Hitachi Spare Parts for Impact Drill DV20VB2

SKU: Hitachi DV20VB2
€1.79
VAT included

Hitachi Spare Parts for Impact Drill DV20VB2

Distribution and Sale at attractive prices of Hitachi-HIKOKI Tanaka Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Impact Drill DV20VB2.
Hitachi Spare Parts for Impact Drill DV20VB2
  • Hitachi Spare Parts for Impact Drill DV20VB2
  • Hitachi Spare Parts for Impact Drill DV20VB2

Hitachi Spare Parts for Impact Drill DV20VB2

SKU: Hitachi DV20VB2 Condition: New
€1.79
VAT included

Hitachi Spare Parts for Impact Drill DV20VB2

Distribution and Sale at attractive prices of Hitachi-HIKOKI Tanaka Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Impact Drill DV20VB2.
settings 60 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 7/10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

49 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Pos. Item Price Buy
1
photo_cameraImage coming soon 995344 Flat Hd. Screw (A) M6x25 €3.09
2
photo_cameraImage coming soon 987576 Chuck Wrench For 13vlb -> HTA100106 €7.99
3
Keyless Chuck for Percussion Drill Hitachi DV20VB2 HFAM231220 Keyless Chuck for Percussion Drill Hitachi DV20VB2 €48.31
4
Chuck Spindle for Percussion Drills Hitachi DV18V-DV20VB2 322857 Chuck Spindle for Percussion Drills Hitachi DV18V-DV20VB2 €27.77
5
photo_cameraImage coming soon 939556 Ring Type C X D.35 Holes €13.80
6
Oil Seal for Impact Drills Hitachi DV18V - DV20VB2 322851 Oil Seal for Impact Drills Hitachi DV18V - DV20VB2 €4.18
7
photo_cameraImage coming soon 6202DD Ball Bearing 6202dd €7.97
8
photo_cameraImage coming soon 322850 Toothed ring Dv20vb2 €5.48
9
photo_cameraImage coming soon 984101 spring €1.87
10
Steel Ball 6,35 mm for Hammers Hitachi 959150 Steel Ball 6,35 mm for Hammers Hitachi €3.48
11
photo_cameraImage coming soon 322845 Graft (B) €7.66
13
photo_cameraImage coming soon 322852 washer Dm20v €2.20
14
photo_cameraImage coming soon 322858 According Pinion Dv20vb2 €31.69
14
photo_cameraImage coming soon 322867 FITTING FEMALE-stand €48.07
15
photo_cameraImage coming soon 322841 Clutch Lever Dv20vb2 €2.20
16
photo_cameraImage coming soon 322842 Cover Lever Dv20vb2 €2.20
17
photo_cameraImage coming soon 322840 bracket Exchange €7.66
18
photo_cameraImage coming soon 322859 Cop. Inp. Internal (B) €21.86
19
photo_cameraImage coming soon 322847 Clutch Lever €5.36
21
photo_cameraImage coming soon 322848 roll €3.13
22
photo_cameraImage coming soon 306353 O-ring (S-22) €1.87
23
photo_cameraImage coming soon 981328 Spring H Dh24dva €1.91
25
photo_cameraImage coming soon 322844 Cop. Gears Compl. (A) €27.32
26
photo_cameraImage coming soon 323048 Ring Seal (E-Type) €2.52
27
photo_cameraImage coming soon 322849 hook €34.71
28
photo_cameraImage coming soon 322860 Without Dv18v €2.20
28
photo_cameraImage coming soon 984104 pin D.5 €2.20
29
photo_cameraImage coming soon 322846 September Dv20vb230 Gear €27.22
31
photo_cameraImage coming soon 608DDM BALL BEARING 608DDC2PS2L €7.07
32
photo_cameraImage coming soon 939553 Seeger Dm20vRetaining €5.48
33
photo_cameraImage coming soon 360652E 230v led Dv20vb2Armature €46.98
34
photo_cameraImage coming soon 322843 Help Air Dv18v €3.29
36
photo_cameraImage coming soon 340587E Stator Stator 230v Dv20vb2 €32.79
37a
photo_cameraImage coming soon 698VVC bearing 698vvc €5.36
38a
photo_cameraImage coming soon 331663 Complete carcass €54.63
40
photo_cameraImage coming soon 301653 Tapp.Screw (W / Flange) D4x20 €5.63
42
Pusching Button for Drills Hitachi DV16-18V-DV20VB2 322853 Pusching Button for Drills Hitachi DV16-18V-DV20VB2 €2.78
43
Switch for Drills Hitachi DV18V-DV20VB2 322854 Switch for Drills Hitachi DV18V-DV20VB2 €30.80
46
Carbon Brushes for Sanders Hitachi SV12-13 999041 Carbon Brushes for Sanders Hitachi SV12-13 €9.62
47
Brush Holder for Demolition Hammer Hitachi DH28PCY 955203 Brush Holder for Demolition Hammer Hitachi DH28PCY €4.39
49
Noise Suppressor for Angle Grinder Hitachi G12SA2 994273 Noise Suppressor for Angle Grinder Hitachi G12SA2 €9.62
52
photo_cameraImage coming soon 321634 Cable Blue Interior €9.73
54
photo_cameraImage coming soon 937631 CORD CLIP €1.37
55
Cord Armor D.8.8 for Hitachi Power Tools 953327 Cord Armor D.8.8 for Hitachi Power Tools €1.37
56
photo_cameraImage coming soon 500409Z Cord €13.41
57
photo_cameraImage coming soon 309929 RUBBER BUSHING €1.32
501
photo_cameraImage coming soon 323130 houses €54.52
502
photo_cameraImage coming soon 323050 Side Handle Dv20vb2 €27.32
503
photo_cameraImage coming soon 303709 delimiter Depth €1.75

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Hitachi Spare Parts for Impact Drill DV20VB2

Distribution and Sale at attractive prices of Hitachi-HIKOKI Tanaka Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Impact Drill DV20VB2.

In the following table look for the model of the impact drill and the respective parts of the code .
Hitachi DV20VB2

Impact Drill DV 20VB2
# Part Num. Description
1 995344 Flat Hd. Screw (A) M6x25
2 987576 Chuck Wrench For 13vlb
3 HFAM231220 Drill Chuck 1,5-13MM 1:2X20
4 322857 Shaft Dv20vb2
4 322866 Spindle (A)
5 939556 Ring Type C X D.35 Holes
6 322851 Oil Seal Dv20vb2
7 6202dd Ball Bearing 6202dd
8 322850 Toothed ring Dv20vb2
9 984101 spring
10 959150 Steel Ball D.6
11 322845 Graft (B)
12 316321 Tapp. Screw (W / Flange) D5x45
12 322869 Tapp.Screw (W / Flange) D5x50
13 322852 washer Dm20v
14 322858 According Pinion Dv20vb2
14 322867 according Pign.Compl.D13vbFor
15 322841 Clutch Lever Dv20vb2
16 322842 Cover Lever Dv20vb2
17 322840 bracket Exchange
18 322859 Cop. Inp. Internal (B)
18 322868 Inner Cover (A)
19 322847 Clutch Lever
21 322848 roll
22 306353 O-ring (S-22)
23 981328 Spring H Dh24dva
24a 335299 Steel Ball D3.5 (10 Pcs.)
25 322844 Cop. Gears Compl. (A)
26 323048 Ring Seal (E-Type)
27 322849 hook
28 322860 Without Dv18v
28 984104 pin D.5
29 322846 September Dv20vb2 Gear
31 608ddm Ball Bearing 608ddm
32 939553 Seeger Dm20v Retaining Ring
33 360652e 230v led Dv20vb2Armature
33 360652f Armature 240v
33 360781f Armature 240v
34 322843 Help Air Dv18v
35 961672 Hex. Hd. Tapping Screw D4x50
36 340587e Stator Stator 230v Dv20vb2
36 340587f Stator 240v
37a 698vvc bearing 698vvc
38a 331663 carcass
40 301653 Tapp. Screw (W / Flange) D4x20
42 322853 Rev. Button
43 322854 switch
43 327061 Switch (1p Pillar Type) 730W
46 999041 Brushes (1 pair)
47 955203 brush holder
49 994273 filter Dampers
52 321634 Cable Blue Interior
53 984750 Tapp. Screw (W / Flange) D4x16
54 937631 terminal Wire Tie
55 953327 Sleeve saver D8.8
56 500409z Cord
57 309929 bushing
501 323130 houses
502 323050 Side Handle Dv20vb2
503 303709 delimiter Depth
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
