HiKOKI Power Tools Italia S.p.a.

Hitachi Spare Parts for Angle Grinder G13SR2

SKU: Hitachi G13SR2
€3.12
VAT included

Hitachi Spare Parts for Angle Grinder G13SR2

Hitachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues fo Angle Grinder G13SR2.
Hitachi Spare Parts for Angle Grinder G13SR2
  • Hitachi Spare Parts for Angle Grinder G13SR2
  • Hitachi Spare Parts for Angle Grinder G13SR2
HiKOKI Power Tools Italia S.p.a.

Hitachi Spare Parts for Angle Grinder G13SR2

SKU: Hitachi G13SR2 Condition: New
€3.12
VAT included

Hitachi Spare Parts for Angle Grinder G13SR2

Hitachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues fo Angle Grinder G13SR2.
settings 38 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 7/10 Business Days Approx

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
38 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
2
 photo_cameraImage coming soon 302149 GUARD PLATE €2.87
3
 Pushing Button for Angle Grinders Hitachi G15VA - G15YF 301944 Pushing Button for Angle Grinders Hitachi G15VA - G15YF €1.52
4
 photo_cameraImage coming soon 314125 GEAR COVER ASS'Y €14.79
5
 photo_cameraImage coming soon 309191 SPECIAL NUT M6 €1.33
8
 photo_cameraImage coming soon 608VVM BALL BEARING 608VVC2PS2L €7.12
9
 photo_cameraImage coming soon 301935 INNER COVER €4.41
11
 photo_cameraImage coming soon 306840 FAN GUIDE €2.33
13
 photo_cameraImage coming soon 340552E STATOR G12SR2-G13SR2 €19.99
14
 photo_cameraImage coming soon 321722 DUST SEAL €2.14
15
 photo_cameraImage coming soon 626VVM BALL BEARING 626VVC2PS2L €5.14
16
 photo_cameraImage coming soon 309929 RUBBER BUSHING €1.32
17
 Pin Retainer for Angle Grinder Hitachi G12 301943 Pin Retainer for Angle Grinder Hitachi G12 €4.19
18
 Retaining Ring for Angle Grinder Hitachi G12 316487 Retaining Ring for Angle Grinder Hitachi G12 €1.89
19
 Wave Washer for Angle Grinder Hitachi G12SR3 316486 Wave Washer for Angle Grinder Hitachi G12SR3 €2.78
23
 photo_cameraImage coming soon 6001VV BALL BEARING 6001VVCMPS2L €8.22
24
 Felt Packing for Angle Grinder Hitachi G12SN 301946 Felt Packing for Angle Grinder Hitachi G12SN €1.34
25
 photo_cameraImage coming soon 301947 BEARING HOUSING €4.12
27
 photo_cameraImage coming soon 302047 WOODRUFF KEY €1.30
31
 photo_cameraImage coming soon 319116 WHEEL GUARD ASS'Y €25.64
32
 photo_cameraImage coming soon 376067 WHEEL WASHER €6.66
34
 photo_cameraImage coming soon 339579 CLAMP WASHER €7.20
36
 photo_cameraImage coming soon 314429 SPRING €1.32
37
 Slide Bar for Angle Grinders Hitachi G12SS - SG 314427 Slide Bar for Angle Grinders Hitachi G12SS - SG €2.08
38
 Slide Knob for Angle Grinders Hitachi G12SA2 - G12SG 314428 Slide Knob for Angle Grinders Hitachi G12SA2 - G12SG €1.66
39
 photo_cameraImage coming soon 321721 HOUSING ASS'Y G12SR2-G13SR2 €17.83
43
 Noise Suppressor for Angle Grinder Hitachi G12SA2 994273 Noise Suppressor for Angle Grinder Hitachi G12SA2 €9.62
44
 photo_cameraImage coming soon 314432 SWITCH HOLDER €2.68
45
 photo_cameraImage coming soon 938307 PILLAR TERMINAL (OLD 938307Z / 512-31) €2.60
47
 Brush Cap for Angle Grinders Hitachi G12SS - G12SG 936551 Brush Cap for Angle Grinders Hitachi G12SS - G12SG €1.80
48
 Carbon Brushes for Grinder Hitachi G12SS 999021 Carbon Brushes for Grinder Hitachi G12SS €9.62
49
 Brush Holder for Angle Grinders Hitachi G12SS - SG 313777 Brush Holder for Angle Grinders Hitachi G12SS - SG €3.48
50
 Switch for Angle Grinders Hitachi 115 mm G12SN 314603 Switch for Angle Grinders Hitachi 115 mm G12SN €21.20
53
 photo_cameraImage coming soon 937631 CORD CLIP €1.37
55
 Cord Armor D.8.8 for Hitachi Power Tools 953327 Cord Armor D.8.8 for Hitachi Power Tools €1.37
56
 photo_cameraImage coming soon 321726 TAIL COVER G12SR2-G13SR2 €8.23
58
 photo_cameraImage coming soon 714500 POWER CABLE €15.65
501
 photo_cameraImage coming soon 938332Z WRENCH €6.52
502
 photo_cameraImage coming soon 711283 SIDE SEALING M10 €14.02

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Hitachi Spare Parts for Angle Grinder G13SR2

Hitachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues fo Angle Grinder G13SR2.

In the following table , look for the model of the grinder and the ripettivo spare part.
Hitachi G13SR2

Disc Grinder G13SR2
# Part Num. Description
2 302149 GUARD PLATE
3 301944 PUSHING BUTTON WITH SPRING G13SB3
4 314125 GEAR COVER ASS'Y
5 309191 SPECIAL NUT M6
6 321742 PINION
8 608VVM BALL BEARING 608VVM
9 301935 INNER COVER
10 360605E ARMATURE G12SR2-G13SR2
11 306840 FAN GUIDE
12 963712 STATOR SCREW D4X65
13 340552E STATOR G12SR2-G13SR2
14 321722 DUST SEAL
15 626VVM BALL BEARING 626VVM
16 309929 RUBBER BUSHING
17 301943 LOCK PIN
18 316487 RETAINING RING FOR D11 SHAFT
19 316486 WAVE WASHER
20 321743 GEAR
22 938058 BEARING COVER (B)
23 6001VV BALL BEARING 6001VV
24 301946 FELT PACKING
25 301947 PACKING GLAND
27 302047 WOODRUFF KEY
28 321729 SPINDLE M14
30 301949 SET PLATE
31 319116 WHEEL GUARD ASS'Y
32 376067 WHEEL WASHER
34 339579 WHEEL WASHER M14
35 321741 GEAR AND PINION ASS'Y G13SR2
36 314429 SPRING
37 314427 SLIDE BAR
38 314428 SLIDE KNOB
39 321721 HOUSING ASS'Y G12SR2-G13SR2
41 314854 EARTH TERMINAL
42 980063 TERMINAL
43 994273 NOISE SUPPRESSOR
44 314432 SWITCH HOLDER
45 938307 PILLAR TERMINAL (OLD 938307Z / 512-31
47 936551 BRUSH CAP
48 999021 CARBON BRUSHE (1 PAIR)
49 313777 BRUSH HOLDER
50 314603 SWITCH (1P SOLDER TYPE)
52 980063 TERMINAL
53 937631 CORD CLIP
55 953327 CORD ARMOR D8.8
56 321726 TAIL COVER G12SR2-G13SR2
58 714500 CORD 5M 2 X 1.0 WITH PLUG
STANDARD ACCESSORIES
501 938332Z WRENCH
502 711283 SIDE HANDLE M10

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.

Hitachi G13SR2
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Drawing Hitachi G13SR2

Drawing Hitachi G13SR2

Download (218.29KB)
