Hitachi Spare Parts for Cordless Circular Saw C18DL
€2.08
VAT included
Hitachi Spare Parts for Cordless Circular Saw C18DL
Hitachi - HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Cordless Circular Saw C18DL
Hitachi Spare Parts for Cordless Circular Saw C18DL
€2.08
VAT included
Hitachi Spare Parts for Cordless Circular Saw C18DL
Hitachi - HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Cordless Circular Saw C18DL
settings
40 spare parts
description
2 exploded views
verified_user
Original Product
Manufacturer warranty included
support_agent
Technical Support
Our team helps you choose
Secure and guaranteed payments
40 spare parts
Page 1
zoom_in View exploded
local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Page 2
local_shipping Usually Ships in: 7/10 BUSINESS DAYS
| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
502
|
photo_cameraImage coming soon | 940543 BOX WRENCH 10MM | €3.15 | |
|
503
|
|
302756 GUIDE | €7.04 | |
|
504
|
photo_cameraImage coming soon | 324579 Case | €81.34 | |
|
601
|
photo_cameraImage coming soon | 324580 Dust Collector Set (a) | €6.98 |
Informazioni sulle spedizioni e consegne saranno disponibili a breve.
Hitachi Spare Parts for Cordless Circular Saw C18DL
Hitachi - HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Cordless Circular Saw C18DLIn the following table, look for the model of the Cordless Circular Saw C18DL and their spare part.
| Cordless Circular Saw C18DL Pag.1 |
||
| # | Part Num. | Description |
| 1 | 998335 | Bolt (left Hand) W/washer M7x17.5 |
| 4 | 990100 | Ring D15.9/i.d14.5 |
| 7 | 308362 | Bearing Cover |
| 8 | 6002VV | Ball Bearing 6002vvcmps2l |
| 9 | 324567 | Protective Cover |
| 10 | 318192 | Bushing |
| 12 | 308361 | Bearing Holder |
| 13 | 324564 | Gear |
| 16 | 310842 | Cushion |
| 17 | 326773 | Hitachi Plate |
| 18A | 331434 | Saw Cover |
| 19 | 317203 | Return Spring |
| 21 | 324577 | Light Cover Ass'y |
| 22 | 317196 | Nylock Bolt (w/flange) M4x12 |
| 23 | 324565 | Inner Cover (b) |
| 24 | 609VVM | Ball Bearing 609vvc2ps2l |
| 25 | 324568 | Lock Lever |
| 26 | 317914 | Special Bolt M5 |
| 27A | 331435 | Inner Cover (a) Ass'y |
| 28 | 324572 | Motor (b) EXCEPT FOR EUROPE (TILL 2.2012) |
| 30 | 319820 | Socket |
| 31 | 315229 | Lamp (12v 5w) |
| 32 | 319823 | Terminal (d) |
| 34A | 334223 | HOUSING. HANDLE COVER SET |
| 37 | 961803 | Spring |
| 38 | 308364 | Wing Bolt (a) M6x15 |
| 39 | 948167 | Super Lock Washer M6 |
| 40 | 324561 | Base Ass'y |
| 41 | 324562 | Knob Bolt |
| 42 | 947859 | Lock Spring |
| 43 | 302469 | Slotted Hd. Set Screw (seal Lock) M6x6 |
| 44 | 314620 | Bolt Ass'y (square) M6x22 |
| 45 | 949425 | Washer M6 (10 Pcs.) |
| 46 | 949750 | Roll Pin D6x50 (10 Pcs.) |
| 49 | 324570 | Resistor |
| 50 | 324573 | Resistor (a) |
| 51 | 959141 | Connector 50092 (10 Pcs.) |
| 52 | 321002 | Internal Wire |
| 53 | 319825 | Switch (1p Screw Type) W/o Lock |
| 54 | 301631 | Spring (f) |
| 55 | 317207 | Terminal (a) |
| 56A | 331433 | Knob |
| 57 | 996118 | Holder Spring |
| 58 | 324574 | Terminal |
| 59 | 320997 | Terminal Piece |
| 60 | 321000 | Terminal |
| STANDARD ACCESSORIES Pag.2 |
||
| 501 | CHARGER (MODEL UC18YRL) | |
| 502 | 940543 | Box Wrench 10mm |
| 503 | 302756 | Guide |
| 504 | 324579 | Case |
| 601 | 324580 | Dust Collector Set (a) |
| 602 | 324581 | Dust Collector Set (a) |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
