Hitachi Spare Parts for Angle Grinder G23SR

SKU: Hitachi G23SR
€23.76
VAT included

Hitachi Spare Parts for Angle Grinder G23SR

Hitachi-HIKOKI Original spare parts at attractive prices never seen on the web, we are a licensed service center with after-sales service able to quickly solve the maintenance or repair any issues for Angle Grinder G23SR.

Original spare parts sourced directly from the manufacturer, with after-sales assistance at the best price on the web.

Hitachi Spare Parts for Angle Grinder G23SR
  • Hitachi Spare Parts for Angle Grinder G23SR
  • Hitachi Spare Parts for Angle Grinder G23SR
HiKOKI Power Tools Italia S.p.a.

Hitachi Spare Parts for Angle Grinder G23SR

SKU: Hitachi G23SR Condition: New
€23.76
VAT included

Hitachi Spare Parts for Angle Grinder G23SR

Hitachi-HIKOKI Original spare parts at attractive prices never seen on the web, we are a licensed service center with after-sales service able to quickly solve the maintenance or repair any issues for Angle Grinder G23SR.

Original spare parts sourced directly from the manufacturer, with after-sales assistance at the best price on the web.

settings 65 Spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN: Usually Ships in 10/15 BUSINESS DAYS
MORE INFO:: [email protected]
Machine Type: Grinder
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
65 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 315636 SEAL LOCK SCREW (W/SP.WASHER)M5X14(BLACK €0.00 Not available for order
2
 photo_cameraImage coming soon 323209 TAPPING SCREW (W/FLANGE) D5X35 (BLACK) €0.00 Not available for order
3
 Pushing Button for Angle Grinders Hitachi G23 306888 Pushing Button for Angle Grinders Hitachi G23 €1.16
4
 Button Spring for Angle Grinders Hitachi G23 320219 Button Spring for Angle Grinders Hitachi G23 €3.60
5
 photo_cameraImage coming soon 320217 GEAR COVER ASS'Y €23.12
6
 photo_cameraImage coming soon 320226 SPECIAL NUT M10 €3.60
8
 photo_cameraImage coming soon 320221 SEAL WASHER €2.38
9
 photo_cameraImage coming soon 320222 FELT PACKING €2.38
10
 photo_cameraImage coming soon 6301VV BALL BEARING 6301VVCMPS2L €12.14
11
 photo_cameraImage coming soon 994208 RUBBER RING (B) €1.16
12
 photo_cameraImage coming soon 320220 BEARING COVER (A) €6.04
13
 Armature for Grinder Hitachi 230 mm G23SR-SRU 360762E Armature for Grinder Hitachi 230 mm G23SR-SRU €75.58
14
 photo_cameraImage coming soon 320215 FAN GUIDE €2.38
15
 photo_cameraImage coming soon 961501 HEX. HD. TAPPING SCREW D5X60 €0.00 Not available for order
16
 photo_cameraImage coming soon 340664E STATOR ASS'Y 220V-230V €54.84
17
 photo_cameraImage coming soon 958032 BRUSH TERMINAL €1.16
18
 photo_cameraImage coming soon 937981 SIDE HANDLE FOR M14 €17.02
19
 Retaining Ring 12 mm for Hitachi Power Tools 939542 Retaining Ring 12 mm for Hitachi Power Tools €3.60
21
 photo_cameraImage coming soon 949236 MACHINE SCREW M5X10 €0.00 Not available for order
22
 Bearing Cover (B) for Angle Grinder Hitachi G23SS 320229 Bearing Cover (B) for Angle Grinder Hitachi G23SS €3.60
23
 Ball Bearing Hitachi 6302VV 6302VV Ball Bearing Hitachi 6302VV €9.70
24
 photo_cameraImage coming soon 990852 FELT PACKING (B) €2.38
25
 photo_cameraImage coming soon 320234 SPINDLE €18.24
25
 photo_cameraImage coming soon 321541 SPINDLE €0.00 Not available for order
26
 Packing Gland Gasket for Angle Grinder Hitachi G23SS 320228 Packing Gland Gasket for Angle Grinder Hitachi G23SS €3.60
27
 Packing Gland for Angle Grinder Hitachi G23SS 320227 Packing Gland for Angle Grinder Hitachi G23SS €15.80
28
 photo_cameraImage coming soon 994192 HEX. SOCKET HD. BOLT (W/FLANGE) M5X16 €0.00 Not available for order
29
 photo_cameraImage coming soon 949656 HEX. SOCKET HD. BOLT M8X20 (10 PCS.) €0.00 Not available for order
29A
 photo_cameraImage coming soon 949760 HEX. SOCKET HD. BOLT M8X25 €0.00 Not available for order
30
 photo_cameraImage coming soon 306120 WHEEL GUARD ASS'Y €19.46
30A
 Wheel Guard Ass’y for Angle Grinder Hitachi G 23SF 330036 Wheel Guard Ass’y for Angle Grinder Hitachi G 23SF €26.78
30
 photo_cameraImage coming soon 937984Z WHEEL GUARD €40.20
31A
 Wheel Washer for Angle Grinder Hitachi G23SS 937907Z Wheel Washer for Angle Grinder Hitachi G23SS €12.14
31
 photo_cameraImage coming soon 937908Z WHEEL WASHER (B) €0.00 Not available for order
31
 photo_cameraImage coming soon 937922P WHEEL WASHER (B) G13SC2 €0.00 Not available for order
32
 photo_cameraImage coming soon 316825 D. C. WHEELS 230MM A24R €0.00 Not available for order
33
 Wheel Nut for Angle Grinder Hitachi G23SS 937909Z Wheel Nut for Angle Grinder Hitachi G23SS €17.02
33
 photo_cameraImage coming soon 937923P WHEEL NUT 5/811 UMC THREAD €0.00 Not available for order
34
 photo_cameraImage coming soon 320218 0-RING €2.38
35
 Lock Pin for Angle Grinder Hitachi G23SS 306890 Lock Pin for Angle Grinder Hitachi G23SS €2.38
36A
 Gear an Pinion for Grinder Hitachi G23SS 330032 Gear an Pinion for Grinder Hitachi G23SS €35.32
37
 photo_cameraImage coming soon 320216 DUST SEAL €2.38
38
 photo_cameraImage coming soon 6000VV BALL BEARING 6000VVCMPS2L €9.70
39
 Bearing Bush for Angle Grinder Hitachi G23SR 321536 Bearing Bush for Angle Grinder Hitachi G23SR €17.02
40
 photo_cameraImage coming soon 325640 HOUSING ASS'Y €67.04
42
 photo_cameraImage coming soon 325641 HANDLE (B) €13.36
43
 photo_cameraImage coming soon 305812 SCREW WITH FLANGE D4X16 BLACK €0.00 Not available for order
45
 Brushe Cap for Routers Hitachi M12SA-M12V G 940540 Brushe Cap for Routers Hitachi M12SA-M12V G €1.16
46
 Carbon Brushe Set for Hitachi Wall Chasers CM7R - CM9SR 999044 Carbon Brushe Set for Hitachi Wall Chasers CM7R - CM9SR €9.70
46
 Carbon Brushes for Angle Grinder Hitachi G23SF - G23SR 999074 Carbon Brushes for Angle Grinder Hitachi G23SF - G23SR €14.58
47
 photo_cameraImage coming soon 980487 BRUSH HOLDER €9.70
48
 photo_cameraImage coming soon 325642 HANDLE (A) €12.14
49
 photo_cameraImage coming soon 938477 HEX. SOCKET SET SCREW MSX8 €0.00 Not available for order
50
 Switch for Angle Grinders Hitachi 230 mm 320238 Switch for Angle Grinders Hitachi 230 mm €37.76
50A
 Switch for Angle Grinders Hitachi G-23SR G 23SS 320239 Switch for Angle Grinders Hitachi G-23SR G 23SS €31.66
50
 Switch for Angle Grinders Hitachi G-23SR G 23SS 320239 Switch for Angle Grinders Hitachi G-23SR G 23SS €31.66
51
 photo_cameraImage coming soon 960266 CORD CLIP €1.16
52
 photo_cameraImage coming soon 984750 Tapp. Screw (W / Flange) D4x16 €0.00 Not available for order
53
 photo_cameraImage coming soon 961820 TUBE (D) €0.00 Not available for order
53
 photo_cameraImage coming soon 981373 TUBE (D) €1.16
54
 photo_cameraImage coming soon 940778 CORD ARMOR D10.7 €3.60
54
 photo_cameraImage coming soon 958049 CORD ARMOR D8.2 €1.16
56
 photo_cameraImage coming soon 949457 SPRING WASHER M8 €0.00 Not available for order
57
 photo_cameraImage coming soon 937911 SET RING (A) €3.60
58
 photo_cameraImage coming soon 322549 SWITCH COVER  €0.00 Not available for order
59
 photo_cameraImage coming soon 930804 TERMINAL M4.0 €0.00 Not available for order

Shipping and delivery information will be available shortly.

Hitachi Spare Parts for Angle Grinder G23SR

Hitachi-HIKOKI Original spare parts at attractive prices never seen on the web, we are a licensed service center with after-sales service able to quickly solve the maintenance or repair any issues for Angle Grinder G23SR.

In the following table, choose the Spare Part number for the Grinder to be ordered.
Hitachi G23SR

Disc Grinder 230 mm G23SR
# Part Num. Description
1 315636 SEAL LOCK SCREW (W/SP.WASHER)M5X14(BLACK
2 323209 TAPPING SCREW (W/FLANGE) D5X35 (BLACK)
3 306888 PUSHING BUTTON
4 320219 SPRING
5 320217 GEAR COVER ASS'Y
6 320226 SPECIAL NUT M10
8 320221 SEAL WASHER
9 320222 FELT PACKING
10 6301VV BALL BEARING 6301VVCMPS2L
11 994208 RUBBER RING (B)
12 320220 BEARING COVER (A)
13 360762E ARMATURE 220V-240V
14 320215 FAN GUIDE
15 961501 HEX. HD. TAPPING SCREW D5X60
16 340664E STATOR ASS'Y 220V-230V
17 958032 BRUSH TERMINAL
18 937981 SIDE HANDLE FOR M14
19 939542 RETAINING RING FOR D12 SHAFT
21 949236 MACHINE SCREW M5X10
22 320229 BEARING COVER (B)
23 6302VV BALL BEARING 6302VVCMPS2L
24 990852 FELT PACKING (B)
25 320234 SPINDLE
25 321541 SPINDLE
26 320228 PACKING GLAND GASKET
27 320227 PACKING GLAND
28 994192 HEX. SOCKET HD. BOLT (W/FLANGE) M5X16
29 949656 HEX. SOCKET HD. BOLT M8X20
29A 949760 HEX. SOCKET HD. BOLT M8X25
30 306120 WHEEL GUARD ASS'Y
30 937984Z WHEEL GUARD
30A 330036 WHEEL GUARD ASS'Y
31 937908Z WHEEL WASHER (B)
31 937922P WHEEL WASHER (B) FOR D5/8" HOLE
31A 937907Z WHEEL WASHER (C)
32 316825 D. C. WHEELS 230MM A24R
33 937909Z WHEEL NUT M14X2
33 937923P WHEEL NUT 5/8"-11UNC
34 320218 O-RING
35 306890 LOCK PIN
36A 330032 GEAR AND PINION SET
37 320216 DUST SEAL
38 6000VV BALL BEARING 6000VVCMPS2L
39 321536 BEARING BUSHING
40 325640 HOUSING ASS'Y
42 325641 HANDLE (B)
43 305812 TAPPING SCREW (W/FLANGE) D4X16 (BLACK)
45 940540 BRUSH CAP
46 999044 CARBON BRUSH (1 PAIR)
46 999074 CARBON BRUSH (AUTO STOP TYPE) (1 PAIR)
47 980487 BRUSH HOLDER
48 325642 HANDLE (A)
49 938477 HEX. SOCKET SET SCREW M5X8
50 320238 SWITCH (2P PILLAR TYPE) W/SAFETY LOCK
50 320239 SWITCH (2P PILLAR TYPE) W/SAFETY LOCK
50A 320239 SWITCH (2P PILLAR TYPE) W/SAFETY LOCK
51 960266 CORD CLIP
52 984750 TAPPING SCREW (W/FLANGE) D4X16
53 981373 TUBE (D)
53 961820 TUBE (D)
54 958049 CORD ARMOR D8.2
54 940778 CORD ARMOR D10.7
56 949457 SPRING WASHER M8
57 937911 SET RING (A)
58 322549 SWITCH COVER
59 930804 TERMINAL M4.0
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Hitachi G23SR
11 Items

Data sheet

SHIPPING IN
Usually Ships in 10/15 BUSINESS DAYS
Machine Type
Grinder
MORE INFO:
[email protected]

Specific References

New

Download

Diagram Hitachi G23SR

Diagram Hitachi G23SR

Download (73.25KB)

You might also like

Switch for Angle Grinders Hitachi 230 mm Sale
HiKOKI Power Tools Italia S.p.a. SKU: 320238
Switch for Angle Grinders Hitachi 230 mm
Switch for Angle Grinders Hitachi 230 mm Original spare part Hitachi Koky, Switch for Angle Grinders,  G23SR - G 23MR - G 23SF2 - G 23SS- G 23SW - G 23SC - WALL CHASER CM 7MR - CUTTER CM 9SR. Part for the following products: - Wall...
AVAILABLE €37.76
Details
Carbon Brushe Set for Hitachi Wall Chasers CM7R - CM9SR
HiKOKI Power Tools Italia S.p.a. SKU: 999044
Carbon Brushe Set for Hitachi Wall Chasers CM7R - CM9SR
Carbon Brushe Set for Hitachi Wall Chasers CM7R - CM9SR Genuine part Hitachi, Carbon Brushe Set for Hitachi Wall Chasers CM7R-CM9SR-CM12Y, Hammer DH50MRY, Demolition Hammers H60MC, Grinder G23SR, Router M12V2, Mitre Saw...
AVAILABLE €9.70
Details
Armature for Grinder Hitachi 230 mm G23SR-SRU
HiKOKI Power Tools Italia S.p.a. SKU: 360762E
Armature for Grinder Hitachi 230 mm G23SR-SRU
Armature for Grinder Hitachi 230 mm G23SR-SRU Original spare parts for Hitachi KOKY grinder with disc 230 mm, G23SR - G23SRU - Cutting Machine CM9SR - Wall Chaser CM7MR. - Hitachi Code: 360762E
AVAILABLE €75.58
Details
Ball Bearing Hitachi 6302VV
HiKOKI Power Tools Italia S.p.a. SKU: 6302VV
Ball Bearing Hitachi 6302VV
Ball Bearing Hitachi 6302VV Genuine parts Hitachi, Ball Bearing 6302VV CMPS2S for Angle Grinders S 23UBY - G 23SR - G 23SS - G 23SW. Parts for the following products: - Angle Grinder Hitachi 230 mm S 23UBY - Angle Grinder Hitachi 230...
AVAILABLE €9.70
Details
Ball Bearing Hitachi 6301DD
HiKOKI Power Tools Italia S.p.a. SKU: 6301DD
Ball Bearing Hitachi 6301DD
Ball Bearing Hitachi 6301DD Genuine parts Hitachi, Ball Bearing 6301DD CMPS2S for Angle Grinders G 23SF2 - G 23MR - S 23UBY - G 23SF. Parts for the following products: - Angle Grinder Hitachi 230 mm G 23SF2 - Angle Grinder Hitachi 230...
AVAILABLE €10.92
Details
Carbon Brushes for Angle Grinder Hitachi G23SF - G23SR
HiKOKI Power Tools Italia S.p.a. SKU: 999074
Carbon Brushes for Angle Grinder Hitachi G23SF - G23SR
Carbon Brushes for Angle Grinder Hitachi G23SF - G23SR Genuine parts HITACHI, Carbon Brushes for Angle Grinder Hitachi G23SF - G23SR  230 mm G23SF - G23SR - Combination Hammer UVP DH50MRY - Demolition Hammer H60MC...
AVAILABLE €14.58
Details
Pushing Button for Angle Grinders Hitachi G15VA - G15YF
HiKOKI Power Tools Italia S.p.a. SKU: 306888
Pushing Button for Angle Grinders Hitachi G23
Pushing Button for Angle Grinders Hitachi G23 Original spare parts Hitachi, Pushing Button for Angle Grinders G23SS - G23SW - G23SF2 - S23UBY - G23UBY - G23SWU - G23SR - G23MR - G23SF - CM12Y - CM7MR - CM9SR - SP18VA. Part for the...
AVAILABLE €1.16
Details
Pushing Button for Angle Grinders Hitachi G23
HiKOKI Power Tools Italia S.p.a. SKU: 320219
Button Spring for Angle Grinders Hitachi G23
Button Spring for Angle Grinders Hitachi G23 Original spare parts Hitachi, Button Spring for Angle Grinders S23UBY - G23UBY - G23SWU - G23SS - G23SW - G23SR - G23MR - G23SF2 - CM7MR - CM9SR. Part for the following items: - Angle...
AVAILABLE €3.60
Details
Carbon Brushes for Angle Grinders Hitachi G23SR-S23UBY
Bosch SKU: 999061
Carbon Brushes for Angle Grinders Hitachi G23SR-S23UBY
Carbon Brushes for Angle Grinders Hitachi G23SR-S23UBY Genuine replacement part Bosch, Carbon Brushes mm 7X17X22.5 for Angle Grinders G23SR - S23UBY - G23UBY - G23SF2. Part for the following products: - Angle Grinder Hitachi 230 mm S...
AVAILABLE €10.20
Details
Wheel Guard Ass’y for Angle Grinder Hitachi G 23SF
HiKOKI Power Tools Italia S.p.a. SKU: 330036
Wheel Guard Ass’y for Angle Grinder Hitachi G 23SF
Wheel Guard Ass’y for Angle Grinder Hitachi G 23SF Genuine part Hitachi, Wheel Guard Ass’y for Angle Grinders G 23SF2 - G 23SS - G 23SW -  G 23SR - G 23SWU Parts for the following products: - Angle Grinder Hitachi G 23SF2 - Angle...
AVAILABLE €26.78
Details
Wheel Washer for Angle Grinder Hitachi G23SS
HiKOKI Power Tools Italia S.p.a. SKU: 937907Z
Wheel Washer for Angle Grinder Hitachi G23SS
Wheel Washer for Angle Grinder Hitachi G23SS Genuine spare part Hitachi HIKOKI, Wheel Washer for Angle Grinders G23SS - G23MR - G23SC3 - G23SE2 - G23SF2 - G23SR - G23ST. Part for the following products: - Angle Grinder HITACHI G23SS -...
on 7/10 Business Days Approx. €12.14
Details
Wheel Nut for Angle Grinder Hitachi G23SS
HiKOKI Power Tools Italia S.p.a. SKU: 937909Z
Wheel Nut for Angle Grinder Hitachi G23SS
Wheel Nut for Angle Grinder Hitachi G23SS Genuine spare part Hitachi KOKY, Wheel Nut for Angle Grinders G23SS - G23MR - G23SC3 - G23SE2 - G23SF2 - G23SR - G23ST Part for the following products: - Angle Grinder HITACHI G23SS - Angle...
AVAILABLE €17.02
Details
Bearing Bush for Angle Grinder Hitachi G23SR
HiKOKI Power Tools Italia S.p.a. SKU: 321536
Bearing Bush for Angle Grinder Hitachi G23SR
Bearing Bush for Angle Grinder Hitachi G23SR Genuine Spare Part Hitachi, Bearing Bush for Angle Grinders G23SR - G23UBY - G23UDY - G23SC3 - G23SE2. Part for the following products: - Angle Grinder G23SR - Angle Grinder G23UBY - Angle...
AVAILABLE €17.02
Details
Packing Gland for Angle Grinder Hitachi G23SS
HiKOKI Power Tools Italia S.p.a. SKU: 320227
Packing Gland for Angle Grinder Hitachi G23SS
Packing Gland for Angle Grinder Hitachi G23SS Genuine spare part Hitachi HIKOKI, Packing Gland for Angle Grinders G23SS - G23MR - G23SC3 - G23SE2 - G23SE2 - G23SR - G23ST Part for the following products: -  Angle Grinder G23SS -...
on 7/10 Business Days Approx. €15.80
Details
Packing Gland Gasket for Angle Grinder Hitachi G23SS
HiKOKI Power Tools Italia S.p.a. SKU: 320228
Packing Gland Gasket for Angle Grinder Hitachi G23SS
Packing Gland Gasket for Angle Grinder Hitachi G23SS Genuine spare part Hitachi HIKOKI, Packing Gland Gasket for Angle Grinders G23SS - G23MR - G23SC3 - G23SE2 - G23SE2 - G23SR - G23ST Part for the following products: -  Angle Grinder...
on 7/10 Business Days Approx. €3.60
Details
Lock Pin for Angle Grinder Hitachi G23SS
HiKOKI Power Tools Italia S.p.a. SKU: 306890
Lock Pin for Angle Grinder Hitachi G23SS
Lock Pin for Angle Grinder Hitachi G23SS Genuine spare part Hitachi HIKOKI, Lock Pin for Angle Grinders G23SS - G23MR - G23SC3 - G23SE2 - G23SE2 - G23SR - G23ST Part for the following...
Usually Ships in: 7/10 Business Days Approx. €2.38
Details
Bearing Cover (B) for Angle Grinder Hitachi G23SS
HiKOKI Power Tools Italia S.p.a. SKU: 320229
Bearing Cover (B) for Angle Grinder Hitachi G23SS
Bearing Cover (B) for Angle Grinder Hitachi G23SS Genuine spare part Hitachi HIKOKI, Bearing Cover (B) for Angle Grinders G23SS - G23MR - G23SC3 - G23SE2 - G23SE2 - G23SR - G23ST Part for the following products: -  Angle Grinder G23SS...
on 7/10 Business Days Approx. €3.60
Details
Comments (0)
No customer reviews for the moment.
