FIAC Spare Parts for Pump Unit GMS 105

SKU: Fiac GMS105 from 02/03/2011
€82.29
VAT included

FIAC Spare Parts for Pump Unit GMS 105

We are Dealers of FIAC original spare parts for piston Air Compressors, at low at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for pump unit GMS 105 validity date - from 02/03/2011

FIAC Spare Parts for Pump Unit GMS 105
  • FIAC Spare Parts for Pump Unit GMS 105
  • FIAC Spare Parts for Pump Unit GMS 105

FIAC Spare Parts for Pump Unit GMS 105

SKU: Fiac GMS105 from 02/03/2011 Condition: New
€82.29
VAT included

FIAC Spare Parts for Pump Unit GMS 105

We are Dealers of FIAC original spare parts for piston Air Compressors, at low at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for pump unit GMS 105 validity date - from 02/03/2011

settings 37 spare parts
description 1 exploded view
ITEM CODE
Quantity
on 10/15 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
MORE INFO:: [email protected]
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

37 spare parts
Pos. Item Price Buy
*
Fiac GMS 100 Pump Unit Set of Gaskets 4082090000 Fiac GMS 100 Pump Unit Set of Gaskets €10.74 Available
*
photo_cameraImage coming soon 4190320000 Kit rod €104.77 Available
1
Start Valve M 3/8 " 1.5 bar for Pumping Unit Fiac CCS-GM-GMS 7196010000 Start Valve M 3/8 " 1.5 bar for Pumping Unit Fiac CCS-GM-GMS €10.13 Available
2
photo_cameraImage coming soon 7011220000 Screw M6X40 UNI-5737 €1.44 Available
3
photo_cameraImage coming soon 7084040000 Fitting "L" M3 / 8 " €9.84 Available
4
Filter Plate for Pumping Uniti and Air Compressor Fiac 7458340000 Filter Plate for Pumping Uniti and Air Compressor Fiac €1.52 Available
5
Air Filter Element for Pumping Units Fiac VX - VS - GM 7210010000 Air Filter Element for Pumping Units Fiac VX - VS - GM €4.37 Available
6
Air Filter Cover for Pump Units FIAC Series VS - VX 7210430000 Air Filter Cover for Pump Units FIAC Series VS - VX €4.34 Available
8
photo_cameraImage coming soon 5030100008 Head €24.63 Available
11
photo_cameraImage coming soon 4081030000 VALVE KIT LAMEL.10PZ SP.0,20 INOX €21.15 Available
15
photo_cameraImage coming soon 7575040000 Cylinder €183.69 Available
16
photo_cameraImage coming soon 7020070000 Nut M8 UNI-5587 €1.48 Available
17
Kit Rings for Pistons of Pump Units GMS-VS 4080043000 Kit Rings for Pistons of Pump Units GMS-VS €82.31 Available
18
photo_cameraImage coming soon 7220300000 Piston €38.56 Available
19
photo_cameraImage coming soon 7050050000 Pin Ø12/8,5X46 "GMS" €4.35 Available
20
Circlip for Pumping Units Fiac VX 194-VX 214 7041010000 Circlip for Pumping Units Fiac VX 194-VX 214 €1.52 Available
26
photo_cameraImage coming soon 7310140000 Capacitor MF.40 V.450 €19.19 Available
27
photo_cameraImage coming soon 7060140000 Bearing 6204-2RS2 / HT-22-C3 SKF €23.84 Available
28
photo_cameraImage coming soon 7098010000 Cork €10.26 Available
29
photo_cameraImage coming soon 7070010000 O-Ring 108 €1.44 Available
30
photo_cameraImage coming soon 7012060000 Screw M4X12 UNI-8112 €1.52 Available
31
photo_cameraImage coming soon 7151010000 COVER CARTER GMS €7.02 Available
32
FIAC GMS 100 Air Filter 7210120000 FIAC GMS 100 Air Filter €3.32 Available
33
photo_cameraImage coming soon 7458031000 Filter plate €5.87 Available
35
photo_cameraImage coming soon 7060020000 Bearing 6205 2RS 25.52.15 €19.95 Available
36
photo_cameraImage coming soon 5070300008 Sump €11.08 Available
39
photo_cameraImage coming soon 7170370000 BASE ENGINE GM190 €10.82 Available
40
photo_cameraImage coming soon 7012290000 Screw M5X20 TAP-TITE €24.21 Available
41
photo_cameraImage coming soon 7060010000 Bearing 6203 ZZ 17:40:12 QE6 €13.55 Available
42
photo_cameraImage coming soon 7018010000 Screw M6x139 UNI-5737 €1.73 Available
43
photo_cameraImage coming soon 7200010000 FAN BLACK NYLON 155 D €7.94 Available
44
photo_cameraImage coming soon 7012070000 Screw M4X8 UNI-8112 €2.07 Available
46
photo_cameraImage coming soon 5110061008 Cover €29.96 Available
47
Fiac Stud M.8X35X14X16 7015020000 Fiac Stud M.8X35X14X16 €1.52 Available
48
photo_cameraImage coming soon 7150151000 CASING GM BLACK VERS.96 €8.23 Available
100
photo_cameraImage coming soon 4082640000 Valve plate kit €80.06 Available
101
Set Conrod-Piston for Pump Unit Fiac VS 204 4191140000 Set Conrod-Piston for Pump Unit Fiac VS 204 €111.51 Available

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

FIAC Spare Parts for Pump Unit GMS 105

We are Dealers of FIAC original spare parts for piston Air Compressors, at low at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for pump unit GMS 105 validity date - from 02/03/2011

In the following table , look for the model of the pumping unit and the respective parts of the code .
Fiac GMS 105 from 02/03/2011

GMS 105 validity date - from 02/03/2011
# Part Num. Description
1 7196010000 Start valve M3 / 8 "1.5 bar
2 7011220000 Screw M6X40 UNI-5737
3 7084040000 Fitting "L" M3 / 8 "
4 7458340000 Filter plate
5 7210010000 Filter element
6 7210430000 Filter cover
7 7012120000 Ø Screw 4,2X19 UNI-6954
8 5030100008 Head
11 4081030000 VALVE KIT LAMEL.10PZ SP.0,20 INOX
15 7575040000 Cylinder
16 7020070000 Nut M8 UNI-5587
17 4080043000 Kit segments
18 7220300000 Piston
19 7050050000 Pin Ø12/8,5X46 "GMS"
20 7041010000 Seeger Ø12
26 7310140000 Capacitor MF.40 V.450
27 7060140000 Bearing 6204-2RS2 / HT-22-C3 SKF
28 7098010000 Cork
29 7070010000 O-ring 108
30 7012060000 Screw M4X12 UNI-8112
31 7151010000 COVER CARTER GMS
32 7210120000 FILTER COVER CARTER
33 7458031000 Filter plate
34 5040280008 Tree in Elbow
35 7060020000 Bearing 6205 2RS 25.52.15
36 5070300008 Sump
37 5090030008 Rotor
38 4010550000 HOUSING STATOR GM85 V115/60 C/CABLE C/T
39 7170370000 BASE ENGINE GM190
40 7012290000 Screw M5X20 TAP-TITE
41 7060010000 Bearing 6203 ZZ 17:40:12 QE6
42 7018010000 Screw M6x139 UNI-5737
43 7200010000 FAN BLACK NYLON 155 D
44 7012070000 Screw M4X8 UNI-8112
45 7031020000 Washer Ø4 UNI-3703
46 5110061008 Cover
47 7015020000 STUD M.8X35X14X16
48 7150151000 CASING GM BLACK VERS.96
100 4082640000 Valve plate kit
101 4191140000 SET CONROD-PISTON VS SINGLE RING-DSB
102 4280400000 GROUP CARTER SHAFT-ROTOR GMS-105
* 4082090000 Set of Kaskets - 009-012-014
* 7458271000 VALVE plate - 010-013
* 4190320000 Kit rod - 021-025
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
