Femi Spare Parts for Cleaners series Industry / Ecology

SKU: Pulitrici Industria-Ecologica
€98.83
VAT included

Femi Spare Parts for Cleaners series Industry / Ecology

We are FEMI original spare parts and Accessories Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to solve any maintenance or repair issues for Cleaners series Industry/Ecology Art.282-208-213-214-209-211-201-204-202-203.

Femi Spare Parts for Cleaners  series Industry / Ecology
  • On sale!
  • Femi Spare Parts for Cleaners  series Industry / Ecology
  • Femi Spare Parts for Cleaners  series Industry / Ecology
  • Femi Spare Parts for Cleaners  series Industry / Ecology

Femi Spare Parts for Cleaners series Industry / Ecology

SKU: Pulitrici Industria-Ecologica Condition: New
€98.83
VAT included

Femi Spare Parts for Cleaners series Industry / Ecology

We are FEMI original spare parts and Accessories Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to solve any maintenance or repair issues for Cleaners series Industry/Ecology Art.282-208-213-214-209-211-201-204-202-203.

settings 37 Spare parts
description 10 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 10 Business Days Approx.

SHIPPING IN: Usually Ships in 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK ITEM CODE OR S/N FEMI: FEMI ITEM CODE START WITH (8....) AND HAVE 7 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

37 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Pos. Item Price Buy
1
photo_cameraImage coming soon 5042755 HALF-BODY €60.87
2
photo_cameraImage coming soon 0802617 SWITCH €40.74
9
photo_cameraImage coming soon 5182237 CONVEYOR €104.06
10
photo_cameraImage coming soon 7013573 ROTOR €71.87
20
photo_cameraImage coming soon 5100110 NUT €2.50
21
photo_cameraImage coming soon 5100109 HEX NUT M16X2 LH H.10 HEX 27 ZINC-PLATED €2.50
35
photo_cameraImage coming soon 5024326 STATOR €98.79
36
photo_cameraImage coming soon 0526202 BALL BEARING €8.78
37
photo_cameraImage coming soon 5042755 HALF-BODY €60.87
38
photo_cameraImage coming soon 5190275 WHEEL FLANGE €5.51
39
photo_cameraImage coming soon 5181616 BLADE PROTECTION €5.04
Page 3 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Pos. Item Price Buy
1
photo_cameraImage coming soon 5042755 HALF-BODY €60.87
2
Three Phase 380V Switch for Belt Sanders Femi 510 - 511 0803617 Three Phase 380V Switch for Belt Sanders Femi 510 - 511 €41.74
9
photo_cameraImage coming soon 5182237 CONVEYOR €104.06
10
photo_cameraImage coming soon 7013573 ROTOR €71.87
20
photo_cameraImage coming soon 5100110 NUT €2.50
21
photo_cameraImage coming soon 5100109 HEX NUT M16X2 LH H.10 HEX 27 ZINC-PLATED €2.50
35
photo_cameraImage coming soon 5024627 STATOR A. 90X47X60 C24 TF 2P 220/380-50 €347.17
36
photo_cameraImage coming soon 0526202 BALL BEARING €8.78
37
photo_cameraImage coming soon 5042755 HALF-BODY €60.87
38
photo_cameraImage coming soon 5190275 WHEEL FLANGE €5.51
39
photo_cameraImage coming soon 5181616 BLADE PROTECTION €5.04
Page 4 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Pos. Item Price Buy
1
photo_cameraImage coming soon 5042755 HALF-BODY €60.87
2
Three Phase 380V Switch for Belt Sanders Femi 510 - 511 0803617 Three Phase 380V Switch for Belt Sanders Femi 510 - 511 €41.74
9
photo_cameraImage coming soon 5182237 CONVEYOR €104.06
10
photo_cameraImage coming soon 7013573 ROTOR €71.87
20
photo_cameraImage coming soon 5100110 NUT €2.50
21
photo_cameraImage coming soon 5100109 HEX NUT M16X2 LH H.10 HEX 27 ZINC-PLATED €2.50
35
photo_cameraImage coming soon 5024627 STATOR A. 90X47X60 C24 TF 2P 220/380-50 €347.17
36
photo_cameraImage coming soon 0526202 BALL BEARING €8.78
37
photo_cameraImage coming soon 5042755 HALF-BODY €60.87
38
photo_cameraImage coming soon 5190275 WHEEL FLANGE €5.51
39
photo_cameraImage coming soon 5181616 BLADE PROTECTION €5.04
Page 5 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Page 6 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Page 8 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Pos. Item Price Buy
1
photo_cameraImage coming soon 5042776 IND. HALF-HOUSING HP1.5 135X60 C/52 70 - NO LONGER AVAILABLE €0.00 Not available for order
2
photo_cameraImage coming soon 7075030 GRINDER SWITCH REPLACEMENT KIT 1100/1500W €48.95
9
photo_cameraImage coming soon 5182238 CREVERSIBLE BRUSH CONVEYOR D.250 - USE 5182262 €159.54
10
photo_cameraImage coming soon 7013593 ROTOR ASSY FOR 209 €130.53
20
photo_cameraImage coming soon 5100117 HEX NUT M20X2.5 RH ZINC-PLATED €5.12
21
photo_cameraImage coming soon 5100116 HEX NUT M20X2.5 LH ZINC-PLATED €5.12
36
photo_cameraImage coming soon 5024636 STATOR A.135x70x60 C24 TF 2P 380-50 S01-120°C €203.05
37
photo_cameraImage coming soon 5042776 IND. HALF-HOUSING HP1.5 135X60 C/52 70 - NO LONGER AVAILABLE €0.00 Not available for order
38
photo_cameraImage coming soon 5190273 WHEEL PRESS FLANGE 71X20 H. 9.15 SHEET THICKNESS 5 €7.32
39
photo_cameraImage coming soon 5181620 SHAFT PROTECTION BRUSH SIDE HP 1.5/2 BLACK €36.26
Page 9 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Pos. Item Price Buy
1
photo_cameraImage coming soon 5042776 IND. HALF-HOUSING HP1.5 135X60 C/52 70 - NO LONGER AVAILABLE €0.00 Not available for order
2
photo_cameraImage coming soon 7075030 GRINDER SWITCH REPLACEMENT KIT 1100/1500W €48.95
9
photo_cameraImage coming soon 5182238 CREVERSIBLE BRUSH CONVEYOR D.250 - USE 5182262 €159.54
10
photo_cameraImage coming soon 7013593 ROTOR ASSY FOR 209 €130.53
20
photo_cameraImage coming soon 5100117 HEX NUT M20X2.5 RH ZINC-PLATED €5.12
35
photo_cameraImage coming soon 5024636 STATOR A.135x70x60 C24 TF 2P 380-50 S01-120°C €203.05
36
photo_cameraImage coming soon 0526205 BALL BEARING €17.56
37
photo_cameraImage coming soon 5042776 IND. HALF-HOUSING HP1.5 135X60 C/52 70 - NO LONGER AVAILABLE €0.00 Not available for order
38
photo_cameraImage coming soon 5190273 WHEEL PRESS FLANGE 71X20 H. 9.15 SHEET THICKNESS 5 €7.32
39
photo_cameraImage coming soon 5181620 SHAFT PROTECTION BRUSH SIDE HP 1.5/2 BLACK €36.26

Shipping and delivery information will be available shortly.

Femi Spare Parts for Cleaners series Industry / Ecology

We are FEMI original spare parts and Accessories Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to solve any maintenance or repair issues for Cleaners series Industry/Ecology Art.282-208-213-214-209-211-201-204-202-203.

In the following table, look for the model of Belt Sander and the respective parts of the Part Num..

Industry / Eco Series Polishing / Buffing Machines Art. 282-208-213-214-209-211 201-204-202-203
Art. 282 8041121 - Page 1
# Part Num. Description
1 5042755 MEDIUM HALF-HOUSING 90x60 C/42 RAL 7000 PEBBLED
2 0802617 CABLED PUSH-BUTTON SWITCH 230V W/ AUX CONTACT + EMERGENCY STOP
9 5182237 REVERSIBLE BRUSH CONVEYOR D.150
10 7013573 COMPLETE ROTOR FOR 14.61-15.61
20 5100110 HEX NUT M16X2 RH H.10 HEX 27 ZINC-PLATED
21 5100109 HEX NUT M16X2 LH H.10 HEX 27 ZINC-PLATED
35 5024326 WOUND STATOR 90X47X60 C24 SINGLE-PHASE 2P 220-50
36 0526202 BEARING 6202 15X35X11 ZZ ABEC3
37 5042755 MEDIUM HALF-HOUSING 90x60 C/42 RAL 7000 PEBBLED
38 5190275 WHEEL PRESS FLANGE 71X16 H. 9.15 SHEET THICKNESS 5
39 5181616 SHAFT PROTECTION BRUSH SIDE (NY 6 VT 30 BLACK)
Art. 211 8045731 - Page 2
# Part Num. Description
1 5043551 RH CAST IRON HALF-HOUSING P.152X110 C.72 (***)
2 7800239 THREE-PHASE CONTROL PANEL 1-SPEED 380V MAGNETOTHERMIC 6.3-10
9 5182239 REVERSIBLE BRUSH CONVEYOR D.300
10 7013520 COMPLETE ROTOR FOR 8.24.05.31
20 5100103 RIGHT-HAND RING NUT FOR POLISHING MACHINE
21 5100104 LEFT-HAND RING NUT FOR POLISHING MACHINE
35 5024630 WOUND STATOR 152X80X110 C24 THREE-PHASE 2P 220/380-50
36 0526207 BALL BEARING 6207 ZZ ABEC3
37 5043551 RH CAST IRON HALF-HOUSING P.152X110 C.72 (***)
38 5190259 WHEEL PRESS FLANGE 84X25 H.10 SHEET THICKNESS 6
39 5181621 SHAFT PROTECTION BRUSH SIDE HP 3 BLACK PEBBLED
Art. 208 8041231 - Page 3
# Part Num. Description
1 5042755 MEDIUM HALF-HOUSING 90x60 C/42 RAL 7000 PEBBLED
2 0803617 CABLED PUSH-BUTTON SWITCH 230V W/ AUX CONTACT + EMERGENCY STOP
9 5182237 REVERSIBLE BRUSH CONVEYOR D.150
10 7013573 COMPLETE ROTOR FOR 14.61-15.61
20 5100110 HEX NUT M16X2 RH H.10 HEX 27 ZINC-PLATED
21 5100109 HEX NUT M16X2 LH H.10 HEX 27 ZINC-PLATED
35 5024627 WOUND STATOR 90X47X60 C24 THREE-PHASE 2P 220/380-50
36 0526202 BEARING 6202 15X35X11 ZZ ABEC3
37 5042755 MEDIUM HALF-HOUSING 90x60 C/42 RAL 7000 PEBBLED
38 5190275 WHEEL PRESS FLANGE 71X16 H. 9.15 SHEET THICKNESS 5
39 5181616 SHAFT PROTECTION BRUSH SIDE (NY 6 VT 30 BLACK)
Art. 201 8007031 - Page 4
# Part Num. Description
1 5042755 MEDIUM HALF-HOUSING 90x60 C/42 RAL 7000 PEBBLED
2 0803617 CABLED PUSH-BUTTON SWITCH 230V W/ AUX CONTACT + EMERGENCY STOP
9 5182237 REVERSIBLE BRUSH CONVEYOR D.150
10 7013573 COMPLETE ROTOR FOR 14.61-15.61
20 5100110 HEX NUT M16X2 RH H.10 HEX 27 ZINC-PLATED
21 5100109 HEX NUT M16X2 LH H.10 HEX 27 ZINC-PLATED
35 5024627 WOUND STATOR 90X47X60 C24 THREE-PHASE 2P 220/380-50
36 0526202 BEARING 6202 15X35X11 ZZ ABEC3
37 5042755 MEDIUM HALF-HOUSING 90x60 C/42 RAL 7000 PEBBLED
38 5190275 WHEEL PRESS FLANGE 71X16 H. 9.15 SHEET THICKNESS 5
39 5181616 SHAFT PROTECTION BRUSH SIDE (NY 6 VT 30 BLACK)
Art. 213 8041321 - Page 5
# Part Num. Description
1 5042764 MEDIUM HALF-HOUSING 110x70 C/54 RAL 7000 PEBBLED
2 0802617 CABLED PUSH-BUTTON SWITCH 230V W/ AUX CONTACT + EMERGENCY STOP
9 5182210 REVERSIBLE BRUSH CONVEYOR D.200
10 7013633 COMPLETE ROTOR
20 5100110 HEX NUT M16X2 RH H.10 HEX 27 ZINC-PLATED
21 5100109 HEX NUT M16X2 LH H.10 HEX 27 ZINC-PLATED
35 5024342 WOUND STATOR 110x55x70 24 SLOTS STR. SINGLE-PHASE 2P 220-50
36 0526202 BEARING 6202 15X35X11 ZZ ABEC3
37 5042764 MEDIUM HALF-HOUSING 110x70 C/54 RAL 7000 PEBBLED
38 5190275 WHEEL PRESS FLANGE 71X16 H. 9.15 SHEET THICKNESS 5
39 5181616 SHAFT PROTECTION BRUSH SIDE (NY 6 VT 30 BLACK)
Art. 204 8007131 - Page 6
# Part Num. Description
1 5042764 MEDIUM HALF-HOUSING 110x70 C/54 RAL 7000 PEBBLED
2 0803617 CABLED PUSH-BUTTON SWITCH 230V W/ AUX CONTACT + EMERGENCY STOP
9 5182210 REVERSIBLE BRUSH CONVEYOR D.200
10 7013633 COMPLETE ROTOR
20 5100110 HEX NUT M16X2 RH H.10 HEX 27 ZINC-PLATED
21 5100109 HEX NUT M16X2 LH H.10 HEX 27 ZINC-PLATED
35 5024638 WOUND STATOR 110x55x70 24 SLOTS STR. THREE-PHASE 2P 380-50
36 0526202 BEARING 6202 15X35X11 ZZ ABEC3
37 5042764 MEDIUM HALF-HOUSING 110x70 C/54 RAL 7000 PEBBLED
38 5190275 WHEEL PRESS FLANGE 71X16 H. 9.15 SHEET THICKNESS 5
39 5181616 SHAFT PROTECTION BRUSH SIDE (NY 6 VT 30 BLACK)
Art. 214 8041431 - Page 7
# Part Num. Description
1 5042764 MEDIUM HALF-HOUSING 110x70 C/54 RAL 7000 PEBBLED
2 0803617 CABLED PUSH-BUTTON SWITCH THREE-PHASE 380V W/ AUX CONTACT + EMERGENCY STOP
9 5182210 REVERSIBLE BRUSH CONVEYOR D.200
10 7013633 COMPLETE ROTOR
20 5100110 HEX NUT M16X2 RH H.10 HEX 27 ZINC-PLATED
21 5100109 HEX NUT M16X2 LH H.10 HEX 27 ZINC-PLATED
35 5024638 WOUND STATOR 110x55x70 24 SLOTS STR. THREE-PHASE 2P 380-50
36 0526202 BEARING 6202 15X35X11 ZZ ABEC3
37 5042764 MEDIUM HALF-HOUSING 110x70 C/54 RAL 7000 PEBBLED
38 5190275 WHEEL PRESS FLANGE 71X16 H. 9.15 SHEET THICKNESS 5
39 5181616 SHAFT PROTECTION BRUSH SIDE (NY 6 VT 30 BLACK)
Art. 202 8007231 - Page 8
# Part Num. Description
1 5042776 IND. HALF-HOUSING HP1.5 135X60 C/52 70 - NO LONGER AVAILABLE
2 7075030 GRINDER SWITCH REPLACEMENT KIT 1100/1500W
9 5182238 REVERSIBLE BRUSH CONVEYOR D.250 - USE 5182262
10 7013593 COMPLETE ROTOR FOR 209
20 5100117 HEX NUT M20X2.5 RH ZINC-PLATED
21 5100116 HEX NUT M20X2.5 LH ZINC-PLATED
35 5024636 WOUND STATOR 135x70x60 C24 THREE-PHASE 2P 380-50 S01-120°C
36 0526205 BEARING 6205 ZZ P. 5/250 ABEC3
37 5042776 IND. HALF-HOUSING HP1.5 135X60 C/52 70 - NO LONGER AVAILABLE
38 5190273 WHEEL PRESS FLANGE 71X20 H. 9.15 SHEET THICKNESS 5
39 5181620 SHAFT PROTECTION BRUSH SIDE HP 1.5/2 BLACK
Art. 209 8041531 - Page 9
# Part Num. Description
1 5042776 IND. HALF-HOUSING HP1.5 135X60 C/52 70 - NO LONGER AVAILABLE
2 7075030 GRINDER SWITCH REPLACEMENT KIT 1100/1500W
9 5182238 REVERSIBLE BRUSH CONVEYOR D.250 - USE 5182262
10 7013593 COMPLETE ROTOR FOR 209
20 5100117 HEX NUT M20X2.5 RH ZINC-PLATED
21 5100116 HEX NUT M20X2.5 LH ZINC-PLATED
35 5024636 WOUND STATOR 135x70x60 C24 THREE-PHASE 2P 380-50 S01-120°C
36 0526205 BEARING 6205 ZZ P. 5/250 ABEC3
37 5042776 IND. HALF-HOUSING HP1.5 135X60 C/52 70 - NO LONGER AVAILABLE
38 5190273 WHEEL PRESS FLANGE 71X20 H. 9.15 SHEET THICKNESS 5
39 5181620 SHAFT PROTECTION BRUSH SIDE HP 1.5/2 BLACK
Art. 203 8002931 - Page 10
# Part Num. Description
1 5043551 RH CAST IRON HALF-HOUSING P.152X110 C.72 (***)
2 7800239 THREE-PHASE CONTROL PANEL 1-SPEED 380V MAGNETOTHERMIC 6.3-10
9 5182239 REVERSIBLE BRUSH CONVEYOR D.300
10 7013520 COMPLETE ROTOR FOR 8.24.05.31
20 5100103 RIGHT-HAND RING NUT FOR POLISHING MACHINE
21 5100104 LEFT-HAND RING NUT FOR POLISHING MACHINE
35 5024630 WOUND STATOR 152X80X110 C24 THREE-PHASE 2P 220/380-50
36 0526207 BALL BEARING 6207 ZZ ABEC3
37 5043551 RH CAST IRON HALF-HOUSING P.152X110 C.72 (***)
38 5190259 WHEEL PRESS FLANGE 84X25 H.10 SHEET THICKNESS 6
39 5181621 SHAFT PROTECTION BRUSH SIDE HP 3 BLACK PEBBLED

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s FEMI websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to FEMI brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.

Pulitrici Industria-Ecologica
12 Items

Data sheet

SHIPPING IN
Usually Ships in 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK ITEM CODE OR S/N FEMI
FEMI ITEM CODE START WITH (8....) AND HAVE 7 DIGITS

Specific References

New

Download

Drawing Cleaners Indu. Ecol.

Drawing Cleaners Indu. Ecol.

Download (415.86KB)

You might also like

Femi SKU: Femi 780 XL
Mitre Saw for Metal Femi 780 XL Portable band saw FEMI MOD. P 780 Dry cutting Practical and lightweight, suitable for any use. Technical Features: - Practical and lightweight, suitable for any use; - Cutting up: 0 ° Ø 105 mm - 105 x...
AVAILABLE €562.09
Femi SKU: CPD6858
Steel Tape for Femi 780P Femi Tape 780P article CDP6858 Size: - 1335 x 13 x 0.65 mm - 8 / 12 Z / I " - 60/80 Mt / min - Code : CPD6858
AVAILABLE €36.16
Femi SKU: CPD45703
Steel Band for Band Saw Femi 785P Femi Steel Band for Band Saw 785P-XL - article 45703 Size: - 1735 x 13 x 0.9 mm - 6/10 Z/I " - 60/80 Mt / min - Codice : CPD45703
AVAILABLE €41.52
Femi SKU: 0802317
Switch for Band Saws FEMI 780-781-783-784-785 Genuine part FEMI, 8A Bipolar Switch with Button for Band Saws 780P - 781 - 785P - 783XL - ABS 105 - 780XL - 784XL - 785XL. Part for the following items: - Band Saw FEMI 780P-8484320 -...
Usually Ships in: 7/10 Business Days Approx. €12.00
Industrial Tilting Belt Femi 504B Sale
Femi SKU: 504B
Industrial Tilting Belt Femi 504B Description: - Powerful and quiet motor to three-phase induction 600/900 Watts, 400 Volts and 50 Hz frequency. - Ability to perform work on the flat, and in support of the platen roller - Replacing the...
AVAILABLE €1,515.76
Comments (0)
No customer reviews for the moment.
