FIAC spa

FIAC New Silver 3-90 Parts

SKU: New Silver 3/90 1121680814
€472.98
VAT included

FIAC New Silver 3/90 9-bar Spare Parts

Fiac Genuine spare parts or replacement parts for to Fix New Silver 3/90 9-bar / V230-50 Hz 1121680814.
FIAC New Silver 3-90 Parts
  • Online only
  • FIAC New Silver 3-90 Parts
  • FIAC New Silver 3-90 Parts Diagram
  • FIAC New Silver 3-90 Parts Diagram - 1
FIAC spa

FIAC New Silver 3-90 Parts

SKU: New Silver 3/90 1121680814 Condition: New
€472.98
VAT included

FIAC New Silver 3/90 9-bar Spare Parts

Fiac Genuine spare parts or replacement parts for to Fix New Silver 3/90 9-bar / V230-50 Hz 1121680814.
settings 53 spare parts
description 2 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10/15 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
MORE INFO:: ON DEMAND ONLY
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
53 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 1124010139 Stator €445.84
3
 photo_cameraImage coming soon 1125140010 Handle €41.93
4
 photo_cameraImage coming soon 1125150258 Tank €332.12
22
 photo_cameraImage coming soon 1127200059 Fan €8.21
27
 photo_cameraImage coming soon 1127060065 Bearing €27.30
28
 photo_cameraImage coming soon 1127080016 Joint €11.42
29
 photo_cameraImage coming soon 1127080081 Joint €13.70
30
 photo_cameraImage coming soon 1127080100 Joint €9.65
31
 photo_cameraImage coming soon 1127080134 Joint €5.60
32
 photo_cameraImage coming soon 1127080219 Joint €4.29
33
 photo_cameraImage coming soon 1127080425 Joint €22.59
34
 photo_cameraImage coming soon 1127090003 Plug -receiver €1.18
35
 photo_cameraImage coming soon 1127090007 Plug €4.16
36
 photo_cameraImage coming soon 1127110018 Pressure gauge €20.50
37
 Drain Tap 3/8" for Air Compressor ABAC B26-50 CM2 1127130016 Drain Tap 3/8" for Air Compressor ABAC B26-50 CM2 €9.91
38
 photo_cameraImage coming soon 1127130057 TAP €12.80
39,2
 photo_cameraImage coming soon 1127150030 Side plastic schroud €192.26
39.2
 photo_cameraImage coming soon 1127150030 Side plastic schroud €192.26
39.3
 photo_cameraImage coming soon 1127150031 Side plastic schroud €180.49
39,3
 photo_cameraImage coming soon 1127150031 Side plastic schroud €180.49
39.4
 photo_cameraImage coming soon 1127150595 Instruments support €38.01
39,4
 photo_cameraImage coming soon 1127150595 Instruments support €38.01
39,1
 photo_cameraImage coming soon 1127150598 Upper cover €321.66
39.1
 photo_cameraImage coming soon 1127150598 Upper cover €321.66
40.3
 photo_cameraImage coming soon 1125160024 Instruments support €73.31
40,3
 photo_cameraImage coming soon 1125160024 Instruments support €73.31
41
 photo_cameraImage coming soon 1127190209 Safety Valve 3/8 10.4B €24.56
43
 photo_cameraImage coming soon 6211472650 Oil filter €23.31
45.1
 photo_cameraImage coming soon 1127210607 Intake filter €43.25
45,1
 photo_cameraImage coming soon 1127210607 Intake filter €43.25
46
 photo_cameraImage coming soon 1127210608 Oil separator filter €83.76
47
 photo_cameraImage coming soon 1127230001 RILSAN TUBE €8.78
48
 photo_cameraImage coming soon 1127230003 Rilsan hose €9.65
51
 photo_cameraImage coming soon 1127230884 Rubber hose €52.40
52
 photo_cameraImage coming soon 1127250002 Pressure switch €36.71
53
 photo_cameraImage coming soon 1127080210 FITTING €19.42
55
 FIAC New Silver 3/90 ON/OFF Switch 18A 1127300046 FIAC New Silver 3/90 ON/OFF Switch 18A €111.05
56
 photo_cameraImage coming soon 1127310053 Capacitor €35.40
59
 photo_cameraImage coming soon 1127380234 Terminal cover €4.16
60
 photo_cameraImage coming soon 1127380670 Fan cover €7.67
62
 photo_cameraImage coming soon 1127420343 Screw pump unit €2,405.21
63
 photo_cameraImage coming soon 1125160081 Motor Flange €164.81
65
 photo_cameraImage coming soon 1127500105 Cable clip €4.16
67
 photo_cameraImage coming soon 1127510674 Radiator €234.08
68
 photo_cameraImage coming soon 1127560002 Hour meter €45.86
69
 photo_cameraImage coming soon 1127560446 Oil Thermostat €87.68
70
 photo_cameraImage coming soon 1127640016 Covering €16.45
71
 photo_cameraImage coming soon 1129701523 Distributor €36.71
72
 photo_cameraImage coming soon 1127560103 Heather €60.23
73
 photo_cameraImage coming soon 1127090008 Plug €1.41
101
 photo_cameraImage coming soon 1124080315 Wheel kit €83.76
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
photo_cameraImage coming soon 1127210607 Intake filter €43.25
27
 photo_cameraImage coming soon 1127060065 Bearing €27.30
41
 photo_cameraImage coming soon 1127190209 Safety Valve 3/8 10.4B €24.56
43
 photo_cameraImage coming soon 6211472650 Oil filter €23.31
45.1
 photo_cameraImage coming soon 1127210607 Intake filter €43.25
45,1
 photo_cameraImage coming soon 1127210607 Intake filter €43.25
46
 photo_cameraImage coming soon 1127210608 Oil separator filter €83.76
51
 photo_cameraImage coming soon 1127230884 Rubber hose €52.40
200
 photo_cameraImage coming soon 1127120034 Maintenance oil €272.18
201
 Gasket kit 1124090522 Gasket kit €78.53
202
 photo_cameraImage coming soon 1124090201 Bearing kit €390.74
204
 photo_cameraImage coming soon 1124090203 Oil seal Kit €214.61
206
 photo_cameraImage coming soon 1124090527 Oil recovery hose kit €233.76
207
 photo_cameraImage coming soon 1120002646 Flange kit €369.36
208
 photo_cameraImage coming soon 1127190292 Safety valve €21.81
209
 photo_cameraImage coming soon 1127420073 Thermostatic valve kit €124.35

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

FIAC New Silver 3/90 9-bar Spare Parts

Fiac Genuine spare parts or replacement parts for to Fix New Silver 3/90 9-bar / V230-50 Hz 1121680814.

In the following table, look for the type of the Compressor and the respective parts of the code.
New Silver 3/90 9-bar

FIAC New Silver 3/90 9-bar / V230-50 Hz 1121680814 Parts List Pag.1
# Part Num. Description
1 1124010139 Stator
2 1124280094 Rotor kit
3 1125140010 Handle
4 1125150258 Tank
5 x Screw
6 x Screw
7 x Screw
8 x Screw
9 x Screw
10 x Screw
11 x Screw
12 x Screw
13 x Screw
14 x Tension rod
15 x Nut
16 x Nut
17 x Nut
18 x Nut
19 x Nut
20 x Washer
21 x Washer
22 1127200059 Fan
23 x Washer
24 x Washer
25 1127040327 Clamp
26 1127040334 Clamp
27 1127060065 Bearing
28 1127080016 Joint
29 1127080081 Joint
30 1127080100 Joint
31 1127080134 Joint
32 1127080219 Joint
33 1127080425 Joint
34 1127090003 Plug
35 1127090007 Plug
36 1127110018 Pressure gauge
37 1127130016 Discharge tap
38 1127130057 Universal Tap
39 1120011397 Plastic schroud kit
39,1 1127150598 Upper cover
39,2 1127150030 Side plastic schroud
39,3 1127150031 Side plastic schroud
39,4 1127150595 Instruments support
40 1127150596 Sheet metal Kit
40,1 1125160082 Base
40,2 1120004645 Press. reducer sup.
40,3 1125160024 Instruments support
40,4 1125160085 Front cover
40,5 1125160104 Conveyor
40,6 1125160139 Pressure switch Support
40,7 1125160143 Support
40,8 1125160145 Rear cover
40,9 1125160190 Support
41 1127190209 Safety valve
42 1127200157 Fan
43 6211472650 Oil filter
44 1127210451 Soundprof Kit
45 1127210292 Intake filter kit
45,1 1127210607 Intake filter
46 1127210608 Oil separator filter
47 1127230001 Rilsan hose
48 1127230003 Rilsan hose
49 1127230882 Rubber hose
50 1127230883 Rubber hose
51 1127230884 Rubber hose
52 1127250002 Pressure switch
53 1127080210 Joint
54 x Wheel
55 1127300046 Main switch
56 1127310053 Capacitor
57 1127320626 Infeed cable
58 x Wheel pin
59 1127380234 Terminal cover
60 1127380670 Fun Cover
61 1127410566 Elettric board
61,1 1120004647 Electric box
62 1127420343 Screw pump unit
63 1125160081 Motor Flange
64 1127480850 Thermostat Capsule
65 1127500105 Cable clamp
66 1127500106 Cable clamp
67 1127510674 Radiator
68 1127560002 Hour meter
69 1127560446 Oil Thermostat
70 1127640016 Covering
71 1129701523 Distributor
72 1127560103 Heather
73 1127090008 Plug
74 x Rubber Foot
101 1124080315 Wheel kit
102 1124080376 Rubber Foot Kit
Maintenance programs Pag.2
# Part Num. Description
A Maintenance program 500 Hours (3 months - 3 months)
43 6211472650 Oil filter
200 1127120034 Maintenance oil
B . Maintenance program 2500 Hours (1 Year - 1 year)
43 6211472650 Oil filter
45,1 1127210607 Intake filter
46 1127210608 Oil separator filter
200 1127120034 Maintenance oil
C . Maintenance program 5000 Hours (2 Years - 2 years)
43 6211472650 Oil filter
45,1 1127210607 Intake filter
46 1127210608 Oil separator filter
200 1127120034 Maintenance oil
206 1124090527 Oil recovery hose kit
205 1124090205 Intake valve kit
D . Maintenance program 7500 Hours (3 Years - 3 years)
43 6211472650 Oil filter
45,1 1127210607 Intake filter
46 1127210608 Oil separator filter
27 1127060065 Bearing
200 1127120034 Maintenance oil
203 1124090524 Minimun valve kit
209 1127420073 Thermostatic valve kit
41 1127190209 Safety valve
208 1127190292 Safety valve
E . Maintenance program 10000 Hours (4 years)
43 6211472650 Oil filter
45,1 1127210607 Intake filter
46 1127210608 Oil separator filter
200 1127120034 Maintenance oil
206 1124090527 Oil recovery hose kit
205 1124090205 Intake valve kit
49 1127230882 Rubber hose
50 1127230883 Rubber hose
51 1127230884 Rubber hose
201 1124090522 Gasket kit
F . Maintenance program 12500 Hours (5 years)
43 6211472650 Oil filter
45,1 1127210607 Intake filter
46 1127210608 Oil separator filter
200 1127120034 Maintenance oil
G . Maintenance program 15000 Hours (6 Years - 6 years)
43 6211472650 Oil filter
45,1 1127210607 Intake filter
46 1127210608 Oil separator filter
200 1127120034 Maintenance oil
206 1124090527 Oil recovery hose kit
205 1124090205 Intake valve kit
203 1124090524 Minimun valve kit
209 1127420073 Thermostatic valve kit
27 1127060065 Bearing
41 1127190209 Safety valve
208 1127190292 Safety valve
H . Maintenance program 17500 Hours (7 years)
43 6211472650 Oil filter
45,1 1127210607 Intake filter
46 1127210608 Oil separator filter
200 1127120034 Maintenance oil
I . Maintenance program 20000 Hours (8 years)
43 6211472650 Oil filter
45,1 1127210607 Intake filter
46 1127210608 Oil separator filter
200 1127120034 Maintenance oil
49 1127230882 Rubber hose
50 1127230883 Rubber hose
51 1127230884 Rubber hose
201 1124090522 Gasket kit
202 1124090201 Bearing kit
203 1124090524 Minimun valve kit
204 1124090203 Oil seal Kit
205 1124090205 Intake valve kit
206 1124090527 Oil recovery hose kit
207 1120002646 Flange kit
208 1127190292 Safety valve
209 1127420073 Thermostatic valve kit
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
New Silver 3/90 1121680814
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS
MORE INFO:
ON DEMAND ONLY
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT

Specific References

New

Download

Fiac New Silver 3/90 Diagram

Fiac New Silver 3/90 Diagram

Download (679.96KB)

You might also like

FIAC New Silver 3/90 ON/OFF Switch 18A
FIAC spa SKU: 1127300046
FIAC New Silver 3/90 ON/OFF Switch 18A
FIAC ON/OFF Switch 18A for Air Compressor New Silver 3/90 Fiac Genuine Spare Parts, ON/OFF Switch 18A for Air Compressor New Silver 3/90 1121680814. Part for the following products: - FIAC New Silver 3/90 1121680814 -...
Usually Ships in: 10/15 Business Days Approx. €111.05
Details
Comments (0)
