FIAC spa

FIAC Spare Parts for Pump Unit VX 402

SKU: Fiac VX402 - from 15/04/2003
€562.05
VAT included

FIAC Spare Parts for Pump Unit VX 402

FIAC Genuine Parts or replacement parts for to repair Piston Air Compressor components for direct driven lubricared Pump Unit VX 402 validity date - from 15/04/2003.

FIAC Spare Parts for Pump Unit VX 402
  • FIAC Spare Parts for Pump Unit VX 402
  • FIAC Spare Parts for Pump Unit VX 402
FIAC spa

FIAC Spare Parts for Pump Unit VX 402

SKU: Fiac VX402 - from 15/04/2003 Condition: New
€562.05
VAT included

FIAC Spare Parts for Pump Unit VX 402

FIAC Genuine Parts or replacement parts for to repair Piston Air Compressor components for direct driven lubricared Pump Unit VX 402 validity date - from 15/04/2003.

settings 64 spare parts
description 2 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10/15 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
62 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 1
Pos. Item Price Buy
1
 photo_cameraImage coming soon 7570090000 Head €29.39
2
 photo_cameraImage coming soon 7011220000 Screw M6X40 UNI-5737 €1.44
3
 Filter Plate for Pumping Uniti and Air Compressor Fiac 7458340000 Filter Plate for Pumping Uniti and Air Compressor Fiac €1.52
4
 Air Filter Element for Pumping Units Fiac VX - VS - GM 7210010000 Air Filter Element for Pumping Units Fiac VX - VS - GM €4.37
5
 photo_cameraImage coming soon 7012010000 Screw Ø3,9X19 UNI-6954 €1.48
6
 Air Cleaner Cover for Pump Units Fiac VX 254-304 7210180000 Air Cleaner Cover for Pump Units Fiac VX 254-304 €7.69
7
 Start Valve 2.2 BAR-G 1/4 for Pump Units Fiac VX - VS 7196000000 Start Valve 2.2 BAR-G 1/4 for Pump Units Fiac VX - VS €14.40
8
 photo_cameraImage coming soon 7458370000 plate Tool box €16.06
10
 photo_cameraImage coming soon 7575090000 Cylinder €65.76
11
 Fiac Stud M.8X35X14X16 7015020000 Fiac Stud M.8X35X14X16 €1.52
12
 Conrod for Pump Units FIAC GM-VX 5050150008 Conrod for Pump Units FIAC GM-VX €27.33
13
 Piston D.50 MM for Pump Units FIAC Series VX - GM 7220020000 Piston D.50 MM for Pump Units FIAC Series VX - GM €26.96
14
 Piston Rings for Pumping Units FIAC VX 194-254-402 4080020000 Piston Rings for Pumping Units FIAC VX 194-254-402 €26.02
15
 Circlip for Pumping Units Fiac VX 194-VX 214 7041010000 Circlip for Pumping Units Fiac VX 194-VX 214 €1.52
16
 photo_cameraImage coming soon 7050020000 Pin Ø12 / 8X42 €5.60
17
 Dipstick Level Oil for Pump Unit and Compressors Fiac GM-Vx-Colibrì 7181060000 Dipstick Level Oil for Pump Unit and Compressors Fiac GM-Vx-Colibrì €10.47
19
 photo_cameraImage coming soon 7011460000 Screw M6X16 TAP-TITE €1.48
20
 photo_cameraImage coming soon 7650010000 Crankcase cover €28.94
21
 Motor Carter Gasket for Pumping Units FIAC VX 7078440000 Motor Carter Gasket for Pumping Units FIAC VX €7.53
22
 Seeger E 20 for Pumping Units FIAC S 15-GM 25-GM 50 7040040000 Seeger E 20 for Pumping Units FIAC S 15-GM 25-GM 50 €0.62
23
 photo_cameraImage coming soon 5040341008 CrankShaft €159.97
23
 photo_cameraImage coming soon 5040351008 CrankShaft €159.97
24
 photo_cameraImage coming soon 5070180008 Crankshaft housing €125.56
25
 photo_cameraImage coming soon 7090080000 Stopper M3 / 8 " €1.50
26
 photo_cameraImage coming soon 5090230008 Rotor €101.65
26
 photo_cameraImage coming soon 5090260008 Rotor €119.60
27
 Capacitor 50 mf for Pump Units Fiac VX 304-402-422 7310410000 Capacitor 50 mf for Pump Units Fiac VX 304-402-422 €56.93
27
 photo_cameraImage coming soon 7310530000 Capacitor MF.60 V400 €38.09
28
 photo_cameraImage coming soon 7329870000 PR WIRE / MOTGMV25-30 3X1,5 + T PVC90CM €22.13
28
 photo_cameraImage coming soon 7329900000 Cable Pressure / Motor €15.66
29
 photo_cameraImage coming soon 7501050000 Cable locks €4.48
30
 photo_cameraImage coming soon 7501060000 Cable locks €1.52
31
 photo_cameraImage coming soon 7382340000 Terminal cover €4.34
31
 photo_cameraImage coming soon 7382350000 COVER Morset MEC90 GMV-E TRIFAS €4.34
32
 photo_cameraImage coming soon 7012020000 Screw Ø3,9X12,7 DIN-7981 €1.52
32
 photo_cameraImage coming soon 7012060000 Screw M4X12 UNI-8112 €1.52
34
 photo_cameraImage coming soon 7410460000 Prot. Thermal ETA-3120-F521-P7T1-W09D-6A €125.92
34
 photo_cameraImage coming soon 7410480000 Prot. Thermal AMF 20A W58 €30.62
36
 Motor Fan for Pumping Unit Fiac VX-GM 7200020000 Motor Fan for Pumping Unit Fiac VX-GM €59.99
37
 photo_cameraImage coming soon 7038020000 Washer Ø8X30X3 UNI-6593 €1.52
38
 photo_cameraImage coming soon 7011090000 Screw M8x20 UNI-5739 €1.52
39
 FIAC Motor Cover for Series VS-VX 7150370000 FIAC Motor Cover for Series VS-VX €36.88
40
 photo_cameraImage coming soon 7031010000 Washer 8 UNI-3703 €1.52
41
 photo_cameraImage coming soon 7015100000 Guy M6X185 €1.44
42
 photo_cameraImage coming soon 7060030000 Bearing 6204 20-47-14 2RS1- €17.12
43
 photo_cameraImage coming soon 4011030000 CARCASS GMVHP3 MOT V380 / 50 RPM2800 €624.74
43
 photo_cameraImage coming soon 4011420000 HOUSING MOT V240 GMV 30 / 50HZ S / TERMBLK €519.41
43
 photo_cameraImage coming soon 4012440000 HOUSING MOTOR VX 402 V.230 / 50HZ " €583.19
44
 photo_cameraImage coming soon 7071030000 RING 3462/10 SMIM €4.30
45
 photo_cameraImage coming soon 7060070000 Bearing 6007 €24.51
47
 photo_cameraImage coming soon 7020070000 Nut M8 UNI-5587 €1.48
49
 Flap Valves Kit 10 pcs for Puming Units Fiac VX-GM 4081010000 Flap Valves Kit 10 pcs for Puming Units Fiac VX-GM €10.82
51
 photo_cameraImage coming soon 7081100000 3/8 " €8.35
52
 photo_cameraImage coming soon 7089950000 Collector €25.04
53
 FIAC Copper Pipe Right for Series VX 7237010000 FIAC Copper Pipe Right for Series VX €26.95
54
 photo_cameraImage coming soon 7237020000 Copper pipe €25.42
55
 photo_cameraImage coming soon 7010120000 Screw M6X25 UNI-5931 €1.40
100
 Valves Plate Kit for Puming Units Fiac VX 402 4082660000 Valves Plate Kit for Puming Units Fiac VX 402 €45.39
101
 Conrod + Piston Kit for Air Compressors FIAC GM 191-192-243 4191020000 Conrod + Piston Kit for Air Compressors FIAC GM 191-192-243 €68.53
102
 photo_cameraImage coming soon 4280320000 CARTER GROUP-Crankshaft-ROTOR VX-402 M €367.84
103
 Gasket Set for Pumping Units FIAC VX 194-214-254-402 4082150000 Gasket Set for Pumping Units FIAC VX 194-214-254-402 €15.23
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 2
info_outline

No spare parts mapped to this page.
Check the other pages for available parts.

Page 3 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 3
Pos. Item Price Buy
103
 Gasket Set for Pumping Units FIAC VX 194-214-254-402 4082150000 Gasket Set for Pumping Units FIAC VX 194-214-254-402 €15.23

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

FIAC Spare Parts for Pump Unit VX 402

FIAC Genuine Parts or replacement parts for to repair Piston Air Compressor components for direct driven lubricared Pump Unit VX 402 validity date - from 15/04/2003.

In the following table , look for the model of the Pumping Unit and the respective parts of the code .
Fiac VX 402 - from 15/04/2003

Pump Unit VX 402 validity date - from 15/04/2003
# Part Num. Description
1 7570090000 Head
2 7011220000 Screw M6X40 UNI-5737
3 7458340000 Plate filter
4 7210010000 Filter element
5 7012010000 Screw Ø3,9X19 UNI-6954
6 7210180000 Air Cleaner Cover
7 7196000000 Start valve M1 / ​​4 "2.2 bar
8 7458370000 Plate Tool box
10 7575090000 Cylinder
11 7015020000 Stud M.8X35X14X16
12 5050150008 Connecting Rod
13 7220020000 Piston
14 4080020000 Kit segments
15 7041010000 Seeger Ø12
16 7050020000 Pin Ø12 / 8X42
17 7181060000 Dipstick
18 7012180000 Screw M6X20 UNI-8112
19 7011460000 Screw M6X16 TAP-TITE
20 7650010000 Crankcase cover
21 7078440000 Gasket
22 7040040000 Seeger E 20
23 5040341008 CrankShaft
23 5040351008 CrankShaft
24 5070180008 Sump
25 7090080000 Cap M3/8"
26 5090230008 Rotor
26 5090260008 Rotor
27 7310410000 Capacitor MF.50 V450
27 7310530000 Capacitor MF.60 V400
28 7329870000 PR WIRE / MOTGMV25-30 3X1,5 + T PVC90CM
28 7329900000 Cable Pressure / Motor
29 7501050000 Block Cable
30 7501060000 Block Cable
31 7382340000 Terminal cover
31 7382350000 COVER TERMINALS MEC90 GMV-E TRIFAS
32 7012020000 Screw Ø3,9X12,7 DIN-7981
32 7012060000 Screw M4X12 UNI-8112
34 7410460000 Prot. Thermal ETA-3120-F521-P7T1-W09D-6A
34 7410480000 Prot. Thermal AMF 20A W58
35 7640010000 Cover
36 7200020000 Fan raff.
37 7038020000 Washer Ø8X30X3 UNI-6593
38 7011090000 Screw M8X20 UNI-5739
39 7150370000 Carena plastic
40 7031010000 Washer Ø8 UNI-3703
41 7015100000 tie rod M6X185
42 7060030000 Bearing 6204 20-47-14 2RS1-
43 4011030000 CARCASS GMVHP3 MOT V380 / 50 RPM2800
43 4011420000 HOUSING MOT V240 GMV 30 / 50HZ S / TERMBLK
43 4012440000 HOUSING MOTOR VX 402 V.230 / 50HZ "
44 7071030000 RING 3462/10 SMIM
45 7060070000 Bearing 6007
47 7020070000 Nut M8 UNI-5587
49 4081010000 KIT VALVE FLAP 10 PZ 110-200
51 7081100000 Fitting 3/8 "
52 7089950000 Collector
53 7237010000 Copper pipe
54 7237020000 Copper pipe
55 7010120000 Screw M6X25 UNI-5931
100 4082660000 Kit Valve plate
101 4191020000 Kit rod / piston
102 4280320000 CARTER GROUP-Crankshaft-ROTOR VX-402 M
103 4082150000 Kits
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Fiac VX402 - from 15/04/2003
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Diagram Fiac VX402

Diagram Fiac VX402

Download (424.2KB)
