HiKOKI Power Tools Italia S.p.a.

Hitachi Spare Parts for Portable Cut-Off Machine CM9SR

SKU: Hitachi CM9SR
€40.34
VAT included

Hitachi Spare Parts for Portable Cut-Off Machine CM9SR

We are Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Portable Cut-Off Machine CM9SR
Hitachi Spare Parts for Portable Cut-Off Machine CM9SR
  • Hitachi Spare Parts for Portable Cut-Off Machine CM9SR
  • Hitachi Spare Parts for Portable Cut-Off Machine CM9SR
HiKOKI Power Tools Italia S.p.a.

Hitachi Spare Parts for Portable Cut-Off Machine CM9SR

SKU: Hitachi CM9SR Condition: New
€40.34
VAT included

Hitachi Spare Parts for Portable Cut-Off Machine CM9SR

We are Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Portable Cut-Off Machine CM9SR
settings 83 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
62 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
Pos. Item Price Buy
3
 Pushing Button for Angle Grinders Hitachi G23 306888 Pushing Button for Angle Grinders Hitachi G23 €0.83
4
 Button Spring for Angle Grinders Hitachi G23 320219 Button Spring for Angle Grinders Hitachi G23 €3.19
5
 photo_cameraImage coming soon 320218 0-RING €2.67
6
 Lock Pin for Angle Grinder Hitachi G23SS 306890 Lock Pin for Angle Grinder Hitachi G23SS €2.96
7
 Retaining Ring 12 mm for Hitachi Power Tools 939542 Retaining Ring 12 mm for Hitachi Power Tools €3.13
10
 Bearing Cover (B) for Angle Grinder Hitachi G23SS 320229 Bearing Cover (B) for Angle Grinder Hitachi G23SS €3.71
11
 Ball Bearing Hitachi 6302VV 6302VV Ball Bearing Hitachi 6302VV €9.62
12
 photo_cameraImage coming soon 990852 FELT PACKING (B) €2.64
13
 photo_cameraImage coming soon 320234 SPINDLE €18.12
14
 Packing Gland Gasket for Angle Grinder Hitachi G23SS 320228 Packing Gland Gasket for Angle Grinder Hitachi G23SS €3.33
15
 Packing Gland for Angle Grinder Hitachi G23SS 320227 Packing Gland for Angle Grinder Hitachi G23SS €16.00
17
 Gear an Pinion for Grinder Hitachi G23SS 330032 Gear an Pinion for Grinder Hitachi G23SS €34.89
18
 photo_cameraImage coming soon 994208 RUBBER RING (B) €1.34
19
 photo_cameraImage coming soon 320220 BEARING COVER (A) €5.81
20
 Armature for Grinder Hitachi 230 mm G23SR-SRU 360762E Armature for Grinder Hitachi 230 mm G23SR-SRU €75.00
21
 photo_cameraImage coming soon 320215 FAN GUIDE €2.67
23A
 photo_cameraImage coming soon 340664H Stator CM9SR €57.93
24
 photo_cameraImage coming soon 958032 BRUSH TERMINAL €1.34
27
 photo_cameraImage coming soon 320217 GEAR COVER ASS'Y €23.07
28
 photo_cameraImage coming soon 320226 SPECIAL NUT M10 €3.19
30
 photo_cameraImage coming soon 320221 SEAL WASHER €2.67
31
 photo_cameraImage coming soon 320222 FELT PACKING €2.67
32
 photo_cameraImage coming soon 6301VV BALL BEARING 6301VVCMPS2L €12.55
33
 photo_cameraImage coming soon 328754 HOSE BAND €2.93
34
 photo_cameraImage coming soon 328748 DUST DUCT €16.92
35
 photo_cameraImage coming soon 328752 COVER (B) €7.92
37
 photo_cameraImage coming soon 997467 KNOB NUT €5.53
38
 photo_cameraImage coming soon 328758 ADATT.Intake CM9SR €2.93
39
 photo_cameraImage coming soon 328761 O-RING CM9SR €2.93
42
 photo_cameraImage coming soon 328759 ADAPTER (A) €2.93
43
 photo_cameraImage coming soon 328760 ADAPTER (B) €2.93
44
 photo_cameraImage coming soon 324865 DUST CAP €8.03
46
 photo_cameraImage coming soon 885414 HOLDER SLEEVE (B) €2.32
48
 photo_cameraImage coming soon 314622 WING NUT M6 €5.03
52
 photo_cameraImage coming soon 321545 LEVER €3.04
53
 photo_cameraImage coming soon 306887 BOLT M8X22 €1.73
55
 photo_cameraImage coming soon 321544 SET PIECE €2.00
56
 photo_cameraImage coming soon 328745 WHEEL GUARD ASS'Y €24.52
58A
 Wheel Washer for Angle Grinder Hitachi G23SS 937907Z Wheel Washer for Angle Grinder Hitachi G23SS €12.42
59
 Wheel Nut for Angle Grinder Hitachi G23SS 937909Z Wheel Nut for Angle Grinder Hitachi G23SS €17.44
60
 photo_cameraImage coming soon 328749 COVER (A) €7.03
61
 photo_cameraImage coming soon 328750 ATTACCO REGOLAB.CM9SR €7.53
62
 photo_cameraImage coming soon 314429 SPRING €1.32
63
 photo_cameraImage coming soon 328751 POCKET GUIDE €4.03
65
 photo_cameraImage coming soon 328755 GOMMINO CM9SR €2.93
66
 photo_cameraImage coming soon 328756 ROLLER SHAFT €3.92
68
 photo_cameraImage coming soon 328747 BASE CM9SR €27.02
69
 photo_cameraImage coming soon 320216 DUST SEAL €2.67
70
 photo_cameraImage coming soon 6000VV BALL BEARING 6000VVCMPS2L €9.76
71
 Bearing Bush for Angle Grinder Hitachi G23SR 321536 Bearing Bush for Angle Grinder Hitachi G23SR €16.60
72
 photo_cameraImage coming soon 325640 HOUSING ASS'Y €66.07
74
 photo_cameraImage coming soon 325642 HANDLE (A) €11.59
77
 Brushe Cap for Routers Hitachi M12SA-M12V G 940540 Brushe Cap for Routers Hitachi M12SA-M12V G €1.78
78
 Carbon Brushe Set for Hitachi Wall Chasers CM7R - CM9SR 999044 Carbon Brushe Set for Hitachi Wall Chasers CM7R - CM9SR €10.04
78
 Carbon Brushes for Angle Grinder Hitachi G23SF - G23SR 999074 Carbon Brushes for Angle Grinder Hitachi G23SF - G23SR €15.05
79
 photo_cameraImage coming soon 980487 BRUSH HOLDER €9.92
81
 Switch for Angle Grinders Hitachi 230 mm 320238 Switch for Angle Grinders Hitachi 230 mm €46.06
81
 Switch for Angle Grinders Hitachi G-23SR G 23SS 320239 Switch for Angle Grinders Hitachi G-23SR G 23SS €31.82
82
 photo_cameraImage coming soon 960266 CORD CLIP €1.37
84
 photo_cameraImage coming soon 325641 HANDLE (B) €12.75
85
 photo_cameraImage coming soon 981373 TUBE (D) €1.37
86
 photo_cameraImage coming soon 940778 CORD ARMOR D10.7 €3.43

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Hitachi Spare Parts for Portable Cut-Off Machine CM9SR

We are Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Portable Cut-Off Machine CM9SR

In the following table, look for the model of the Miter Saw and theirs spare part.
Hitachi CM9SR

Portable Cut-Off Machine CM9SR
1 985597 BOLT M14
2 322141 PIPE HANDLE
3 306888 PUSHING BUTTON
4 320219 SPRING
5 320218 O-RING
6 306890 LOCK PIN
7 939542 RETAINING RING FOR D12 SHAFT
9 949236 MACHINE SCREW M5X10
10 320229 BEARING COVER (B)
11 6302VV BALL BEARING 6302VVCMPS2L
12 990852 FELT PACKING (B)
13 320234 SPINDLE
14 320228 SEAL PLATE
15 320227 PACKING GLAND
16 994192 HEX. SOCKET HD. BOLT (W/FLANGE) M5X16
17 330032 GEAR AND PINION SET
18 994208 RUBBER RING (B)
19 320220 BEARING COVER (A)
20 360762E ARMATURE 220V-240V
21 320215 FAN GUIDE
22 961501 HEX. HD. TAPPING SCREW D5X60
23A 340664H STATOR 220V-230V
24 958032 BRUSH TERMINAL
25 984509 SEAL LOCK HEX. SOCKET HD. BOLT M5X14
26 323209 TAPPING SCREW (W/FLANGE) D5X35 (BLACK)
27 320217 GEAR COVER ASS'Y
28 320226 SPECIAL NUT M10
30 320221 SEAL WASHER
31 320222 FELT PACKING
32 6301VV BALL BEARING 6301VVCMPS2L
33 328754 HOSE BAND
34 328748 DUST DUCT
35 328752 COVER (B)
37 997467 KNOB NUT
38 328758 ADAPTER
39 328761 RING
40 305720 TAPPING SCREW (W/FLANGE) D4X12
41 324877 BOLT (SQUARE) M6X57
42 328759 ADAPTER (A)
43 328760 ADAPTER (B)
44 324865 DUST CAP
46 885414 HOLDER SLEEVE (B)
47 328841 SLEEVE
48 314622 WING NUT M6
49 311492 LABEL
50 673489 RETAINING RING (E-TYPE) FOR D5 SHAFT
51 321546 SET PIN
52 321545 LEVER
53 306887 BOLT M8X22
54 949457 SPRING WASHER M8
55 321544 SET PIECE
56 328745 WHEEL GUARD ASS'Y
57 328843 BOLT (A)
58A 937907Z WHEEL WASHER (C)
59 937909Z WHEEL NUT M14X2
60 328749 COVER (A)
61 328750 HOLDER
62 314429 SPRING
63 328751 POCKET GUIDE
64 974577 RETAINING RING (E-TYPE) FOR D7 SHAFT
65 328755 ROLLER
66 328756 ROLLER SHAFT
67 328757 BOLT (SQUARE) M5
68 328747 BASE
69 320216 DUST SEAL
70 6000VV BALL BEARING 6000VVCMPS2L
71 321536 BEARING BUSHING
72 325640 HOUSING ASS'Y
74 325642 HANDLE (A)
75 305812 TAPPING SCREW (W/FLANGE) D4X16 (BLACK)
77 940540 BRUSH CAP
78 999044 CARBON BRUSH (1 PAIR)
78 999074 CARBON BRUSH (AUTO STOP TYPE) (1 PAIR)
78 999044 CARBON BRUSH (1 PAIR)
79 980487 BRUSH HOLDER
80 938477 HEX. SOCKET SET SCREW M5X8
81 320239 SWITCH (2P PILLAR TYPE) W/SAFETY LOCK
81 320238 SWITCH (2P PILLAR TYPE) W/SAFETY LOCK
82 960266 CORD CLIP
83 984750 TAPPING SCREW (W/FLANGE) D4X16
84 325641 HANDLE (B)
85 981373 TUBE (D)
86 940778 CORD ARMOR D10.7
93 944950 U-NUT (B) M8

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Hitachi CM9SR
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Diagram Hitachi CM9SR

Diagram Hitachi CM9SR

Download (1.41MB)
