| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
1A
|
|
7383760000 Electric motor 230V compressor - Motor elettrico compressore 230V | €0.11 | Not available for order |
|
1
|
|
7385000000 Electric motor 400V compressor - Motor elettrico compressore 400V | €7,441.12 | |
|
2
|
|
7583450000 Fan connection - Mozzo Fan | €0.11 | Not available for order |
|
3
|
|
7200011500 Fan - Fan 50Hz | €403.17 | |
|
3A
|
|
7201350000 Fan - Fan 60Hz | €0.11 | Not available for order |
|
4
|
|
7030030000 Washer 8 UNI-6592 | €1.42 | Not available for order |
|
5
|
|
7031010000 Washer 8 UNI-3703 | €1.51 | |
|
6
|
|
7011090000 Screw M8x20 UNI-5739 | €1.52 | |
|
7
|
|
7014190000 Screw - Screw STEI M8x30 | €0.00 | Not available for order |
|
8
|
|
7020070000 Nut M8 UNI-5587 | €1.48 | |
|
9
|
|
7011660000 Screw - Screw TE M18x50 | €4.32 | |
|
10
|
|
7423230000 Air end - Vite completa B170D | €0.11 | Not available for order |
|
11
|
|
7020140000 Nut - Nut M18 | €0.00 | Not available for order |
|
12
|
|
7030610000 Washer - Washer Ø18 | €0.00 | Not available for order |
|
13
|
|
7012800000 Screw - Screw TE M18x30 | €4.89 | |
|
14
|
|
7030600000 Toothed washer - Washer dentata Ø18 | €0.00 | Not available for order |
|
15
|
|
7172140000 Support - Support Motor | €0.11 | Not available for order |
|
16
|
|
7510790000 Support - Plate trasmissione Motor | €0.11 | Not available for order |
|
17
|
|
7234020000 Hose - Tube iniezione | €228.53 | |
|
18
|
|
7020100000 Nut M12 UNI-5588 | €17.63 | |
|
19
|
|
7030140000 Washer Ø12 UNI-6592 | €4.23 | Not available for order |
|
20
|
|
7459440000 Guide - Guida Spring | €36.40 | |
|
21
|
|
7160280000 Tensioning spring - Spring tensionatore | €36.57 | |
|
22
|
|
7459430000 Guide - Guida Plate | €36.40 | |
|
23
|
|
7011620000 Screw - Screw TE M16x35 | €0.00 | Not available for order |
|
24
|
|
7010050000 Screw M8X20 UNI-5931 | €1.52 | |
|
25
|
|
7018650000 Screw bolt - Pin tenditore | €36.40 | |
|
26
|
|
7024200000 Nut - Nut M16 | €0.00 | Not available for order |
|
27
|
|
7030490000 Toothed washer - Washer dentata Ø16 | €0.00 | Not available for order |
|
28
|
|
7030730000 Washer - Washer Ø16 | €0.00 | Not available for order |
|
29
|
|
7583100000 Connection - Mozzo | €0.11 | Not available for order |
|
30A
|
|
7370840000 Belt - Cinghia (10bar) | €268.07 | |
|
30
|
|
7371380000 Belt - Belt (8bar) | €388.32 | |
|
30B
|
|
7371470000 Belt - Cinghia (13bar) | €192.91 | |
|
31
|
|
7407140000 Pulley - Puleggia vite Øp193 (8bar 50Hz) | €0.11 | Not available for order |
|
31B
|
|
7407180000 Pulley - Puleggia vite Øp153 (13bar 50Hz) | €0.11 | Not available for order |
|
31C
|
|
7407180000 Pulley - Puleggia vite Øp153 (13bar 50Hz) | €0.11 | Not available for order |
|
31D
|
|
7407200000 Pulley - Puleggia vite Øp173 (10bar 50Hz) | €0.11 | Not available for order |
|
31A
|
|
7407200000 Pulley - Puleggia vite Øp173 (10bar 50Hz) | €0.11 | Not available for order |
|
31E
|
|
7407210000 Pulley - Puleggia vite Øp132 (13bar 60Hz) | €0.11 | Not available for order |
|
32
|
|
7407170000 Pulley - Puleggia motore Øp 125 (8-10-13bar 50Hz - 8bar 60Hz) | €0.11 | Not available for order |
|
32A
|
|
7407180000 Pulley - Puleggia vite Øp153 (13bar 50Hz) | €0.11 | Not available for order |
|
32B
|
|
7407210000 Pulley - Puleggia vite Øp132 (13bar 60Hz) | €0.11 | Not available for order |
|
33
|
|
7511240000 Plate - Plate | €0.11 | Not available for order |
|
34
|
|
7583021400 Connection - Mozzo | €264.17 | |
|
35
|
|
7070650000 Or - Or Flange of mandata | €5.12 | |
|
36
|
|
7488290000 Delivery flange - Flange of mandata | €324.11 | |
|
37
|
|
7010610000 Screw - Vite TCCE M12x60 | €0.11 | Not available for order |
|
38
|
|
4094540000 Oil seal kit (See kit assembling table) - Kit paraolio (Vedi tavola assemblaggio kit) | €465.48 | Not available for order |
|
39
|
|
4094550000 Bearings kit+Oil seal kit (See kit assembling table) - Kit cuscinetti+Kit paraolio (Vedi tavola assemblaggio kit) | €0.11 | Not available for order |
|
40
|
|
7079630000 Gasket - Gasket Valve of Intake | €9.68 | |
|
41
|
|
7195860000 Suction valve - Valve of Intake | €2,012.38 | |
|
42
|
|
7082600000 Suction valve maintenance kit (See kit assembling table) - Kit manutenzione valvola di aspirazione (Vedi tavola assemblaggio kit | €180.01 | |
|
43
|
|
7085940000 Joint - Riduzione 1/2" x 3/8" | €122.11 | |
|
44
|
|
4111800000 Sensor - Sensore temperatura | €0.11 | Not available for order |
|
45
|
|
7080200000 JOINT | €6.51 | |
|
46
|
|
7085180000 Fitting 1 / 4-1 / 8 MF | €6.97 | |
|
47
|
|
7011480000 Screw M6X12 UNI-5739 | €0.00 | Not available for order |
|
48
|
|
7030190000 Washer Ø6,4X18X1,5 UNI-6593 | €0.00 | Not available for order |
|
49
|
|
7010400000 Screw - Screw TCCE M12x40 | €0.00 | Not available for order |
|
50
|
|
7080890000 Joint | €13.84 | Not available for order |
|
51
|
|
7043011500 Clamp - Fascetta | €9.68 | |
|
52
|
|
7080780000 FITTING | €13.18 | Not available for order |
|
53
|
|
7212050000 Air filter - Filter aria | €240.62 | |
|
54
|
|
7212050010 Air filter cartridge - Cartuccia Filter aria | €65.47 | |
|
55
|
|
4094250000 Filters kit - Kit filtri | €666.74 | |
|
56
|
|
4094220000 Maintenance kit - Kit manutenzione | €1,518.34 | |
|
57
|
|
7473420000 Separator tank - Serbatoio separatore | €3,163.95 | |
|
58
|
|
7081011300 Joint - Nipplo 1"1/4 | €43.25 | |
|
59
|
|
7090490000 Plug - Cap 1" with Washer | €0.00 | Not available for order |
|
60
|
|
7030460000 Washer | €4.23 | |
|
61
|
|
7180140000 Oil level sight glass - Spia livello olio | €64.91 | |
|
62
|
|
7562600000 Relief valve | €128.28 | |
|
63
|
|
7011160000 Screw M10x30 UNI-5739 | €1.52 | |
|
64
|
|
7030360000 Washer 10 UNI-3703 | €0.00 | Not available for order |
|
65
|
|
7030040000 Washer Ø10 UNI-6592 | €1.45 | Not available for order |
|
66
|
|
7084010000 Joint - fitting 1/8" with ogiva | €9.68 | |
|
67
|
|
7080040000 Joint - Raccordo "L" 3/4" MF | €9.86 | |
|
68
|
|
7192110000 SAFETY VALVE | €47.17 | |
|
68A
|
|
7192800000 Safety valve - Valve of sicurezza 3/4" (14bar) | €81.15 | |
|
69
|
|
7018620000 Spacer - Distanziale M6x35 | €9.68 | |
|
70
|
|
7080870000 Joint - fitting "L" 1/8" MF | €4.49 | |
|
71
|
|
7250700000 Pressure switch for separator filter clogging - Pressostato intasamento filtro disoleatore (8 bar) | €51.13 | |
|
71A
|
|
7250710000 Pressure switch for separator filter clogging - Pressostato intasamento filtro disoleatore (10 bar) | €95.69 | |
|
71B
|
|
7250750000 Pressure switch for separator filter clogging - Pressostato intasamento filtro disoleatore (13 bar) | €87.60 | |
|
72
|
|
7015380000 Screw - Screw STEI M12x60 | €4.00 | |
|
73
|
|
7211410000 Separator cartdridge - Filter disoleatore | €202.71 | |
|
74
|
|
7079650000 O-ring 3187 | €41.31 | |
|
75
|
|
5158790008 Cover - Cover disoleatore | €0.11 | Not available for order |
|
76
|
|
7191010000 RETAINING VALVE | €8.03 | |
|
77
|
|
7080180000 The 1/4 MF Connection | €8.35 | |
|
78
|
|
7240490000 Belt guard - Paracinghia | €92.77 | |
|
79
|
|
5166050008 Conveyor - Convogliatore | €148.36 | |
|
80
|
|
7230010000 Black Rilsan Tube Ø 6X4 for Compressors Fiac | €2.57 | |
|
81
|
|
7020080000 Nut M10 UNI-5588 | €0.98 | |
|
82
|
|
7090460000 Washer - Washer 1" | €0.11 | Not available for order |
|
83
|
|
7081700000 Joint - Nipplo 1"1/4x1" | €0.11 | Not available for order |
|
84
|
|
7196300000 Minimum pressure valve - Valve of minima pressione | €517.73 | |
|
85
|
|
7231330000 Hose - Tube pescaggio olio | €229.87 | |
|
86
|
|
4093270000 Joint kit | €48.17 | |
|
87
|
|
7239140000 Hose - Tube recupero olio | €33.31 | |
|
88
|
|
7030750000 Toothed washer - Washer dentata Ø12 | €0.00 | Not available for order |
|
89
|
|
7364530000 Shock absorbe - Antivibranti | €44.13 | |
|
90
|
|
7080780000 FITTING | €13.18 | Not available for order |
|
91
|
|
7082300000 Joint - fitting "T" 1/8"x6 | €16.34 | |
|
92
|
|
7080810000 Joint | €13.18 | Not available for order |
|
93
|
|
7194330000 Solenoid valve - Elettrovalvola | €1,311.15 | Not available for order |
|
94
|
|
7085600000 Joint - fitting 1/2" 1/4" MF | €19.55 | |
|
95
|
|
7084220000 Fitting DIR.M1 / 4 "-6 QUICK | €5.03 | |
|
96
|
|
7194340000 Solenoid valve | €353.03 | |
|
97
|
|
7230010000 Black Rilsan Tube Ø 6X4 for Compressors Fiac | €2.57 | |
|
98
|
|
7232820000 Hose - Tube mandata | €342.57 | |
|
99
|
|
7012290000 Screw M5X20 TAP-TITE | €24.21 | Not available for order |
|
100
|
|
7155700008 Support - Bracket | €0.11 | Not available for order |
|
101
|
|
7011480000 Screw M6X12 UNI-5739 | €0.00 | Not available for order |
|
102
|
|
5160860008 Support | €17.15 | |
|
103
|
|
7016220000 Screw - Screw S.T.E.I. M12x30 | €0.00 | Not available for order |
|
104
|
|
5165850008 Base - Base | €1,372.98 | |
|
105
|
|
7011270000 Screw | €1.34 | |
|
106
|
|
7084650000 Joint - Raccordo "L" 3/4" MF | €70.57 | |
|
107
|
|
7010520000 Screw - Screw T.C.C.E. M6x55 | €0.00 | Not available for order |
|
108
|
|
7195810000 Thermostatic - Termostatica | €456.82 | |
|
109
|
|
7081390000 Joint - Nipplo 3/4" MM | €28.79 | |
|
110
|
|
7211131500 Oil filter - Filter olio | €47.17 | |
|
111
|
|
7081120000 Joint - Nipplo 3/4" MM | €10.56 | |
|
112
|
|
7236270000 Hose - Tube mandata aria 1"1/4 | €0.11 | Not available for order |
|
113
|
|
7180110000 FITTING "L" X AC1300 | €121.62 | |
|
114
|
|
7081140000 Joint 1/4" MM | €6.97 | |
|
115
|
|
7564020000 Device for air filter clogging - Dispoditivo intasamento filtro aria | €77.87 | |
|
116
|
|
7562600010 Valve | €43.84 | |
|
117
|
|
7233450000 Hose - Tube recupero olio | €20.15 | |
|
118
|
|
7196540000 Thermostatic valve kit 2200599825 | €136.06 |
| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
130
|
|
5118000008 Compressor base - Base compressore | €0.11 | Not available for order |
|
131
|
|
5162360008 Panel - Pannello intermedio upper nero | €398.54 | |
|
132
|
|
5165860008 Panel - Pannello intermedio lower nero | €273.44 | |
|
133
|
|
7413290000 Electric board - Apperecchiatura elettrica | €0.11 | Not available for order |
|
134
|
|
7020070000 Nut M8 UNI-5587 | €1.48 | |
|
135
|
|
7031010000 Washer 8 UNI-3703 | €1.51 | |
|
136
|
|
7583190000 Fan conveyor - Convogliatore aria | €0.11 | Not available for order |
|
137
|
|
5166080000 Support - Support montanti | €0.11 | Not available for order |
|
138
|
|
7030030000 Washer 8 UNI-6592 | €1.42 | Not available for order |
|
139
|
|
7081100000 3/8 " | €8.35 | |
|
140
|
|
7111040000 Pressure gauge | €71.49 | |
|
141
|
|
5165960008 Angular - Angolare posteriore upper | €105.12 | |
|
142
|
|
7030560000 Washer - Washer Ø5x20 | €0.00 | Not available for order |
|
143
|
|
5165980008 Angular - Angolare right lower | €117.48 | |
|
144
|
|
7080800000 Joint | €9.26 | |
|
145
|
|
7012240000 Screw M5X15 UNI-8112 | €5.34 | Not available for order |
|
146
|
|
5165940008 Angular - Angolare lower anteriore/posteriore | €97.40 | |
|
147
|
|
5166040008 Column - Montante right anteriore | €278.09 | |
|
148
|
|
7360340000 Rubber Foot | €20.85 | Not available for order |
|
149
|
|
7020080000 Nut M10 UNI-5588 | €0.98 | |
|
150
|
|
7030040000 Washer Ø10 UNI-6592 | €1.45 | Not available for order |
|
151
|
|
5165950008 Angular - Angolare upper anteriore | €105.12 | |
|
152
|
|
5165930008 Panel - Sportello cassetta elettrica | €313.61 | |
|
153
|
|
7018590000 Hinge | €57.60 | |
|
154
|
|
7014140000 Screw | €4.23 | |
|
155
|
|
7020060000 M6 nut UNI-5587 | €0.00 | Not available for order |
|
156
|
|
7458640000 Key hole | €17.93 | |
|
157
|
|
7458650000 Key | €13.84 | |
|
158
|
|
7500410000 Stretch eliminator - Pressacavo M40x1,5 | €20.19 | |
|
159
|
|
7090440000 Plug - Cap M20x1,5 | €0.00 | Not available for order |
|
160
|
|
5165920008 Electric box - Cassetta elettrica | €776.89 | |
|
161
|
|
4111810000 Pressure sensor - Sensore of pressione | €0.11 | Not available for order |
|
162
|
|
7300230000 RESET Push-button | €50.33 | |
|
163
|
|
7500440000 Stretch eliminator | €4.16 | Not available for order |
|
164
|
|
7432760000 Fuse carrier | €22.83 | |
|
165
|
|
7080800000 Joint | €9.26 | |
|
166
|
|
7230010000 Black Rilsan Tube Ø 6X4 for Compressors Fiac | €2.57 | |
|
167
|
|
7084310000 Joint - fitting diritto 1/8"x6 with ogiva | €7.37 | |
|
168
|
|
7239130000 Hose - Tube rame aria | €22.79 | |
|
169
|
|
7080800000 Joint | €9.26 | |
|
170
|
|
7300080000 EMERGENCY BUTTON | €0.11 | Not available for order |
|
171
|
|
7012240000 Screw M5X15 UNI-8112 | €5.34 | Not available for order |
|
172
|
|
7433090000 Electronic panel | €1,250.10 | Not available for order |
|
173
|
|
7500430000 Stretch eliminator - Pressacavo M16x1.5 | €1.35 | |
|
174
|
|
5165970008 Angular - Angolare right upper | €123.66 | |
|
175
|
|
5162990008 Support | €23.63 | |
|
176
|
|
7070580000 Gasket - Gasket pannello portastrumenti | €46.45 | |
|
177
|
|
5164530008 Support | €23.63 | |
|
178
|
|
7155450000 Dashboard - Pannello portastrumenti | €0.11 | Not available for order |
|
179
|
|
7510660000 Electric base - Base impianto elettrico | €724.09 | |
|
180
|
|
7564260000 Transformer | €302.02 | |
|
181
|
|
7031010000 Washer 8 UNI-3703 | €1.51 | |
|
182
|
|
7020070000 Nut M8 UNI-5587 | €1.48 | |
|
183A
|
|
7432770000 Relay 230V compressor | €388.90 | |
|
183
|
|
7433030000 Relay 400V compressor | €389.50 | |
|
184
|
|
7432300000 Contactor 400V compressor - Contattore compressore 400V K3 | €618.44 | |
|
184A
|
|
7432400000 Contactor 230V compressor - Contattore compressore 230V K3 | €1,358.51 | |
|
185
|
|
7432390000 Contactor 400V compressor - Contattore compressore 400V K1-K2 | €0.11 | Not available for order |
|
185A
|
|
7432840000 Contactor 230V compressor - Contattore compressore 230V K1-K2 | €0.11 | Not available for order |
|
186
|
|
7432480000 Thermal relay 400V compressor - Rele termico compressore 400V F1 | €505.09 | |
|
186A
|
|
7432580000 Thermal relay 230V compressor - Rele termico compressore 230V F1 | €0.11 | Not available for order |
|
187
|
|
7432840000 Contactor 230V compressor - Contattore compressore 230V K1-K2 | €0.11 | Not available for order |
|
188
|
|
7432720000 Fuse | €4.23 | |
|
189
|
|
7431640000 Fuse | €4.23 | |
|
190
|
|
7432730000 Fuse | €4.23 | |
|
191
|
|
5166350008 Column - Montante right posteriore | €1,019.34 |
| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
200
|
|
5166020008 Panel - Pannello right apribile | €0.11 | Not available for order |
|
201
|
|
5166010008 Panel - Pannello posteriore fisso | €0.11 | Not available for order |
|
202
|
|
7288030000 Handle | €23.61 | |
|
203
|
|
7459370000 Key hole | €41.20 | |
|
204
|
|
7018590000 Hinge | €57.60 | |
|
205
|
|
7014140000 Screw | €4.23 | |
|
206
|
|
5166030008 Panel - Pannello upper apribile | €0.11 | Not available for order |
|
207
|
|
5166000008 Panel - Pannello Intake right | €0.11 | Not available for order |
|
208
|
|
7512170000 Panel | €21.05 | |
|
209
|
|
5165870008 Panel - Pannello Intake dx | €0.11 | Not available for order |
|
210
|
|
5165910008 Panel - Pannello chiusura Intake | €0.00 | Not available for order |
|
211
|
|
7517430000 Radiator | €929.92 | |
|
212
|
|
5165880008 Panel - Pannello Intake left | €0.11 | Not available for order |
|
213
|
|
5165910008 Panel - Pannello chiusura Intake | €0.00 | Not available for order |
|
214
|
|
7014150000 Screw - Screw M5x15 | €0.00 | Not available for order |
|
215
|
|
7458650000 Key | €13.84 | |
|
216
|
|
7014450000 Screw | €4.23 | Not available for order |
|
217
|
|
5165890008 Panel - Pannello intermedio Intake nero | €0.11 | Not available for order |
|
218
|
|
7011040000 Screw M6X20 UNI-5739 | €1.52 | |
|
219
|
|
7030020000 Ø6 washer UNI-6592 | €0.00 | Not available for order |
|
220
|
|
7160800000 Spring - Spring a gas | €0.11 | Not available for order |
|
221
|
|
7012240000 Screw M5X15 UNI-8112 | €5.34 | Not available for order |
|
222
|
|
5161200008 Support - Support right prefiltro | €43.84 | |
|
223
|
|
7173410000 Support - Bracket | €0.11 | Not available for order |
|
224
|
|
5161190008 Support - Support left prefiltro | €43.84 | |
|
225
|
|
7210830000 Pre-filter - Prefiltro | €162.11 | |
|
226
|
|
7014050000 Screw - Screw M4x25 | €0.11 | Not available for order |
|
227
|
|
7030180000 Washer Ø4 UNI-6592 | €0.00 | Not available for order |
| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
1
|
|
7082600000 Suction valve maintenance kit (See kit assembling table) - Kit manutenzione valvola di aspirazione (Vedi tavola assemblaggio kit | €180.01 | |
|
2
|
|
4094540000 Oil seal kit (See kit assembling table) - Kit paraolio (Vedi tavola assemblaggio kit) | €465.48 | Not available for order |
|
3+2
|
|
4094550000 Bearings kit+Oil seal kit (See kit assembling table) - Kit cuscinetti+Kit paraolio (Vedi tavola assemblaggio kit) | €0.11 | Not available for order |
Shipping and delivery information will be available shortly.
We are FIAC PROFESSIONAL AIR COMPRESSORS original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Super Silent Belt Drive Rotary Screw Compressor AIRBLOK 60.
In the following table, look for the type of the Compressor and the respective parts of the code.
| FIAC AIRBLOK60 8 BAR 10 BAR 13 BAR - B170D Spare Parts Pag.1 | ||
| # | Part Num. |
Description |
| 1 | 7385000000 | Electric motor 400V compressor - Motore elettrico compressore 400V |
| 1A | 7383760000 | Electric motor 230V compressor - Motore elettrico compressore 230V |
| 2 | 7583450000 | Fan connection - Mozzo ventola |
| 3 | 7200011500 | Fan - Ventola 50Hz |
| 3A | 7201350000 | Fan - Ventola 60Hz |
| 4 | 7030030000 | Washer - Rondella Ø8 |
| 5 | 7031010000 | Toothed washer - Rondella dentata Ø8 |
| 6 | 7011090000 | Screw - Vite TE M8x20 |
| 7 | 7014190000 | Screw - Vite STEI M8x30 |
| 8 | 7020070000 | Nut - Dado M8 |
| 9 | 7011660000 | Screw - Vite TE M18x50 |
| 10 | 7423230000 | Air end - Vite completa B170D |
| 11 | 7020140000 | Nut - Dado M18 |
| 12 | 7030610000 | Washer - Rondella Ø18 |
| 13 | 7012800000 | Screw - Vite TE M18x30 |
| 14 | 7030600000 | Toothed washer - Rondella dentata Ø18 |
| 15 | 7172140000 | Support - Supporto motore |
| 16 | 7510790000 | Support - Piastra trasmissione motore |
| 17 | 7234020000 | Hose - Tubo iniezione |
| 18 | 7020100000 | Nut - Dado M12 |
| 19 | 7030140000 | Washer - Rondella Ø12 |
| 20 | 7459440000 | Guide - Guida molla |
| 21 | 7160280000 | Tensioning spring - Molla tensionatore |
| 22 | 7459430000 | Guide - Guida piastra |
| 23 | 7011620000 | Screw - Vite TE M16x35 |
| 24 | 7010050000 | Screw - Vite TCCE M8x20 |
| 25 | 7018650000 | Screw bolt - Perno tenditore |
| 26 | 7024200000 | Nut - Dado M16 |
| 27 | 7030490000 | Toothed washer - Rondella dentata Ø16 |
| 28 | 7030730000 | Washer - Rondella Ø16 |
| 29 | 7583100000 | Connection - Mozzo |
| 30 | 7371380000 | Belt - Cinghia (8bar) |
| 30A | 7370840000 | Belt - Cinghia (10bar) |
| 30B | 7371470000 | Belt - Cinghia (13bar) |
| 31 | 7407140000 | Pulley - Puleggia vite Øp193 (8bar 50Hz) |
| 31A | 7407200000 | Pulley - Puleggia vite Øp173 (10bar 50Hz) |
| 31B | 7407180000 | Pulley - Puleggia vite Øp153 (13bar 50Hz) |
| 31C | 7407180000 | Pulley - Puleggia vite Øp153 (8bar 60Hz) |
| 31D | 7407200000 | Pulley - Puleggia vite Øp173 (10bar 60Hz) |
| 31E | 7407210000 | Pulley - Puleggia vite Øp132 (13bar 60Hz) |
| 32 | 7407170000 | Pulley - Puleggia motore Øp 125 (8-10-13bar 50Hz - 8bar 60Hz) |
| 32A | 7407180000 | Pulley - Puleggia motore Øp 153 (10bar 60Hz) |
| 32B | 7407210000 | Pulley - Puleggia motore Øp 132 (13bar 60Hz) |
| 33 | 7511240000 | Plate - Piastra |
| 34 | 7583021400 | Connection - Mozzo |
| 35 | 7070650000 | Or - Or flangia di mandata |
| 36 | 7488290000 | Delivery flange - Flangia di mandata |
| 37 | 7010610000 | Screw - Vite TCCE M12x60 |
| 38 | 4094540000 | Oil seal kit (See kit assembling table) - Kit paraolio (Vedi tavola assemblaggio kit) |
| 39 | 4094550000 | Bearings kit+Oil seal kit (See kit assembling table) - Kit cuscinetti+Kit paraolio (Vedi tavola assemblaggio kit) |
| 40 | 7079630000 | Gasket - Guarnizione valvola di aspirazione |
| 41 | 7195860000 | Suction valve - Valvola di aspirazione |
| 42 | 7082600000 | Suction valve maintenance kit (See kit assembling table) - Kit manutenzione valvola di aspirazione (Vedi tavola assemblaggio kit) |
| 43 | 7085940000 | Joint - Riduzione |
| 44 | 4111800000 | Sensor - Sensore temperatura |
| 45 | 7080200000 | Joint - Raccordo "L" 1/8" con ogiva |
| 46 | 7085180000 | Joint - Riduzione |
| 47 | 7011480000 | Screw - Vite TE M6x12 |
| 48 | 7030190000 | Washer - Rondella Ø6x18 |
| 49 | 7010400000 | Screw - Vite TCCE M12x40 |
| 50 | 7080890000 | Joint - Raccordo "L" 1/4"x6 |
| 51 | 7043011500 | Clamp - Fascetta |
| 52 | 7080780000 | Joint - Raccordo "L" 1/8"x6 |
| 53 | 7212050000 | Air filter - Filtro aria |
| 54 | 7212050010 | Air filter cartridge - Cartuccia filtro aria |
| 55 | 4094250000 | Filters kit - Kit filtri |
| 56 | 4094220000 | Maintenance kit - Kit manutenzione |
| 57 | 7473420000 | Separator tank - Serbatoio separatore |
| 58 | 7081011300 | Joint - Nipplo 1"1/4 |
| 59 | 7090490000 | Plug - Tappo 1" con rondella |
| 60 | 7030460000 | Washer - Rondella |
| 61 | 7180140000 | Oil level sight glass - Spia livello olio |
| 62 | 7562600000 | Relief valve - Scaricatore olio 1/2" |
| 63 | 7011160000 | Screw - Vite TE M10x30 |
| 64 | 7030360000 | Toothed washer - Rondella dentata Ø10 |
| 65 | 7030040000 | Washer - Rondella Ø10 |
| 66 | 7084010000 | Joint - Raccordo 1/8" con ogiva |
| 67 | 7080040000 | Joint - Raccordo "L" 3/4" MF |
| 68 | 7192110000 | Safety valve - Valvola di sicurezza 3/4" (10,4bar) |
| 68A | 7192800000 | Safety valve - Valvola di sicurezza 3/4" (14bar) |
| 69 | 7018620000 | Spacer - Distanziale M6x35 |
| 70 | 7080870000 | Joint - Raccordo "L" 1/8" MF |
| 71 | 7250700000 | Pressure switch for separator filter clogging - Pressostato intasamento filtro disoleatore (8 bar) |
| 71A | 7250710000 | Pressure switch for separator filter clogging - Pressostato intasamento filtro disoleatore (10 bar) |
| 71B | 7250750000 | Pressure switch for separator filter clogging - Pressostato intasamento filtro disoleatore (13 bar) |
| 72 | 7015380000 | Screw - Vite STEI M12x60 |
| 73 | 7211410000 | Separator cartdridge - Filtro disoleatore |
| 74 | 7079650000 | Gasket - Guarnizione |
| 75 | 5158790008 | Cover - Coperchio disoleatore |
| 76 | 7191010000 | Valve - Valvola flusso unidirezionale |
| 77 | 7080180000 | Joint - Raccordo "L" 1/4" MF |
| 78 | 7240490000 | Belt guard - Paracinghia |
| 79 | 5166050008 | Conveyor - Convogliatore |
| 80 | 7230010000 | Rilsan hose - Tubo Rilsan nero |
| 81 | 7020080000 | Nut - Dado M10 |
| 82 | 7090460000 | Washer - Rondella 1" |
| 83 | 7081700000 | Joint - Nipplo 1"1/4x1" |
| 84 | 7196300000 | Minimum pressure valve - Valvola di minima pressione |
| 85 | 7231330000 | Hose - Tubo pescaggio olio |
| 86 | 4093270000 | Joint - Raccordo ad asta 1/4" |
| 87 | 7239140000 | Hose - Tubo recupero olio |
| 88 | 7030750000 | Toothed washer - Rondella dentata Ø12 |
| 89 | 7364530000 | Shock absorbe - Antivibranti |
| 90 | 7080780000 | Joint - Raccordo "L" |
| 91 | 7082300000 | Joint - Raccordo "T" 1/8"x6 |
| 92 | 7080810000 | Joint - Raccordo "L" 1/4"x8 |
| 93 | 7194330000 | Solenoid valve - Elettrovalvola |
| 94 | 7085600000 | Joint - Raccordo 1/2" 1/4" MF |
| 95 | 7084220000 | Joint - Raccordo diritto 1/4"x6 |
| 96 | 7194340000 | Solenoid valve - Elettrovalvola |
| 97 | 7230010000 | Rilsan hose - Tubo Rilsan |
| 98 | 7232820000 | Hose - Tubo mandata |
| 99 | 7012290000 | Screw - Vite T.C. M5x20 |
| 100 | 7155700008 | Support - Staffa |
| 101 | 7011480000 | Screw - Vite TE M6x12 |
| 102 | 5160860008 | Support - Staffa |
| 103 | 7016220000 | Screw - Vite S.T.E.I. M12x30 |
| 104 | 5165850008 | Base - Base |
| 105 | 7011270000 | Screw - Vite TE M12x30 |
| 106 | 7084650000 | Joint - Raccordo "L" 3/4" |
| 107 | 7010520000 | Screw - Vite T.C.C.E. M6x55 |
| 108 | 7195810000 | Thermostatic - Termostatica |
| 109 | 7081390000 | Joint - Nipplo 3/4" |
| 110 | 7211131500 | Oil filter - Filtro olio |
| 111 | 7081120000 | Joint - Nipplo 3/4" |
| 112 | 7236270000 | Hose - Tubo mandata aria 1"1/4 |
| 113 | 7180110000 | Joint - Raccordo |
| 114 | 7081140000 | Joint - Nipplo 1/4" |
| 115 | 7564020000 | Device for air filter clogging - Dispoditivo intasamento filtro aria |
| 116 | 7562600010 | Relief valve - Scaricatore olio 1/2" |
| 117 | 7233450000 | Hose - Tubo recupero olio |
| 118 | 7196540000 | Thermostatic valve kit - Kit valvola termostatica |
| Pag.2 | ||
| 130 | 5118000008 | Compressor base - Base compressore |
| 131 | 5162360008 | Panel - Pannello intermedio superiore nero |
| 132 | 5165860008 | Panel - Pannello intermedio inferiore nero |
| 133 | 7413290000 | Electric board - Apperecchiatura elettrica |
| 134 | 7020070000 | Nut - Dado M8 |
| 135 | 7031010000 | Washer - Rondella Ø8 |
| 136 | 7583190000 | Fan conveyor - Convogliatore aria |
| 137 | 5166080000 | Support - Supporto montanti |
| 138 | 7030030000 | Washer - Rondella Ø8 |
| 139 | 7081100000 | Screw - Vite TE M8x25 |
| 140 | 7111040000 | Pressure gauge - Manometro |
| 141 | 5165960008 | Angular - Angolare posteriore superiore |
| 142 | 7030560000 | Washer - Rondella Ø5x20 |
| 143 | 5165980008 | Angular - Angolare destro inferiore |
| 144 | 7080800000 | Joint - Raccordo a "L" 1/8"x6 |
| 145 | 7012240000 | Screw - Vite M5x15 |
| 146 | 5165940008 | Angular - Angolare inferiore anteriore/posteriore |
| 147 | 5166040008 | Column - Montante destro anteriore |
| 148 | 7360340000 | Shock absorber - Antivibranti |
| 149 | 7020080000 | Nut - Dado M10 |
| 150 | 7030040000 | Washer - Rondella Ø10 |
| 151 | 5165950008 | Angular - Angolare superiore anteriore |
| 152 | 5165930008 | Panel - Sportello cassetta elettrica |
| 153 | 7018590000 | Hinge - Cerniera |
| 154 | 7014140000 | Screw - Vite T.E. M6x22 |
| 155 | 7020060000 | Nut - Dado M6 |
| 156 | 7458640000 | Key hole - Serratura |
| 157 | 7458650000 | Key - Chiave |
| 158 | 7500410000 | Stretch eliminator - Pressacavo M40x1,5 |
| 159 | 7090440000 | Plug - Tappo M20x1,5 |
| 160 | 5165920008 | Electric box - Cassetta elettrica |
| 161 | 4111810000 | Pressure sensor - Sensore di pressione |
| 162 | 7300230000 | RESET Push-button - Pulsante RESET |
| 163 | 7500440000 | Stretch eliminator - Pressacavo M20x1,5 |
| 164 | 7432760000 | Fuse carrier - Portafusibili |
| 165 | 7080800000 | Joint - Raccordo a "L" 1/8"x6 |
| 166 | 7230010000 | Rilsan hose - Tubo Rilsan Ø6 |
| 167 | 7084310000 | Joint - Raccordo diritto 1/8"x6 con ogiva |
| 168 | 7239130000 | Hose - Tubo rame aria |
| 169 | 7080800000 | Joint - Raccordo "L" 1/2" |
| 170 | 7300080000 | Emergency push-button - Interruttore a fungo |
| 171 | 7012240000 | Screw - Vite TC M5x15 |
| 172 | 7433090000 | Electronic panel - Scheda elettronica |
| 173 | 7500430000 | Stretch eliminator - Pressacavo M16x1,5 |
| 174 | 5165970008 | Angular - Angolare destro superiore |
| 175 | 5162990008 | Support - Supporto destro cruscotto |
| 176 | 7070580000 | Gasket - Guarnizione pannello portastrumenti |
| 177 | 5164530008 | Support - Supporto sinistro cruscotto |
| 178 | 7155450000 | Dashboard - Pannello portastrumenti |
| 179 | 7510660000 | Electric base - Base impianto elettrico |
| 180 | 7564260000 | Transformer - Trasformatore |
| 181 | 7031010000 | Washer - Rondella Ø8 |
| 182 | 7020070000 | Nut - Dado M8 |
| 183 | 7433030000 | Relay 400V compressor - Rele sequenza fasi compressore 400V KR |
| 183A | 7432770000 | Relay 230V compressor - Rele sequenza fasi compressore 230V KR |
| 184 | 7432300000 | Contactor 400V compressor - Contattore compressore 400V K3 |
| 184A | 7432400000 | Contactor 230V compressor - Contattore compressore 230V K3 |
| 185 | 7432390000 | Contactor 400V compressor - Contattore compressore 400V K1-K2 |
| 185A | 7432840000 | Contactor 230V compressor - Contattore compressore 230V K1-K2 |
| 186 | 7432480000 | Thermal relay 400V compressor - Rele termico compressore 400V F1 |
| 186A | 7432580000 | Thermal relay 230V compressor - Rele termico compressore 230V F1 |
| 187 | 7432840000 | Contact - Contatti ausiliari |
| 188 | 7432720000 | Fuse - Fusibile 1A ritardato |
| 189 | 7431640000 | Fuse - Fusibile 1A rapido |
| 190 | 7432730000 | Fuse - Fusibile 630mA ritardato |
| 191 | 5166350008 | Column - Montante destro posteriore |
| Pag.3 | ||
| 200 | 5166020008 | Panel - Pannello destro apribile |
| 201 | 5166010008 | Panel - Pannello posteriore fisso |
| 202 | 7288030000 | Handle - Maniglia |
| 203 | 7459370000 | Key hole - Serratura |
| 204 | 7018590000 | Hinge - Cerniera |
| 205 | 7014140000 | Screw - Vite M6x22 |
| 206 | 5166030008 | Panel - Pannello superiore apribile |
| 207 | 5166000008 | Panel - Pannello aspirazione destro |
| 208 | 7512170000 | Oil level panel - Pannello spia olio |
| 209 | 5165870008 | Panel - Pannello aspirazione dx |
| 210 | 5165910008 | Panel - Pannello chiusura aspirazione |
| 211 | 7517430000 | Radiator - Radiatore |
| 212 | 5165880008 | Panel - Pannello aspirazione sinistro |
| 213 | 5165910008 | Panel - Pannello superiore radiatore |
| 214 | 7014150000 | Screw - Vite M5x15 |
| 215 | 7458650000 | Key - Chiave |
| 216 | 7014450000 | Screw - Vite M5x50 |
| 217 | 5165890008 | Panel - Pannello intermedio aspirazione nero |
| 218 | 7011040000 | Screw - Vite TE M6x20 |
| 219 | 7030020000 | Washer - Rondella Ø6 |
| 220 | 7160800000 | Spring - Molla a gas |
| 221 | 7012240000 | Screw - Vite M5x15 |
| 222 | 5161200008 | Support - Supporto destro prefiltro |
| 223 | 7173410000 | Support - Staffa |
| 224 | 5161190008 | Support - Supporto sinistro prefiltro |
| 225 | 7210830000 | Pre-filter - Prefiltro |
| 226 | 7014050000 | Screw - Vite M4x25 |
| 227 | 7030180000 | Washer - Rondella Ø4 |
| AIRBLOK60 - B170D Pag.4 | ||
| 1 | 7082600000 | Suction valve kit - Kit valvola di aspirazione |
| 2 | 4094540000 | Oil seal kit - Kit paraolio |
| 3+2 | 4094550000 | Oil seal kit+bearings kit - Kit paraolio+kit cuscinetti |
