HIKOKI DH40MEY2 Rotary Hammer Parts

SKU: Hitachi DH40MEY2
€20.31
VAT included

HIKOKI DH40MEY2 Rotary Hammer Spare Parts

Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Rotary Hammer DH40MEY2.
HIKOKI DH40MEY2 Rotary Hammer Parts
  • HIKOKI DH40MEY2 Rotary Hammer Parts
  • HIKOKI DH40MEY2 Rotary Hammer Parts Diagram

HIKOKI DH40MEY2 Rotary Hammer Parts

SKU: Hitachi DH40MEY2 Condition: New
€20.31
VAT included

HIKOKI DH40MEY2 Rotary Hammer Spare Parts

Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Rotary Hammer DH40MEY2.
settings 98 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

93 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Pos. Item Price Buy
1
photo_cameraImage coming soon 381618 SIDE HANDLE ASSY €19.15
4
photo_cameraImage coming soon 380324 MOUNT €2.82
6
photo_cameraImage coming soon 380210 SCREW €7.04
7
photo_cameraImage coming soon 380208 HANDLE BAND €4.16
8
photo_cameraImage coming soon 331247 HANDLE BOLT €5.95
9
photo_cameraImage coming soon 371151 FRONT CAP €2.50
10
photo_cameraImage coming soon 318590 STOPPER RING €2.27
11
photo_cameraImage coming soon 371138 RETAINER WASHER €2.62
12
photo_cameraImage coming soon 381003 RING €5.50
13
Retainer Damper (A) for Rotary Hammer Hitachi DH40MEY 337559 Retainer Damper (A) for Rotary Hammer Hitachi DH40MEY €1.60
14
photo_cameraImage coming soon 380375 BIT LOCK HOLDER €7.51
15
photo_cameraImage coming soon 380374 THRUST PLATE €9.54
16
photo_cameraImage coming soon 337556 RETAINER SPRING €2.01
17
photo_cameraImage coming soon 371145 SPRING HOLDER (A) €1.33
19
photo_cameraImage coming soon 380344 CYLINDER COVER €9.81
20
photo_cameraImage coming soon 967270 RETAINING RING FOR D52 HOLE €3.32
21
photo_cameraImage coming soon 380373 STOPPER WASHER €1.46
22
photo_cameraImage coming soon 380370 OIL SEAL (B) €1.61
23
photo_cameraImage coming soon 380369 METAL BUSHING ASSY INCLUDED 22 €12.89
24
photo_cameraImage coming soon 380371 RETAINER DAMPER (B) €1.46
25
photo_cameraImage coming soon 380372 WASHER €4.16
26
photo_cameraImage coming soon 331244 0-RING €1.60
27
photo_cameraImage coming soon 380361 BIT HOLDER €41.82
28
photo_cameraImage coming soon 370654 BIT LOCK €7.01
29
O-Ring 20X26X3 mm for Demolition Hammers Hitachi DH38MS-DH40MRY-H41MB 313396 O-Ring 20X26X3 mm for Demolition Hammers Hitachi DH38MS-DH40MRY-H41MB €7.67
30
photo_cameraImage coming soon 380362 SECOND HAMMER €9.54
31
photo_cameraImage coming soon 380363 WASHER €4.16
32
photo_cameraImage coming soon 380364 DAMPER €4.83
33
photo_cameraImage coming soon 380365 DAMPER HOLDER €2.82
34
photo_cameraImage coming soon 380367 NEEDLE SLEEVE €3.89
35
photo_cameraImage coming soon 331217 NEEDLE €1.55
36
photo_cameraImage coming soon 323073 RING (A) €1.96
37
photo_cameraImage coming soon 380366 CYLINDER €25.01
38
photo_cameraImage coming soon 380368 WASHER (B) €3.89
39
photo_cameraImage coming soon 380355 STRIKER €5.50
40
O-Ring 23X30X3 mm for Demolition Hammers Hitachi DH40MRY-DH38MS 986104 O-Ring 23X30X3 mm for Demolition Hammers Hitachi DH40MRY-DH38MS €2.08
41
photo_cameraImage coming soon 380337 FAN GUIDE €1.46
44
photo_cameraImage coming soon 341170E STATOR SENSOR PCB SET 230V-240V €45.19
45
Dust Washer for Demolition Hammer Hitachi H45MRY 982631 Dust Washer for Demolition Hammer Hitachi H45MRY €1.34
46
photo_cameraImage coming soon 608VVM BALL BEARING 608VVC2PS2L €7.12
47
photo_cameraImage coming soon 380334 HOUSING €17.20
49
photo_cameraImage coming soon 333263 DUST SEAL €1.47
50
photo_cameraImage coming soon 380336 TAIL COVER €2.13
54
photo_cameraImage coming soon 381004 PACKING (B) €1.46
56
photo_cameraImage coming soon 317492 SUPPORT (B) €1.91
57
O-Ring S-32 for Hammers Hitachi H25PV-DH30PC2-DH40MRY-H60MC 872767 O-Ring S-32 for Hammers Hitachi H25PV-DH30PC2-DH40MRY-H60MC €2.78
58
photo_cameraImage coming soon 6201DD BALL BEARING 6201DDCMPS2L €7.04
59
photo_cameraImage coming soon 361227 ROTOR (B) €57.96
62
photo_cameraImage coming soon 322808 O-RING (C) €2.02
64
photo_cameraImage coming soon 380389 HANDLE HOLDER €1.73
68
photo_cameraImage coming soon 380387 BACK COVER €8.20
70
photo_cameraImage coming soon 334379 FERRITE CORE €6.61
72
photo_cameraImage coming soon 380341 FILTER PCB 220V-240V €14.25
77
photo_cameraImage coming soon 338171 ON LOCK BUTTON €1.33
79
photo_cameraImage coming soon 381005 SWITCH €17.60
81
photo_cameraImage coming soon 374772 WASHER €1.33
86
photo_cameraImage coming soon 380386 CRANK COVER €6.84
88
photo_cameraImage coming soon 380646 LOCK CARD (B) €12.22
90
photo_cameraImage coming soon 380385 SEAL RING €4.43
94
photo_cameraImage coming soon 380384 HOOK €1.88
96
photo_cameraImage coming soon 380357 CRANK PLATE €2.00
98
photo_cameraImage coming soon 380380 LEVER SHAFT €2.13
101
photo_cameraImage coming soon 380358 WASHER €1.46
103
photo_cameraImage coming soon 380360 CLUTCH €6.17
105
photo_cameraImage coming soon 331221 PISTON PIN €1.55
106
Piston for Hammers Hitachi DH38MS-DH40MRY-H41MB 326369 Piston for Hammers Hitachi DH38MS-DH40MRY-H41MB €5.27
107
photo_cameraImage coming soon 337535 CONNECTING ROD ASS'Y €15.30
108
photo_cameraImage coming soon 380348 CRANK GEAR €27.02
109
photo_cameraImage coming soon 380346 NEEDLE BEARING €6.84
110
photo_cameraImage coming soon 380347 WASHER (A) €1.46
111
photo_cameraImage coming soon 380376 WEIGHT HOLDER €1.46
112
photo_cameraImage coming soon 380377 WEIGHT SHAFT €3.49
114
photo_cameraImage coming soon 380378 WEIGHT SPRING €1.46
115
photo_cameraImage coming soon 380379 WEIGHT €8.20
116
photo_cameraImage coming soon 380349 SLIP CLUTCH ASSY INCLUDES 35.117-123 €36.44
117
photo_cameraImage coming soon 380350 BEVEL PINION €7.11
118
photo_cameraImage coming soon 944109 FEATHER KEY 3X3X8 €2.99
119
photo_cameraImage coming soon 380351 CLUTCH WASHER €1.73
120
photo_cameraImage coming soon 380352 SECOND GEAR €11.55
121
photo_cameraImage coming soon 380353 GEAR HOLDER €11.70
122
photo_cameraImage coming soon 321282 SPRING (C) €2.46
123
photo_cameraImage coming soon 380354 SPACER €6.17
124
photo_cameraImage coming soon 380339 OIL SEAL €1.46
125
photo_cameraImage coming soon 380338 CRANK CASE €56.62
126
photo_cameraImage coming soon 995396 BREATHER VALVE €2.99
127
photo_cameraImage coming soon 339061 CAP SCREW €9.17
128
photo_cameraImage coming soon 380345 FELT €1.46
501
photo_cameraImage coming soon 308471 GREASE 70 GR €19.79
501
photo_cameraImage coming soon 335782 GREASE FOR ROTARY HAMMER (60G) €18.17
501
photo_cameraImage coming soon 980927 GREASE 500 GR €84.44
501
photo_cameraImage coming soon 981840 GREASE 30 GR €10.98
603
photo_cameraImage coming soon 949859 ROLL PIN D2X8 (10 PCS.) €1.90
605
photo_cameraImage coming soon 971786 DEPTH DELIMITER €7.11

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

HIKOKI DH40MEY2 Rotary Hammer Spare Parts

Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Rotary Hammer DH40MEY2.

In the following table, look for the model of the Demolition Hammer and the respective parts of the code.
Hitachi DH40MEY2
HIKOKI DH40MEY2 Rotary Hammer Spare Parts
# Part Num. Description
1 381618 COMPLETE SIDE HANDLE
4 380324 MOUNT
6 380210 SIDE HANDLE
7 380208 HANDLE BAND
8 331247 HANDLE BOLT
9 371151 FRONT CAP
10 318590 STOPPER RING
11 371138 RETAINER WASHER
12 381003 RING NUT
13 337559 RETAINER DAMPER (A)
14 380375 BIT LOCK HOLDER
15 380374 THRUST PLATE
16 337556 RETAINER SPRING
17 371145 SPRING HOLDER (A)
19 380344 CYLINDER COVER
20 967270 RETAINING RING FOR HOLE D52
21 380373 STOPPER WASHER
22 380370 OIL SEAL (B)
23 380369 METAL ASS'Y INCLUDED 22
24 380371 RETAINER DAMPER (B)
25 380372 RETAINER DAMPER WASHER (B)
26 331244 O-RING
27 380361 RETAINER SLEEVE
28 370654 BIT LOCK
29 313396 O-RING (C)
30 380362 SECOND HAMMER
31 380363 DAMPER WASHER
32 380364 DAMPER
33 380365 DAMPER HOLDER
34 380367 NEEDLE SLEEVE
35 331217 CLUTCH NEEDLE
36 323073 RING (A)
37 380366 CYLINDER
38 380368 THRUST WASHER (B)
39 380355 STRIKER
40 986104 O-RING
41 380337 FAN GUIDE
44 341170E STATOR SENSOR PCB SET 230V-240V
45 982631 WASHER (A)
46 608VVM BALL BEARING 608VVM
47 380334 HOUSING
49 333263 DUST SEAL
50 380336 TAIL COVER
52 339059 PACKING (A)
54 381004 PACKING (B)
56 317492 SWITCH GUARD FOR EUROPE.GBR(230V).AUS.N ZL.SAF
57 872767 O-RING S.32
58 6201DD BALL BEARING 6201DD
59 361227 ROTOR (B)
62 322808 O-RING (C)
64 380389 HANDLE HOLDER
68 380387 BACK COVER
70 334379 FERRITE CORE FOR EUROPE.GBR(230V).AUS.N ZL.SAF
72 380341 FILTER PCB 220V-240V
75 380888 ON LOCK PCB (A) INCLUD.52
77 338171 ON LOCK BUTTON
79 381005 SWITCH
81 374772 WASHER
86 380386 CRANK COVER
88 380646 ON LOCK PCB (B)
90 380385 SEAL RING
92 337567 LEVER SPRING
94 380384 HOOK
96 380357 CRANK PLATE
98 380380 LEVER SHAFT
101 380358 METAL WASHER
103 380360 CLUTCH MOD.
105 331221 PISTON PIN
106 326369 PISTON
107 337535 CONNECTING ROD
108 380348 CRANK GEAR
109 380346 NEEDLE CAGE
110 380347 THRUST WASHER (A)
111 380376 WEIGHT HOLDER
112 380377 WEIGHT SHAFT
113 307292 O-RING (4PC-5)
114 380378 WEIGHT SPRING
115 380379 WEIGHT
116 380349 SLIP CLUTCH ASS'Y INCLUDED 35.117-123
117 380350 BEVEL PINION
118 944109 FEATHER KEY 3X3X8
119 380351 CLUTCH WASHER
120 380352 SECOND GEAR
121 380353 GEAR HOLDER
122 321282 CLUTCH SPRING (C)
123 380354 SPACER
124 380339 OIL SEAL (A)
125 380338 CRANK CASE
126 995396 BREATHER VALVE
127 339061 CAP SCREW
128 380345 FELT
501 981840 GREASE 30G
501 335782 GREASE 60G
501 308471 GREASE FOR HAMMER.HAMMER DRILL (70G)
501 980927 GREASE 500G
502 380421 INCLUDED 503
603 949859 ROLL PIN D2X8 (10 PCS)
605 971786 STOPPER ROD
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Hitachi DH40MEY2
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

HIKOKI DH40MEY2 Parts Diagram

HIKOKI DH40MEY2 Parts Diagram

Download (545.83KB)

You might also like

HiKOKI Power Tools Italia S.p.a. SKU: 326369
Piston for Hammers Hitachi DH38MS-DH40MRY-H41MB Genuine parts Hitachi, Piston for Hitachi Hammers model DH38MS - DH40MRY - H41MB. Part for the following items: - Combined Hammer 9 Joule - 6.4kg DH38MS - Hammer Comb.10.5 Joule -...
Last items in stock €5.27
HiKOKI Power Tools Italia S.p.a. SKU: 939299
Needle Bearing for Demolition Hammers Hitachi DH 40/50MRY-DH45MR Genuine part HITACHI, Needle Bearing M661 for Demolition Hammers H45MR - H45MRY - H45FRV - H45SR - DH40MRY - DH45MR - H41MB - H25PV - DH30PC2 - DH38MS - DH50MRY - PR-38E....
AVAILABLE €13.81
HiKOKI Power Tools Italia S.p.a. SKU: 986104
O-Ring 23X30X3 mm for Demolition Hammers Hitachi DH40MRY-DH38MS Genuine part HITACHI, O-Ring 23X30X3 mm for Demolition Hammers Hitachi DH40MRY-DH38MS-DH50MRY-H41MB. Part for the following products: - Demolition Hammer Hitachi...
Last items in stock €2.08
HiKOKI Power Tools Italia S.p.a. SKU: 321274
Oil Seal mm 17x35x7 for Rotary Hammer Hitachi DH38MS-DH40MRY Original Spare Parts Hitachi, Oil Seal mm 17x35x7 for Rotary Hammer Hitachi DH38MS-DH40MRY. Part for the following article : - Hammer DH38MS - Hammer DH40MRY - Codice :...
AVAILABLE €8.23
HiKOKI Power Tools Italia S.p.a. SKU: 313050
Oil Seal 20x32x5 for Rotary Hammer Hitachi DH45MR-DH40MRY-DH38MS Original Spare Part Hitachi, Oil Seal 20x32x5 for Rotary Hammers Hitachi DH45MR-DH40MRY-DH38MS. Part for the following products: - Rotary Hammer DH45MR - Rotary Hammer...
AVAILABLE €5.43
HiKOKI Power Tools Italia S.p.a. SKU: 302429
Dust Washer for Demolition Hammers Hitachi H45MR Genuine Spare Parts Hitachi, Dust Washer for Demolition Hammers H45MR - H45FRV - H45MRY - H45SR - DH40MRY - H41MB. Part for the following items: - Demolition Hammer Hitachi H45MR...
AVAILABLE €1.36
HiKOKI Power Tools Italia S.p.a. SKU: 980708
Piston Pin for Hammers Hitachi DH40MRY-H41M Hitachi genuine parts, Rod/Piston Pin for Combined Hammer 10.5 Joule-6.8Kg UVP DH40MRY - Demolition Hammer Class 5 Kg Hitachi H41M. Part for the following items: - Combined Hammer 10.5...
AVAILABLE €3.48
HiKOKI Power Tools Italia S.p.a. SKU: 321835
Damper for Hammers Hitachi DH38MS-H41MB Original spare parts Hitachi, Damper for Demolition Hammers 9 Joule - 6.4Kg DH38MS - Class 5 Kg H41MB Part For the following items: - Hammer Hitachi 9 Joule - 6.4Kg DH38MS -...
AVAILABLE €11.16
HiKOKI Power Tools Italia S.p.a. SKU: 310123
Transatory Unit for Demolition Hammer Hitachi H45SA Original spare parts Hitachi, Transatory Unit for Rotary Hammers DH40MEY - DH40MRY - DH45ME - DH52MEY - H41SA - H41SC - H45MR - H45MRY - H45S - H60KA - H60MEY - H60MR - H60MRV.
Last items in stock €16.13
HiKOKI Power Tools Italia S.p.a. SKU: 956996
O-RING 1AS.60 for Hammer DH40MRY-DH45MR Genuine spare part Hitachi, O-RING 1AS.60 for Rotary Hammer DH40MRY - DH45MR - DH38MS. For the follows items: - Rotary Hammer DH40MRY - Rotary Hammer DH45MR - Rotary Hammer...
AVAILABLE €3.83
HiKOKI Power Tools Italia S.p.a. SKU: 310124
Damper for Demolition Hammers H60MRV-H45MR-H45MRY Hitachi genuine part, Damper for Demolition Hammers H60MRV - H45MR - H45MRY - DH40MRY - DH45MR - H45FRV - H45SR - DH45ME -H60MC. Part for the following items:...
Last items in stock €5.77
HiKOKI Power Tools Italia S.p.a. SKU: 337589
Handle (A) for Rotary Hammer Hitachi DH40MEY Genuine part Hitachi HIKOKI, Handle (A) for Rotary Hammer DH40MEY For the following items: -  Combined Rotary Hammer Hitachi DH40MEY - Code: 337589
Last items in stock €15.19
Retainer Sleeve for Rotary Hammer Hitachi DH40MEY Sale
HiKOKI Power Tools Italia S.p.a. SKU: 337536
Retainer Sleeve for Rotary Hammer Hitachi DH40MEY Genuine part Hitachi HIKOKI, Retainer Sleeve for Rotary Hammer DH40MEY For the following items: -  Combined Rotary Hammer Hitachi DH40MEY - Code: 337536
Last items in stock €59.51
HiKOKI Power Tools Italia S.p.a. SKU: 337559
Retainer Damper (A) for Rotary Hammer Hitachi DH40MEY Genuine part Hitachi HIKOKI, Retainer Damper (A) for Rotary Hammer DH40MEY - Demolition Hammer H41MB2 For the following items: -  Combined Rotary Hammer Hitachi DH40MEY -...
on 7/10 Business Days Approx €1.60
HiKOKI Power Tools Italia S.p.a. SKU: 339910
Spacer for Rotary Hammer Hitachi DH40MEY Genuine part Hitachi HIKOKI, Spacer for Rotary Hammer DH40MEY - Demolition Hammer H45MEY For the following items: -  Combined Rotary Hammer Hitachi DH40MEY - Demolition Hammer Hitachi H45MEY -...
on 7/10 Business Days Approx €1.24
HiKOKI Power Tools Italia S.p.a. SKU: 877315
O-Ring I.D.63,9 for Rotary Hammer Hitachi DH40MEY Genuine part Hitachi HIKOKI, O-Ring I.D.63,9 for Rotary Hammer DH40MEY - Demolition Hammer DH40MC For the following items: -  Combined Rotary Hammer Hitachi DH40MEY -  Demolition...
on 7/10 Business Days Approx €3.05
HiKOKI Power Tools Italia S.p.a. SKU: 337563
Change Plate for Rotary Hammer Hitachi DH40MEY Genuine part Hitachi HIKOKI, Change Plate for Rotary Hammer DH40MEY For the following items: -  Combined Rotary Hammer Hitachi DH40MEY - Code: 337563
Last items in stock €2.34
HiKOKI Power Tools Italia S.p.a. SKU: 944525
Bearing Washer (C) for Demolition Hammer Hitachi DH40MA Original replacement part Hitachi HIKOKI, Bearing Washer (C) for Demolition Hammer DH40SA - DH40YB - DH40MA. Part for the following items : -  Demolition Hammer DH40SA -...
on 7/10 Business Days Approx €1.26
Comments (0)
