Annovi Reverberi S.p.A.

HUfirma Parts for Pressure Washer HU 460 DS

SKU: HUfirma HU 4600 DS - 15221
€0.10
VAT included

HUfirma Spare Parts for Pressure Washer HU 460 DS • 15013

We have the original Spares Hufirma for Pressure Washer HU 460 DS • 15013, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.

HUfirma Parts for Pressure Washer HU 460 DS
  • New
  • Out-of-Stock
  • HUfirma Parts for Pressure Washer HU 460 DS
  • HUfirma Parts Diagram for Pressure Washer HU 460 DS
  • HUfirma Parts Diagram for Pressure Washer HU 460 DS - 1
  • HUfirma Parts Diagram for Pressure Washer HU 460 DS - 2
  • HUfirma Parts Diagram for Pressure Washer HU 460 DS - 3
Annovi Reverberi S.p.A.

HUfirma Parts for Pressure Washer HU 460 DS

SKU: HUfirma HU 4600 DS - 15221 Condition: New
€0.10
VAT included

HUfirma Spare Parts for Pressure Washer HU 460 DS • 15013

We have the original Spares Hufirma for Pressure Washer HU 460 DS • 15013, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.

settings 63 Spare parts
description 4 exploded views
picture_as_pdf Download Exploded PDF
Quantity
Out-of-Stock

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N AR:: AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
63 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
M
 photo_cameraImage coming soon 4381470 Screw Kit €4.23
1
 photo_cameraImage coming soon 4380640 HANDLE SA €17.80
2
 photo_cameraImage coming soon 4380691 Knob €8.30
3
 photo_cameraImage coming soon 50943 Screw €1.85
4
 photo_cameraImage coming soon 4383330 Protection €3.14
5
 photo_cameraImage coming soon 4383320 Guard €3.90
6
 photo_cameraImage coming soon 4383410 Guard €2.60
7
 photo_cameraImage coming soon 4380650 CASING SA €23.34
8
 photo_cameraImage coming soon 50943 Screw €1.85
9
 photo_cameraImage coming soon 3081390 Screw €1.04
10
 photo_cameraImage coming soon 5480500 Screw €0.23
11
 photo_cameraImage coming soon 4380680 FOOT €10.42
12
 photo_cameraImage coming soon 3081390 Screw €1.04
13
 photo_cameraImage coming soon 3080580 cable clamp €1.37
14
 photo_cameraImage coming soon 4580800 Plug €1.92
15
 photo_cameraImage coming soon 4580672 Grey RAL 7042 knob €8.82
16
 photo_cameraImage coming soon 4720250 Locking €1.31
17
 photo_cameraImage coming soon 4380590 COVER €2.12
18
 photo_cameraImage coming soon 4380580 COVER €1.44
19
 photo_cameraImage coming soon 4380491 base €24.63
20
 photo_cameraImage coming soon 4380540 Accessories carrier €10.75
21
 photo_cameraImage coming soon 2180330 Rubber €3.86
22
 photo_cameraImage coming soon 50943 Screw €1.85
23
 photo_cameraImage coming soon 4383420 Accessories Holder €1.31
24
 photo_cameraImage coming soon 4383400 Support €4.34
25
 photo_cameraImage coming soon 3081390 Screw €1.04
26
 Annovi Accessory Holder for AR589 4580590 Annovi Accessory Holder for AR589 €7.78
27
 photo_cameraImage coming soon 5480500 Screw €0.23
28
 photo_cameraImage coming soon 4720760 Wheel €11.07
29
 photo_cameraImage coming soon 4380621 Guard €6.05
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4380470 BRACKET €3.07
2
 photo_cameraImage coming soon 50943 Screw €1.85
3
 photo_cameraImage coming soon 3080200 Plate €9.22
4
 photo_cameraImage coming soon 4380550 SHIM €2.12
5
 photo_cameraImage coming soon 50943 Screw €1.85
6
 photo_cameraImage coming soon 4380460 BRACKET €3.07
7
 photo_cameraImage coming soon 4380560 LEVER €3.64
8
 photo_cameraImage coming soon 4380452 Knob €3.14
9
 photo_cameraImage coming soon 5460700 Screw €0.35
Page 3 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
B
 Kit Pistons for Pressure Washers Annovi & Reverberi AR142-AR260-AR388 3081270 Kit Pistons for Pressure Washers Annovi & Reverberi AR142-AR260-AR388 €20.24
A
 Kit Inlet-Outlet Valves for Pressure Washers Blue Clean AR142/490 3081290 Kit Inlet-Outlet Valves for Pressure Washers Blue Clean AR142/490 €6.50
E
 photo_cameraImage coming soon 4384310 TSS valve kit €15.41
C
 photo_cameraImage coming soon 4384420 TSS kit €11.55
D
 photo_cameraImage coming soon 4720810 Brush kit for motor €7.43
1
 photo_cameraImage coming soon 4720680 Electric pump pre-assembly €198.56
2
 photo_cameraImage coming soon 4380170 Conveyor €9.16
3
 photo_cameraImage coming soon 3085940 Screw €0.12
4
 photo_cameraImage coming soon 4720590 Shift €1.04
5
 photo_cameraImage coming soon 4380160 Conveyor €10.80
6
 photo_cameraImage coming soon 4720480 Support €2.21
7
 photo_cameraImage coming soon 3085940 Screw €0.12
8
 photo_cameraImage coming soon 4720500 Spring €1.11
9
 photo_cameraImage coming soon 4720610 Switch €7.21
10
 photo_cameraImage coming soon 4720470 Rod €1.31
11
 photo_cameraImage coming soon 4720490 Cover €0.92
12
 photo_cameraImage coming soon 4383370 Extension cord €7.54
13
 photo_cameraImage coming soon 3086020 Inductance €8.03
14
 photo_cameraImage coming soon 3081440 Capacitor €10.58
15
 photo_cameraImage coming soon 4720620 Board €25.99
16
 photo_cameraImage coming soon 4383520 Joint €13.68
17
 photo_cameraImage coming soon 5480830 EMC interference filter €6.03
18
 Power Cord for Pressure Washer Black&Decker PW 1400 E 3082360 Power Cord for Pressure Washer Black&Decker PW 1400 E €20.62
Page 4 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 4
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4381482 Gun €22.79
2
 O-Ring for Pressure Washers Black & Decker 3083700 O-Ring for Pressure Washers Black & Decker €0.52
3
 photo_cameraImage coming soon 4381492 Extension €19.36
4
 O-Ring mm 6x2 80 SHORE C for Pressure Washers Black & Decker 3083370 O-Ring mm 6x2 80 SHORE C for Pressure Washers Black & Decker €0.52
5
 Extension Turbo Head for Pressure Washers Black & Decker PW 1300-1400S 4100800 Extension Turbo Head for Pressure Washers Black & Decker PW 1300-1400S €13.75
6
 Lance Head for Pressure Washer Stanley SXPW22E 4101550 Lance Head for Pressure Washer Stanley SXPW22E €13.75
7
 photo_cameraImage coming soon 4383501 Tank €19.36
8
 O-Ring mm 5.1x1.6 80 SHORE for Pressure Washers Black & Decker 3083400 O-Ring mm 5.1x1.6 80 SHORE for Pressure Washers Black & Decker €0.52
9
 photo_cameraImage coming soon 4821170 High pressure hose €32.33

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

HUfirma Spare Parts for Pressure Washer HU 460 DS • 15013

We have the original Spares Hufirma for Pressure Washer HU 460 DS • 15013, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.

In the following table, look for the model of the Pressure Washer and the respective parts of the code.
Idropulitrice HU 460 DS • 15013

HU 460 DS • 15013 Pressure Washer Parts List Pag.1
Pos. Code Description
1 4380640 Handle
2 4380691 Knob Blu RAL 5002
3 50943 Screw
4 4383330 Guard Nero
5 4383320 Guard Blu RAL 5002
6 4383410 Guard Grigio RAL 7042
7 4380650 Casing
8 50943 Screw
9 3081390 Screw
10 5480500 Screw
11 4380680 Base
12 3081390 Screw
13 3080580 Cable gland
14 4580800 Plug Blu RAL 5002
15 4580672 Knob Grigio RAL 7042
16 4720250 Lock
17 4380590 Guard
18 4380580 Guard
19 4380491 Base
20 4380540 Accessories carrier
21 2180330 Rubber foot
22 50943 Screw
23 4383420 Accessories carrier
24 4383400 Support
25 3081390 Screw
26 4580590 Accessories carrier
27 5480500 Screw
28 4720760 Wheel
29 4380621 Guard Grigio RAL 7042
M 4381470 Screw kit
HU 460 DS • 15013 Hose reel Pag.2
Pos. Code Description
1 4380470 Bracket
2 50943 Screw
3 3080200 Plate
4 4380550 Shim
5 50943 Screw
6 4380460 Bracket
7 4380560 Lever
8 4380452 Knob Blu RAL 5002
9 5460700 Screw
HU 460 DS • 15013 Electric pump Pag.3
Pos. Code Description
1 4720680 Electric pump assembly
2 4380170 Conveyor
3 3085940 Screw
4 4720590 Shim
5 4380160 Conveyor
6 4720480 Support
7 3085940 Screw
8 4720500 Spring
9 4720610 Switch
10 4720470 Pin
11 4720490 Cover
12 4383370 Extension
13 3086020 Inductance
14 3081440 Capacitor
15 4720620 Board
16 4383520 Fitting Blu RAL 5002
17 5480830 EMC Interference filter
18 3082360 Cable
A 3081290 Valves + seals kit
B 3081270 Piston + seals kit
C 4384420 TSS kit
D 4720810 Brush kit for motor
E 4384310 Valve kit TSS
HU 460 DS • 15013 Standard accessories Pag.4
Pos. Code Description
1 4381482 Gun
2 3083700 O-ring
3 4381492 Extension (Lance)
4 3083370 O-ring
5 4100800 Lance head (Rotopower)
6 4101550 Lance head (Adjustable jet)
7 4383501 High pressure foam lance
8 3083400 O-ring
9 4821170 High pressure hose
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi&Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi&Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
HUfirma HU 4600 DS - 15221

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N AR:
AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS

Specific References

New

Download

HUfirma HU 460 DS Diagram

HUfirma HU 460 DS Diagram

Download (1.07MB)

You might also like

Boiler Burner Engine for Pressure Washers AR2590-3590-4590
Annovi Reverberi S.p.A. SKU: 3520810
Boiler Burner Motor for Pressure Washers AR2590-3590-4590
Boiler Burner Motor Kit for Pressure Washers AR2590-3590-4590 Genuine part Annovi Reverberi, Boiler Burner Motor + Fan Kit MP 43.5 230 V 50 Hz (# 8+9+10) for Pressure Washers Annovi & Reverberi AR 2590 - AR 3590 - AR 4590. Parts For...
Usually Ships in: 10/15 Business Days Approx €126.94
Details
Extension Turbo Head for Pressure Washers Black & Decker PW 1300-1400S
Annovi Reverberi S.p.A. SKU: 4100800
Extension Turbo Head for Pressure Washers Black & Decker PW 1300-1400S
Extension Turbo Head for Pressure Washers Black & Decker PW 1300-1400S Genuine parts Black & Decker,Extension Turbo Head for Pressure Washers BXPW 1300 E - 1400-1500 - 1600-1700 - 1800-2000 - 2200 E - 1300 EP - 1400 PE - PW...
Usually Ships in: 7/10 Business Days Approx. €13.75
Details
O-Ring 23,52x1,78 for Pressure Washers AR 610-757-810-935
Annovi Reverberi S.p.A. SKU: 770260
O-Ring 23,52x1,78 for Pressure Washers AR 610-757-810-935
O-Ring 23,52x1,78 for Pressure Washers AR 610-757-810-935 Original part Annovi & Rverberi, O-Ring 23,52x1,78 mm, for models AR Serie 6 - 610-613-614-615 - Serie 7 - 757 - Serie 8 - 810-820-830 - Serie 9 - 935-945 Part for the...
AVAILABLE €0.39
Details
O-Ring mm 5.1x1.6 80 SHORE for Pressure Washers Black & Decker
Annovi Reverberi S.p.A. SKU: 3083400
O-Ring mm 5.1x1.6 80 SHORE for Pressure Washers Black & Decker
O-Ring mm 5.1x1.6 80 SHORE for Pressure Washers Black & Decker Original part Annovi & Rverberi, HP Hose O-Ring mm 5.1x1.6 80 SHORE for Pressure Washers Black & Decker - Michelin - AR BC - ARSG - Stanley. Part for the...
Usually Ships in: 7/10 Business Days Approx. €0.52
Details
O-Ring mm 6x2 80 SHORE C for Pressure Washers Black & Decker
Annovi Reverberi S.p.A. SKU: 3083370
O-Ring mm 6x2 80 SHORE C for Pressure Washers Black & Decker
O-Ring mm 6x2 80 SHORE C for Pressure Washers Black & Decker Original part Annovi & Rverberi, HP Hose O-Ring mm 6x2 80 SHORE C for Pressure Washers Black & Decker - Michelin - AR BC - ARSG - Stanley. Part for the...
AVAILABLE €0.52
Details
Lance Head for Pressure Washer Stanley SXPW22E
Annovi Reverberi S.p.A. SKU: 4101550
Lance Head for Pressure Washer Stanley SXPW22E
Lance Head for Pressure Washer Stanley SXPW22E Genuine spare part Stanley, Lance Head for Pressure Washers Stanley SXPW22E - SXPW22PE. Part for the following products: - Pressure...
Usually Shipped On 10/15 Business Days Approx. €13.75
Details
Hose HP Reinforced 8mt for Pressure Washer AR Blue Clean 2590
Annovi Reverberi S.p.A. SKU: 3520550
Hose HP Reinforced 8mt for Pressure Washer AR Blue Clean 2590
Hose HP Reinforced 8mt for Pressure Washer AR Blue Clean 2590 Genuine part Annovi & Reverberi, Hose HP Reinforced 8mt for Pressure Washers AR Blue Clean 2590 - 3590 - 4590. Parts For the Following Products: -  Idropulitrice AR...
AVAILABLE €118.12
Details
Power Cord for Pressure Washer Black&Decker PW 1400 E
Annovi Reverberi S.p.A. SKU: 3082360
Power Cord for Pressure Washer Black&Decker PW 1400 E
Power Cord for Pressure Washer Black&Decker PW 1400 E Genuine part Black & Decker, Power Cord 2x0.75 mm2 hd5vv-f for Pressure Washers Annovi Reverberi - ARSG - Black&Decker - Michelin - Stanley Parts for the following...
AVAILABLE €20.62
Details
Diesel Pump for Pressure Washer AR2590
Annovi Reverberi S.p.A. SKU: 3522760
Diesel Pump for Pressure Washer AR2590
Diesel Pump for Pressure Washer AR2590 Genuine part Annovi & Reverberi, Diesel Pump VSC 63 A5H 220V 50/60HZ 0.5 GPH 15 BAR for Pressure Washers AR BC - AR 2590 - AR 3590 - AR 4590. Part For the Following...
Usually Ships in: 10/15 Business Days Approx. €201.63
Details
Diesel Pump Filter for Pressure Washer AR2590
Annovi Reverberi S.p.A. SKU: 3520760
Diesel Pump Filter for Pressure Washer AR2590
Diesel Pump Filter for Pressure Washer AR2590 Genuine part Annovi & Reverberi, Diesel Pump Filter for Pressure Washers AR BC - AR 2590 - AR 3590 - AR 4590. Part For the Following Products: -  Pressure Washer AR Blue Clean AR 2590...
on 10 Business Days Approx €27.32
Details
Boiler Inlet Fitting for Pressure Washer AR BC 2590
Annovi Reverberi S.p.A. SKU: 3520420
Boiler Inlet Fitting for Pressure Washer AR BC 2590
Boiler Inlet Fitting for Pressure Washer AR BC 2590 Genuine part Annovi & Reverberi, Boiler Inlet Fitting for Pressure Washers AR Blue Clean 2590 - 3590 - 4590. Parts For the Following Products: -  Idropulitrice AR Blue Clean...
Usually Ships in: 7/10 Business Days Approx. €23.55
Details
Boiler Outlet Fitting for Pressure Washer AR BC 2590
Annovi Reverberi S.p.A. SKU: 3520530
Boiler Outlet Fitting for Pressure Washer AR BC 2590
Boiler Outlet Fitting for Pressure Washer AR BC 2590 Genuine part Annovi & Reverberi, Boiler Outlet Fitting for Pressure Washers AR Blue Clean 2590 - 3590 - 4590. Parts For the Following Products: -  Idropulitrice AR Blue Clean...
Usually Ships in: 7/10 Business Days Approx. €23.69
Details
Annovi Accessory Holder for AR589
Annovi Reverberi S.p.A. SKU: 4580590
Annovi Accessory Holder for AR589
Annovi Accessory Holder for Pressure Washer AR589 Genuine part Annovi Reverberi, Accessory Holder for Pressure Washer AR589 - AR 4.0 Twin Flow. Part for the Following Products: -  Pressure Washer Pressure Washer Annovi Reverberi...
Usually Ships in: 7/10 Business Days Approx. €7.78
Details
Comments (0)
No customer reviews for the moment.
