HiKOKI Power Tools Italia S.p.a.

Hitachi DV18DMR Spare Parts

SKU: Hitachi DV18DMR
€2.22
VAT included

Hitachi Impact Drill Driver DV18DMR Spare Parts

Hitachi-HIKOKI original spare parts for to make maintenance, replacement of damaged parts or repair electrical or mechanical components of the Cordless Impact Driver Drill DV18DMR.
Hitachi DV18DMR Spare Parts
  • Hitachi DV18DMR Spare Parts
  • Hitachi DV18DMR Spare Parts - Drawing
HiKOKI Power Tools Italia S.p.a.

Hitachi DV18DMR Spare Parts

SKU: Hitachi DV18DMR Condition: New
€2.22
VAT included

Hitachi Impact Drill Driver DV18DMR Spare Parts

Hitachi-HIKOKI original spare parts for to make maintenance, replacement of damaged parts or repair electrical or mechanical components of the Cordless Impact Driver Drill DV18DMR.
settings 51 spare parts
description 2 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
51 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 311959 Sp.Screw (Left Hand) M6x23 €2.10
2
 photo_cameraImage coming soon 752065 Drill Chuck 13vlrl-n (w/o Chuck Wrench) 1/2X20 1.5X13MM €45.02
4
 Front Cap Ass'y for Codless Drill Drivers Hitachi DV14DL - DV18DL 324074 Front Cap Ass'y for Codless Drill Drivers Hitachi DV14DL - DV18DL €18.00
5
 photo_cameraImage coming soon 324136 SWITCH PLATE €2.02
6
 photo_cameraImage coming soon 324064 NUT €2.02
7
 photo_cameraImage coming soon 324135 SPRING €2.02
8
 photo_cameraImage coming soon 324063 THRUST WASHER €2.02
9
 photo_cameraImage coming soon 322972 STOPPER €3.90
10
 photo_cameraImage coming soon 322971 STOPPER SPRING €2.02
11A
 photo_cameraImage coming soon 323231 CLICK SPRING €2.02
12
 photo_cameraImage coming soon 324062 FRONT CASE €46.72
13
 photo_cameraImage coming soon 322975 PIN SET (6 PCS.) €22.77
14
 photo_cameraImage coming soon 324065 WASHER (D) €2.02
15
 photo_cameraImage coming soon 322976 LOCK RING €12.16
16
 photo_cameraImage coming soon 324066 RING GEAR €5.73
17
 photo_cameraImage coming soon 322978 CARRIER €3.68
18
 photo_cameraImage coming soon 324067 PLANET GEAR (C) SET €5.73
19
 photo_cameraImage coming soon 322980 WASHER (A) €2.02
20
 Gears Housing for Cordless Drills Hitachi DV14DL-DV18DL 322981 Gears Housing for Cordless Drills Hitachi DV14DL-DV18DL €6.83
21
 photo_cameraImage coming soon 322990 SHIFT ARM €2.02
23
 photo_cameraImage coming soon 324069 SLIDE RING GEAR €7.34
24
 photo_cameraImage coming soon 324068 PINION (C) €5.48
25
 photo_cameraImage coming soon 324070 PLANET GEAR (B) SET €3.90
26
 photo_cameraImage coming soon 324071 PINION (B) €7.65
27
 photo_cameraImage coming soon 324073 PLANET GEAR (A) SET €3.90
28
 photo_cameraImage coming soon 324072 FIRST RING GEAR €3.90
29
 photo_cameraImage coming soon 322988 WASHER (B) €2.02
30
 photo_cameraImage coming soon 322989 MOTOR SPACER €3.90
31
 Armature for Cordless Drill Hitachi DV18DL 360996 Armature for Cordless Drill Hitachi DV18DL €47.32
32
 Magnet for Codless Drill Drivers Hitachi DV14DL - DV18DL 322996 Magnet for Codless Drill Drivers Hitachi DV14DL - DV18DL €16.60
33
 Carbon Brushes Holder for Cordless Drills Hitachi DV14DL-DV18DL 338733 Carbon Brushes Holder for Cordless Drills Hitachi DV14DL-DV18DL €18.00
34
 Carbon Brushes for Cordless Drill and Grinders Hitachi 999054 Carbon Brushes for Cordless Drill and Grinders Hitachi €9.76
35
 Brushes Cap for Cordless Driver Drill Hitachi DS14DSAL/DS18DSAL 319918 Brushes Cap for Cordless Driver Drill Hitachi DS14DSAL/DS18DSAL €4.32
38
 photo_cameraImage coming soon 322998 HOUSING A+B SET DS18DMR €22.07
40
 photo_cameraImage coming soon 322999 PLATE A -. DS18DMR €3.28
42
 photo_cameraImage coming soon 324137 SHIFT KNOB €3.02
44
 photo_cameraImage coming soon 322997 PUSHING BUTTON €2.03
45
 photo_cameraImage coming soon 333640 SWITCH * EX 322994 €29.92
47
 photo_cameraImage coming soon 996118 HOLDER SPRING €3.28
48
 photo_cameraImage coming soon 322995 TERMINAL €1.59
49
 photo_cameraImage coming soon 320997 TERMINAL PIECE €2.02
50
 photo_cameraImage coming soon 323003 TERMINAL €1.59
51
 photo_cameraImage coming soon 320287 HOOK ASS'Y €6.60
52
 photo_cameraImage coming soon 320288 M5 V-LOCK NUT €2.20
53
 Hook Ass'Y with Ligh for Cordless Drills Hitachi DV14DL-DV18DL 321918 Hook Ass'Y with Ligh for Cordless Drills Hitachi DV14DL-DV18DL €18.00
55
 photo_cameraImage coming soon 306952 STRAP (BLACK) €8.78
56
 photo_cameraImage coming soon 319926 HOOK SPRING €2.20
57
 photo_cameraImage coming soon 320881 SPECIAL SCREW (A) M5 €2.27
502
 photo_cameraImage coming soon 983006 + DRIVER BIT NO.2 65L €13.19
503
 photo_cameraImage coming soon 323001 FOOT €2.39
504
 photo_cameraImage coming soon 323230 HOUSES €63.57
Page 2 local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Pos. Item Price Buy
502
 photo_cameraImage coming soon 983006 + DRIVER BIT NO.2 65L €13.19
503
 photo_cameraImage coming soon 323001 FOOT €2.39
504
 photo_cameraImage coming soon 323230 HOUSES €63.57

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Hitachi Impact Drill Driver DV18DMR Spare Parts

Hitachi-HIKOKI original spare parts for to make maintenance, replacement of damaged parts or repair electrical or mechanical components of the Cordless Impact Driver Drill DV18DMR.

In the following table, look for the model of the Cordells Drill and their spare part.
Hitachi DV18DMR
Hitachi - Hikoki DV18DMR CORDLESS IMPACT DRILL DRIVER 18V Spare Parts Pag.1
# Part Num. Description
1 311959 SPECIAL SCREW M6X23 LEFT Hand
2 752065 Drill Chuck 13vlrl-n (w/o Chuck Wrench) 1/2X20 1.5X13MM
3 324061 Gear Box Ass'y DV14-18DL-DMR
4 324074 FRONT CAP
5 324136 Switch Plate DV14-18DL
6 324064 Nut DV18DMR
7 324135 CLUTCH SPRING DV18DMR
8 324063 THRUST WASHER DV18DMR
9 322972 STOPPER DS/DV/14-18DMR
10 322971 STOPPER RING DS/DV/14-18DMR
11A 323231 CLICK SPRING
12 324062 FRONT CASE   DV14-18DL-DMR
13 322975 PIN SET DS/14-18DMR 6PCS
14 324065 WASHER D - DS/14-18DMR
15 322976 LOCK RING DV18DMR
16 324066 RING GEAR DV18DMR
17 322978 CARRIER DV18DMR
18 324067 PLATE GEAR (C)-5 PCS.-DV18DMR
19 322980 WASHER (A)
20 322981 REAR CASE DS18DL
21 322990 SHIFT ARM
23 324069 SIDE RING GEAR DV14-18DL
24 324068 PINION (C)
25 324070 PLATE GEAR (B) (4PCS)
26 324071 PINION B - DV18DMR
27 324073 PLATE GEAR (A) (4PCS)
28 324072 FIRST RING GEAR DV18DMR
29 322988 WASHER (B) DV18DMR
30 322989 MOTOR SPACER
31 360996 ARMATURE & PINION SET DV18DL *EX 360701
32 322996 MAGNET
33 338733 BRUSH BLOCK DS14-18DL
34 999054 CARBON BRUSHE 5X6X115 (1 PAIR)
35 319918 BRUSH CAP
38 322998 HOUSING A+B SET DS18DMR
40 322999 PLATE A -. DS18DMR
42 324137 SHIFT KNOB
43 323229 FERRITE CORE
44 322997 PUSHING BUTTON
45 333640 DC-SPEED CONTROL SWITCH *EX 322994
47 996118 HOLDER SPRING
48 322995 TERMINAL DS14-18DMR
49 320997 TERMINAL PIECE DS18DMR
50 323003 TERMINAL
51 320287 HOOK ASS'Y
52 320288 V-LOCK NUT M5
53 321918 HOOK ASS'Y WITH LED
55 306952 STRAP BLACK
56 319926 HOOK SPRING
57 320881 SPECIAL SCREW A - M5 WR14DM
STANDARD ACCESSORIES Pag.2
501 CHARGER (MODEL UC 24YFA)
501 CHARGER (MODEL UC 24YJ)
502 983006 + DRIVER BIT NO.2 65L
503 323001 SIDE HANDLE DS18DMR
504 323230 CASE
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s HITACHI websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to HITACHI brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
