Hitachi Spare Parts for Hand Shear CE16SA

SKU: Hitachi CE16SA
€2.53
VAT included

Hitachi Spare Parts for Hand Shear CE16SA

Hitachi-HIKOKI Original spare parts for to replace broken parts or to fix Hand Shear CE16SA.

Fix Your Hand Shear CE16SA. All Spares can be supplied at low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Hitachi Spare Parts for Magnetic Drill Press BM20Y
  • Hitachi Spare Parts for Magnetic Drill Press BM20Y
  • Hitachi Spare Parts for Hand Shear CE16SA

Hitachi Spare Parts for Hand Shear CE16SA

SKU: Hitachi CE16SA Condition: New
€2.53
VAT included

Hitachi Spare Parts for Hand Shear CE16SA

Hitachi-HIKOKI Original spare parts for to replace broken parts or to fix Hand Shear CE16SA.

Fix Your Hand Shear CE16SA. All Spares can be supplied at low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
settings 52 spare parts
description 1 exploded view
ITEM CODE
Quantity
on 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

34 spare parts
Pos. Item Price Buy
2
photo_cameraImage coming soon 998003 GEAR COVER €39.92 Available
3
photo_cameraImage coming soon 998008 HEX. SOCKET SET SCREW M8X20 €1.52 Available
4
photo_cameraImage coming soon 608VVM BALL BEARING 608VVC2PS2L €7.12 Available
5
photo_cameraImage coming soon 998004 CONNECTING ROD ASS'Y €37.02 Available
6
photo_cameraImage coming soon 993163 NEEDLE BEARING (M152112) €8.02 Available
7
photo_cameraImage coming soon 998006 SPINDLE AND GEAR SET €43.92 Available
8
photo_cameraImage coming soon 998002 INNER COVER €39.92 Available
9
photo_cameraImage coming soon 931701 BEARING LOCK €1.33 Available
11
photo_cameraImage coming soon 360622E ARMATURE 220V-230V €63.92 Available
12
photo_cameraImage coming soon 306840 FAN GUIDE €2.33 Available
16
photo_cameraImage coming soon 626VVM BALL BEARING 626VVC2PS2L €5.14 Available
17
photo_cameraImage coming soon 309929 RUBBER BUSHING €1.32 Available
18
photo_cameraImage coming soon 998010 PROTECTOR €8.02 Available
21
photo_cameraImage coming soon 993546 PIN D6 €1.52 Available
22
photo_cameraImage coming soon 998005 PISTON €43.92 Available
23
photo_cameraImage coming soon 998000 MOVING BLADE €13.02 Available
25
photo_cameraImage coming soon 998007 BLADE HOLDER €115.92 Available
26
photo_cameraImage coming soon 998001 STATIONARY BLADE €13.92 Available
29
photo_cameraImage coming soon 314429 SPRING €1.32 Available
30
Slide Bar for Angle Grinders Hitachi G12SS - SG 314427 Slide Bar for Angle Grinders Hitachi G12SS - SG €2.08 Available
31
Slide Knob for Angle Grinders Hitachi G12SA2 - G12SG 314428 Slide Knob for Angle Grinders Hitachi G12SA2 - G12SG €1.66 Available
32
photo_cameraImage coming soon 314438 HOUSING ASS'Y €12.92 Available
36
Noise Suppressor for Angle Grinder Hitachi G12SA2 994273 Noise Suppressor for Angle Grinder Hitachi G12SA2 €9.62 Available
37
photo_cameraImage coming soon 314432 SWITCH HOLDER €2.68 Available
39
photo_cameraImage coming soon 938307 PILLAR TERMINAL (OLD 938307Z / 512-31) €2.60 Available
41
Brush Cap for Angle Grinders Hitachi G12SS - G12SG 936551 Brush Cap for Angle Grinders Hitachi G12SS - G12SG €1.80 Available
42
Carbon Brushes for Grinder Hitachi G12SS 999021 Carbon Brushes for Grinder Hitachi G12SS €9.62 Available
43
Brush Holder for Angle Grinders Hitachi G12SS - SG 313777 Brush Holder for Angle Grinders Hitachi G12SS - SG €3.48 Available
44
Switch for Angle Grinders Hitachi 115 mm G12SN 314603 Switch for Angle Grinders Hitachi 115 mm G12SN €21.20 Available
47
photo_cameraImage coming soon 937631 CORD CLIP €1.37 Available
49
Cord Armor D.10.1 for Hitachi Power Tools 938051 Cord Armor D.10.1 for Hitachi Power Tools €1.34 Available
49
Cord Armor D.8.8 for Hitachi Power Tools 953327 Cord Armor D.8.8 for Hitachi Power Tools €1.37 Available
50
photo_cameraImage coming soon 314433 TAIL COVER €223.75 Available
52A
photo_cameraImage coming soon 500247Z CORD €17.20 Available

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Hitachi Spare Parts for Hand Shear CE16SA

Hitachi-HIKOKI Original spare parts for to replace broken parts or to fix Hand Shear CE16SA.

Fix Your Hand Shear CE16SA. All Spares can be supplied at low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Hand Shear and their spare part.
Hitachi CE16SA

HAND SHEAR CE 16SA
# Part Num. Description
1 957580 TAPPING SCREW D5X30
2 998003 GEAR COVER
3 998008 HEX. SOCKET SET SCREW M8X20
4 608VVM BALL BEARING 608VVC2PS2L
5 998004 CONNECTING ROD ASS'Y
6 993163 NEEDLE BEARING (M152112)
7 998006 SPINDLE AND GEAR SET
8 998002 INNER COVER
9 931701 BEARING LOCK
10 608VVM BALL BEARING 608VVC2PS2L
11 360622E ARMATURE 220V-230V
11 360622F ARMATURE 240V
12 306840 FAN GUIDE
13 982021 HEX. HD. TAPPING SCREW D4X70
14 340567E STATOR 220V-230V
14 340567F STATOR 240V
15 942204 WASHER
16 626VVM BALL BEARING 626VVC2PS2L
17 309929 RUBBER BUSHING
18 998010 PROTECTOR
19 949454 SPRING WASHER M5
20 949237 MACHINE SCREW M5X12
21 993546 PIN D6
22 998005 PISTON
23 998000 MOVING BLADE
24 949812 HEX. SOCKET HD. BOLT M4X10
25 998007 BLADE HOLDER
26 998001 STATIONARY BLADE
27 998009 SLOTTED HD. SET SCREW M4X14
28 949565 LOCK NUT M4
29 314429 SPRING
30 314427 SLIDE BAR
31 314428 SLIDE KNOB
32 314438 HOUSING ASS'Y
34 314854 EARTH TERMINAL
35 311741 TERMINAL
36 994273 NOISE SUPPRESSOR
37 314432 SWITCH HOLDER
38 959140 CONNECTOR 50091
39 938307 PILLAR TERMINAL
41 936551 BRUSH CAP
42 999021 CARBON BRUSH (1 PAIR)
43 313777 BRUSH HOLDER
44 314603 SWITCH (1P SOLDER TYPE)
45 305499 MACHINE SCREW (W/WASHER) M3.5X6
46 980063 TERMINAL
47 937631 CORD CLIP
48 984750 TAPPING SCREW (W/FLANGE) D4X16
49 953327 CORD ARMOR D8.8
49 938051 CORD ARMOR D10.1
50 314433 TAIL COVER
51 301815 TAPPING SCREW (W/FLANGE) D4X45 (BLACK)
52A 500247Z CORD

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Hitachi CE16SA
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Esploso Hitachi CE16SA
