Hitachi Spare Parts for Demolition Hammer DH52MEY

SKU: Hitachi DH52MEY
€19.79
VAT included

Hitachi Spare Parts for Demolition Hammer DH52MEY

Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Demolition Hammer DH52MEY.
Hitachi Spare Parts for Demolition Hammer DH52MEY
  • Hitachi Spare Parts for Demolition Hammer DH52MEY
  • Hitachi Spare Parts for Demolition Hammer DH52MEY
HiKOKI Power Tools Italia S.p.a.

Hitachi Spare Parts for Demolition Hammer DH52MEY

SKU: Hitachi DH52MEY Condition: New
€19.79
VAT included

Hitachi Spare Parts for Demolition Hammer DH52MEY

Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Demolition Hammer DH52MEY.
settings 118 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
118 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 337562 FRONT CAP €3.88
2
 photo_cameraImage coming soon 318590 STOPPER RING €2.27
3
 photo_cameraImage coming soon 338155 RETAINER WASHER €6.38
4
 photo_cameraImage coming soon 339053 RETAINER DAMPER (A) €11.01
5
 photo_cameraImage coming soon 338154 GRIP €2.25
6
 photo_cameraImage coming soon 338153 BIT LOCK HOLDER €16.51
7
 photo_cameraImage coming soon 339051 THRUST PLATE €8.68
8
 photo_cameraImage coming soon 339052 RETAINER SPRING €2.11
9
 photo_cameraImage coming soon 337557 SPRING HOLDER (A) €1.65
10
 photo_cameraImage coming soon 872470 O-RING (S-26) €2.09
11
 photo_cameraImage coming soon 338198 CYLINDER CASE COVER €16.15
13
 photo_cameraImage coming soon 318582 RETAINING RING D40 €6.24
14
 photo_cameraImage coming soon 338200 RETAINING RING D68 €5.53
15
 photo_cameraImage coming soon 339063 BALL BEARING 6008DDU €16.98
16
 photo_cameraImage coming soon 338201 BEARING WASHER €1.40
17
 photo_cameraImage coming soon 318588 OIL SEAL (NBR710) €8.26
18
 photo_cameraImage coming soon 338199 CYLINDER CASE €17.47
21
 photo_cameraImage coming soon 338204 RETAINER DAMPER HOLDER €6.22
22
 photo_cameraImage coming soon 338203 RETAINER DAMPER (B) €4.68
24
 photo_cameraImage coming soon 338202 RETAINER DAMPER WASHER €6.11
25A
 photo_cameraImage coming soon 370654 BIT LOCK €7.01
26
 photo_cameraImage coming soon 338205 RETAINER SLEEVE €36.34
27
 photo_cameraImage coming soon 338210 NEEDLE PIN D8 €2.11
28
 O-Ring 23X30X3 mm for Demolition Hammers Hitachi DH40MRY-DH38MS 986104 O-Ring 23X30X3 mm for Demolition Hammers Hitachi DH40MRY-DH38MS €2.08
29
 photo_cameraImage coming soon 338206 SECOND HAMMER €22.38
30
 photo_cameraImage coming soon 338207 DAMPER WASHER €7.56
31
 photo_cameraImage coming soon 328887 DAMPER €5.41
32
 photo_cameraImage coming soon 338208 DAMPER HOLDER €10.91
33
 photo_cameraImage coming soon 338209 CYLINDER €36.01
34
 photo_cameraImage coming soon 338214 STRIKER €13.82
35
 photo_cameraImage coming soon 328880 O-RING €7.45
36
 photo_cameraImage coming soon 338211 SPRING HOLDER (B) €17.04
37
 photo_cameraImage coming soon 338216 LOCK SPRING WASHER €1.29
38
 photo_cameraImage coming soon 338217 LOCK SPRING €1.57
39
 photo_cameraImage coming soon 338215 LOCK SLEEVE €1.32
40
 photo_cameraImage coming soon 338212 CLUTCH SPRING €1.57
41
 photo_cameraImage coming soon 338213 CLUTCH €30.77
43
 photo_cameraImage coming soon 338235 SLIDER €3.80
44
 photo_cameraImage coming soon 338219 METAL (A) €12.11
46
 photo_cameraImage coming soon 338221 BEVEL GEAR €15.70
47
 photo_cameraImage coming soon 328880 O-RING €7.45
49
 photo_cameraImage coming soon 328877 PISTON €10.84
50
 Connecting Rod for Rotary Hammers Hitachi DH50MRY 328878 Connecting Rod for Rotary Hammers Hitachi DH50MRY €9.62 Not available for order
51
 photo_cameraImage coming soon 944954 BEARING WASHER €1.30
52
 photo_cameraImage coming soon 6201VV BALL BEARING 6201VVCMPS2L €6.76
54
 photo_cameraImage coming soon 340899 STATOR SENSOR PCB SET 220V-240V €53.30
55
 photo_cameraImage coming soon 338168 HOUSING €29.40
56
 photo_cameraImage coming soon 333225 DUST SEAL €1.29
58
 photo_cameraImage coming soon 338170 TAIL COVER €3.13
60
 photo_cameraImage coming soon 6202DD Ball Bearing 6202dd €7.97
61
 photo_cameraImage coming soon 980700 DUST WASHER (B) €1.24
62
 photo_cameraImage coming soon 360992 ROTOR €166.98
63
 Controller Ass'y 220-240V for Demolition Hammer Hitachi DH52MEY 338189 Controller Ass'y 220-240V for Demolition Hammer Hitachi DH52MEY €115.18
64
 photo_cameraImage coming soon 339056 RUBBER SHEET (C) €2.56
66
 photo_cameraImage coming soon 339057 RUBBER SHEET (D) €1.74
67
 photo_cameraImage coming soon 338184 PANEL ASS'Y €19.04
69
 photo_cameraImage coming soon 991711 DISTANCE PIECE (B) €1.33
70
 photo_cameraImage coming soon 338173 HANDLE (A) €7.38
71
 Filter PCB Ass'y for Rotary Hammer DH45ME 338181 Filter PCB Ass'y for Rotary Hammer DH45ME €25.00
72
 Transatory Unit for Demolition Hammer Hitachi H45SA 310123 Transatory Unit for Demolition Hammer Hitachi H45SA €16.13
73
 Damper for Demolition Hammers H60MRV-H45MR-H45MRY 310124 Damper for Demolition Hammers H60MRV-H45MR-H45MRY €5.77
75
 photo_cameraImage coming soon 338176 BELLOWS €6.78
76
 photo_cameraImage coming soon 337588 TRIGGER €1.25
77
 photo_cameraImage coming soon 337587 SWITCH €18.75
78
 photo_cameraImage coming soon 338174 HANDLE (B) €7.38
80
 photo_cameraImage coming soon 339058 FILTER PACKING €1.32
82
 photo_cameraImage coming soon 940778 CORD ARMOR D10.7 €3.43
83
 photo_cameraImage coming soon 960266 CORD CLIP €1.37
87
 photo_cameraImage coming soon 338197 BACK COVER €8.25
90
 photo_cameraImage coming soon 338171 ON LOCK BUTTON €1.33
92
 photo_cameraImage coming soon 338185 ON LOCK PCB (A) ASS'Y €11.41
94
 photo_cameraImage coming soon 330209 SIDE HANDLE €20.87
95
 photo_cameraImage coming soon 337577 WING BOLT €1.32
96
 photo_cameraImage coming soon 949859 ROLL PIN D2X8 (10 PCS.) €1.90
97
 photo_cameraImage coming soon 338239 MOUNT €4.85
99
 photo_cameraImage coming soon 333227 HANDLE BOLT €21.70
100
 photo_cameraImage coming soon 338238 BAND €6.77
101
 Retaining Ring 12 mm for Hitachi Power Tools 939542 Retaining Ring 12 mm for Hitachi Power Tools €3.13
102
 photo_cameraImage coming soon 338224 CRANK SHAFT €21.68
103
 photo_cameraImage coming soon 328869 FEATHER KEY 3X3X25 €2.70
104
 photo_cameraImage coming soon 948227 RETAINING RING FOR D47 HOLE €1.65
105
 photo_cameraImage coming soon 6204DD BALL BEARING 6204DDCMPS2L €11.52
107
 photo_cameraImage coming soon 949859 ROLL PIN D2X8 (10 PCS.) €1.90
108
 photo_cameraImage coming soon 339112 WEIGHT DAMPER €2.56
109
 photo_cameraImage coming soon 339067 WEIGHT ASS'Y €37.41
111
 photo_cameraImage coming soon 338179 ON LOCK PCB (B) €9.63
112
 photo_cameraImage coming soon 338192 WEIGHT PIN €4.40
115
 photo_cameraImage coming soon 328906 SPRING HOLDER €10.16
116
 photo_cameraImage coming soon 338190 ANTIVIBRATION Ø40X30 MF M8X25 65SH €11.76
120
 photo_cameraImage coming soon 338237 CRANK COVER €4.85
122
 photo_cameraImage coming soon 338159 CHANGE LEVER €2.62
124
 photo_cameraImage coming soon 959149 STEEL BALL D4.76 €1.28
125
 O-Ring S-18 for Rotary Hammers Hitachi DH24PC3-PD3 878885 O-Ring S-18 for Rotary Hammers Hitachi DH24PC3-PD3 €1.34
126
 photo_cameraImage coming soon 338236 LEVER SHAFT HOLDER €10.74
127
 photo_cameraImage coming soon 939547 RETAINING RING FOR D20 SHAFT €5.65
128
 O-RING (A) mm 76x2,3 for Rotary Hammer Hitachi DH52MEY 338160 O-RING (A) mm 76x2,3 for Rotary Hammer Hitachi DH52MEY €1.23
132
 photo_cameraImage coming soon 339061 CAP SCREW €9.17
133
 photo_cameraImage coming soon 995396 BREATHER VALVE €2.99
134
 Oil Seal mm 25x35x6 for Rotary Hammers Hitachi 328867 Oil Seal mm 25x35x6 for Rotary Hammers Hitachi €6.26
135
 photo_cameraImage coming soon 338223 CRANK CASE €32.16
136
 photo_cameraImage coming soon 338242 SLIP CLUTCH ASS'Y €50.69
137
 photo_cameraImage coming soon 338229 BEVEL PINION €8.89
138
 photo_cameraImage coming soon 944109 FEATHER KEY 3X3X8 €2.99
139
 photo_cameraImage coming soon 338230 COLLAR €1.43
140
 photo_cameraImage coming soon 6202DD Ball Bearing 6202dd €7.97
141
 photo_cameraImage coming soon 313058 WASHER €1.34
142
 photo_cameraImage coming soon 338231 WASHER (A) €2.52
143
 photo_cameraImage coming soon 318554 GEAR HOLDER €11.58
144
 Needle Pin 6x6 mm for Demolition Hammers Hitachi DH40/50MRY-DH45MR 313057 Needle Pin 6x6 mm for Demolition Hammers Hitachi DH40/50MRY-DH45MR €5.52
145
 photo_cameraImage coming soon 329095 SPRING (C) €2.70
146
 photo_cameraImage coming soon 338232 SECOND GEAR €11.84
147
 photo_cameraImage coming soon 338233 SPACER €14.44
148
 photo_cameraImage coming soon 629VVM BALL BEARING 629VVC2PS2L €7.32
149
 photo_cameraImage coming soon 338225 FIRST GEAR €10.79
150
 photo_cameraImage coming soon 338226 SECOND PINION €6.50
151
 photo_cameraImage coming soon 629VVM BALL BEARING 629VVC2PS2L €7.32
152
 Bearing Washer (C) for Hammer Hitachi DH40MA 944525 Bearing Washer (C) for Hammer Hitachi DH40MA €1.26
155
 photo_cameraImage coming soon 338241 GEAR COVER €16.22
501
 photo_cameraImage coming soon 981840 GREASE 30 GR €10.98
502
 photo_cameraImage coming soon 339066 CASE €122.47
601
 photo_cameraImage coming soon 308471 GREASE 70 GR €19.79
602
 photo_cameraImage coming soon 980927 GREASE 500 GR €84.44

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Hitachi Spare Parts for Demolition Hammer DH52MEY

Hitachi-HIKOKI Tanaka

 authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Demolition Hammer DH52MEY.

In the following table, look for the model of the Demolition Hammer and the respective parts of the code.
Hitachi DH52MEY

Demolition Hammer DH52MEY
# Part Num. Description
1 337562 FRONT CAP
2 318590 STOPPER RING
3 338155 RETAINER WASHER
4 339053 RETAINER DAMPER (A)
5 338154 GRIP
6 338153 BIT LOCK HOLDER
7 339051 THRUST PLATE
8 339052 RETAINER SPRING
9 337557 SPRING HOLDER (A)
10 872470 O-RING (S-26)
11 338198 CYLINDER CASE COVER
13 318582 RETAINING RING D40
14 338200 RETAINING RING D68
15 339063 BALL BEARING 6008DDU
16 338201 BEARING WASHER
17 318588 OIL SEAL (NBR710)
18 338199 CYLINDER CASE
20 338222 O-RING (C)
21 338204 RETAINER DAMPER HOLDER
22 338203 RETAINER DAMPER (B)
23 339064 DAMPER SLEEVE
24 338202 RETAINER DAMPER WASHER
25A 370654 BIT LOCK
26 338205 RETAINER SLEEVE
27 338210 NEEDLE PIN D8
28 986104 O-RING
29 338206 SECOND HAMMER
30 338207 DAMPER WASHER
31 328887 DAMPER
32 338208 DAMPER HOLDER
33 338209 CYLINDER
34 338214 STRIKER
35 328880 O-RING
36 338211 SPRING HOLDER (B)
37 338216 LOCK SPRING WASHER
38 338217 LOCK SPRING
39 338215 LOCK SLEEVE
40 338212 CLUTCH SPRING
41 338213 CLUTCH
42 338218 SLEEVE
43 338235 SLIDER
44 338219 METAL (A)
45 338220 METAL WASHER
46 338221 BEVEL GEAR
47 328880 O-RING
49 328877 PISTON
50 328878 CONNECTING ROD
51 944954 BEARING WASHER
52 6201VV BALL BEARING 6201VV
54 340899 STATOR SENSOR PCB SET 220V-240V
55 338168 HOUSING
56 333225 DUST SEAL
57 339065 PACKING (B)
58 338170 TAIL COVER
60 6202DD BALL BEARING 6202DD
61 980700 DUST WASHER (B)
62 360992 ROTOR
63 338189 CONTROLLER ASS'Y 220V-240V
64 339056 RUBBER SHEET (C)
65 339055 RUBBER SHEET (A)
66 339057 RUBBER SHEET (D)
67 338184 PANEL ASS'Y
69 991711 DISTANCE PIECE (B)
70 338173 HANDLE (A)
71 338181 FILTER PCB ASS'Y 220V-240V
72 310123 TRANSATORY UNIT
73 310124 HANDLE DAMPER
74 338162 HANDLE DAMPER HOLDER
75 338176 BELLOWS
76 337588 TRIGGER
77 337587 SWITCH
78 338174 HANDLE (B)
80 339058 FILTER PACKING
82 940778 CORD ARMOR D10.7
83 960266 CORD CLIP
86 338175 HANDLE SHAFT
87 338197 BACK COVER
90 338171 ON LOCK BUTTON
91 338172 ON LOCK SPRING
92 338185 ON LOCK PCB (A) ASS'Y
93 339059 PACKING (A)
94 330209 SIDE HANDLE
95 337577 WING BOLT
96 949859 ROLL PIN D2X8
97 338239 MOUNT
98 949556 NUT M6
99 333227 HANDLE BOLT
100 338238 BAND
101 939542 RETAINING RING FOR D12 SHAFT
102 338224 CRANK SHAFT
103 328869 FEATHER KEY 3X3X25
104 948227 RETAINING RING FOR D47 HOLE
105 6204DD BALL BEARING 6204DD
106 338227 O-RING (F)
107 949859 ROLL PIN D2X8
108 339112 WEIGHT DAMPER
109 339067 WEIGHT ASS'Y
110 338191 WASHER
111 338179 ON LOCK PCB (B)
112 338192 WEIGHT PIN
114 338187 LEAF SPRING (B)
115 328906 SPRING HOLDER
116 338190 BASE
117 338194 WEIGHT BUMPER
119 339050 FELT PACKING (D)
120 338237 CRANK COVER
122 338159 CHANGE LEVER
123 337567 LEVER SPRING
124 959149 STEEL BALL D4.76
125 878885 O-RING (S-18)
126 338236 LEVER SHAFT HOLDER
127 939547 RETAINING RING FOR D20 SHAFT
128 338160 O-RING (A)
129 338234 CHANGE PLATE
131 339062 FELT PACKING (C)
132 339061 CAP SCREW
133 995396 VALVE
134 328867 OIL SEAL
135 338223 CRANK CASE
136 338242 SLIP CLUTCH ASS'Y
137 338229 BEVEL PINION
138 944109 FEATHER KEY 3X3X8
139 338230 COLLAR
140 6202DD BALL BEARING 6202DD
141 313058 WASHER
142 338231 WASHER (A)
143 318554 GEAR HOLDER
144 313057 NEEDLE PIN D6X6
145 329095 SPRING (C)
146 338232 SECOND GEAR
147 338233 SPACER
148 629VVM BALL BEARING 629VV
149 338225 FIRST GEAR
150 338226 SECOND PINION
151 629VVM BALL BEARING 629VV
152 944525 BEARING WASHER (C)
153 338240 SEAL PACKING
155 338241 GEAR COVER
501 981840 GREASE (A) FOR HAMMER.HAMMER DRILL (30G)
502 339066 CASE
601 308471 GREASE FOR HAMMER.HAMMER DRILL (70G)
602 980927 GREASE FOR HAMMER.HAMMER DRILL (500G)
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Hitachi DH52MEY
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Diagram Hitachi DH52MEY

Diagram Hitachi DH52MEY

Download (583.34KB)

You might also like

O-RING (A) mm 76x2,3 for Rotary Hammer Hitachi DH52MEY
HiKOKI Power Tools Italia S.p.a. SKU: 338160
O-RING (A) mm 76x2,3 for Rotary Hammer Hitachi DH52MEY
O-RING (A) mm 76x2,3 for Demolition Hammer Hitachi DH52MEY Original spare part Hitachi - HIKOKI, O-RING (A) mm 76x2,3 for Demolition Hammer SDS MAX DH52MEY Equipped with Brushless Motor. Part for the follows items: - Rotary Hammer...
AVAILABLE €1.23
Details
Bearing Washer (C) for Hammer Hitachi DH40MA
HiKOKI Power Tools Italia S.p.a. SKU: 944525
Bearing Washer (C) for Hammer Hitachi DH40MA
Bearing Washer (C) for Demolition Hammer Hitachi DH40MA Original replacement part Hitachi HIKOKI, Bearing Washer (C) for Demolition Hammer DH40SA - DH40YB - DH40MA. Part for the following items : -  Demolition Hammer DH40SA -...
on 7/10 Business Days Approx €1.26
Details
Filter PCB Ass'y for Rotary Hammer DH45ME
HiKOKI Power Tools Italia S.p.a. SKU: 338181
Filter PCB Ass'y for Rotary Hammer DH45ME
Filter PCB Ass'y for Rotary Hammer DH45ME Original spare parts HITACHI, Filter PCB Ass'y 220V-240V for Rotary Hammer DH45ME - Demolition Hammers DH52MEY - H60MEY Parts for the following products: -  Rotary Hammer DH45ME Y -...
on 7/10 Business Days Approx. €25.00
Details
Comments (0)
