HiKOKI Power Tools Italia S.p.a.

Hikoki DH12DD Cordless Rotary Hammer Parts

SKU: Hikoki DH12DD
€4.49
VAT included

Hikoki DH12DD Cordless Rotary Hammer Parts

Hitachi-HIKOKI Original spare parts at the most competitive prices on the web, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for DH12DD Cordless Rotary Hammer.
Hikoki DH12DD Cordless Rotary Hammer Parts
  • Hikoki DH12DD Cordless Rotary Hammer Parts
  • Hikoki DH12DD Cordless Rotary Hammer Parts - Drawing
HiKOKI Power Tools Italia S.p.a.

Hikoki DH12DD Cordless Rotary Hammer Parts

SKU: Hikoki DH12DD Condition: New
€4.49
VAT included

Hikoki DH12DD Cordless Rotary Hammer Parts

Hitachi-HIKOKI Original spare parts at the most competitive prices on the web, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for DH12DD Cordless Rotary Hammer.
settings 55 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 7/10 Business Days Approx

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
55 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 376603 GRIP SET INCLUD.1-3.5-7.19 €4.12
2
 Front Cap for Rotary Hammers Hitachi DH22/28 306345 Front Cap for Rotary Hammers Hitachi DH22/28 €4.18
3
 Stopper Ring for Hammers Hitachi 306340 Stopper Ring for Hammers Hitachi €2.08
4
 photo_cameraImage coming soon 376338 GRIP €1.27
5
 photo_cameraImage coming soon 324528 BALL HOLDER €7.34
6
 photo_cameraImage coming soon 374435 HOLDER PLATE €1.33
7
 photo_cameraImage coming soon 322812 Spring Gate Punta €2.05
9
 photo_cameraImage coming soon 376342 GEAR COVER €17.29
11
 photo_cameraImage coming soon 376334 CHANGE LEVER €1.27
12
 photo_cameraImage coming soon 889495 O-RING (1AP-10) *SEE HTR889495 €1.27
13
 Stopper for Hammers Hitachi DH14DSL 327875 Stopper for Hammers Hitachi DH14DSL €4.04
16
 photo_cameraImage coming soon 944274 washer Dh22pg €2.02
17
 photo_cameraImage coming soon 376743 SPRING (A) €1.27
18
 photo_cameraImage coming soon 376676 SECOND GEAR €9.70
19
 Steel Ball 7 mm for Hammers Hitachi 959156 Steel Ball 7 mm for Hammers Hitachi €3.48
20
 photo_cameraImage coming soon 376335 CYLINDER €19.23
21
 O-RING (B) for Rotary Hammer Hitachi DH20PB 301672 O-RING (B) for Rotary Hammer Hitachi DH20PB €1.13
22
 photo_cameraImage coming soon 376336 SECOND HAMMER €1.77
23
 photo_cameraImage coming soon 311814 O-Ring Dh14/18dl €2.02
24
 photo_cameraImage coming soon 376337 HAMMER HOLDER €1.79
25
 photo_cameraImage coming soon 376673 STOPPER RING €2.21
26
 photo_cameraImage coming soon 376339 DAMPER €1.27
27
 photo_cameraImage coming soon 376340 THRUST WASHER (A) €1.27
28
 photo_cameraImage coming soon 376674 THRUST WASHER (B) €1.27
29
 photo_cameraImage coming soon 376325 STRIKER €3.32
30
 photo_cameraImage coming soon 306326 O-Ring (A) Dh14/18dl €4.74
31
 photo_cameraImage coming soon 376326 PISTON €6.66
32
 photo_cameraImage coming soon 376327 376327 PLATE €1.27
33
 photo_cameraImage coming soon 306976 Spring (B) Dh14/18dl €6.09
35
 photo_cameraImage coming soon 376321 INNER COVER (B) €5.44
36
 photo_cameraImage coming soon 327870 O-Ring Dh22pg €1.51
37
 photo_cameraImage coming soon 376318 FELT PACKING (A) €1.27
38
 photo_cameraImage coming soon 376328 HANDLE PLATE (A) €1.27
39
 photo_cameraImage coming soon 376329 HANDLE PLATE (B) €1.27
41
 photo_cameraImage coming soon 306322 Piston pin Dh14/18dl €6.77
43
 photo_cameraImage coming soon 376322 SECOND SHAFT (A) €6.16
44
 photo_cameraImage coming soon 376593 CLUTCH €4.20
45
 photo_cameraImage coming soon 325585 Bearing Articulated Dh14/18dl €40.66
46
 photo_cameraImage coming soon 306320 Needle Bearing For Dh14/18dl €8.13
47
 photo_cameraImage coming soon 376675 THRUST WASHER (C) €1.27
48
 photo_cameraImage coming soon 376324 BEVEL GEAR €6.48
49
 photo_cameraImage coming soon 377012 INNER COVER ASS'Y (A) €51.37
50
 photo_cameraImage coming soon 626VVM BALL BEARING 626VVC2PS2L €5.14
58
 photo_cameraImage coming soon 376332 DUST WASHER (B) €1.27
59
 photo_cameraImage coming soon 333826 BALL BEARING 625DD €7.39
60
 photo_cameraImage coming soon 324225 PUSHING BUTTON (B) €1.63
61
 photo_cameraImage coming soon 376527 SWDC-SPEED CONTROL SWITCH €23.22
62
 photo_cameraImage coming soon 376703 BATTERY RUBBER €1.27
63
 photo_cameraImage coming soon 376348 HOUSING (A).(B) SET €17.36
64
 photo_cameraImage coming soon 376356 WIRING €113.52
502
 photo_cameraImage coming soon 324548 Lateral grip €17.67
505
 photo_cameraImage coming soon 303709 delimiter Depth €1.75
506
 photo_cameraImage coming soon 376557 INNER TRAY €9.00
507
 photo_cameraImage coming soon 402545 CASE ASS'Y (STACKABLE 2) €64.34
509
 photo_cameraImage coming soon 336473 HANDLE FOR EUROPE.RUS €6.68

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Hikoki DH12DD Cordless Rotary Hammer Parts

Hitachi-HIKOKI Original spare parts at the most competitive prices on the web, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for DH12DD Cordless Rotary Hammer.

In the following table, look for the model of the Rotary Hammer and the respective parts of the code.
Hitachi DH12DD Cordless Rotary Hammer

Hikoki DH12DD Cordless Rotary Hammer Parts
# Part Num. Description
1 376603 GRIP SET
2 306345 FRONT CAP
3 306340 STOPPER RING
4 376338 GRIP
5 324528 BALL HOLDER
6 374435 HOLDER PLATE
7 322812 HOLDER SPRING
9 376342 GEAR COVER
11 376334 CHANGE LEVER
12 889495 O-RING (1AP-10)
13 327875 STOPPER DH14/18DL
15 965469 RETAINING RING FOR D25 SHAFT
16 944274 WASHER
17 376743 SPRING (A)
18 376676 SECOND GEAR
19 959156 STEEL BALLS D7.0 (10PCS)
20 376335 CYLINDER
21 301672 O-RING (B)
22 376336 SECOND HAMMER
23 311814 O-RING (P-15)
24 376337 HAMMER HOLDER
25 376673 STOPPER RING
26 376339 DAMPER
27 376340 THRUST WASHER (A)
28 376674 THRUST WASHER (B)
29 376325 STRIKER
30 306326 O-RING (A)
31 376326 PISTON
32 376327 THRUST PLATE
33 306976 SPRING (B)
35 376321 INNER COVER (B)
36 327870 O-RING (A)
37 376318 FELT PACKING (A)
38 376328 HANDLE PLATE (A)
39 376329 HANDLE PLATE (B)
41 306322 PISTON PIN
42 328660 WASHER
43 376322 SECOND SHAFT (A)
44 376593 CLUTCH
45 325585 RECIPROCATING BEARING
46 306320 NEEDLE CAGE
47 376675 THRUST WASHER (C)
48 376324 BEVEL GEAR
49 377012 INNER COVER ASS'Y (A)
50 626VVM BALL BEARING 626VVC2PS2L
58 376332 DUST WASHER (B)
59 333826 BALL BEARING 625DD
60 324225 PUSHING BUTTON (B)
61 376527 DC-SPEED CONTROL SWITCH
62 376703 BATTERY RUBBER
63 376348 HOUSING (A).(B) SET
64 376356 WIRING
STANDARD ACCESSORIES
502 324548 SIDE HANDLE
505 303709 DEPTH GAUGE
506 376557 INNER TRAY
507 402545 CASE ASS'Y (STACKABLE 2)
508 336472 LATCH
509 336473 HANDLE
510 336474 HINGE

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Hikoki DH12DD
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Hikoki DH12DD Drawing

Hikoki DH12DD Drawing

Download (375.16KB)
