Flex Spare Parts for Safety Vacuum Cleaner VCE 35 L AC
Flex original spare parts at the best price on the web for the maintenance or replacement of damaged or worn spare parts of the
Safety Vacuum Cleaner with automatic filter cleaning VCE 35 L AC - from 2014-11-01.
In the following table, look for the model of the Safety Vacuum Cleaner and the respective parts of the code.
| Safety Vacuum Cleaner with automatic filter cleaning VCE 35 L AC - from 2014-11-01 |
| A Pag.1 |
| # |
Part Num. |
Description |
| 1 |
415227 |
COMPLETE COVER VCE45 |
| 2 |
337641 |
HANDLE |
| 3 |
337706 |
SCREW, 5X30 S 47 |
| 4 |
341797 |
ON / OFF BUTTON |
| 5 |
340499 |
SPRING S47 |
| 6 |
341800 |
BUTTON S47M |
| 7 |
329797 |
SCREW, KT-, KT 4 X 16 GALVANIZED |
| 8 |
297615 |
MICRO SWITCH X S36 |
| 9 |
297607 |
SOCKET S 36 |
| 10 |
340456 |
ROTATING KNOB S47 GRAY |
| 11 |
340367 |
INSTRUMENT PANEL F. ERS. S47 |
| 12 |
297593 |
GREEN LED S36 |
| 13 |
340596 |
SWITCH WITH LED S47 |
| 14 |
340618 |
SWITCH S47 |
| 15 |
337668 |
LATERAL HOOK X S47 |
| 16 |
297534 |
COMPLETE POWER CABLE S 36 |
| 17 |
297542 |
ACCESSORIES SUPPORT S36 |
| 18 |
325910 |
SCREW 3X12 S36M |
| 19 |
340359 |
SPEED POTENTIOMETER |
| 20 |
297623 |
PLATE S36 |
| B Pag.2 |
| 1 |
415235 |
CASING VCE45 |
| 2 |
415219 |
GASKET SET VCE45 |
| 3 |
421650 |
MOTORE 230V VCE35-45 |
| 6 |
415324 |
WHIRE VCE4 |
| 7 |
297860 |
GASKET X S36 |
| 8 |
340308 |
INTERMEDIATE COVER S47 |
| 9 |
340421 |
ELECTRIC PROBE, S 47 / M, VCE 35/45-L / M |
| 10 |
415243 |
ELECTRONIC BOARD - from 2014-11-01 |
| 11 |
340677 |
TERMINAL S47 |
| 12 |
297550 |
SCREW 4X16 VCE |
| 13 |
340642 |
CABLE PROBE |
| 15 |
337706 |
SCREW, 5X30 S 47 |
| 16 |
337692 |
FLAT FOLDER FILTER |
| 17 |
340537 |
QUICK CLOSURE S47 |
| 18 |
341908 |
SCREW, 4 X 22 S47M |
| 26 |
374490 |
FERRITE RING VCE 35/45 L AC |
| C Pag.3 |
| 1 |
415251 |
PORTA MAGNETE, DOMEL, VCE45 |
| 2 |
340669 |
MAGNET X S47 |
| 3 |
340545 |
0-RING S47 |
| 4 |
340294 |
SET X PORTA MAGNETE S47 |
| 5 |
340502 |
GUARNIZIONE DELL'ARIA DI MANDATA S47 |
| 6 |
340375 |
SUPPORTO MOLLA S47 |
| 7 |
415278 |
COPERCHIO FILTRO VCE45 |
| 8 |
415286 |
SUPPORTO FILTRO VCE45 |
| 9 |
340650 |
VITE 5X80 S47 |
| 10 |
375020 |
CAVO, MAGNETE VCE35 / 45L-AC |
| 11 |
325937 |
VITE M4X8 S36M |
| 13 |
195715 |
VITE LK 604 4X12 |
| 15 |
374490 |
FERRITRING VCE 35/45 L AC |
| D Pag.4 |
| 2 |
298131 |
TANK 10 X S36 |
| 3 |
298158 |
HOOK S36 / S47 |
| 4 |
340413 |
SUPPORT X S47 |
| 5 |
298174 |
WASHER X S47 |
| 6 |
394041 |
WHEEL COVER (VC / VCE - 35/45) |
| 7 |
298190 |
REAR WHEEL X S47 |
| 8 |
298204 |
WHEELS X S36 |
| 9 |
298212 |
CONNECTION X S36 |
| 10 |
298298 |
BOLT S 36 |
| 11 |
340448 |
WASHER X S47 |
| 12 |
375039 |
LABEL VCE35 / 45 |
| E Pag.5 |
| 1 |
408697 |
CONNECTION SLEEVE |
| 2 |
298239 |
RUBBER CORD S 36 |
| 3 |
379654 |
SNAP RING SH-C 32 GRAY |
| 4 |
378526 |
CONNECTOR FOR AS HOSE, VC / E 35/45 |
| 5 |
406708 |
SUCTION HOSE |
| 17 |
296961 |
PAPER FILTER BAG S36 / VC35 5PCS |
| 18 |
340766 |
DISPOSAL BAG, PACK OF 10 |
| 19 |
320188 |
ADAPTER |
| 21 |
413437 |
NOZZLE |
