FIAC spa

FIAC Spare Parts for Air Compressor Pump Unit ABS 415-515

SKU: ABS415-515 - da 01/01/2013
€48.84
VAT included

FIAC Spare Parts for Air Compressor Pump Units ABS 415-515

FIAC Genuine Spare Parts or replacements parts for to repair components for piston Air Compressors Pump unit ABS 415-515 validity date - da 01/01/2013.
FIAC Spare Parts for Air Compressor Pump Unit ABS 415-515
  • FIAC Spare Parts for Air Compressor Pump Unit ABS 415-515
  • FIAC Spare Parts for Air Compressor Pump Unit ABS 415-515
FIAC spa

FIAC Spare Parts for Air Compressor Pump Unit ABS 415-515

SKU: ABS415-515 - da 01/01/2013 Condition: New
€48.84
VAT included

FIAC Spare Parts for Air Compressor Pump Units ABS 415-515

FIAC Genuine Spare Parts or replacements parts for to repair components for piston Air Compressors Pump unit ABS 415-515 validity date - da 01/01/2013.
settings 26 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Shipped on: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
MORE INFO:: [email protected]
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
26 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 1
Pos. Item Price Buy
1
 Connecting Rod for Pump Unit Fiac AB 415 9105450240 Connecting Rod for Pump Unit Fiac AB 415 €24.05
11
 FIAC Pump Unit AB415 Piston Ring Kit 4080070000 FIAC Pump Unit AB415 Piston Ring Kit €48.85
15
 photo_cameraImage coming soon 7050110000 Pin 015X55 €4.23
16
 FIAC Woodruf Metric Key 5x7,5 7051510000 FIAC Woodruf Metric Key 5x7,5 €6.42
17
 Crank Shaft Ball Bearing 6205 for Pump Unit FIAC AB 360 7060060000 Crank Shaft Ball Bearing 6205 for Pump Unit FIAC AB 360 €17.31
18
 photo_cameraImage coming soon 7060150000 bearing 6206 €41.13
26
 Brass Cap M1/4" for Pump Units Fiac 7090090000 Brass Cap M1/4" for Pump Units Fiac €4.42
27
 Fiac AB598 Pump Unit Oil Sight Glass 7180060000 Fiac AB598 Pump Unit Oil Sight Glass €6.57
29
 Flywheel for Pumping unit Fiac AB 410-510-512 7201010000 Flywheel for Pumping unit Fiac AB 410-510-512 €168.83
31
 FIAC Pump Unit AB415 Piston D.65MM 7220090000 FIAC Pump Unit AB415 Piston D.65MM €30.23
31A
 FIAC Pump Unit AB415 Piston Kit 9700002940 FIAC Pump Unit AB415 Piston Kit €31.97
32
 photo_cameraImage coming soon 9100270270 Aftercooler €17.75
34
 photo_cameraImage coming soon 9105450010 Crankcase €102.81
35
 photo_cameraImage coming soon 9105450020 Crankshaft €50.73
36
 photo_cameraImage coming soon 9105450060 Cylinder €107.55
37
 FIAC Pump Unit AB415 Front Cover 9105450070 FIAC Pump Unit AB415 Front Cover €6.38
38
 Fiac AB415 Rear Cover 9105450080 Fiac AB415 Rear Cover €7.79
39
 photo_cameraImage coming soon 9105450090 Carter cover €14.32
44
 Fiac AB415 Head 9105450180 Fiac AB415 Head €62.65
45
 FIAC AB415-425-525 Air Conveyor 7153140000 FIAC AB415-425-525 Air Conveyor €12.86
46
 Oil Filler Neck Komplett for Pump Units FIAC 9700001377 Oil Filler Neck Komplett for Pump Units FIAC €13.60
47
 FIAC Pump Unit AB415 Piston Ring Kit 4080070000 FIAC Pump Unit AB415 Piston Ring Kit €48.85
100
 photo_cameraImage coming soon 4231260000 Valve plate kit €71.99
101
 photo_cameraImage coming soon 4291070000 Piston kit €69.97
102
 Air Filter Kit for Pump Unit Fiac AB 415 4250130000 Air Filter Kit for Pump Unit Fiac AB 415 €22.18
103
 FIAC Pump Unit AB415 Gaskets Kit 4081990000 FIAC Pump Unit AB415 Gaskets Kit €46.00
104
 photo_cameraImage coming soon 4080480000 Screw kit €16.99

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

FIAC Spare Parts for Air Compressor Pump Units ABS 415-515

FIAC Genuine Spare Parts or replacements parts for to repair components for piston Air Compressors Pump unit ABS 415-515 validity date - da 01/01/2013.

In the following table, look for the model of the pumping unit and the respective parts code.
piston Air Compressors Pump unit ABS 415-515 validity date - da 01/01/2013

Pump Unit ABS 415-515 validity date - da 01/01/2013
# Part Num. Description
1 9105450240 Conrod Ab 415
11 4080070000 Piston Ring kit
14 7041410000 Seeger 015
15 7050110000 Pin 015x55
16 7051510000 Key Round 5X7.5
17 7060060000 bearing 6205
18 7060150000 Bearing 6206
26 7090090000 M1/4 "Brass cap
27 7180060000 Oil level warning light
29 7201010000 Flywheel
31 7220090000 Piston 65MM
31A 9700002940 Piston Kit AB415 - AB515
32 9100270270 Chiller
34 9105450010 Carter
35 9105450020 Crankshaft
36 9105450060 Cylinder
37 9105450070 Front cover
38 9105450080 Rear cover
39 9105450090 Carter cover
44 9105450180 Head
45 1120036650 conveyor
45 7153140000 Air conveyor Ab 415-425-525
46 9700001377 Oil Filler Neck Komplett
47 4080070000 Piston Ring kit
100 4231260000 Valve plate kit
101 4291070000 Piston kit
102 4250130000 Intake filter kit
103 4081990000 Gaskets kit
104 4080480000 Screws kit
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
