HiKOKI Power Tools Italia S.p.a.

Hitachi Spare Parts for Lawnmower ML53SHS

SKU: Hitachi ML53SHS
€15.28
VAT included

Hitachi Spare Parts for Lawnmower ML53SHS

We supply original Hitachi HIKOKI Tanaka spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Lawnmower ML53SHS.
Hitachi Spare Parts for Lawnmower ML53SHS
  • Hitachi Spare Parts for Lawnmower ML53SHS
  • Hitachi Spare Parts for Lawnmower ML53SHS - Diagram
  • Hitachi Spare Parts for Lawnmower ML53SHS- Diagram - 1
  • Hitachi Spare Parts for Lawnmower ML53SHS - Diagram - 2
  • Hitachi Spare Parts for Lawnmower ML53SHS - Diagram - 3
  • Hitachi Spare Parts for Lawnmower ML53SHS - Diagram - 4
  • Hitachi Spare Parts for Lawnmower ML53SHS - Diagram - 5
  • Hitachi Spare Parts for Lawnmower ML53SHS - Diagram - 6
  • Hitachi Spare Parts for Lawnmower ML53SHS - Diagram - 7
  • Hitachi Spare Parts for Lawnmower ML53SHS - Diagram - 8
  • Hitachi Spare Parts for Lawnmower ML53SHS - Diagram - 9
  • Hitachi Spare Parts for Lawnmower ML53SHS - Hitachi Label
HiKOKI Power Tools Italia S.p.a.

Hitachi Spare Parts for Lawnmower ML53SHS

SKU: Hitachi ML53SHS Condition: New
€15.28
VAT included

Hitachi Spare Parts for Lawnmower ML53SHS

We supply original Hitachi HIKOKI Tanaka spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Lawnmower ML53SHS.
settings 91 spare parts
description 11 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 7/10 Business Days Approx

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
91 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
2
 photo_cameraImage coming soon 3221083080 FRONT BAFFLE €14.58
3
 photo_cameraImage coming soon 1127286990 SCREW €1.16
4
 photo_cameraImage coming soon 3221083020 REAR BAFFLE €28.00
5
 photo_cameraImage coming soon 1127286990 SCREW €1.16
6
 photo_cameraImage coming soon 3225452130 PLATE €2.38
7
 photo_cameraImage coming soon 3810051670 LEFT BRACKET €8.48
8
 photo_cameraImage coming soon 1127278010 SCREW €1.16
9
 photo_cameraImage coming soon 3810051650 RIGHT BRACKET €8.48
10
 photo_cameraImage coming soon 3220602501 BELT COVER €10.92
11
 photo_cameraImage coming soon 3221402441 MULCHING CAP €17.02
12
 photo_cameraImage coming soon 1127285300 SCREW €2.38
Page 2 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 3813028530 FRONT WHEEL AXLE €32.88
2
 photo_cameraImage coming soon 3225451420 PLATE €1.16
3
 photo_cameraImage coming soon 1127286980 SCREW €1.16
4
 photo_cameraImage coming soon 1125213500 WASHER €1.16
5
 photo_cameraImage coming soon 1121550000 NUT €1.16
6
 photo_cameraImage coming soon 1124360510 PLATE €2.38
7
 photo_cameraImage coming soon 3228696790 HEIGHT ADJUST CONTROL ROD €25.56
8
 photo_cameraImage coming soon 1225198230 PIN €2.38
9
 photo_cameraImage coming soon 1224461930 SPRING €4.82
11
 photo_cameraImage coming soon 1127286980 SCREW €1.16
12
 photo_cameraImage coming soon 3225451520 PLATE €1.16
13
 photo_cameraImage coming soon 3813028490 REAR WHEEL AXLE €51.18
14
 photo_cameraImage coming soon 1225341310 PIN €1.16
15
 photo_cameraImage coming soon 3810033570 CENTRALIZED HEIGHT ADJUST LEVER €15.80
16
 photo_cameraImage coming soon 1224461920 SPRING €2.38
17
 photo_cameraImage coming soon 1121545100 NUT M6 €2.38
18
 photo_cameraImage coming soon 3226002400 Inner Wheel Cover €6.04
21
 photo_cameraImage coming soon 1125213500 WASHER €1.16
22
 photo_cameraImage coming soon 1121550000 NUT €1.16
Page 3 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
2
 photo_cameraImage coming soon 1127286980 SCREW €1.16
Page 4 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 4
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
2
 photo_cameraImage coming soon 1128191100 SCREW €2.38
3
 photo_cameraImage coming soon 1226716510 WASHER €3.60
4
 photo_cameraImage coming soon 1223999000 KNOB €2.38
5
 photo_cameraImage coming soon 1122932000 NUT €1.16
7
 photo_cameraImage coming soon 1128189000 SCREW €2.38
9
 photo_cameraImage coming soon 1223999000 KNOB €2.38
10
 photo_cameraImage coming soon 1122932000 NUT €1.16
11
 photo_cameraImage coming soon 1121550000 NUT €1.16
12
 photo_cameraImage coming soon 1125213500 WASHER €1.16
13
 photo_cameraImage coming soon 1123695000 ELASTIC DISC €1.16
14
 photo_cameraImage coming soon 1127606050 SCREW €3.60
15
 photo_cameraImage coming soon 3810086910 SCREWS OUTFIT €13.36
Page 5 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 5
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
2
 photo_cameraImage coming soon 1224303130 SPRING GUIDE €3.60
3
 photo_cameraImage coming soon 1125213300 WASHER €1.16
4
 photo_cameraImage coming soon 1121545100 NUT M6 €2.38
5
 photo_cameraImage coming soon 1183900200 CABLE CLIP €2.38
6
 photo_cameraImage coming soon 1810033631 ENGINE BRAKE LEVER BLACK €14.58
7
 photo_cameraImage coming soon 1810300880 ENGINE BRAKE CABLE €13.36
8
 photo_cameraImage coming soon 1127277830 SCREW €1.16
9
 photo_cameraImage coming soon 1121545100 NUT M6 €2.38
10
 photo_cameraImage coming soon 1810033640 TRACTION CONTROL LEVER €15.80
11
 photo_cameraImage coming soon 3810300510 TRACTION CABLE €54.84
12
 photo_cameraImage coming soon 3225516400 PLATE €7.26
Page 6 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 6
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 1126086000 SEEGER FOR SHAFT D = 12 UNI 7435 C60 €1.16
2
 photo_cameraImage coming soon 1225701340 LEFT PINION ML53 €7.26
3
 photo_cameraImage coming soon 1225701330 RIGHT PINION ML53 €7.26
4
 photo_cameraImage coming soon 3220420670 TRACTION AXLE BUSH €4.82
5
 photo_cameraImage coming soon 1125213710 WASHER €1.16
6
 photo_cameraImage coming soon 1810030920 COMPLETE TRACTION GROUP €113.40
7
 photo_cameraImage coming soon 1226019090 STARTER PULLEY €6.04
8
 photo_cameraImage coming soon 1126457050 ELASTIC SPINE €1.16
9
 photo_cameraImage coming soon 1220332830 ADJUST ROD €4.82
10
 photo_cameraImage coming soon 1350641960 V-BELT €9.70
11
 photo_cameraImage coming soon 1220419571 BUSH €1.16
12
 photo_cameraImage coming soon 1224500630 SPRING €1.16
13
 photo_cameraImage coming soon 3226800090 WASHER €2.38
14
 photo_cameraImage coming soon 1121545100 NUT M6 €2.38
15
 photo_cameraImage coming soon 1221102300 HUBCAP €1.16
16
 photo_cameraImage coming soon 1227530000 PLUG €1.16
Page 7 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 7
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 3810074162 FRONT WHEEL CPL. €18.24
2
 photo_cameraImage coming soon 1192160350 BALL BEARING 6001 2RS (12X28X8) €3.60
3
 photo_cameraImage coming soon 3221106430 FRONT WHEEL COVER ML53 €2.38
5
 photo_cameraImage coming soon 3810074172 REAR WHEEL ML53 CPL. €41.42
6
 photo_cameraImage coming soon 1192160350 BALL BEARING 6001 2RS (12X28X8) €3.60
7
 photo_cameraImage coming soon 1127287060 SCREW €1.16
8
 photo_cameraImage coming soon 3810074722 WHEEL ASS'Y €41.42
9
 photo_cameraImage coming soon 3221106440 REAR WHEEL COVER ML53 €3.60
9A
 photo_cameraImage coming soon 3810074720 REAR WHEEL €31.66
Page 8 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 8
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 3221083091 SIDE BAFFLE €10.92
2
 photo_cameraImage coming soon 3226003140 EXIT GUARD €12.14
3
 photo_cameraImage coming soon 1127278030 TORX SCREW M6X14 €1.16
4
 photo_cameraImage coming soon 3228066390 PIN €3.60
5
 photo_cameraImage coming soon 1121545100 NUT M6 €2.38
6
 photo_cameraImage coming soon 1182038530 CAP €2.38
7
 photo_cameraImage coming soon 1224504560 SPRING €3.60
8
 photo_cameraImage coming soon 1225178691 FULCRUM PIN €3.60
9
 photo_cameraImage coming soon 1126048960 WASHER D6 €1.16
Page 9 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 9
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 1126911150 SCREW €1.16
2
 photo_cameraImage coming soon 1224656083 BLADE HUB €9.70
3
 photo_cameraImage coming soon 1810044590 MULCHING BLADE €18.24
4
 photo_cameraImage coming soon 1221604000 WASHER €2.38
5
 photo_cameraImage coming soon 1125230800 WASHER €1.16
6
 photo_cameraImage coming soon 1127356980 SCREW BLADE €2.38
7
 photo_cameraImage coming soon 1121391500 WOODRUFF KEY €2.38
8
 photo_cameraImage coming soon 1121542100 NUT €1.16
Page 10 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 10
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 3227853310 BAFFLE SUPPORT (BLACK) €8.48
2
 photo_cameraImage coming soon 1224504640 BAFFLE SPRING €2.38
4
 photo_cameraImage coming soon 1127286990 SCREW €1.16
5
 photo_cameraImage coming soon 3226003310 STONE PROTECTION ORANGE ML48 €8.48
6
 photo_cameraImage coming soon 3223936440 BAG HANDLE €6.04
7
 photo_cameraImage coming soon 3814860180 BAG, BLACK TOP €38.98
8
 photo_cameraImage coming soon 1226085610 LOWER REINFORCEMENT €12.14
9
 photo_cameraImage coming soon 1127286920 SCREW €1.16
10
 photo_cameraImage coming soon 3225451590 PLATE €1.16
11
 photo_cameraImage coming soon 1810023180 COLLECTION BAG BLACK €36.54
Page 11 zoom_in View exploded local_shipping Usually Ships in: 7/10 BUSINESS DAYS
Esploso pagina 11
info_outline

No spare parts mapped to this page.
Check the other pages for available parts.

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Hitachi Spare Parts for Lawnmower ML53SHS

We supply original Hitachi HIKOKI Tanaka spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Lawnmower ML53SHS.

In the following table, look for the model of the Lawnmower and ripettivo spare part.
Hitachi ML53SHS
Rasaerba Hitachi ML53SHS Pag.1
1.01 SCOCCA / TAPPO MULCHING / CARTER CINGHIA / CONVOGLIATORE
Pos. Codice Description
1 3810048290 DECK - GRAY
2 3221083080 FRONT BAFFLE
3 1127286990 SCREW
4 3221083020 REAR BAFFLE
5 1127286990 SCREW
6 3225452130 PLATE
7 3810051670 LEFT BRACKET
8 1127278010 SCREW
9 3810051650 RIGHT BRACKET
10 3220602501 BELT COVER
11 3221402441 MULCHING CAP
12 1127285300 SCREW
1.02 ALZARUOTA / ASSI RUOTE Pag.2
1 3813028530 FRONT WHEEL AXLE
2 3225451420 PLATE
3 1127286980 SCREW
4 1125213500 WASHER
5 1121550000 NUT
6 1124360510 PLATE
7 3228696790 HEIGHT ADJUST CONTROL ROD
8 1225198230 PIN
9 1224461930 SPRING
11 1127286980 SCREW
12 3225451520 PLATE
13 3813028490 REAR WHEEL AXLE
14 1225341310 PIN
15 3810033570 HEIGHT ADJUST LEVER - CENTRALIZED
16 1224461920 SPRING
17 1121545100 NUT M6
18 3226002400 Inner Wheel Cover
21 1125213500 WASHER
22 1121550000 NUT
1.03 MASCHERINA FRONTALE Pag.3
1 3222262390 FRONT MASK - ORANGE
2 1127286980 SCREW
1.04 MANICO INFERIORE Pag.4
1 3810067910 HANDLE, LOWER PART GRAY
2 1128191100 SCREW
3 1226716510 WASHER
4 1223999000 KNOB
5 1122932000 NUT
7 1128189000 SCREW
9 1223999000 KNOB
10 1122932000 NUT
11 1121550000 NUT
12 1125213500 WASHER
13 1123695000 SPRING WASHER
14 1127606050 SCREW
15 3810086910 SCREW OUTFIT
1.05 MANICO SUPERIORE / CAVI Pag.5
1 3810075061 HANDLE, GRAY UPPER PART
2 1224303130 SPRING GUIDE
3 1125213300 WASHER
4 1121545100 NUT M6
5 1183900200 CABLE CLIP
6 1810033631 ENGINE BRAKE LEVER - BLACK
7 1810300880 ENGINE BRAKE CABLE
8 1127277830 SCREW
9 1121545100 NUT M6
10 1810033640 TRACTION CONTROL LEVER
11 3810300510 TRACTION CABLE
12 3225516400 PLATE
1.06 TRAZIONE / CINGHIA Pag.6
1 1126086000 SEEGER FOR SHAFT D = 12 UNI 7435 C60
2 1225701340 LEFT PINION ML53
3 1225701330 RIGHT PINION ML53
4 3220420670 TRACTION AXLE BUSH
5 1125213710 WASHER
6 1810030920 GEAR CASE ASS'Y
7 1226019090 PULLEY
8 1126457050 SPRING PIN
9 1220332830 ADJUST ROD
10 1350641960 V-BELT
11 1220419571 SLEEVE
12 1224500630 SPRING
13 3226800090 WASHER
14 1121545100 NUT M6
15 1221102300 HUBCAP
16 1227530000 PLUG
1.07 RUOTE Pag.7
1 3810074162 FRONT WHEEL CPL.
2 1192160350 BALL BEARING 6001 2RS (12X28X8)
3 3221106430 FRONT WHEEL COVER ML53
5 3810074172 REAR WHEEL ML53 CPL.
9A 3810074720 REAR WHEEL
6 1192160350 BALL BEARING 6001 2RS (12X28X8)
7 1127287060 SCREW
8 3810074722 WHEEL ASS'Y
9 3221106440 REAR WHEEL COVER ML53
1.08 SCARICO LATERALE Pag.8
1 3221083091 SIDE BAFFLE
2 3226003140 EXIT GUARD
3 1127278030 TORX SCREW M6X14
4 3228066390 PIN
5 1121545100 NUT M6
6 1182038530 CAP
7 1224504560 SPRING
8 1225178691 FULCRUM PIN
9 1126048960 WASHER D6
1.09 MOZZO LAMA / LAMA Pag.9
1 1126911150 SCREW
2 1224656083 BLADE HUB
3 1810044590 MULCHING BLADE
4 1221604000 SPRING WASHER
5 1125230800 WASHER
6 1127356980 SCREW BLADE
7 1121391500 WOODRUFF KEY
8 1121542100 NUT
1.10 PARASASSI / SACCO Pag.10
1 3227853310 BAFFLE HOLDER (BLACK)
2 1224504640 SPRING BAFFLE
3 3221095770 STONE GUARD COVER, ORANGE
4 1127286990 SCREW
5 3226003310 STONE GUARD ORANGE ML48
6 3223936440 GRASS BAG HANDLE
7 3814860180 GRASS BAG, BLACK TOP
8 1226085610 LOWER REINFORCEMENT
9 1127286920 SCREW
10 3225451590 PLATE
11 1810023180 BLACK COLLECTION BAG
1.11 ETICHETTA Pag.11
1 1143691360 FRONT LABEL HITACHI
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Hitachi ML53SHS
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Drawing Hitachi ML53SHS

Drawing Hitachi ML53SHS

Download (1.25MB)

You might also like

Einhell EM1650 -20% Sale
Einhell Italia s.r.l. SKU: EM1650
Electric Lawn Mower 1600 Watts Einhell EM1650
Electric Lawn Mower 1600 Watts Einhell EM1650 Powerful electric lawn, ergonomic and space saving with adjustable cutting height. Technical Data: - Voltage: 230 ~ 50 Hz - Power: 1600 W - Cutting height adjustment: 10-positions from 25...
Last items in stock €197.63 €247.03
Details
Electric Lawn Mower Makita 1400W ELM3800 -10% Sale
Makita SKU: ELM3800
Electric Lawn Mower Makita 1400W ELM3800
Electric Lawn Mower Makita 1400W ELM3800 Features: - Innovative Makita Design. - Polypropylene shell with UV and weather resistance. - Easy drainage of the picking basket provided already assembled. - Integrated transport handle. -...
Out-of-Stock €172.32 €191.47
Details
Axle Bush for Self Propelled Lawnmower Alpina BL 510 SB
GGP Italy SKU: 322042067/0
Axle Bush for Self Propelled Lawnmower Alpina BL 510 SB
Axle Bush for Self Propelled Lawnmower Alpina BL 510 SB Original replacement part Alpina, Rear Wheels Axle Bush TR CRUISER for Self Propelled Lawnmowers BL 510 SB - BL 510 SHQ - AL3 51 SBQ....
Usually Ships in: 7/10 Business Days Approx. €4.10
Details
Alpina Rod Pin for BL 510 SHQ
GGP Italy SKU: 122519823/0
Alpina Rod Pin for BL 510 SHQ
Alpina Rod Pin for Lawnmower BL 510 SHQ Original part Alpina, Wheel Control Rod Pin for Lawnmowers BL 510 SHQ - AL3 51 SBQ. Part for the following products: -  Lawnmower Alpina BL 510 SHQ - 295546934 -  Lawnmower Alpina...
AVAILABLE €2.44
Details
Comments (0)
