FIAC spa

FIAC SCS 958-C Spare Parts

SKU: SCS 958-C 1121690294
€117.60
VAT included

FIAC SCS 958-C Spare Parts

We are FIAC PROFESSIONAL AIR COMPRESSORS original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Super Silent Belt Drive SCS 958-C-HP.7,5-V.400/50/3-CE 1121690294.
FIAC SCS 958-C Spare Parts
  • Online only
  • FIAC SCS 958-C Spare Parts
  • FIAC SCS 958-C Spare Parts
  • FIAC SCS 958-C Spare Parts
  • FIAC SCS 958-C Spare Parts
  • FIAC SCS 958-C Spare Parts
FIAC spa

FIAC SCS 958-C Spare Parts

SKU: SCS 958-C 1121690294 Condition: New
€117.60
VAT included

FIAC SCS 958-C Spare Parts

We are FIAC PROFESSIONAL AIR COMPRESSORS original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Super Silent Belt Drive SCS 958-C-HP.7,5-V.400/50/3-CE 1121690294.
settings 40 spare parts
description 4 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on Demand Only Call Us Before

MORE INFO:: ON DEMAND ONLY
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
40 spare parts
Page 1 zoom_in View exploded
Esploso pagina 1
Pos. Item Price Buy
029
 photo_cameraImage coming soon 1127200125 Flywheel €114.18
035
 photo_cameraImage coming soon 7011100000 Screw M8X25 UNI-5739 €1.52
036
 photo_cameraImage coming soon 7030270000 Washer 8 5X30X4 UNI-6593 €1.52
099
 photo_cameraImage coming soon 1123020109 Pump UNIT AB998S €1,030.39
103
 photo_cameraImage coming soon 7360340000 Rubber Foot €20.85
105
 photo_cameraImage coming soon 7190150000 Check valve FM 1.2 " €38.30
112
 photo_cameraImage coming soon 7083630000 Delivery pipe fitting €12.74
126
 photo_cameraImage coming soon 7371110000 Belt €27.92
127
 photo_cameraImage coming soon 7234470000 RILSAN TUBE €15.31
131
 FIAC SCS 500-600-951 Pressure Switch MDR3 7251221000 FIAC SCS 500-600-951 Pressure Switch MDR3 €98.07
135
 photo_cameraImage coming soon 7380120000 Three-phase motor €715.89
145
 photo_cameraImage coming soon 7231850000 Air pipe COPPER D14 SCS 678/998 €67.30
163
 photo_cameraImage coming soon 7234530000 Infeed hose €29.40
469
 photo_cameraImage coming soon 5167360008 Base €471.53
489
 photo_cameraImage coming soon 6266369400 COUNTER_HOURS 380V 50HZ ABAC €76.00
Page 2 zoom_in View exploded
Esploso pagina 2
Pos. Item Price Buy
001
 FIAC AB678 Crankcase 5070270008 FIAC AB678 Crankcase €199.89
002
 photo_cameraImage coming soon 7575470000 CRANKSHAFT €207.01
003
 photo_cameraImage coming soon 5030630008 HEAD €100.36
004
 Crank Shaft for Pump Units FIAC AB 901-981-998 5041260008 Crank Shaft for Pump Units FIAC AB 901-981-998 €297.86
024
 Fiac Pumping Unit AB 678 Aftercooler 5130010008 Fiac Pumping Unit AB 678 Aftercooler €41.59
025
 photo_cameraImage coming soon 7232720000 COOLER €84.97
026
 FIAC AB678 Holder Oil Cap 5082090008 FIAC AB678 Holder Oil Cap €30.83
027
 FIAC AB678 Crankshaft Holder 5082050008 FIAC AB678 Crankshaft Holder €30.83
030
 Crank Shaft Ball Bearing for Pumping Units FIAC AB 671-678 7060160000 Crank Shaft Ball Bearing for Pumping Units FIAC AB 671-678 €20.38
031
 Main Bearing (6206) 9170020 0502210600 Main Bearing (6206) 9170020 €41.24
032
 FIAC Pump Unit AB268 Oil Sight Glass 9700000408 FIAC Pump Unit AB268 Oil Sight Glass €7.04
033
 Oil Venting Cap for Pumping Units FIAC AB 335-410-671-851-901 7091120000 Oil Venting Cap for Pumping Units FIAC AB 335-410-671-851-901 €4.34
034
 Oil Seal for Pumping Units FIAC AB 671-AB 901-981 7071130000 Oil Seal for Pumping Units FIAC AB 671-AB 901-981 €5.89
128
 photo_cameraImage coming soon 7230040000 Rilsan hose €5.99
305
 Air Filter Kit for Air Compressor Fiac AB678 9700002979 Air Filter Kit for Air Compressor Fiac AB678 €16.60
325
 Valve Plate Kit for Pump Unit FIAC AB 998 4231290000 Valve Plate Kit for Pump Unit FIAC AB 998 €162.18
356
 FIAC AB998 HP Conrod-Piston Kit 4081870000 FIAC AB998 HP Conrod-Piston Kit €178.06
357
 LP Con-Rod + Piston Kit for Pump Unit FIAC AB 998 4081880000 LP Con-Rod + Piston Kit for Pump Unit FIAC AB 998 €219.52
370
 Safety Valve M1/4-6 bar for Pumping Units Fiac 7192350000 Safety Valve M1/4-6 bar for Pumping Units Fiac €13.02
Page 3 zoom_in View exploded
Esploso pagina 3
Pos. Item Price Buy
KM1
 photo_cameraImage coming soon 1124080925 Easy kit AB678/858/998 €24.84
PK1
 photo_cameraImage coming soon 1124080929 Performance kit AB998 €178.82
HDK
 photo_cameraImage coming soon 1124080930 Heavy duty kit AB998 €179.82
305
 Air Filter Kit for Air Compressor Fiac AB678 9700002979 Air Filter Kit for Air Compressor Fiac AB678 €16.60
325
 Valve Plate Kit for Pump Unit FIAC AB 998 4231290000 Valve Plate Kit for Pump Unit FIAC AB 998 €162.18
330
 photo_cameraImage coming soon 1124080931 Upgrade kit AB998 €96.87
335
 Fiac AB998 Pump Unit Gaskets Kit 4081890000 Fiac AB998 Pump Unit Gaskets Kit €64.63
Page 4 zoom_in View exploded
Esploso pagina 4
Pos. Item Price Buy
375
 photo_cameraImage coming soon 1126002673 Can 1l fiac performance oil €17.68

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

FIAC SCS 958-C Spare Parts

We are FIAC PROFESSIONAL AIR COMPRESSORS original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Super Silent Belt Drive SCS 958-C-HP.7,5-V.400/50/3-CE 1121690294.

In the following table, look for the type of the Compressor and the respective parts of the code.
SCS 958-C-HP.7,5-V.400/50/3-CE 1121690294-

FIAC SCS 958-C-HP.7,5-V.400/50/3-CE 1121690294 Parts List
1121690294_00 Compressor package Pag.1
#
Part Num.
 Description
029
1127200125
 Flywheel
035
7011100000
 Screw
036
7030270000
 Flywheel washer
099
 Pump UNIT AB998S
103
7360340000
 Rubber foot
105
7190150000
 Non return valve
109
1504203002
 Pressure gauge
112
7083630000
 Delivery pipe fitting
125
2236112768
 PULLEY 140X2A-BUSH 2012
126
7371110000
 Belt a61
127
7234470000
 Rilsan tube SCS 500-600-95
131
 Pressure switch CONDOR 4VIE 10/16AMP.8-1
135
7380120000
 Motor M112 7.5HP V230/400/50-3
145
7231850000
 Air pipe COPPER D14 SCS 678/998
163
7234530000
 Hose COPPER D.14 SERB.USCITA SCS
469
5167360008
 Motor base SSA/SCS BLACK
472
5156280008
 TANK - DISCONTINUED
489
6266369400
 COUNTER_HOURS 380V 50HZ ABAC
1123020109_00 Pump Pag.2
#
Part Num.
 Description
001
 5070270008 Crankcase
002
7575470000
 Cylinder AB998
003
5030630008
 Cylinder head AB 998-NEW
004
 5041260008 Crankshaft
024
 Aftercooler FINALE AB-MONOSTAD.LAVORATO
025
7232720000
 Intercooler INTERM.AB 998-S-
026
 5082090008 Non drive end bearing housing AB 850 LAVOR
027
 5082050008 Drive end bearing housing AB 650 LAV.
030
 7060160000 Bearing 6006
031
0502210600
 Bearing 6206
032
 Oil sight glass 3/4'C/GUARN.METALLO
033
 Oil plug AB 410/510-GREEN
034
 Oil seal 30x47x7
128
7230040000
 Rilsan Ø6X4 PA11 WHITE
305
 Air filter AB671/998
325
 Valve Plate Kit AB 998
356
 4081870000 Piston conrod kit HP AB 998
357
 Piston conrod kit LP AB 998
370
 Relief valve 1/4 6 BAR
1122000025_00 Service kits Pag.3
#
Part Num.
 Description
305
 Air filter AB671/998
325
 Valve Plate Kit AB 998
330
1124080931
 Upgrade kit AB998
335
 All Gaskets Kit AB 998
KM1
1124080925
 Easy kit AB678/858/998
PK1
1124080929
 Performance kit AB998
HDK
1124080930
 Heavy duty kit AB998
1121690294_00 Lubricants Pag.4
#
Part Num.
 Description
375
1126002673
 Can 1l fiac performance oil
375
 Piston Oil pack 6x1l FIAC Performance
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
SCS 958-C 1121690294
6 Items

Data sheet

MORE INFO:
ON DEMAND ONLY
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT

Specific References

New

Download

Fiac SCS 958-C Parts Diagram

Fiac SCS 958-C Parts Diagram

Download (1.01MB)
