Dolmar Spare Parts for Chain Saw PS352
We are DOLMAR original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Chain Saw PS352.
In the following table, look for the model of the Edgecutter and the respective parts of the code.
| PS352 PETROL CHAIN SAW |
| # |
Part Num |
Description |
| 1 |
142225-1 |
FRONT HANDLE COMPLETE |
| 2 |
142226-9 |
DAMPER SPRING RCOMPLETE |
| 3 |
326339-6 |
STOPPER PIN |
| 4 |
454506-4 |
SPRING HOLDER |
| 5 |
266856-3 |
H.L. TAPPING SCREW 5X20 |
| 6 |
326339-6 |
STOPPER PIN |
| 7 |
142227-7 |
DAMPER SPRING FCOMPLETE |
| 9 |
454506-4 |
SPRING HOLDER |
| 10 |
266856-3 |
H.L. TAPPING SCREW 5X20 |
| 11 |
168396-6 |
BREATHER |
| 12 |
424576-7 |
GROMMET |
| 13 |
424577-5 |
SIDE STOPPER |
| 14 |
126346-7 |
RIGHT HANDLE ASSEMBLY |
| 16 |
266858-9 |
H.L. TAPPING SCREW 4X18 |
| 17 |
168812-8 |
THROTTLE CABLE |
| 18 |
454501-4 |
CABLE BRACKET |
| 19 |
454499-5 |
THROTTLE LEVER |
| 20 |
233606-1 |
RETURN SPRING |
| 21 |
454500-6 |
CABLE PULL LEVER |
| 22 |
268187-6 |
PIN 3 |
| 23 |
454502-2 |
LOCKOUT LEVER |
| 24 |
454503-0 |
GRIP COVER |
| 25 |
326339-6 |
STOPPER PIN |
| 26 |
424577-5 |
SIDE STOPPER |
| 27 |
168507-3 |
TANK CAP COMPLETE |
| 27-1 |
168823-3 |
TANK CAP COMPLETE O |
| 28 |
213080-9 |
O RING 29.5 |
| 29 |
422116-5 |
JOINT PIPE |
| 30 |
424573-3 |
DUST GROMMET |
| 31 |
126347-5 |
FUEL PIPE ASSEMBLY |
| 32 |
168398-2 |
PRIMER PUMP |
| 33 |
142226-9 |
DAMPER SPRING RCOMPLETE |
| 34 |
814S88-6 |
PS-352 NAME PLATE |
| 35 |
454506-4 |
SPRING HOLDER |
| 36 |
266856-3 |
H.L. TAPPING SCREW 5X20 |
| 38 |
805U48-1 |
SOUND 111DB LABEL |
| 39 |
801Y91-2 |
GAS EMISSION APPROVAL LABEL |
| 40 |
142240-5 |
CLEANER COVER COMPLETE |
| C10 |
263002-9 |
RUBBER PIN 4 |
| 41 |
266858-9 |
H.L. TAPPING SCREW 4X18 |
| 42 |
126344-1 |
CYLINDER COVER ASSEMBLY |
| 43 |
632A97-3 |
SWITCH CORD |
| 44 |
632A98-1 |
EARTH CORD |
| 45 |
454532-3 |
MANIFOLD |
| 45-1 |
457411-4 |
MANIFOLD (S) |
| 46 |
126370-0 |
CLEANER ASSEMBLY |
| C10 |
454537-3 |
KNOB |
| 47 |
346704-3 |
EARTH PLATE |
| 48 |
346705-1 |
SWITCH SPRING |
| 49 |
266860-2 |
H.L. TAPPING SCREW 4X45 |
| 50 |
266861-0 |
H.L. TAPPING SCREW 4X22 |
| 51 |
424582-2 |
DAMPER |
| 52 |
454533-1 |
SWITCH LEVER |
| 53 |
424582-2 |
DAMPER |
| 54 |
168819-4 |
CARBURETOR ASSEMBLY |
| 54-1 |
161633-7 |
CARBURETOR ASSEMBLY (S) |
| 54-2 |
161914-9 |
CARBURETOR ASSEMBLY (S) |
| 55 |
454531-5 |
BRACKET |
| 56 |
266848-2 |
H.L. HEAD BIND BOLT M4X16 |
| 57 |
454488-0 |
BUFFLE PLATE |
| 58 |
332074-6 |
INNER RING |
| 59 |
424571-7 |
INLET PIPE |
| 60 |
332075-4 |
INNER RING |
| 61 |
326304-5 |
SPACER |
| 62 |
413164-5 |
MUFFLER GASKET |
| 63 |
126342-5 |
MUFFLER ASSEMBLY |
| 63-1 |
126936-6 |
MUFFLER ASSEMBLY (S) |
| 65 |
352023-7 |
SCREEN |
| 66 |
266796-5 |
TAPPING SCREW 4X8 |
| 67 |
266851-3 |
H.L. BIND BOLT M5X20 |
| 68 |
266850-5 |
H.L. BIND BOLT M5X10 |
| 69 |
266849-0 |
H.L. SOCKET HEAD BOLT M5X16 |
| 70 |
346691-6 |
DUST COVER |
| 71 |
266936-5 |
H.L. BIND BOLT M4X8 |
| 80 |
266859-7 |
H.L. SOCKET HEAD BOLT M5X12 |
| 81 |
266847-4 |
H.L. SOCKET HEAD BOLT M5X20 |
| 82 |
142223-5 |
CYLINDER COMPLETE |
| 83 |
649500-1 |
SPARK PLUG (BPMR8Y) |
| 84 |
257365-3 |
PISTON RING |
| 85 |
319023-0 |
PISTON |
| 85-1 |
319711-9 |
PISTON (O) |
| 86 |
268331-5 |
PISTON PIN |
| 87 |
212127-6 |
NEEDLE CAGE 1011 |
| 88 |
346698-2 |
THRUST WASHER |
| 89 |
234307-4 |
RETAINING RING |
| 90 |
142229-3 |
CRANK SHAFT COMPLETE |
| 90-1 |
140B29-7 |
CRANK SHAFT COMPLETE (O) |
| 91 |
413163-7 |
BASE GASKET |
| 92 |
266848-2 |
H.L. HEAD BIND BOLT M4X16 |
| 93 |
424581-4 |
GROMMET |
| 94 |
126350-6 |
IGNITION COIL ASSEMBLY |
| C10 |
424580-6 |
PLUG CAP |
| 95 |
454520-0 |
PLATE |
| 96 |
142224-3 |
CRANK CASE COMPLETE |
| C10 |
213697-8 |
OIL SEAL |
| 97 |
266852-1 |
H.L. SOCKET HEAD BOLT M5X25 |
| 98 |
413165-3 |
GASKET |
| 99 |
126343-3 |
REED VALVE |
| 99-1 |
123924-4 |
REED VALVE (S) |
| 104 |
911013-5 |
PAN HEAD SCREW M3X10 |
| 105 |
319022-2 |
REED VALVE COVER |
| 106 |
266848-2 |
H.L. HEAD BIND BOLT M4X16 |
| 107 |
266846-6 |
H.L. BIND BOLT M4X12 |
| 108 |
454489-8 |
BRACKET |
| 109 |
424572-5 |
AIR BOOT |
| 110 |
911013-5 |
PAN HEAD SCREW M3X10 |
| 111 |
126343-3 |
REED VALVE |
| 111-1 |
123923-6 |
REED VALVE (S) |
| 116 |
266854-7 |
H.L. BIND BOLT M5X14 |
| 116-1 |
251500-5 |
H.L. BIND BOLT M5X14 (O) |
| 117 |
234207-8 |
COMPRESSION SPRING 6 |
| 118 |
452666-6 |
NIPPLE |
| 118-1 |
452666-6 |
NIPPLE (O) |
| 120 |
346695-8 |
SPIKE BUMPER |
| 121 |
266857-1 |
H.L. TAPPING SCREW 5X16 |
| 122 |
346694-0 |
GUIDE PLATE ES |
| 123 |
421298-0 |
CHECK VALVE |
| 124 |
266854-7 |
H.L. BIND BOLT M5X14 |
| 125 |
346722-1 |
CHAIN CATCHER |
| 126 |
266856-3 |
H.L. TAPPING SCREW 5X20 |
| 127 |
454509-8 |
PUMP COVER |
| 128 |
266846-6 |
H.L. BIND BOLT M4X12 |
| 129 |
267047-9 |
FLAT WASHER 10 |
| 130 |
221427-3 |
WORM GEAR |
| 131 |
212129-2 |
NEEDLE CAGE 1013 |
| 132 |
165725-4 |
CLUTCH DRUM COMPLETE |
| 133 |
346693-2 |
BACK PLATE |
| 134 |
126348-3 |
CLUTCH ASSEMBLY |
| C10 |
231883-9 |
TENSION SPRING 8 |
| 138 |
424579-1 |
OIL PIPE (OUT) |
| 139 |
142156-4 |
OIL PUMP COMPLETE |
| 139-1 |
142156-4 |
OIL PUMP COMPLETE (O) |
| 140 |
266846-6 |
H.L. BIND BOLT M4X12 |
| 141 |
126349-1 |
OIL PIPE ASSEMBLY |
| 142 |
126373-4 |
CHAIN COVER ASSEMBLY |
| 142-1 |
127249-8 |
CHAIN COVER ASSEMBLY (<) |
| 142-2 |
127249-8 |
CHAIN COVER ASSEMBLY (O) |
| 143 |
266855-5 |
H.L. TAPPING SCREW 4X12 |
| 144 |
454515-3 |
SPRING COVER |
| 145 |
233607-9 |
TORSION SPRING 6 |
| 146 |
346702-7 |
LEVER |
| 147 |
313265-8 |
WEIGHT |
| 148 |
346699-0 |
GUIDE PLATE CS |
| 149 |
266166-8 |
TAPPING SCREW CT 3X8 |
| 150 |
227496-2 |
STRAIGHT BEVEL GEAR 14 |
| 151 |
326311-8 |
ADJUST PIN |
| 152 |
326313-4 |
ADJUST SCREW |
| 153 |
227620-7 |
DRIVE GEAR |
| 154 |
234304-0 |
COMPRESSION SPRING 7 |
| 155 |
142234-0 |
LEVER COMPLETE |
| 156 |
142119-0 |
BRAKE BAND COMPLETE |
| 156-1 |
143383-6 |
BRAKE BAND COMPLETE (S) |
| 157 |
266855-5 |
H.L. TAPPING SCREW 4X12 |
| 158 |
454547-0 |
CHAIN COVER |
| 158-1 |
456229-0 |
CHAIN COVER (<) |
| 159 |
454620-6 |
NUT COVER |
| 160 |
142168-7 |
FLANGE NUT COMPLETE |
| 160-1 |
144582-3 |
FLANGE NUT COMPLETE (<) |
| 160-2 |
144689-5 |
FLANGE NUT COMPLETE |
| 160-3 |
162493-0 |
FLANGE NUT COMPLETE |
| 160-4 |
162493-0 |
FLANGE NUT COMPLETE |
| 170 |
142228-5 |
FRONT GUARD COMPLETE |
| C10 |
802E03-8 |
CAUTION LABEL |
| 171 |
266857-1 |
H.L. TAPPING SCREW 5X16 |
| 172 |
346697-4 |
HOLDER |
| 173 |
346697-4 |
HOLDER |
| 174 |
266857-1 |
H.L. TAPPING SCREW 5X16 |
| 175 |
266856-3 |
H.L. TAPPING SCREW 5X20 |
| 176 |
801Y89-9 |
PS-352 MODEL NO. LABEL |
| 177 |
126352-2 |
RECOIL STARTER ASSEMBLY |
| 178 |
454522-6 |
STARTER GRIP |
| 179 |
142238-2 |
STARTER CASE COMPLETE |
| 180 |
SG00000020 |
SPRING ASSEMBLY |
| 181 |
SG00000025 |
STARTER ROPE |
| 182 |
454523-4 |
REEL |
| 183 |
SG00000023 |
DAMPER SPRING |
| 184 |
454524-2 |
RATCHET WHEEL |
| 185 |
266777-9 |
TAPPING SCREW 5X12 |
| 186 |
142213-8 |
FAN COVER COMPLETE |
| 187 |
264094-1 |
HEX. NUT M8-12 WITH CW |
| 188 |
142236-6 |
FLYWHEEL COMPLETE |
| 189 |
266866-0 |
H.L. SOCKET HEAD BOLT M5X12 |
| 190 |
346703-5 |
RATCHET |
| 191 |
233609-5 |
TORSION SPRING 15 |
| 192 |
266856-3 |
H.L. TAPPING SCREW 5X20 |
| 193 |
454493-7 |
AIR GUIDE PLATE |
| 194 |
266855-5 |
H.L. TAPPING SCREW 4X12 |
| 195 |
424574-1 |
DUMPER STOPPER |
| 196 |
168508-1 |
TANK CAP COMPLETE |
| 197 |
266854-7 |
H.L. BIND BOLT M5X14 |
| 198 |
135663-4 |
ENGINE CASE ASS’Y |
| 199 |
234210-9 |
COMPRESSION SPRING 3 |
| 200 |
313212-9 |
HAND GUARD GUIDE |
| 201 |
266856-3 |
H.L. TAPPING SCREW 5X20 |
| 202 |
213355-6 |
O-RING 25 |
| 203 |
163518-3 |
GASOLINE FILTER |
| 204 |
282020-8 |
HOSE CLAMP |
| 205 |
422113-1 |
OUTER FUEL PIPE |
| 206 |
422114-9 |
INNER FUEL PIPE |
| 207 |
424575-9 |
GROMMET |
| 208 |
454508-0 |
HOSE JOINT |
| 209 |
424595-3 |
NEEDLE GUIDE |
| 210 |
454496-1 |
SHUTTER PLATE |
| 211 |
232284-4 |
LEAF SPRING |
| 212 |
346696-6 |
HOOK |
| 215 |
ZJ00000063 |
SCREW |
| 216 |
ZJ00000014 |
SCREW (WITH SERRATION) |
| 217 |
ZJ00000055 |
COVER, METERING |
| 218 |
ZJ00000058 |
DIAPHRAGM ASS'Y, METERING |
| 219 |
ZJ00000011 |
GASKET, METERING CHAMBER |
| 220 |
ZJ00000006 |
LEVER |
| 221 |
ZJ00000009 |
SCREW (METERING LEVER PIN) |
| 222 |
ZJ00000008 |
PIN |
| 223 |
ZJ00000010 |
SPRING, METERING LEVER |
| 224 |
ZJ00000007 |
VALVE, INLET NEEDLE |
| 225 |
ZJ00000048 |
LEVER, CHOKE |
| 226 |
ZJ00000003 |
STRAINER |
| 227 |
ZJ00000029 |
DIAPHRAGM, PUMP |
| 228 |
ZJ00000016 |
GASKET, PUMP |
| 229 |
ZJ00000056 |
COVER, PUMP |
| 230 |
ZJ00000020 |
SCREW (PUMP COVER) |
| 231 |
ZJ00000051 |
SCREW, MAIN MIXTURE |
| 232 |
ZJ00000050 |
SCREW, IDLE MIXTURE |
| 233 |
ZJ00000074 |
PLUNGER |
| 234 |
ZJ00000054 |
O-RING |
| 235 |
ZJ00000073 |
SPRING |
| 236 |
ZJ00000062 |
PIECE, FRICTION |
| 237 |
ZJ00000061 |
SCREW, THROTTLE ADJUST |
| 238 |
ZJ00000068 |
SPRING, ADJUST SCREW |
| 239 |
ZJ00000075 |
AIR HEAD KIT |
| 240 |
ZJ00000076 |
GASKET AND DIAPHRAGM KIT |
| A01A |
165441-8 |
GUIDE BAR 14 |
| A01B |
165428-0 |
GUIDE BAR 16 |
| A01-1A |
165441-8 |
GUIDE BAR 14 (O) |
| A01-1B |
165428-0 |
GUIDE BAR 16 (O) |
| A02A |
419561-3 |
CHAIN PROTECTION COVER 330 |
| A02B |
451023-5 |
CHAIN COVER 430MM |
| A03 |
782027-9 |
BOX WRENCH |
| A04A |
196207-5 |
SAW CHAIN SET |
| A04B |
196208-3 |
SAW CHAIN SET |
| E01 |
347558-1 |
HEAT PROTECTION FOIL |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Dolmar websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Dolmar brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Italiano
