455-9
Piston Set for Brushcutter Dolmar MS-4300.4R
Piston Set for Brushcutter Dolmar MS-4300.4R Genuine replacement part Dolmar, Piston Set for Brushcutters MS-430.4U - MS-4300.4R - MS-430.4C - MS335.4U. Part for the following products: -  MS-430.4U - BRUSHCUTTER 43CC 4T DOLMAR -...
Last items in stock €20.54
Details
Makita EBH341U Gasket
Makita SKU: 442155-9
Makita EBH341U Pump Gasket
Makita Gasket for Brushcutter EBH341U Genuine spare part Makita, Pump Gasket for Brushcutters EBH341U - DBC260L - MS350.4C - EX2650LHRH. Part for the following products: - MS350.4C – 34CC-4T BRUSHCUTTER DOLMAR - PB7650.4...
Last items in stock €4.06
Details
Makita Tank for Brushcutter EM2651UH
Makita SKU: 451736-8
Makita Tank for Brushcutter EM2651UH
Makita Tank for Brushcutter EM2651UH Genuine replacement part Makita Dolmar, Fuel Tank for Brushcutter EM2651UH - EY2650H25H. Part for the following products: -  Brushcutter Makita...
Last items in stock €18.03
Details
Makita Rubber for Brushcutter EM2651UH
Makita SKU: 424080-6
Makita Rubber for Brushcutter EM2651UH
Makita Rubber for Brushcutter EM2651UH Genuine replacement part Makita Dolmar, Fuel Tank Buffer Rubber for Brushcutter EM2651UH - DBC260L. Part for the following products: -  Brushcutter Makita EM2651UH -  Trimmer Makita...
Last items in stock €1.65
Details
Comments (0)
