Hitachi-HIKOKI original spare parts, sourced from the manufacturer, for to make maintenance or repair damaged parts for Demolition Hammer H60MRV with efficient and professional After Sales Service.
Hitachi-HIKOKI original spare parts, sourced from the manufacturer, for to make maintenance or repair damaged parts for Demolition Hammer H60MRV with efficient and professional After Sales Service.
Informazioni sulle spedizioni e consegne saranno disponibili a breve.
, sourced from the manufacturer, for to make maintenance or repair damaged parts for Demolition Hammer H60MRV with efficient and professional After Sales Service.
In the following table, look for the model of the Rotary Hammer and the respective parts of the code.
| Rotary Hammer Hitachi H 60MRV PARTS LIST | ||
| # | Part Num. | Description |
| 1 | 315529 | FRONT CAP |
| 2 | 324025 | GRIP (A) |
| 3 | 320803 | RING |
| 4 | 320804 | NEEDLE HOLDER |
| 5 | 324027 | SPRING (A) |
| 6 | 317088 | RETAINING RING D42 |
| 7 | 320810 | BALL HOLDER |
| 8 | 324028 | GRIP (B) |
| 9 | 320635 | BAND |
| 10 | 959150 | STEEL BALL D6.35 |
| 11 | 985479 | SEAL LOCK HEX. SOCKET HD. BOLT M8X25 |
| 12A | 324029 | FRONT COVER |
| 13 | 313421 | NEEDLE ROLLER D8X20 |
| 14 | 324026 | RETAINER SLEEVE |
| 15 | 872470 | O-RING (S-26) |
| 16 | 872767 | O-RING (S-32) |
| 17 | 317094 | DAMPER (B) |
| 18A | 324030 | HAMMER HOLDER (B) |
| 19 | 324031 | SECOND HAMMER |
| 20 | 317091 | HAMMER HOLDER (A) |
| 21 | 324032 | DAMPER (A) |
| 22 | 317095 | DAMPER WASHER |
| 23 | 317119 | O-RING (S-56) |
| 24 | 324034 | CYLINDER CASE |
| 26 | 956996 | O-RING (1AS-60) |
| 27 | 324033 | STRIKER |
| 28 | 985454 | O-RING (A) (FPM810) |
| 29 | 301509 | PISTON PIN |
| 30 | 317084 | PISTON |
| 31 | 317082 | CONNECTING ROD |
| 32 | 939543 | RETAINING RING FOR D14 SHAFT |
| 34 | 324035 | CRANK CASE |
| 37 | 324037 | CRANK COVER |
| 38 | 317078 | CRANK SHAFT |
| 39 | 940533 | FEATHER KEY 3X3X10 |
| 41 | 985443 | BEARING COVER |
| 42 | 6204DD | BALL BEARING 6204DDCMPS2L |
| 43A | 326257 | O-RING (I.D 74.5) |
| 44 | 324038 | BACK COVER |
| 47 | 317107 | BOLT M8 |
| 48 | 317106 | HANDLE HOLDER (B) |
| 49 | 317105 | HANDLE HOLDER (A) |
| 50 | 317103 | SIDE HANDLE ASS'Y |
| 51 | 317108 | GRIP |
| 52 | 995403 | OIL SEAL |
| 53 | 995402 | DISTANCE RING (C) |
| 54 | 317080 | FIRST GEAR |
| 55 | 985442 | NEEDLE BEARING (A) (BK1512) |
| 56 | 324048 | GEAR COVER ASS'Y |
| 57 | 6203DD | BALL BEARING 6203DDCMPS2L |
| 58 | 992841 | BEARING WASHER |
| 59 | 996370 | FAN |
| 60 | 360691E | ARMATURE ASS'Y 230V |
| 61 | 305610 | FAN GUIDE |
| 63 | 340610E | STATOR ASS'Y (B) 230V |
| 64 | 945932 | BRUSH TERMINAL |
| 65 | 944954 | BEARING WASHER |
| 66 | 6201DD | BALL BEARING 6201DDCMPS2L |
| 67 | 324040 | HOUSING ASS'Y |
| 68 | 940540 | BRUSH CAP |
| 69 | 999074 | CARBON BRUSH (AUTO STOP TYPE) (1 PAIR) |
| 70 | 956984 | BRUSH HOLDER |
| 72 | 317087 | MAGNET |
| 73 | 324041 | TAIL COVER |
| 75 | 324045 | SLEEVE (B) |
| 77 | 317100 | CASE (B) |
| 78 | 324052 | CONTROLLER CIRCUIT 230V-240V |
| 82 | 324036 | CRANK CASE COVER |
| 84 | 324046 | HANDLE PACKING (A) |
| 85 | 310124 | HANDLE DAMPER |
| 86 | 310123 | TRANSATORY UNIT |
| 88 | 306143 | SWITCH (B) (1P SCREW TYPE) W/LOCK |
| 89 | 324042 | HANDLE (A) |
| 90 | 991711 | DISTANCE PIECE (B) |
| 92 | 324047 | HANDLE PACKING (B) |
| 93 | 324043 | HANDLE (B) |
| 99 | 960266 | CORD CLIP |
| 100 | 953327 | CORD ARMOR D8.8 |
| 102 | 324130 | DAMPER (C) |
| 103 | 938051 | CORD ARMOR D10.1 |
| 104 | 956683 | STOP PLATE |
| 601 | 981840 | GREASE (A) FOR HAMMER.HAMMER DRILL (30G) |
| 602 | 308471 | GREASE FOR HAMMER.HAMMER DRILL (70G) |
| 603 | 980927 | GREASE FOR HAMMER.HAMMER DRILL (500G) |
