Hitachi Spare Parts for Angle Grinder G23UBY

SKU: Hitachi G23UBY
€1.61
VAT included

Hitachi Spare Parts for Angle Grinder G23UBY

HItachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Angle Grinder G23UBY.

Hitachi Spare Parts for Angle Grinder G23UBY
  • Hitachi Spare Parts for Angle Grinder G23UBY
  • Hitachi Spare Parts for Angle Grinder G23UBY
HiKOKI Power Tools Italia S.p.a.

Hitachi Spare Parts for Angle Grinder G23UBY

SKU: Hitachi G23UBY Condition: New
€1.61
VAT included

Hitachi Spare Parts for Angle Grinder G23UBY

HItachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Angle Grinder G23UBY.

settings 72 Spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 7/10 Business Days Approx

SHIPPING IN: Usually Ships in 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
Machine Type: Grinder
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
72 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 984509 SEAL LOCK HEX. SOCKET HD. BOLT MSX14 €0.00 Not available for order
2
 photo_cameraImage coming soon 323209 TAPPING SCREW (W/FLANGE) D5X35 (BLACK) €0.00 Not available for order
3
 Pushing Button for Angle Grinders Hitachi G23 306888 Pushing Button for Angle Grinders Hitachi G23 €1.16
4
 Button Spring for Angle Grinders Hitachi G23 320219 Button Spring for Angle Grinders Hitachi G23 €3.60
5
 photo_cameraImage coming soon 326717 GEAR COVER ASS'Y €30.44
6
 photo_cameraImage coming soon 320226 SPECIAL NUT M10 €3.60
7
 photo_cameraImage coming soon 320221 SEAL WASHER €2.38
8
 photo_cameraImage coming soon 320222 FELT PACKING €2.38
9
 Ball Bearing Hitachi 6301DD 6301DD Ball Bearing Hitachi 6301DD €10.92
10
 photo_cameraImage coming soon 994208 RUBBER RING (B) €1.16
11
 photo_cameraImage coming soon 320220 BEARING COVER (A) €6.04
12
 photo_cameraImage coming soon 360777E ARMATURE 220V-230V €82.90
13
 photo_cameraImage coming soon 320215 FAN GUIDE €2.38
14
 photo_cameraImage coming soon 984271 HEX. HD. TAPPING SCREW D5X75 €0.00 Not available for order
15
 photo_cameraImage coming soon 340682E STATOR 220V-240V €57.28
16
 photo_cameraImage coming soon 937033 FELT WASHER €2.38
17A
 photo_cameraImage coming soon 336864 SIDE HANDLE €29.22
18
 photo_cameraImage coming soon 320218 0-RING €2.38
19
 Lock Pin for Angle Grinder Hitachi G23SS 306890 Lock Pin for Angle Grinder Hitachi G23SS €2.38
20
 photo_cameraImage coming soon 326718 GEAR AND PINION SET €36.54
21
 Retaining Ring D.10 for Hammer DH45ME - DH40MR 939540 Retaining Ring D.10 for Hammer DH45ME - DH40MR €0.00
22
 photo_cameraImage coming soon 326722 COUPLING COVER €0.00 Not available for order
23
 photo_cameraImage coming soon 326721 COUPLING DAMPER €13.36
24A
 photo_cameraImage coming soon 333147 COUPLING €7.26
25
 photo_cameraImage coming soon 949236 MACHINE SCREW M5X10 €0.00 Not available for order
26
 photo_cameraImage coming soon 326723 BEARING COVER (B) €0.00 Not available for order
27
 Ball Bearing Hitachi 6302VV 6302VV Ball Bearing Hitachi 6302VV €9.70
28
 photo_cameraImage coming soon 990852 FELT PACKING (B) €2.38
29
 Spindle for Angle Grinders Hitachi G 23UBY-S 23UBY 326727 Spindle for Angle Grinders Hitachi G 23UBY-S 23UBY €18.24
30
 Packing Gland Gasket for Angle Grinder Hitachi G23SS 320228 Packing Gland Gasket for Angle Grinder Hitachi G23SS €3.60
31
 Packing Gland for Angle Grinder Hitachi G23SS 320227 Packing Gland for Angle Grinder Hitachi G23SS €15.80
32
 photo_cameraImage coming soon 994192 HEX. SOCKET HD. BOLT (W/FLANGE) M5X16 €0.00 Not available for order
33
 photo_cameraImage coming soon 311492 Label G12Se G18Se3 G23Sc3 €0.00 Not available for order
34
 photo_cameraImage coming soon 321546 SET PIN €0.00 Not available for order
35
 photo_cameraImage coming soon 321545 LEVER €3.60
36
 photo_cameraImage coming soon 306887 BOLT M8X22 €1.16
37
 photo_cameraImage coming soon 949457 SPRING WASHER M8 €0.00 Not available for order
38
 photo_cameraImage coming soon 321544 SET PIECE €2.38
39
 photo_cameraImage coming soon 673489 RETAINING RING (E-TYPE) FOR D5 SHAFT €0.00 Not available for order
40
 photo_cameraImage coming soon 321547 WHEEL GUARD ASS'Y €48.74
40A
 photo_cameraImage coming soon 337225 WHEEL GUARD ASS'Y €0.00 Not available for order
41A
 Wheel Washer for Angle Grinder Hitachi G23SS 937907Z Wheel Washer for Angle Grinder Hitachi G23SS €12.14
41
 photo_cameraImage coming soon 937908Z WHEEL WASHER (B) €0.00 Not available for order
42
 photo_cameraImage coming soon 316825 D. C. WHEELS 230MM A24R €0.00 Not available for order
43
 Wheel Nut for Angle Grinder Hitachi G23SS 937909Z Wheel Nut for Angle Grinder Hitachi G23SS €17.02
44
 photo_cameraImage coming soon 320216 DUST SEAL €2.38
45
 photo_cameraImage coming soon 6000VV BALL BEARING 6000VVCMPS2L €9.70
46
 Bearing Bush for Angle Grinder Hitachi G23SR 321536 Bearing Bush for Angle Grinder Hitachi G23SR €17.02
47
 photo_cameraImage coming soon 326712 HOUSING ASS'Y €47.52
48
 photo_cameraImage coming soon 326715 BRUSH COVER €3.60
49
 photo_cameraImage coming soon 326726 HANDLE DAMPER €7.26
50
 photo_cameraImage coming soon 305812 SCREW WITH FLANGE D4X16 BLACK €0.00 Not available for order
51
 Carbon Brushes for Angle Grinders Hitachi G23SR-S23UBY 999061 Carbon Brushes for Angle Grinders Hitachi G23SR-S23UBY €10.20
51
 photo_cameraImage coming soon 999089 CARBON BRUSH (AUTO STOP TYPE) (1 PAIR) €19.46
52
 photo_cameraImage coming soon 322323 BRUSH HOLDER SET €12.14
53
 photo_cameraImage coming soon 326716 BRUSH COVER €4.82
56
 photo_cameraImage coming soon 326724 O-RING €0.00 Not available for order
57
 photo_cameraImage coming soon 326725 O-RING €0.00 Not available for order
58
 photo_cameraImage coming soon 320236 RESISTOR €13.36
59
 photo_cameraImage coming soon 320235 SWITCH (2P PILLAR TYPE) W/SAFETY LOCK €0.00 Not available for order
59
 photo_cameraImage coming soon 320371 SWITCH (2P PILLAR TYPE) W/SAFETY LOCK €37.76
60
 photo_cameraImage coming soon 326714 HANDLE (B) €17.02
61
 photo_cameraImage coming soon 960266 CORD CLIP €1.16
62
 photo_cameraImage coming soon 984750 Tapp. Screw (W / Flange) D4x16 €0.00 Not available for order
63
 photo_cameraImage coming soon 326713 HANDLE (A) €17.02
64
 photo_cameraImage coming soon 981373 TUBE (D) €1.16
65
 photo_cameraImage coming soon 940778 CORD ARMOR D10.7 €3.60
65
 photo_cameraImage coming soon 958049 CORD ARMOR D8.2 €1.16
70
 photo_cameraImage coming soon 328700 INNER €0.00 Not available for order
71
 photo_cameraImage coming soon 328694 INNER SET (W/GEAR) €0.00 Not available for order
72
 photo_cameraImage coming soon 328697 GEAR AND PINION ASS'Y €43.86
73
 photo_cameraImage coming soon 328698 GEAR (A) ASS'Y €0.00 Not available for order

Shipping and delivery information will be available shortly.

Hitachi Spare Parts for Angle Grinder G23UBY

HItachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Angle Grinder G23UBY.

In the following table, look for the model of Brush Cutter and the respective parts of the code.
Hitachi G23UBY

Disc Grinder 230 mm S 23UBY
# Part Num. Description
1 984509 SEAL LOCK HEX. SOCKET HD. BOLT M5X14
2 323209 TAPPING SCREW (W/FLANGE) D5X35 (BLACK)
3 306888 PUSHING BUTTON
4 320219 SPRING
5 326717 GEAR COVER ASS'Y
6 320226 SPECIAL NUT M10
7 320221 SEAL WASHER
8 320222 FELT PACKING
9 6301DD BALL BEARING 6301DDCMPS2L
10 994208 RUBBER RING (B)
11 320220 BEARING COVER (A)
12 360777E ARMATURE 220V-230V
13 320215 FAN GUIDE
14 984271 HEX. HD. TAPPING SCREW D5X75
15 340682E STATOR 220V-240V
16 937033 FELT WASHER
17A 336864 SIDE HANDLE
18 320218 O-RING
19 306890 LOCK PIN
20 326718 GEAR AND PINION SET
21 939540 RETAINING RING FOR D10 SHAFT
22 326722 COUPLING COVER
23 326721 COUPLING DAMPER
24A 333147 COUPLING
25 949236 MACHINE SCREW M5X10 (10 PCS.)
26 326723 BEARING COVER (B)
27 6302VV BALL BEARING 6302VVCMPS2L
28 990852 FELT PACKING (B)
29 326727 SPINDLE
30 320228 SEAL PLATE
31 320227 PACKING GLAND
32 994192 HEX. SOCKET HD. BOLT (W/FLANGE) M5X16
33 311492 LABEL
34 321546 SET PIN
35 321545 LEVER
36 306887 BOLT M8X22
37 949457 SPRING WASHER M8 (10 PCS.)
38 321544 SET PIECE
39 673489 RETAINING RING (E-TYPE) FOR D5 SHAFT
40 321547 WHEEL GUARD ASS'Y
40A 337225 WHEEL GUARD ASS'Y
41 937908Z WHEEL WASHER (B)
41A 937907Z WHEEL WASHER (C)
42 316825 D. C. WHEELS 230MM A24R (25 PCS.)
43 937909Z WHEEL NUT M14X2
44 320216 DUST SEAL
45 6000VV BALL BEARING 6000VVCMPS2L
46 321536 BEARING BUSHING
47 326712 HOUSING ASS'Y
48 326715 BRUSH COVER
49 326726 HANDLE DAMPER
50 305812 TAPPING SCREW (W/FLANGE) D4X16 (BLACK)
51 999061 CARBON BRUSH 7X17X22.5 (1 PAIR)
51 999089 CARBON BRUSH (AUTO STOP TYPE) (1 PAIR)
52 322323 BRUSH HOLDER SET
53 326716 BRUSH COVER
56 326724 O-RING
57 326725 O-RING
58 320236 RESISTOR
59 320371 SWITCH (2P PILLAR TYPE) W/SAFETY LOCK
59 320235 SWITCH (2P PILLAR TYPE) W/SAFETY LOCK
60 326714 HANDLE (B)
61 960266 CORD CLIP
62 984750 TAPPING SCREW (W/FLANGE) D4X16
63 326713 HANDLE (A)
64 981373 TUBE (D)
65 940778 CORD ARMOR D10.7
65 958049 CORD ARMOR D8.2
70 328700 INNER
71 328694 INNER SET (W/GEAR)
72 328697 GEAR AND PINION ASS'Y
73 328698 GEAR (A) ASS'Y

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Hitachi G23UBY
12 Items

Data sheet

SHIPPING IN
Usually Ships in 7/10 BUSINESS DAYS
Machine Type
Grinder
MORE INFO:
[email protected]

Specific References

New

Download

Diagram Hitachi G23UBY

Diagram Hitachi G23UBY

Download (83.69KB)

You might also like

Carbon Brushes for Angle Grinders Hitachi G 23SS - G 23SW
HiKOKI Power Tools Italia S.p.a. SKU: 999038
Carbon Brushes for Angle Grinders Hitachi G 23SS - G 23SW
Carbon Brushes for Angle Grinders Hitachi G 23SS -  G 23SW Genuine parts Hitachi, carbon Brushesfor Angle Grinders 230 mm G 23SS -  G 23SW - G 23SWU - Router M12VE , Circolar Saw C9U2 - Radial Miter Saw C 10FCH2 - C 12LCH. Part for...
AVAILABLE €7.26
Details
Armature for Angle Grinder Hitachi G23SW-SWU
HiKOKI Power Tools Italia S.p.a. SKU: 360959E
Armature for Angle Grinder Hitachi G23SW-SWU
Armature for Angle Grinder Hitachi G23SW-SWU Original replacement part Hitachi KOKI, Armature 220V-230V for disk grinder with 230 mm, G23SW - G23SWU Parts for the following products: - Grinder 230 mm G 23SW - Grinder 230 mm G 23SWU -...
AVAILABLE €63.38
Details
Brush Holder for Angle Grinders Hitachi G23SS-G23SW-G23SWU
HiKOKI Power Tools Italia S.p.a. SKU: 938241
Brush Holder for Angle Grinders Hitachi G23SS-G23SW-G23SWU
Brush Holder for Angle Grinders Hitachi G23SS-G23SW-G23SWU Original parts Hitachi, Brush holder for Angle Grinders G 23SS - 23SW G - G 23SWU - Radial Miter Saws 10FCH2 C - C 12LCH - C 12RSH. For the following items: - Angle Grinder...
AVAILABLE €12.14
Details
Spindle for Angle Grinders Hitachi G 23UBY-S 23UBY
HiKOKI Power Tools Italia S.p.a. SKU: 326727
Spindle for Angle Grinders Hitachi G 23UBY-S 23UBY
Spindle for Angle Grinders Hitachi G 23UBY-S 23UBY Genuine parts Hitachi, Spindle for Angle Grinders 230 mm G 23UBY - S 23UBY. Parts for the following products: - Angle Grinder Hitachi G 18SCY - Angle Grinder Hitachi G 18SE - Angle...
AVAILABLE €18.24
Details
Ball Bearing Hitachi 6302VV
HiKOKI Power Tools Italia S.p.a. SKU: 6302VV
Ball Bearing Hitachi 6302VV
Ball Bearing Hitachi 6302VV Genuine parts Hitachi, Ball Bearing 6302VV CMPS2S for Angle Grinders S 23UBY - G 23SR - G 23SS - G 23SW. Parts for the following products: - Angle Grinder Hitachi 230 mm S 23UBY - Angle Grinder Hitachi 230...
AVAILABLE €9.70
Details
Ball Bearing Hitachi 6301DD
HiKOKI Power Tools Italia S.p.a. SKU: 6301DD
Ball Bearing Hitachi 6301DD
Ball Bearing Hitachi 6301DD Genuine parts Hitachi, Ball Bearing 6301DD CMPS2S for Angle Grinders G 23SF2 - G 23MR - S 23UBY - G 23SF. Parts for the following products: - Angle Grinder Hitachi 230 mm G 23SF2 - Angle Grinder Hitachi 230...
AVAILABLE €10.92
Details
Pushing Button for Angle Grinders Hitachi G15VA - G15YF
HiKOKI Power Tools Italia S.p.a. SKU: 306888
Pushing Button for Angle Grinders Hitachi G23
Pushing Button for Angle Grinders Hitachi G23 Original spare parts Hitachi, Pushing Button for Angle Grinders G23SS - G23SW - G23SF2 - S23UBY - G23UBY - G23SWU - G23SR - G23MR - G23SF - CM12Y - CM7MR - CM9SR - SP18VA. Part for the...
AVAILABLE €1.16
Details
Pushing Button for Angle Grinders Hitachi G23
HiKOKI Power Tools Italia S.p.a. SKU: 320219
Button Spring for Angle Grinders Hitachi G23
Button Spring for Angle Grinders Hitachi G23 Original spare parts Hitachi, Button Spring for Angle Grinders S23UBY - G23UBY - G23SWU - G23SS - G23SW - G23SR - G23MR - G23SF2 - CM7MR - CM9SR. Part for the following items: - Angle...
AVAILABLE €3.60
Details
Carbon Brushes for Angle Grinders Hitachi G23SR-S23UBY
Bosch SKU: 999061
Carbon Brushes for Angle Grinders Hitachi G23SR-S23UBY
Carbon Brushes for Angle Grinders Hitachi G23SR-S23UBY Genuine replacement part Bosch, Carbon Brushes mm 7X17X22.5 for Angle Grinders G23SR - S23UBY - G23UBY - G23SF2. Part for the following products: - Angle Grinder Hitachi 230 mm S...
AVAILABLE €10.20
Details
Wheel Guard Ass’y for Angle Grinder Hitachi G 23SF
HiKOKI Power Tools Italia S.p.a. SKU: 330036
Wheel Guard Ass’y for Angle Grinder Hitachi G 23SF
Wheel Guard Ass’y for Angle Grinder Hitachi G 23SF Genuine part Hitachi, Wheel Guard Ass’y for Angle Grinders G 23SF2 - G 23SS - G 23SW -  G 23SR - G 23SWU Parts for the following products: - Angle Grinder Hitachi G 23SF2 - Angle...
AVAILABLE €26.78
Details
Wheel Washer for Angle Grinder Hitachi G23SS
HiKOKI Power Tools Italia S.p.a. SKU: 937907Z
Wheel Washer for Angle Grinder Hitachi G23SS
Wheel Washer for Angle Grinder Hitachi G23SS Genuine spare part Hitachi HIKOKI, Wheel Washer for Angle Grinders G23SS - G23MR - G23SC3 - G23SE2 - G23SF2 - G23SR - G23ST. Part for the following products: - Angle Grinder HITACHI G23SS -...
on 7/10 Business Days Approx. €12.14
Details
Wheel Nut for Angle Grinder Hitachi G23SS
HiKOKI Power Tools Italia S.p.a. SKU: 937909Z
Wheel Nut for Angle Grinder Hitachi G23SS
Wheel Nut for Angle Grinder Hitachi G23SS Genuine spare part Hitachi KOKY, Wheel Nut for Angle Grinders G23SS - G23MR - G23SC3 - G23SE2 - G23SF2 - G23SR - G23ST Part for the following products: - Angle Grinder HITACHI G23SS - Angle...
AVAILABLE €17.02
Details
Bearing Bush for Angle Grinder Hitachi G23SR
HiKOKI Power Tools Italia S.p.a. SKU: 321536
Bearing Bush for Angle Grinder Hitachi G23SR
Bearing Bush for Angle Grinder Hitachi G23SR Genuine Spare Part Hitachi, Bearing Bush for Angle Grinders G23SR - G23UBY - G23UDY - G23SC3 - G23SE2. Part for the following products: - Angle Grinder G23SR - Angle Grinder G23UBY - Angle...
AVAILABLE €17.02
Details
Packing Gland for Angle Grinder Hitachi G23SS
HiKOKI Power Tools Italia S.p.a. SKU: 320227
Packing Gland for Angle Grinder Hitachi G23SS
Packing Gland for Angle Grinder Hitachi G23SS Genuine spare part Hitachi HIKOKI, Packing Gland for Angle Grinders G23SS - G23MR - G23SC3 - G23SE2 - G23SE2 - G23SR - G23ST Part for the following products: -  Angle Grinder G23SS -...
on 7/10 Business Days Approx. €15.80
Details
Packing Gland Gasket for Angle Grinder Hitachi G23SS
HiKOKI Power Tools Italia S.p.a. SKU: 320228
Packing Gland Gasket for Angle Grinder Hitachi G23SS
Packing Gland Gasket for Angle Grinder Hitachi G23SS Genuine spare part Hitachi HIKOKI, Packing Gland Gasket for Angle Grinders G23SS - G23MR - G23SC3 - G23SE2 - G23SE2 - G23SR - G23ST Part for the following products: -  Angle Grinder...
on 7/10 Business Days Approx. €3.60
Details
Lock Pin for Angle Grinder Hitachi G23SS
HiKOKI Power Tools Italia S.p.a. SKU: 306890
Lock Pin for Angle Grinder Hitachi G23SS
Lock Pin for Angle Grinder Hitachi G23SS Genuine spare part Hitachi HIKOKI, Lock Pin for Angle Grinders G23SS - G23MR - G23SC3 - G23SE2 - G23SE2 - G23SR - G23ST Part for the following...
Usually Ships in: 7/10 Business Days Approx. €2.38
Details
Bearing Cover (B) for Angle Grinder Hitachi G23SS
HiKOKI Power Tools Italia S.p.a. SKU: 320229
Bearing Cover (B) for Angle Grinder Hitachi G23SS
Bearing Cover (B) for Angle Grinder Hitachi G23SS Genuine spare part Hitachi HIKOKI, Bearing Cover (B) for Angle Grinders G23SS - G23MR - G23SC3 - G23SE2 - G23SE2 - G23SR - G23ST Part for the following products: -  Angle Grinder G23SS...
on 7/10 Business Days Approx. €3.60
Details
Comments (0)
No customer reviews for the moment.
