Makita LM003G Lawn Mower Parts

SKU: Makita LM003G
€0.10
VAT included

Makita LM003G Cordless Lawn Mower Spare Parts

We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Lawn Mower LM003G.

Makita LM003G Lawn Mower Parts
  • Out-of-Stock
  • Makita LM003G Lawn Mower Parts
  • Makita LM003G Drawing
  • Makita LM003G Drawing - 1
  • Makita LM003G Drawing - 2
  • Makita LM003G Drawing - 3
Makita

Makita LM003G Lawn Mower Parts

SKU: Makita LM003G Condition: New
€0.10
VAT included

Makita LM003G Cordless Lawn Mower Spare Parts

We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Lawn Mower LM003G.

settings 78 Spare parts
description 4 exploded views
picture_as_pdf Download Exploded PDF
Quantity
Out-of-Stock

SHIPPING IN: Usually Ships in 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
Machine Type: Lawn Mowers
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
78 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Image coming soon 327C33-1 SWITCH LEVER €5.83
2
 Image coming soon 232814-1 TENSION SPRING 7 €0.71
3
 Image coming soon 911536-3 SCREW M4X20 €1.32
4
 Image coming soon 455075-8 LEVER €1.32
5
 Image coming soon 455078-2 ARM €1.32
7
 Image coming soon 141T11-7 UPPER HANDLE €24.56
8
 Image coming soon 1830C3-1 SWITCH BOX €4.89
9
 Image coming soon 233068-3 COMPRESSION SPRING 6 €1.32
10
 Image coming soon 455074-0 SWITCH BUTTON €1.32
11
 Image coming soon 650041-2 SWITCH €22.47
12
 Image coming soon 687124-5 CORD CLAMP MT953 €1.32
13
 Image coming soon 265999-8 4X25 SCREW €1.32
14
 Image coming soon 1830C3-1 SWITCH BOX €4.89
15
 Image coming soon 266424-2 SCREW 4X20 TM 3000 €1.32
16
 Tapping Screw M4X18 for Cordless Drill Makita 6221DW 265995-6 Tapping Screw M4X18 for Cordless Drill Makita 6221DW €1.32
17
 Image coming soon 456352-1 SWITCH LEVER CASE COVER €2.65
18
 Image coming soon 456351-3 SWITCH LEVER CASE €2.65
19
 Image coming soon 327C30-7 LOWER HANDLE €15.77
20
 Image coming soon 265C08-1 HEX BOLT M8X50 €1.32
21
 Image coming soon 265C06-5 LOCK KNOB M8 €2.65
22
 Image coming soon 265B81-5 TAPPING SCREW 3X6 €1.32
23
 Image coming soon 413T46-1 SUPPORT €2.22
24
 Image coming soon 213877-6 O-RING 6 €1.32
25
 Image coming soon 327C36-5 STOP PIN €3.22
26
 Image coming soon 951119-7 SPRING PIN 4-24 €1.32
27
 Image coming soon 413T47-9 LEVER €1.62
28
 Image coming soon 699230-4 POWER SUPPLY CORD €15.45
29
 Image coming soon 911163-6 PAN HEAD SCREW M4X35 €1.32
30
 Image coming soon 413944-9 CORD CLAMP €2.03
Page 2 zoom_in View exploded local_shipping Usually Ships in 7/10 BUSINESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
31
 Image coming soon 413B03-1 LOCK LEVER €2.03
32
 Image coming soon 231037-8 SPRING 7 9607/09 / GA / 3612BR €1.32
33
 Image coming soon 141T10-9 BATTERY COVER €12.98
35
 Image coming soon 266459-3 SCREW 5x25 PC5000C €1.32
36
 Image coming soon 273675-0 GRIP A €5.99
37
 Image coming soon 266816-5 TAPPING SCREW M3X12 €1.32
38
 Image coming soon 413939-2 HEIGHT ADJUSTING KNOB €2.65
39
 Image coming soon 266424-2 SCREW 4X20 TM 3000 €1.32
40
 Image coming soon 162C76-4 HEIGHT ADJUSTING PLATE €11.25
41
 Image coming soon 266424-2 SCREW 4X20 TM 3000 €1.32
42
 Image coming soon 413T52-6 HOOK €0.71
45
 Image coming soon 137034-1 MOTOR COVER €32.26
46
 Image coming soon 266424-2 SCREW 4X20 TM 3000 €1.32
47
 Image coming soon 629C41-1 DC MOTOR €154.17
48
 Image coming soon 265A53-4 HEX BOLT M6X22 €1.32
49
 Image coming soon 688238-3 LINE FILTER €3.83
50
 Image coming soon 620M32-5 CONTROLLER €130.10
51
 Image coming soon 266424-2 SCREW 4X20 TM 3000 €1.32
52
 Image coming soon 1830A2-9 TERMINAL BOX €6.39
54
 Image coming soon 632T08-2 TERMINAL €10.07
55
 Image coming soon 652031-1 SCREW M3x6 €1.32
56
 Image coming soon 1830A2-9 TERMINAL BOX €6.39
57
 Image coming soon 413T39-8 DECK €67.36
58
 Image coming soon 413T45-3 BLADE SUPPORT €3.15
59
 Image coming soon 1913G8-3 BLADE 380mm €31.01
60
 Image coming soon 265A69-9 HEX BOLT M10X35 €1.32
78
 Image coming soon 688165-4 FILTER LINE X AH3655 €1.32
Page 3 zoom_in View exploded local_shipping Usually Ships in 7/10 BUSINESS DAYS
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
69
 Image coming soon 141T59-9 DISCHARGE GUIDE €7.23
70
 Image coming soon LC233597-6 TORSION SPRING 8 €1.32
71
 Image coming soon LC961018-5 EXT E-RING JIS JE-5 €1.32
72
 Image coming soon 327C37-3 ROD 6 €2.55
73
 Image coming soon 266424-2 SCREW 4X20 TM 3000 €1.32
74
 Image coming soon 687124-5 CORD CLAMP MT953 €1.32
75
 Image coming soon 687051-6 STRAIN RELIEF HM 1500 €2.03
76
 Image coming soon 266424-2 SCREW 4X20 TM 3000 €1.32
77
 Image coming soon 413T62-3 LED HOLDER €0.71
80
 Image coming soon 266424-2 SCREW 4X20 TM 3000 €1.32
81
 Image coming soon 347870-9 PLATE €1.32
82
 Image coming soon 951119-7 SPRING PIN 4-24 €1.32
83
 Image coming soon 327C32-3 HEIGHT ADJUSTING LEVER €4.20
84
 Image coming soon 232815-9 TENSION SPRING 12 €2.40
85
 Image coming soon 232430-9 COMPRESSION SPRING 5 €0.71
86
 Image coming soon 413T51-8 SUPPORT €1.70
87
 Image coming soon 252286-4 HEX. LOCK NUT M5-8 €1.32
88
 Image coming soon 347B62-2 REAR LINK ROD €5.78
89
 Image coming soon 266424-2 SCREW 4X20 TM 3000 €1.32
90
 Image coming soon 347869-4 PLATE €1.32
91
 Image coming soon 256A45-4 ROD 7 €0.71
92
 Image coming soon 265C05-7 HEX BOLT 5X20 €1.32
93
 Image coming soon 252286-4 HEX. LOCK NUT M5-8 €1.32
94
 Image coming soon 347B61-4 FRONT LINK ROD €5.65
95
 Image coming soon 413T42-9 UNDER COVER €4.15
96
 Image coming soon 266424-2 SCREW 4X20 TM 3000 €1.32
97
 Image coming soon LC252145-2 COLLARED HEX. NUT M8 €1.32
98
 Image coming soon 413U87-3 REAR WHEEL €12.18
99
 Ball Bearing 6200 ZZ for Portable Cutt-Off Machine Maktec MT240 210070-3 Ball Bearing 6200 ZZ for Portable Cutt-Off Machine Maktec MT240 €2.03
100
 Image coming soon 162C74-8 REAR AXLE €14.97
101
 Image coming soon 347869-4 PLATE €1.32
102
 Image coming soon 266424-2 SCREW 4X20 TM 3000 €1.32
103
 Image coming soon LC252145-2 COLLARED HEX. NUT M8 €1.32
104
 Image coming soon 413U86-5 FRONT WHEEL €10.24
105
 Ball Bearing 6200 ZZ for Portable Cutt-Off Machine Maktec MT240 210070-3 Ball Bearing 6200 ZZ for Portable Cutt-Off Machine Maktec MT240 €2.03
106
 Image coming soon 162C73-0 FRONT AXLE €14.87
107
 Image coming soon 347869-4 PLATE €1.32
108
 Image coming soon 266424-2 SCREW 4X20 TM 3000 €1.32
Page 4 zoom_in View exploded local_shipping Usually Ships in 7/10 BUSINESS DAYS
Esploso pagina 4
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
117
 Image coming soon 122F55-2 GRASS CATCHER €38.41
119
 Image coming soon 459806-7 INDICATOR M €1.32
121
 Image coming soon 266424-2 SCREW 4X20 TM 3000 €1.32
122
 Image coming soon 267438-4 FLAT WASHER 5 €1.32
123
 Image coming soon 266424-2 SCREW 4X20 TM 3000 €1.32
124
 Image coming soon 327C29-2 CATCHER FRAME €8.78

Shipping and delivery information will be available shortly.

Makita LM003G Cordless Lawn Mower Spare Parts

We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Lawn Mower LM003G.

In the following table, look for the model of Lawn Mower and the respective parts of the code.
Makita LM003G

Makita Cordless Lawn Mower LM003G Parts List
# Part Num. Description
1 327C33-1 SWITCH LEVER
2 232814-1 TENSION SPRING 7
3 911536-3 PAN HEAD SCREW M4X20
4 455075-8 LEVER
5 455078-2 JOINT
7 141T11-7 UPPER HANDLE
8 1830C3-1 SWITCH BOX
9 233068-3 COMPRESSION SPRING 6
10 455074-0 SWITCH BUTTON
11 650041-2 SWITCH
12 687124-5 STRAIN RELIEF
13 265999-8 TAPPING SCREW 4X25
14 1830C3-1 SWITCH BOX
15 266424-2 TAPPING SCREW 4X20
16 265995-6 PAN HEAD SCREW M4X18
17 456352-1 SWITCH LEVER COVER
18 456351-3 SWITCH LEVER BOX
19 327C30-7 LOWER HANDLE
20 265C08-1 HEX BOLT M8X50
21 265C06-5 LOCK KNOB M8
22 265B81-5 TAPPING SCREW 3X6
23 413T46-1 SUPPORT
24 213877-6 O-RING 6
25 327C36-5 STOP PIN
26 951119-7 SPRING PIN 4-24
27 413T47-9 LEVER
28 699230-4 POWER SUPPLY CORD
29 911163-6 PAN HEAD SCREW M4X35
30 413944-9 CORD CLAMP
Pag.2
# Part Num. Description
31 413B03-1 LOCK LEVER
32 231037-8 COMPRESSION SPRING 7
33 141T10-9 BATTERY COVER
34 8071M8-0
35 266459-3 TAPPING SCREW 5X25
36 273675-0 GRIP
37 266816-5 TAPPING SCREW M3X12
38 413939-2 HEIGHT ADJUSTING KNOB
39 266424-2 TAPPING SCREW 4X20
40 162C76-4 HEIGHT ADJUSTING PLATE
41 266424-2 TAPPING SCREW 4X20
42 413T52-6 HOOK
43 8142A8-5
45 137034-1 MOTOR COVER
46 266424-2 TAPPING SCREW 4X20
47 629C41-1 DC MOTOR
48 265A53-4 HEX BOLT M6X22
49 688238-3 LINE FILTER
50 620M32-5 CONTROLLER
51 266424-2 TAPPING SCREW 4X20
52 1830A2-9 TERMINAL BOX
53 8142B3-2
54 632T08-2 TERMINAL
55 652031-1 PAN HEAD SCREW M3X6
56 1830A2-9 TERMINAL BOX
57 413T39-8 DECK
58 413T45-3 BLADE SUPPORT
59 1913G8-3 BLADE 380mm
60 265A69-9 HEX BOLT M10X35
78 688165-4 LINE FILTER
Pag.3
# Part Num. Description
69 141T59-9 DISCHARGE GUIDE
70 LC233597-6 TORSION SPRING 8
71 LC961018-5 RETAINING RING E-5
72 327C37-3 ROD 6
73 266424-2 TAPPING SCREW 4X20
74 687124-5 STRAIN RELIEF
75 687051-6 STRAIN RELIEF
76 266424-2 TAPPING SCREW 4X20
77 413T62-3 LED HOLDER
80 266424-2 TAPPING SCREW 4X20
81 347870-9 PLATE
82 951119-7 SPRING PIN 4-24
83 327C32-3 HEIGHT ADJUSTING LEVER
84 232815-9 TENSION SPRING 12
85 232430-9 COMPRESSION SPRING 5
86 413T51-8 SUPPORT
87 252286-4 LOCK NUT M5-8
88 347B62-2 REAR LINK ROD
89 266424-2 TAPPING SCREW 4X20
90 347869-4 PLATE
91 256A45-4 ROD 7
92 265C05-7 HEX BOLT 5X20
93 252286-4 LOCK NUT M5-8
94 347B61-4 FRONT LINK ROD
95 413T42-9 UNDER COVER
96 266424-2 TAPPING SCREW 4X20
97 LC252145-2 FLANGE NUT M8
98 413U87-3 REAR WHEEL
99 210070-3 BALL BEARING 6200ZZ
100 162C74-8 REAR AXLE
101 347869-4 PLATE
102 266424-2 TAPPING SCREW 4X20
103 LC252145-2 FLANGE NUT M8
104 413U86-5 FRONT WHEEL
105 210070-3 BALL BEARING 6200ZZ
106 162C73-0 FRONT AXLE
107 347869-4 PLATE
108 266424-2 TAPPING SCREW 4X20
Pag.4
# Part Num. Description
117 122F55-2 GRASS CATCHER
118 413T48-7
119 459806-7 INDICATOR
120 413T44-5
121 266424-2 TAPPING SCREW 4X20
122 267438-4 FLAT WASHER 5
123 266424-2 TAPPING SCREW 4X20
124 327C29-2 CATCHER FRAME
125 162C75-6
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita LM003G

Data sheet

Machine Type
Lawn Mowers
MORE INFO:
[email protected]
SHIPPING IN
Usually Ships in 7/10 BUSINESS DAYS

Specific References

New

Download

Makita LM003G Drawing

Makita LM003G Drawing

Download (1.51MB)

You might also like

Electric Lawn Mower Makita 1600W ELM4110 Sale
Makita SKU: ELM4110
Electric Lawn Mower Makita 1600W ELM4110
Electric Lawn Mower Makita 1600W ELM4110 Features: - Steel housing of 1.5 mm thick. - Voltage indicator and ignition lock light in case of involuntary drive. - Harvest basket provided fitted. - Larger sculpted wheels mounted on ball...
Out-of-Stock €0.00
Details
Makita DLM432 Front Shaft
Makita SKU: 165668-0
Makita DLM432 Front Shaft
Makita Front Shaft for Battery Lawnmower DLM432 Original Makita spare part, Front Shaft for Electric Lawnmower DLM432. Spare part compatible with the following products: - Makita Battery Lawn Mower DLM432 - Part Number: 165668-0
Usually Ships in: 7/10 Business Days Approx. €21.00
Details
Comments (0)
No customer reviews for the moment.
