Hitachi Spare Parts for Cordless Rotary Hammer DH36DL
Hitachi-HIKOKI original spare parts, at discounted prices, we are a licensed service center with after-sales service able to quickly solve the maintenance and repair any issues for Cordless Rotary Hammer DH36DL.
In the following table, look for the model of the Cordless Rotary Hammer and their spare part.
| Cordless Rotary Hammer DH36DL |
| # |
Part Num. |
Description |
| 1 |
306345 |
FRONT CAP |
| 2 |
306340 |
STOPPER RING |
| 3 |
323154 |
GRIP |
| 4 |
324528 |
BALL HOLDER |
| 5 |
324526 |
HOLDER PLATE |
| 6 |
322812 |
HOLDER SPRING |
| 7 |
984118 |
WASHER (B) |
| 8 |
939547 |
RETAINING RING FOR D20 SHAFT |
| 9 |
305558 |
TAPPING SCREW (W/FLANGE) D5X25 (BLACK) |
| 10 |
323167 |
GEAR COVER |
| 11 |
307688 |
OIL SEAL |
| 12 |
322815 |
SLEEVE |
| 13 |
6904DD |
BALL BEARING 6904DDPS2L |
| 14 |
324522 |
SLEEVE (A) |
| 15 |
322813 |
RETAINING RING 37MM |
| 16 |
959156 |
STEEL BALL D7.0 |
| 17 |
322814 |
CYLINDER |
| 18 |
323172 |
HITACHI PLATE (GREEN) |
| 19 |
323239 |
TAPPING SCREW D2.6X10 |
| 20 |
323161 |
CHANGE LEVER |
| 21 |
878885 |
O-RING (S-18) |
| 22 |
301677 |
SECOND GEAR |
| 23 |
316135 |
SPRING (A) |
| 24 |
301679 |
WASHER (A) |
| 25 |
948310 |
RETAINING RING FOR D30 SHAFT |
| 26 |
324525 |
SECOND HAMMER |
| 27 |
944486 |
O-RING (1AP-20) |
| 28 |
324523 |
HAMMER HOLDER |
| 29 |
322802 |
O-RING (B) |
| 30 |
322805 |
DAMPER (A) |
| 31 |
322808 |
O-RING (C) |
| 32 |
324524 |
DAMPER HOLDER |
| 33 |
322807 |
STOPPER RING |
| 34 |
324535 |
STRIKER |
| 35 |
322834 |
O-RING (I.D. 16) |
| 36 |
324534 |
PISTON |
| 37 |
322799 |
WASHER (C) |
| 38 |
325254 |
O-RING (I.D. 72) |
| 39 |
323157 |
INNER COVER ASS'Y |
| 40 |
626VVM |
BALL BEARING 626VVC2PS2L |
| 41 |
323151 |
SECOND SHAFT |
| 42 |
301659 |
WASHER (B) |
| 43 |
301660 |
CLUTCH SPRING |
| 44 |
324532 |
CLUTCH |
| 45 |
322798 |
PISTON PIN |
| 46 |
324533 |
RECIPROCATING BEARING |
| 47 |
323152 |
COLLAR |
| 48 |
323153 |
FIRST GEAR |
| 49 |
301663 |
SPACER |
| 50 |
323170 |
PINION |
| 51 |
626VVM |
BALL BEARING 626VVC2PS2L |
| 52 |
305812 |
TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 53 |
876796 |
O-RING (P-22) |
| 54 |
608DDM |
BALL BEARING 608DDC2PS2L |
| 55 |
360801 |
ARMATURE AND PINION ASS'Y DC 36V |
| 56 |
323156 |
MAGNET |
| 57 |
982631 |
WASHER (A) |
| 58 |
608DDM |
BALL BEARING 608DDC2PS2L |
| 59 |
308536 |
SPRING |
| 60 |
323164 |
BRUSH HOLDER |
| 61 |
999090 |
CARBON BRUSH (AUTO STOP TYPE) (1 PAIR) |
| 62 |
328064 |
PUSHING BUTTON |
| 63 |
302086 |
TAPPING SCREW (W/FLANGE) D4X20 (BLACK) |
| 65 |
328036 |
BATTERY BSL 3626 (EUROPE.AUS.NZL) |
| 66A |
328067 |
HOUSING (A).(B) SET |
| 68 |
328058 |
DC-SPEED CONTROL SWITCH |
| 69 |
323166 |
INTERNAL WIRE (RED) |
| 70 |
323165 |
INTERNAL WIRE (BLACK) 75L |
| 74A |
328060 |
CONTROLLER TERMINAL SET |
| 75 |
319812 |
HEAT SINK |
| 76 |
323159 |
SHIFT KNOB |
| 77 |
993963 |
MACHINE SCREW (W/WASHERS) M3X12 |
| 78 |
313591 |
RUBBER HOLDER |
| 79 |
949554 |
NUT M4 |
| 80 |
323160 |
GRIP COVER |
| 81 |
949215 |
MACHINE SCREW M4X8 |
| 82 |
328707 |
TAPPING SCREW (W/FLANGE) D5X30 (BLACK) |
| 83 |
328708 |
BEARING (A) |
| 90 |
331415 |
PACKING (B) |
| 91 |
333144 |
PACKING (C) |
| 92 |
332668 |
RUBBER GROMMET |
| 93 |
333991 |
BATTERY TERMINAL |
| 501 |
323155 |
SIDE HANDLE |
| 502 |
303709 |
DEPTH GAUGE |
| 504A |
329319 |
CASE |
| 505 |
329897 |
BATTERY COVER |
