Makita

Makita DUM604 Spare Parts

SKU: Makita DUM604
€1.46
VAT included

Makita DUM604 Spare Parts

Fix Your CORDLESS GRASS SHEAR 18V 160MM - DUM604. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Makita DUM604 Spare Parts
  • Makita DUM604 Spare Parts
  • Makita DUM604 Spare Parts
Makita

Makita DUM604 Spare Parts

SKU: Makita DUM604 Condition: New
€1.46
VAT included

Makita DUM604 Spare Parts

Fix Your CORDLESS GRASS SHEAR 18V 160MM - DUM604. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
settings 26 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
26 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
A01
 photo_cameraImage coming soon 326146-7 BASE FRAME DUM166/DUM168 €11.88
A03
 photo_cameraImage coming soon 452055-5 BLADE COVER FOR GRASS SHEAR €4.24
A02
 photo_cameraImage coming soon 457426-1 GRASS RECEIVER 160 DUM604 €6.08
1
 photo_cameraImage coming soon 915116-7 SCREW M4X12 €1.43
2
 photo_cameraImage coming soon 140599-4 HANDLE GUARD X UM164D €3.95
3
 photo_cameraImage coming soon 187426-4 HOUSING SET BUM168 €33.68
3
 photo_cameraImage coming soon 263005-3 PIN RUBBER 6 €1.32
3
 photo_cameraImage coming soon 931102-0 HEX NUT M4 €1.42
5
 photo_cameraImage coming soon 643852-2 TERMINAL X BVC350Z €4.56
6
 photo_cameraImage coming soon 452438-9 BUTTON BLOCK UH200DWEX €1.40
7
 photo_cameraImage coming soon 231473-8 SPRING COMPRESION 4 X 4604D €1.43
10
 photo_cameraImage coming soon 451812-8 LOCKING LEVER X UM164D €1.43
11
 photo_cameraImage coming soon 651891-8 SWITCH V153A6 DUM166/168/DU €6.81
12
 photo_cameraImage coming soon 231473-8 SPRING COMPRESION 4 X 4604D €1.43
13
 photo_cameraImage coming soon 417564-1 STOP LEVER X UM164D €1.43
16
 photo_cameraImage coming soon 451814-4 POWDER PROTECTION X UM164D €1.43
17
 photo_cameraImage coming soon 268254-7 PIN 6 X UM164D €1.43
18
 photo_cameraImage coming soon 261122-3 WASHER 6 X UM164D €1.43
19
 photo_cameraImage coming soon 268256-3 PIN 4 X UM164D €1.43
20
 Gear 47 for Hedge Trimmers Makita AH1020 - AH1020LGEX 227728-7 Gear 47 for Hedge Trimmers Makita AH1020 - AH1020LGEX €6.90
21
 photo_cameraImage coming soon 165609-6 ECCENTRIC X UM164D €6.81
22
 photo_cameraImage coming soon 629945-9 DC MOTOR BUM168 €19.53
23
 photo_cameraImage coming soon 268076-5 PIN 6 UH200DWEX €1.43
24
 photo_cameraImage coming soon 261122-3 WASHER 6 X UM164D €1.43
25
 Gear 12-31 for Hedge Trimmers Makita AH1020 - AH1020LGEX 226831-1 Gear 12-31 for Hedge Trimmers Makita AH1020 - AH1020LGEX €4.07
26
 photo_cameraImage coming soon 261122-3 WASHER 6 X UM164D €1.43
27
 photo_cameraImage coming soon 187426-4 HOUSING SET BUM168 €33.68
27
 photo_cameraImage coming soon 263005-3 PIN RUBBER 6 €1.32
27
 photo_cameraImage coming soon 931102-0 HEX NUT M4 €1.42
28
 photo_cameraImage coming soon 266429-2 SCREW 3X16 FOR TD0101F €1.46
30
 photo_cameraImage coming soon 195267-4 HEAR BLADE ASSY DUM166/DUM168 €59.64
31
 photo_cameraImage coming soon 140451-6 LOWER COVER X UM164D €3.95

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Makita DUM604 Spare Parts

Fix Your CORDLESS GRASS SHEAR 18V 160MM - DUM604. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Prining Scissor and the respective parts of the code.
Makita CORDLESS GRASS SHEAR 18V 160MM - DUM604
Makita DUM604 18v Cordless 160mm Grass Shear Spare Parts
# Part Num. Description
1 915116-7 BINDING HD SCREW M4X12 DUM166
2 819948-3 LABEL/CAUTION BUM166BUM168U
2 140599-4 PROTECTOR DUM166/UM1
3 346275-0 PLATE DUM166/DUM168/UH200D
3 187426-4 HOUSING SET BUM168
3 931102-0 HEX FULL NUT M4 DUR181/ML123
3 263005-3 RUBBER PIN 6 DUR/DHR/DTW/DG
5 643852-2 TERMINAL BUR181/BUM168/BTD146
6 452438-9 *LOCK OFF BUTTON DUM166/168/UM
7 231473-8 COMPRESSION SPING 4 CL106D
10 451812-8 LOCK LEVER DUM166/168/UM164D
11 651891-8 SWITCH V153A6 DUM166/168/DU
12 231473-8 COMPRESSION SPING 4 CL106D
13 417564-1 SWITCH LEVER DUM166/168/UM164
16 451814-4 DUST GUARD DUM166/168/UM164D
17 268254-7 PIN 6 DUM166/168/UM164D/UH200
18 261122-3 WASHER 6 DUM166/168/UM164D
19 268256-3 PIN 4 DUM166/168/UM164D/UH200
20 227728-7 HELICAL GEAR 47 DUM166/168/UM
21 165609-6 CRANK DUM166/168/UM1
22 629945-9 DC MOTOR BUM168
23 268076-5 PIN 6 DUM166/168/LF1000/UM164
24 261122-3 WASHER 6 DUM166/168/UM164D
25 226831-1 GEAR 1231 DUM166/168/UM164D
26 261122-3 WASHER 6 DUM166/168/UM164D
27 187426-4 HOUSING SET BUM168
27 346275-0 PLATE DUM166/DUM168/UH200D
27 263005-3 RUBBER PIN 6 DUR/DHR/DTW/DG
27 931102-0 HEX FULL NUT M4 DUR181/ML123
28 266429-2 TAPPING SCREW 3X16 TD126/DUM
29 815V20-1 NAME PLATE DUM168
30 195267-4 HEAR BLADE ASSY DUM166/DUM168
30 188369-3 OIL VESSEL SET DUM166/168
31 140451-6 UNDER COVER DUM166
A01 326146-7 BASE FRAME DUM166/DUM168
A02 457426-1 GRASS RECEIVER 160 DUM604
A03 452055-5 BLADE COVER FOR GRASS SHEAR
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Dolmar websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Dolmar brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita DUM604
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Makita DUM604 Drawing

Makita DUM604 Drawing

Download (281.29KB)
