HiKOKI Power Tools Italia S.p.a.

HIKOKI Hammer H90SC Parts

SKU: HIKOKI H90SC
€320.69
VAT included

HIKOKI Spare Parts for Demolition Hammer H90SC

Hitachi-HIKOKI Tanaka authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Demolition Hammer H90SC.
Hitachi Hammer H90SC Parts
  • Hitachi Hammer H90SC Parts
  • Hitachi Hammer H90SC Parts Diagram
HiKOKI Power Tools Italia S.p.a.

HIKOKI Hammer H90SC Parts

SKU: HIKOKI H90SC Condition: New
€320.69
VAT included

HIKOKI Spare Parts for Demolition Hammer H90SC

Hitachi-HIKOKI Tanaka authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Demolition Hammer H90SC.
settings 76 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
76 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 305618 TIP STOP €302.29
3
 photo_cameraImage coming soon 305620 PIN €32.15
5
 photo_cameraImage coming soon 305619 FRONT COVER FOR H90SC €398.78
6
 photo_cameraImage coming soon 305621 RETAINER DAMPER €22.19
7
 photo_cameraImage coming soon 993188 RING €19.42
8
 photo_cameraImage coming soon 877316 O-RING S.90 €3.18
9
 photo_cameraImage coming soon 305617 SECOND HINGE €84.22
10
 photo_cameraImage coming soon 992865 RING €10.52
11
 photo_cameraImage coming soon 956503 O-RING (A) €7.06
12
 photo_cameraImage coming soon 305616 HINGE SUPPORT €118.46
13
 photo_cameraImage coming soon 992859 SHOCK ABSORBER RING €31.80
15
 photo_cameraImage coming soon 305615 CYLINDER FOR H90SC €451.83
18
 photo_cameraImage coming soon 993195 O-RING €4.07
19
 photo_cameraImage coming soon 305612 HINGE €72.35
20
 photo_cameraImage coming soon 305611 PISTON €461.11
21
 photo_cameraImage coming soon 305614 PISTON PIN €26.11
22
 photo_cameraImage coming soon 878716 O-RING P-46 €2.07
23
 photo_cameraImage coming soon 305613 CONNECTING ROD €109.12
24
 photo_cameraImage coming soon 956485 ROLLER BEARING RLM2220 €20.34
25
 photo_cameraImage coming soon 992870 PIN €6.33
26
 photo_cameraImage coming soon 992869 SWITCH LEVER €10.52
27
 photo_cameraImage coming soon 968643 RETAINING RING (E-TYPE) FOR D4 SHAFT €2.40
29
 photo_cameraImage coming soon 305636 HANDLE (A) €23.61
30
 photo_cameraImage coming soon 714520 POWER CORD 5M 2X1.5 €15.00
31
 photo_cameraImage coming soon 940778 CORD ARMOR D10.7 €3.43
32
 Noise Suppressor for Angle Grinder Hitachi G12SA2 994273 Noise Suppressor for Angle Grinder Hitachi G12SA2 €9.62
36
 photo_cameraImage coming soon 938307 PILLAR TERMINAL (OLD 938307Z / 512-31) €2.60
41
 photo_cameraImage coming soon 960266 CORD CLIP €1.37
43
 Switch (A) 1 P Screw type) w/o Lock for Hammer DH50SB 992891 Switch (A) 1 P Screw type) w/o Lock for Hammer DH50SB €29.60
45
 photo_cameraImage coming soon 312408 HANDLE €19.36
46
 photo_cameraImage coming soon 305634 HANDLE SUPPORT €130.94
49
 photo_cameraImage coming soon 305631 HANDLE (B) €22.19
51
 photo_cameraImage coming soon 305624 HANDLE SHAFT €159.00
52
 photo_cameraImage coming soon 305598 COVER €17.87
53
 photo_cameraImage coming soon 305623 SHAFT SUPPORT €90.47
54
 photo_cameraImage coming soon 305622 RUBBER €2.07
56
 photo_cameraImage coming soon 305625 SUPPORT €124.73
59
 photo_cameraImage coming soon 992851 BOLT M10X60 €2.83
60
 photo_cameraImage coming soon 305637 GEARBOX COVER €130.94
62
 photo_cameraImage coming soon 305629 LOCK €9.36
63
 photo_cameraImage coming soon 6204VV BALL BEARING 6204VVCMPSA2L €9.44
64
 photo_cameraImage coming soon 305609 SPACER €9.36
65
 photo_cameraImage coming soon 305608 GEAR €118.46
68
 photo_cameraImage coming soon 6201VV BALL BEARING 6201VVCMPS2L €6.76
69
 photo_cameraImage coming soon 305605 FIRST GEAR €53.52
70
 photo_cameraImage coming soon 305604 SECOND GEAR €67.76
71
 photo_cameraImage coming soon 930511 FEATHER KEY 4X4X10 €2.83
73
 photo_cameraImage coming soon 305600 BEARING SUPPORT €3.61
74A
 photo_cameraImage coming soon 6203DD BALL BEARING 6203DDCMPS2L €8.89
75
 photo_cameraImage coming soon 992841 BEARING WASHER €1.28
76
 photo_cameraImage coming soon 949480 PIN D8X14 (10 PCS) €4.65
77
 photo_cameraImage coming soon 336337 COVER INTERNAL €149.17
79
 photo_cameraImage coming soon 6305VV BALL BEARING 6305VV €15.27
80
 photo_cameraImage coming soon 992847 RING €4.37
81
 photo_cameraImage coming soon 305601 SUPPORT €74.91
83
 photo_cameraImage coming soon 992846 OIL SEAL €2.83
84
 photo_cameraImage coming soon 931008 FEATHER KEY 4X4X12 €1.28
86
 photo_cameraImage coming soon 305596 CASE €554.56
87
 photo_cameraImage coming soon 980717 O-RING (S-38) €1.70
88A
 photo_cameraImage coming soon 990945 OIL CAP ASS'Y €4.86
89
 photo_cameraImage coming soon 992894 RUBBER CAP €5.17
91
 photo_cameraImage coming soon 305635 PLUG €7.06
92
 photo_cameraImage coming soon 937949 BRUSH CAP €1.68
93B
 Carbon Brushes for Angle Grinder Hitachi G23SF - G23SR 999074 Carbon Brushes for Angle Grinder Hitachi G23SF - G23SR €15.05
94
 photo_cameraImage coming soon 305597 BRUSH HOLDER €8.61
96
 photo_cameraImage coming soon 305627 SLEEVE €5.17
97
 photo_cameraImage coming soon 305630 END COVER €12.81
99
 photo_cameraImage coming soon 996370 FAN €19.03
100
 photo_cameraImage coming soon 360262E ARMOR 220-230V €268.07
101
 photo_cameraImage coming soon 993185 SELF-TAPPING SCREW HEX.D5X85 €3.18
104
 photo_cameraImage coming soon 305610 FAN GUIDE €15.53
105
 Brush Terminal for Demolition Hammer H60MRV 945932 Brush Terminal for Demolition Hammer H60MRV €1.36
106
 photo_cameraImage coming soon 340238E STATOR 220-230V FOR H90SC €90.47
107
 photo_cameraImage coming soon 944954 BEARING WASHER €1.30
108
 photo_cameraImage coming soon 305628 COVER €39.26
109
 photo_cameraImage coming soon 996437 COLLAR €1.28

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

HIKOKI Spare Parts for Demolition Hammer H90SC

Hitachi-HIKOKI Tanaka authorized service center

 and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Demolition Hammer H90SC.

In the following table, look for the model of the Demolition Hammer and the respective parts of the code.
Hitachi H90SC

HIKOKI Demolition Hammer Hitachi H90SC Parts List
# Part Num. Description
1 305618 TIP STOP
2 949874 PIN D.6X36 (10 PCS)
3 305620 PIN
4A 306373 NYLOCK HGH TENSION BOLT (M12X40)
5 305619 FRONT COVER FOR H90SC
6 305621 RING
7 993188 RING
8 877316 O-RING S.90
9 305617 SECOND HINGE
10 992865 RING
11 956503 O-RING (A)
12 305616 HINGE SUPPORT
13 992859 SHOCK ABSORBER RING
15 305615 CYLINDER FOR H90SC
16A 306372 NYLOCK BOLT M10X45 (OLD 993198)
17 949445 WASHER M10 (10 PCS) (OLD 949445Z)
18 993195 RING
19 305612 HINGE
20 305611 PISTON
21 305614 PISTON PIN
22 878716 O-RING P-46
23 305613 CONNECTING ROD
24 956485 ROLLER BEARING RLM2220
25 992870 PIN
26 992869 SWITCH HOLDER LEVER
27 968643 RING TYPE E FOR SHAFTS D.4
29 305636 GRIP (A)
30 714520 CABLE 5M 2X1.5 WITH PLUG
31 940778 CABLE PROTECTION SLEEVE 10.7
32 994273 NOISE FILTER
33 930153 SPONGE
34 959140 JOINT
35 959141 JOINT
36 938307 PILLAR TERMINAL (OLD 938307Z/512-31
37 958308Z CLAMP
38 996438 VINYL TUBE (A) I.D.7XTO.5X50
39 981974 INTERNAL WIRE
40 992810 TERMINAL
41 960266 WIRE TERMINAL
43 992891 SINGLE-POLE SWITCH
45 312408 SUPPORT
46 305634 HANDLE SUPPORT
47 949426 WASHER M8 (10 PCS)
48 305632 LOCK NUT M8 (NYLON INSERT) (OLD 975
49 305631 HANDLE (B)
51 305624 HANDLE SHAFT
52 305598 COVER
53 305623 SHAFT SUPPORT
54 305622 RUBBER
55 305633 HANDLE
56 305625 SUPPORT
59 992851 BOLT M10X60
60 305637 GEARBOX COVER
62 305629 LOCK
63 6204VV BALL BEARING 6204VV
64 305609 SPACER
65 305608 GEAR
66 305607 SPACER
68 6201VV BALL BEARING 6201VV
69 305605 FIRST GEAR
70 305604 SECOND GEAR
71 930511 KEY 4X4X10
73 305600 BEARING SUPPORT
74A 6203DD BALL BEARING 6203DD
75 992841 BEARING WASHER
76 949480 PIN D8X14 (10 PCS)
77 336337 COVER INTERNAL
78 305602 SPACER
79 6305VV BALL BEARING 6305VV
80 992847 RING
81 305601 SUPPORT
83 992846 OIL SEAL
84 931008 KEY 4X4X12
85 305606 CRANKSHAFT
86 305596 CASE
87 980717 O-RING S.38
88A 990945 OIL CAP
89 992894 RUBBER CAP
91 305635 PLUG
92 937949 BRUSH COVER
93B 999074 SELF-LOCKING BRUSHES (1 PAIR)
94 305597 BRUSH HOLDER
96 305627 SLEEVE
97 305630 END COVER
99 996370 FAN
100 360262E ARMOR 220-230V
101 993185 SELF-TAPPING SCREW HEX.D5X85
102 956764 SPECIAL WASHER
103 305798 INTERNAL WIRE
104 305610 GUIDE
105 945932 BRUSH TERMINAL
106 340238E STATOR 220-230V FOR H90SC
107 944954 BEARING WASHER
108 305628 COVER
109 996437 COLLAR
STANDARD ACCESSORIES
501 943277 KEY
502 944459 KEY
503 993740 ALLEN WRENCH 10MM
