FIAC spa

FIAC Spare Parts for Pumping Unit AB 268

SKU: Fiac AB268 - 1129740083
€30.62
VAT included

FIAC Spare Parts for Pumping Unit AB 268

FIAC Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Pump Unit AB 268.

FIAC Spare Parts for Pumping Unit AB 268
  • FIAC Spare Parts for Pumping Unit AB 268
  • Fiac AB 268 Parts Drawing
FIAC spa

FIAC Spare Parts for Pumping Unit AB 268

SKU: Fiac AB268 - 1129740083 Condition: New
€30.62
VAT included

FIAC Spare Parts for Pumping Unit AB 268

FIAC Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Pump Unit AB 268.

settings 31 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 10/15 Business Days Approx

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
31 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 9700001075 Case €79.81
2
 FIAC AB268 Carter Cover 9700001076 FIAC AB268 Carter Cover €20.50
5
 Crank Shaft for Pumping Units FIAC AB248-338-360 9100270140 Crank Shaft for Pumping Units FIAC AB248-338-360 €58.71 Not available for order
6
 Crank Shaft Ball Bearing 6203 for Pump Unit FIAC AB 360 7060180000 Crank Shaft Ball Bearing 6203 for Pump Unit FIAC AB 360 €11.77
7
 Crank Shaft Ball Bearing 6204 for Pump Unit FIAC AB 360 7060200000 Crank Shaft Ball Bearing 6204 for Pump Unit FIAC AB 360 €12.86
8
 Oil Seal for Pumping Units FIAC AB248-338-360 9100270150 Oil Seal for Pumping Units FIAC AB248-338-360 €4.30
9
 Front Cover for Pumping Units FIAC AB248-268-338-360 9100270160 Front Cover for Pumping Units FIAC AB248-268-338-360 €12.15
10
 Rear Cover for Pumping Units FIAC AB248-268-338-360 9100270170 Rear Cover for Pumping Units FIAC AB248-268-338-360 €12.15
12
 photo_cameraImage coming soon 7011420000 Screw M6X16 UNI-5739 €1.52
13
 FIAC AB268 Flywheel Key 9100280020 FIAC AB268 Flywheel Key €1.29
14
 Conrod for Pumping unit FIAC AB248 9100280030 Conrod for Pumping unit FIAC AB248 €29.72
15
 Piston Pin for Pumping Unit FIAC AB 248-338-GM 193 9100020080 Piston Pin for Pumping Unit FIAC AB 248-338-GM 193 €15.80
16
 Piston for Pumping unit FIAC AB 248-338-GM193 9100020120 Piston for Pumping unit FIAC AB 248-338-GM193 €25.65
17
 Piston Rings for Pumping Units FIAC AB 248-338 - AB 268 4080030000 Piston Rings for Pumping Units FIAC AB 248-338 - AB 268 €30.64
19
 photo_cameraImage coming soon 7575480000 Cylinder €111.92
20
 photo_cameraImage coming soon 7012220000 Screw M8X 25 UNI-8112 €1.52
21
 FIAC Pump Unit AB268 Oil Sight Glass 9700000408 FIAC Pump Unit AB268 Oil Sight Glass €7.04
28
 Head for Air Compressor Pump Unit FIAC AB 268 7570140000 Head for Air Compressor Pump Unit FIAC AB 268 €55.50
31
 Set Intake Filter for Air Compressor Pump Unit AB 268 9700000843 Set Intake Filter for Air Compressor Pump Unit AB 268 €8.23
33
 photo_cameraImage coming soon 7010080000 Screw M8x35 UNI-5931 €1.52
33A
 photo_cameraImage coming soon 7030030000 Washer 8 UNI-6592 €1.42
34
 Air Conveyor for Pumping Units FIAC AB248-268-338-360 9100270220 Air Conveyor for Pumping Units FIAC AB248-268-338-360 €10.61
35
 photo_cameraImage coming soon 7012090000 Screw M5X12 UNI-8112 €1.52
36
 photo_cameraImage coming soon 7011460000 Screw M6X16 TAP-TITE €1.48
37
 Oil Vent Cap for Air Compressor Pump Unit FIAC AB 268 9700000300 Oil Vent Cap for Air Compressor Pump Unit FIAC AB 268 €6.11
38
 photo_cameraImage coming soon 7030270000 Washer 8 5X30X4 UNI-6593 €1.52
39
 Flywheel for Pumping unit Fiac AB 248-338-360 9100270230 Flywheel for Pumping unit Fiac AB 248-338-360 €64.36
100
 Valves Plate kit for Air Compressor Pump Unit FIAC AB 268 9700003272 Valves Plate kit for Air Compressor Pump Unit FIAC AB 268 €56.90
101
 Gaskets kit for Air Compressor Pump Unit FIAC AB 268 9700003271 Gaskets kit for Air Compressor Pump Unit FIAC AB 268 €21.06
102
 Kit Piston for Pumping unit FIAC AB 248-338 4291030000 Kit Piston for Pumping unit FIAC AB 248-338 €70.16
103
 FIAC AB268 Conrod-Piston Kit 1129704143 FIAC AB268 Conrod-Piston Kit €45.89

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

FIAC Spare Parts for Pumping Unit AB 268

FIAC Original spare parts

at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Pump Unit AB 268.

In the following table, look for the type of the Pumping Unit  and the respective parts of the code.
7570140000

Pump Unit AB 268
# Part Num. Description
1 9700001075 Crankcase
2 9700001076 Carter cover
5 9100270140 CRANKSHAFT
6 7060180000 BEARING
7 7060200000 BEARING
8 9100270150 OIL SEAL
9 9100270160 COVER Front
10 9100270170 COVER Rear
12 7011420000 Screw
13 9100280020 Key
14 9100280030 CONNECTING ROD
15 9100020080 PISTON PIN
16 9100020120 PISTON
17 4080030000 PISTON RING KIT
19 7575480000 Cylinder
20 7012220000 Screw
21 9700000408 Oil sight glass
28 7570140000 Head
31 9700000843 INTAKE FILTER KIT
33 7010080000 Screw
34 9100270220 AIR CONVEYOR
35 7012090000 Screw
36 7011460000 Screw
37 9700000300 Oil Vent Cap
38 7030270000 Washer
39 9100270230 Flywheel
100 9700003272 Valves plate kit
101 9700003271 Gasket Kit
102 4291030000 Piston Kit
103 1129704143 Conrod Piston Kit
33A 7030030000 Washer
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Fiac AB268 - 1129740083
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Fiac AB 268 Parts Drawing

Fiac AB 268 Parts Drawing

Download (718.2KB)
