HIKOKI Cordless Rotary Hammer DA3640DA Parts

SKU: HIKOKI Hitachi DA3640DA
€20.74
VAT included

HIKOKI Cordless Rotary Hammer DA3640DA Spare Parts

Hitachi Koky genuine spare parts or replacement parts for to repair Cordless Rotary Hammer DA3640DA.

HIKOKI Cordless Rotary Hammer DA3640DA Parts
  • HIKOKI Cordless Rotary Hammer DA3640DA Parts
  • HIKOKI Cordless Rotary Hammer DA3640DA Parts
HiKOKI Power Tools Italia S.p.a.

HIKOKI Cordless Rotary Hammer DA3640DA Parts

SKU: HIKOKI Hitachi DA3640DA Condition: New
€20.74
VAT included

HIKOKI Cordless Rotary Hammer DA3640DA Spare Parts

Hitachi Koky genuine spare parts or replacement parts for to repair Cordless Rotary Hammer DA3640DA.

settings 91 Spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN: Usually Ships in 10/15 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
91 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 381618 SIDE HANDLE ASSY €19.46
4
 photo_cameraImage coming soon 380324 MOUNT €2.38
6
 photo_cameraImage coming soon 380210 SCREW €7.04
7
 photo_cameraImage coming soon 380208 HANDLE BAND €3.60
8
 photo_cameraImage coming soon 331247 HANDLE BOLT €6.04
9
 photo_cameraImage coming soon 371151 FRONT CAP €2.38
10
 STOPPER RING 318590 STOPPER RING €2.38
11
 photo_cameraImage coming soon 371138 RETAINER WASHER €2.38
12
 photo_cameraImage coming soon 381003 RING €6.04
13
 Retainer Damper (A) for Rotary Hammer Hitachi DH40MEY 337559 Retainer Damper (A) for Rotary Hammer Hitachi DH40MEY €1.16
14
 photo_cameraImage coming soon 380375 BIT LOCK HOLDER €7.26
15
 photo_cameraImage coming soon 380374 THRUST PLATE €9.70
16
 photo_cameraImage coming soon 337556 RETAINER SPRING €2.38
17
 photo_cameraImage coming soon 371145 SPRING HOLDER (A) €1.16
19
 photo_cameraImage coming soon 380344 CYLINDER COVER €9.70
20
 photo_cameraImage coming soon 967270 RETAINING RING FOR D52 HOLE €3.60
21
 photo_cameraImage coming soon 380373 STOPPER WASHER €1.16
22
 photo_cameraImage coming soon 380370 OIL SEAL (B) €1.16
23
 photo_cameraImage coming soon 380369 METAL BUSHING ASSY INCLUDED 22 €13.36
24
 photo_cameraImage coming soon 380371 RETAINER DAMPER (B) €1.16
25
 photo_cameraImage coming soon 380372 WASHER €3.60
26
 photo_cameraImage coming soon 331244 0-RING €1.16
27
 photo_cameraImage coming soon 380361 BIT HOLDER €43.86
28
 BIT LOCK 370654 BIT LOCK €7.26
29
 O-Ring 20X26X3 mm for Demolition Hammers Hitachi DH38MS-DH40MRY-H41MB 313396 O-Ring 20X26X3 mm for Demolition Hammers Hitachi DH38MS-DH40MRY-H41MB €7.26
30
 photo_cameraImage coming soon 380362 SECOND HAMMER €9.70
31
 photo_cameraImage coming soon 380363 WASHER €3.60
32
 photo_cameraImage coming soon 380364 DAMPER €4.82
33
 photo_cameraImage coming soon 380365 DAMPER HOLDER €2.38
34
 photo_cameraImage coming soon 380367 NEEDLE SLEEVE €3.60
35
 photo_cameraImage coming soon 331217 NEEDLE €1.16
36
 photo_cameraImage coming soon 323073 RING (A) €2.38
37
 photo_cameraImage coming soon 380366 CYLINDER €25.56
38
 photo_cameraImage coming soon 380368 WASHER (B) €3.60
39
 photo_cameraImage coming soon 380355 STRIKER €6.04
40
 O-Ring 23X30X3 mm for Demolition Hammers Hitachi DH40MRY-DH38MS 986104 O-Ring 23X30X3 mm for Demolition Hammers Hitachi DH40MRY-DH38MS €2.38
41
 photo_cameraImage coming soon 380337 FAN GUIDE €1.16
43
 photo_cameraImage coming soon 323210 BOLT WASHER M4 (BLACK) €1.16
45
 Dust Washer for Demolition Hammer Hitachi H45MRY 982631 Dust Washer for Demolition Hammer Hitachi H45MRY €1.16
46
 BALL BEARING 608VVC2PS2L 608VVM BALL BEARING 608VVC2PS2L €7.26
49
 photo_cameraImage coming soon 333263 DUST SEAL €1.16
56
 O-Ring S-32 for Hammers Hitachi H25PV-DH30PC2-DH40MRY-H60MC 872767 O-Ring S-32 for Hammers Hitachi H25PV-DH30PC2-DH40MRY-H60MC €2.38
57
 BALL BEARING 6201DDCMPS2L 6201DD BALL BEARING 6201DDCMPS2L €7.26
60
 photo_cameraImage coming soon 322808 O-RING (C) €2.38
62
 photo_cameraImage coming soon 380389 HANDLE HOLDER €1.16
64
 photo_cameraImage coming soon 338194 WEIGHT BUMPER €0.00 Not available for order
66
 photo_cameraImage coming soon 325910 SCREW 3x12 S36M €2.38
68
 photo_cameraImage coming soon 379349 MV LABEL (A) (2) €0.00 Not available for order
72
 photo_cameraImage coming soon 380888 ON LOCK PCB (A) INCLUD.52 €0.00 Not available for order
73
 photo_cameraImage coming soon 339059 PACKING (A) €0.00 Not available for order
75
 photo_cameraImage coming soon 338171 ON LOCK BUTTON €1.16
76
 photo_cameraImage coming soon 370328 BATTERY RUBBER (B) €2.38
77
 photo_cameraImage coming soon 381005 SWITCH €18.24
78
 photo_cameraImage coming soon 317492 SUPPORT (B) €2.38
80
 photo_cameraImage coming soon 374772 WASHER €1.16
82
 photo_cameraImage coming soon 379350 MV LABEL (B) (2) €0.00 Not available for order
86
 photo_cameraImage coming soon 380386 CRANK COVER €7.26
88
 photo_cameraImage coming soon 380646 LOCK CARD (B) €12.14
90
 photo_cameraImage coming soon 380385 SEAL RING €4.82
91
 photo_cameraImage coming soon 338312 0-RING €1.16
92
 photo_cameraImage coming soon 337567 LEVER SPRING €0.00 Not available for order
93
 photo_cameraImage coming soon 370239 STEEL BALL D5 €1.16
94
 photo_cameraImage coming soon 380384 HOOK €2.38
96
 photo_cameraImage coming soon 380357 CRANK PLATE €2.38
98
 photo_cameraImage coming soon 380380 LEVER SHAFT €2.38
101
 photo_cameraImage coming soon 380358 WASHER €1.16
103
 photo_cameraImage coming soon 380360 CLUTCH €6.04
105
 PISTON PIN 331221 PISTON PIN €1.16
106
 Piston for Hammers Hitachi DH38MS-DH40MRY-H41MB 326369 Piston for Hammers Hitachi DH38MS-DH40MRY-H41MB €4.82
107
 CONNECTING ROD ASS'Y 337535 CONNECTING ROD ASS'Y €15.80
108
 photo_cameraImage coming soon 380348 CRANK GEAR €26.78
109
 photo_cameraImage coming soon 380346 NEEDLE BEARING €7.26
110
 photo_cameraImage coming soon 380347 WASHER (A) €1.16
111
 photo_cameraImage coming soon 380376 WEIGHT HOLDER €1.16
112
 photo_cameraImage coming soon 380377 WEIGHT SHAFT €3.60
113
 photo_cameraImage coming soon 307292 O-RING (4PC-5) €0.00 Not available for order
114
 photo_cameraImage coming soon 380378 WEIGHT SPRING €1.16
115
 photo_cameraImage coming soon 380379 WEIGHT €8.48
116
 photo_cameraImage coming soon 380349 SLIP CLUTCH ASSY INCLUDES 35.117-123 €37.76
117
 photo_cameraImage coming soon 380350 BEVEL PINION €7.26
118
 photo_cameraImage coming soon 944109 FEATHER KEY 3X3X8 €2.38
119
 photo_cameraImage coming soon 380351 CLUTCH WASHER €1.16
120
 photo_cameraImage coming soon 380352 SECOND GEAR €12.14
121
 photo_cameraImage coming soon 380353 GEAR HOLDER €12.14
122
 photo_cameraImage coming soon 321282 SPRING (C) €2.38
123
 photo_cameraImage coming soon 380354 SPACER €6.04
124
 photo_cameraImage coming soon 380339 OIL SEAL €1.16
125
 photo_cameraImage coming soon 380338 CRANK CASE €58.50
126
 BREATHER VALVE 995396 BREATHER VALVE €3.60
127
 photo_cameraImage coming soon 339061 CAP SCREW €9.70
128
 photo_cameraImage coming soon 380345 FELT €1.16

Shipping and delivery information will be available shortly.

HIKOKI Cordless Rotary Hammer DA3640DA Spare Parts

Hitachi Koky genuine spare parts or replacement parts for to repair Cordless Rotary Hammer DA3640DA.

In the following table, look for the model of the Cordless Hammer and the respective parts of the code.
Hitachi DA3640DA

HIKOKI Cordless Rotary Hammer DA3640DA Spare Parts
# Part Num. Description
1 381618 SIDE HANDLE ASSY
4 380324 MOUNT
6 380210 SIDE HANDLE
7 380208 HANDLE BAND
8 331247 HANDLE SCREW
9 371151 FRONT COVER
10 318590 RING
11 371138 WASHER
12 381003 RING
13 337559 Retainer Damper (A)
14 380375 BIT LOCK HOLDER
15 380374 THRUST PLATE
16 337556 SPRING
17 371145 SPRING HOLDER (A)
19 380344 CYLINDER COVER
20 967270 RETAINING RING FOR HOLE D52
21 380373 STOPPER WASHER
22 380370 OIL SEAL (B)
23 380369 METAL BUSHING ASSY INCLUDED 22
24 380371 RETAINER DAMPER (B)
25 380372 WASHER
26 331244 O-RING
27 380361 BIT HOLDER
28 370654 BIT LOCK HOLDER
29 313396 O-RING (C)
30 380362 SECOND HAMMER
31 380363 WASHER
32 380364 DAMPER
33 380365 DAMPER HOLDER
34 380367 NEEDLE SLEEVE
35 331217 NEEDLE
36 323073 RING (A)
37 380366 CYLINDER
38 380368 WASHER (B)
39 380355 STRIKER
40 986104 O-RING
41 380337 FAN GUIDE
43 323210 WASHER M4
44 341171 FIELD
45 982631 WASHER
46 608VVM BALL BEARING 608VVM
47 380335 HOUSING
49 333263 DUST SEAL
50 380413 TAIL COVER
52 380414 PANEL HOLDER
54 380757 CONTROLLER SET
56 872767 O-RING S.32
57 6201DD BALL BEARING
58 361229 ROTOR (B)
59 375306 BELLOWS
60 322808 O-RING (C)
61 380388 HANDLE SPRING
62 380389 HANDLE HOLDER
64 338194 WEIGHT BUMPER
66 325910 SUPPORT (B)
67 380415 BACK COVER
68 379349 LABEL (A)(2)
69 380342 SWITCH LEVER
70 380417 STOPPER LEVER
71 380416 LEVER SPRING (B)
72 380888
73 339059 PACKING (A)
74 375321
75 338171 ON LOCK BUTTON
76 370328 BATTERY RUBBER (B)
77 381005 SWITCH
78 317492 SWITCH SUPPORT (B)
79 380652 HANDLE (A+B) SET
80 374772 WASHER
82 379350 LABEL (B)(2)
86 380386 CRANK COVER
87 380645 CHANGE LEVER
88 380646 LOCK CARD (B)
89 380390 LEVER HOLDER
90 380385 SEAL RING
91 338312 O-RING
92 337567 LEVER SPRING
93 370239 STEEL BALL D5
94 380384 HOOK
95 380382 SLIDER
96 380357 CRANK PLATE
97 380381 BALL HOLDER
98 380380 LEVER SHAFT
99 380383 CLUTCH SPRING
101 380358 WASHER
102 380359 BEVEL GEAR
103 380360 CLUTCH
104 380356 LOCK PLATE
105 331221 PISTON PIN
106 326369 PISTON
107 337535 CONNECTING ROD
108 380348 CRANK GEAR
109 380346 NEEDLE BEARING
110 380347 WASHER (A)
111 380376 WEIGHT HOLDER
112 380377 WEIGHT SHAFT
113 307292 O-RING (4PC-5)
114 380378 WEIGHT SPRING
115 380379 WEIGHT
116 380349 SLIP CLUTCH ASSY INCLUDES 35.117-123
117 380350 BEVEL PINION
118 944109 KEY 3X3X8
119 380351 CLUTCH WASHER
120 380352 SECOND GEAR
121 380353 GEAR HOLDER
122 321282 CLUTCH SPRING (C)
123 380354 SPACER
124 380339 OIL SEAL
125 380338 CRANK CASE
126 995396 BREATHER VALVE
127 339061 CAP SCREW
128 380345 FELT
504 380211 INCLUDES 505
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
HIKOKI Hitachi DA3640DA
6 Items

Data sheet

MORE INFO:
[email protected]
SHIPPING IN
Usually Ships in 10/15 BUSINESS DAYS

Specific References

New

Download

HIKOKI DA3640DA Parts Diagram

HIKOKI DA3640DA Parts Diagram

Download (554.74KB)

You might also like

Piston for Hammers Hitachi DH24-26-28PC
HiKOKI Power Tools Italia S.p.a. SKU: 335255
Piston for Hammers Hitachi DH24-26-28PC
Piston for Rotary Hammers Hitachi DH24-26-28PC Genuine replacement part Hitachi Koky, Piston for Rotary Hammers model DH24PC-DH26PC-DH28PCY-DH28PC. Part for the following items: - Hammer DH 24PG - Hammer DH 26PC - Hammer DH 28 PCY -...
AVAILABLE €24.34
Details
Piston for Hammers Hitachi DH38MS-DH40MRY-H41MB
HiKOKI Power Tools Italia S.p.a. SKU: 326369
Piston for Hammers Hitachi DH38MS-DH40MRY-H41MB
Piston for Hammers Hitachi DH38MS-DH40MRY-H41MB Genuine parts Hitachi, Piston for Hitachi Hammers model DH38MS - DH40MRY - H41MB. Part for the following items: - Combined Hammer 9 Joule - 6.4kg DH38MS - Hammer Comb.10.5 Joule - 6.8Kg...
AVAILABLE €4.82
Details
Steel Ball 7 mm for Hammers Hitachi DH24-26-28
HiKOKI Power Tools Italia S.p.a. SKU: 335300
Steel Ball 7 mm for Hammers Hitachi DH24-26-28
Steel Ball 7 mm for Hammers Hitachi DH24-26-28 Hitachi genuine parts, steel ball diameter MM 7, Box 10 Pcs for Demolition hammers and Drills Hammers, DH 24PG - 26PC DH - DH 28PCY - DH28PC. Suitable for the following items: - Drill...
AVAILABLE €3.60
Details
Second Pinion for Hammers Hitachi DH28PC - Drawing
HiKOKI Power Tools Italia S.p.a. SKU: 335278
Second Pinion for Hammers Hitachi DH28PCY
Second Pinion for Hammers Hitachi DH28PCY Genuine parts Hitachi, Second Pinion for Hammers model Electropneumatic Hammer 3.5 Joule - 3.5Kg DH28PCY. For the following items: - Electropneumatic Hammer DH26PC - Electropneumatic Hammer DH...
AVAILABLE €17.02
Details
Pinion Sleeve for Hammers Hitachi DH28PC
HiKOKI Power Tools Italia S.p.a. SKU: 335275
Pinion Sleeve for Hammers Hitachi DH28PCY
Pinion Sleeve for Hammers Hitachi DH28PCY Genuine parts Hitachi, Pinion Sleeve for Hammers model Electropneumatic Hammer 3.5 Joule - 3.5Kg DH28PCY. Part for the following items: - Electropneumatic Hammer DH26PC - Electropneumatic...
AVAILABLE €9.70
Details
Pinion Lock Plate for Hammers Hitachi DH28PC
HiKOKI Power Tools Italia S.p.a. SKU: 335276
Pinion Lock Plate for Hammers Hitachi DH28PCY
Pinion Lock Plate for Hammers Hitachi DH28PCY Genuine parts Hitachi, Pinion Lock Plate for Hammers model Electropneumatic Hammer 3.5 Joule - 3.5Kg DH28PCY For the following items: - Electropneumatic Hammer DH26PC - Electropneumatic...
AVAILABLE €19.46
Details
O-Ring 23X30X3 mm for Demolition Hammers Hitachi DH40MRY-DH38MS
HiKOKI Power Tools Italia S.p.a. SKU: 986104
O-Ring 23X30X3 mm for Demolition Hammers Hitachi DH40MRY-DH38MS
O-Ring 23X30X3 mm for Demolition Hammers Hitachi DH40MRY-DH38MS Genuine part HITACHI, O-Ring 23X30X3 mm for Demolition Hammers Hitachi DH40MRY-DH38MS-DH50MRY-H41MB. Part for the following products: - Demolition Hammer Hitachi...
AVAILABLE €2.38
Details
O-Ring S-32 for Hammers Hitachi H25PV-DH30PC2-DH40MRY-H60MC
HiKOKI Power Tools Italia S.p.a. SKU: 872767
O-Ring S-32 for Hammers Hitachi H25PV-DH30PC2-DH40MRY-H60MC
O-Ring S-32 for Hammers Hitachi H25PV-DH30PC2-DH40MRY-H60MC Hitachi genuine replacement part, O-Ring S-32 for Demolition Hammers H25PV - DH 30 PC2 - DH40MRY - H60MC - H41MB - 60MRV - H45MRY - Nailer Hitachi NV90HMC. Part for the...
AVAILABLE €2.38
Details
Stopper Ring for Hammers Hitachi
HiKOKI Power Tools Italia S.p.a. SKU: 306340
Stopper Ring for Hammers Hitachi
Stopper Ring for Hammers Hitachi Genuine parts Hitachi, Stopper Ring for Hammers Hitachi. For the following items: - Hammer DH 28 PCY - Hammer DH 26PC - Hammer DH 24PG
AVAILABLE €2.38
Details
Front Cap for Rotary Hammers Hitachi DH22/28
HiKOKI Power Tools Italia S.p.a. SKU: 306345
Front Cap for Rotary Hammers Hitachi DH22/28
Front Cap for Rotary Hammers Hitachi DH22/28 Genuine part HITACHI, Front Cap for Rotary Hammers DH22PG - DH24PG - DH26PC - DH28PCY - DH14DSL - DH18DSL - DH25DL - DH25DAL - DH36DL - DH36DAL - DH28PD - DH24PB3 - DH28PC - DH28PFY.
AVAILABLE €3.60
Details
O-Ring S-18 for Rotary Hammers Hitachi DH24PC3-PD3
HiKOKI Power Tools Italia S.p.a. SKU: 878885
O-Ring S-18 for Rotary Hammers Hitachi DH24PC3-PD3
O-Ring S-18 for Rotary Hammers Hitachi DH24PC3-PD3 Hitachi genuine parts, O-Ring S-18 for Rotary Hammers DH24PC3 - DH24PD3 - DH24PB3 - DH24PG - DH24PH - DH36DAL - DH36DL - DH24DVA Part for the following products: - ROTARY HAMMER...
AVAILABLE €1.16
Details
Cylinder Clutch for Rotative Hammer Hitachi DH26PB
HiKOKI Power Tools Italia S.p.a. SKU: 335263
Cylinder Clutch for Rotative Hammer Hitachi DH26PB
Cylinder Clutch for Rotary Hammer Hitachi DH26PB Genuine Spare Part Hitachi, Cylinder Clutch for Rotary Hammers DH26PB - DH18DBL - DH24PG - DH24PH - DH24PB - DH24PC - DH24PBY - DH24PCY - DH24PMY - DH28PMY. Part for the following...
AVAILABLE €18.24
Details
Cylinder for Rotary Hammer Hitachi DH24PG
HiKOKI Power Tools Italia S.p.a. SKU: 335261
Cylinder for Rotary Hammer Hitachi DH24PG
Cylinder for Rotary Hammer Hitachi DH24PG Original spare part Hitachi, Cylinder for Rotary Hammers DH24PG - DH24PH - DH26PB - DH26PC - DH28PBY - DH28PCY - DH18DBL - DH36DBL Part for the follows products: - Rotary Hammer Hitachi...
Usually Ships in: 7/10 Business Days Approx. €30.44
Details
Dust Washer for Demolition Hammer Hitachi H45MRY
HiKOKI Power Tools Italia S.p.a. SKU: 982631
Dust Washer for Demolition Hammer Hitachi H45MRY
Dust Washer for Demolition Hammer Hitachi H45MRY Genuine Spare Part Hitachi, Dust Washer for Demolition Hammers H45MR - H45FRV - H45MRY - H45SR - DH40MRY - H41MB. Part for the following items: - Rotary Hammer Hitachi DH24PG - Rotary...
AVAILABLE €1.16
Details
Oil Seal mm 9,5x16x4 for Rotary Hammer Hitachi DH24PG
HiKOKI Power Tools Italia S.p.a. SKU: 335262
Oil Seal mm 9,5x16x4 for Rotary Hammer Hitachi DH24PG
Oil Seal mm 9,5x16x4 for Rotary Hammer Hitachi DH24PG Original spare part Hitachi, Oil Seal mm 9,5x16x4 for Rotary Hammers DH24PG - DH24PH - DH26PB - DH26PC - DH28PBY - DH28PCY - DH18DBL - DH36DBL Part for the follows products: -...
AVAILABLE €2.38
Details
Retainer Damper (A) for Rotary Hammer Hitachi DH40MEY
HiKOKI Power Tools Italia S.p.a. SKU: 337559
Retainer Damper (A) for Rotary Hammer Hitachi DH40MEY
Retainer Damper (A) for Rotary Hammer Hitachi DH40MEY Genuine part Hitachi HIKOKI, Retainer Damper (A) for Rotary Hammer DH40MEY - Demolition Hammer H41MB2 For the following items: -  Combined Rotary Hammer Hitachi DH40MEY -...
on 7/10 Business Days Approx €1.16
Details
Comments (0)
No customer reviews for the moment.
