Dolmar Spare Parts for Lawn Mower PM-4660S1

SKU: PM4660S1
€0.12
VAT included

Dolmar Spare Parts for Lawn Mower PM-4660S1

Dolmar original spare parts for the replacement of damaged parts or to repair electrical or mechanical components of Lawn Mower PM-4660S1.

Fix Your Lawn Mower PM-4660S1. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

Dolmar Spare Parts for Lawn Mower PM-4660S1
  • Out-of-Stock
  • Dolmar Spare Parts for Lawn Mower PM-4660S1
  • Dolmar PM-4660S1 Drawing

Dolmar Spare Parts for Lawn Mower PM-4660S1

SKU: PM4660S1 Condition: New
€0.12
VAT included

Dolmar Spare Parts for Lawn Mower PM-4660S1

Dolmar original spare parts for the replacement of damaged parts or to repair electrical or mechanical components of Lawn Mower PM-4660S1.

Fix Your Lawn Mower PM-4660S1. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

settings 97 Spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
Quantity
Out-of-Stock

SHIPPING IN: Usually Ships in 7/10 BUSINESS DAYS
MORE INFO:: [email protected]
Machine Type: Lawn Mowers
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

97 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in 7/10 BUSINESS DAYS
Pos. Item Price Buy
E2
Image coming soon 181004366/2 BLADE FOR PLM4811 €42.70
A171
Image coming soon 322140224/0 MULCHING PLUG FOR PLM4811 €34.45
A59
Image coming soon 664000930 SAFETY WASHER €3.25 Not available for order
A60
Image coming soon 664000930 SAFETY WASHER €3.25 Not available for order
A58
Image coming soon 664002039 ADJUSTMENT ROD €150.39
F11
Image coming soon 664002124 BOX, FABRIC €86.23 Not available for order
D10
Image coming soon 664003079 TRANSMISSION €182.10
C23
Image coming soon 664003253 HANDLE €19.42 Not available for order
C3
Image coming soon 664003344 LEVER, MOTOR BRAKE €169.62 Not available for order
C2
Image coming soon 664003349 LEVER, DRIVING €129.54 Not available for order
A1
Image coming soon 664003506 RED HOUSING €0.00 Not available for order
F12
Image coming soon 664006430 FRAME €150.39 Not available for order
C1
Image coming soon 664006670 HANDGRIP €135.70 Not available for order
C6
Image coming soon 664007046 HANDLE €238.60 Not available for order
C14
Image coming soon 664007145 THROTTLE LEVER WITH CABLE €150.39
B2
Image coming soon 664007487 WHEEL €199.13
F1
Image coming soon 664008114 STONE-GUARD €66.72 Not available for order
C12
Image coming soon 664030077 CONTROL CABLE (MOTOR BRAKE) €36.71 Not available for order
C13
Image coming soon 664030078 CONTROL CABLE (WHEEL DRIVE) €46.06 Not available for order
D13
Image coming soon 664033281 ADJUSTMENT LEVER €8.63
A9
Image coming soon 664034000 WASHING CONNECTION €3.11 Not available for order
A10
Image coming soon 664035000 0-RING €24.95 Not available for order
A36
Image coming soon 664038400 BUSH X PM4850S €3.83
A33
Image coming soon 664038407 BUSH €3.11 Not available for order
D14
Image coming soon 664041957 BUSHING X PM 48S €14.64
C8
Image coming soon 664041967 BUSH €2.65 Not available for order
A12
Image coming soon 664060146 HOUSING €18.31
A6
Image coming soon 664060221 GUARD €24.95
D19
Image coming soon 664064150 BELT Z 32 X PM4850S €24.95
A26
Image coming soon 664108205 PLATE €20.80 Not available for order
D18
Image coming soon 664110230 CAP X PM48S-4850S €3.83
B1
Image coming soon 664110653 WHEEL COVER €7.67 Not available for order
D3
Ring Gear for Lawnmower Dolmar PM48S 664120105 Ring Gear for Lawnmower Dolmar PM48S €17.17
C21
Image coming soon 664131750 NUT €8.86 Not available for order
E6
Image coming soon 664139100 KEY PM 43 €3.83
C5
Image coming soon 664154330 NUT X PM 43 €2.50
A29
Image coming soon 664154330 NUT X PM 43 €2.50
A74
Image coming soon 664154510 NUT X PM 48S €1.32
C9
Image coming soon 664154510 NUT X PM 48S €1.32
D17
Image coming soon 664154510 NUT X PM 48S €1.32
E7
Image coming soon 664155000 NUT X PM 43 €1.32
A70
Image coming soon 664155000 NUT X PM 43 €1.32
C26
Image coming soon 664155000 NUT X PM 43 €1.32
B5
Image coming soon 664155000 NUT X PM 43 €1.32
A22
Image coming soon 664155000 NUT X PM 43 €1.32
E3
Image coming soon 664160400 ELASTIC WASHER X PM43 €4.28
C27
Image coming soon 664203854 PROTECTION CAP €2.93 Not available for order
A14
Image coming soon 664203854 PROTECTION CAP €2.93 Not available for order
B3
Image coming soon 664216035 BEARING €8.03 Not available for order
D7
Image coming soon 664216035 BEARING €8.03 Not available for order
A3
Image coming soon 664226109 MASK €24.95 Not available for order
A73
Image coming soon 664293201 NUT X PM 43 €1.24
D8
Image coming soon 664302845 AXLE, REAR WHEELS €199.13 Not available for order
A51
Image coming soon 664302847 AXLE, FRONT WHEELS €129.54 Not available for order
A66
Image coming soon 664322829 HEIGHT ADJUSTMENT LEVER €10.64
C22
Image coming soon 664399835 GRIP €3.11 Not available for order
C4
Image coming soon 664430309 GUIDE SPRING €10.64 Not available for order
A62
Image coming soon 664436050 PLATE X PM4850S €2.93
A63
Image coming soon 664446176 SPRING X PM4850S €3.61
A61
Image coming soon 664446187 SPRING €19.42 Not available for order
D15
Image coming soon 664450063 SPRING X PM 48S €3.11
F2
Image coming soon 664450270 SPRING €6.32 Not available for order
E1
Image coming soon 664465607 BLADE BOSS EUM 430-480 €33.57
C19
Image coming soon 664488301 SUPPORT, R €99.75 Not available for order
C20
Image coming soon 664488303 SUPPORT, L €99.75 Not available for order
A64
Image coming soon 664517880 PIN €18.31
F3
Image coming soon 664517907 PIN €10.64 Not available for order
A75
Image coming soon 664519746 PIN €10.64
B4
Image coming soon 664521350 WASHER X PM 43 €2.93
A15
Image coming soon 664521350 WASHER X PM 43 €2.93
E8
Image coming soon 664521350 WASHER X PM 43 €2.93
C17
Image coming soon 664523000 WASHER €2.93 Not available for order
A28
Image coming soon 664523020 WASHER €2.93 Not available for order
A8
Image coming soon 664523040 WASHER €1.92 Not available for order
E4
Image coming soon 664523080 WASHER X PM 43 €2.03
A31
Image coming soon 664545147 PLATE €8.63 Not available for order
A35
Image coming soon 664545156 PLATE €2.93 Not available for order
A13
Image coming soon 664546070 PLATE €3.61
D5
Image coming soon 664570110 PINION RIGHT X PM 48S €12.40
D2
Pinion Left for Lawnmower Dolmar PM48S 664570120 Pinion Left for Lawnmower Dolmar PM48S €12.04
A24
Image coming soon 664595352 INSPECTION DOOR X PM4850S €5.12
D4
Image coming soon 664600268 PROTECTIVE COVER €12.96
D11
Image coming soon 664601909 PULLEY X PM4850S €7.69
A67
Image coming soon 664602000 CONTROL LEVER €3.83
D6
Image coming soon 664608600 SEEGER PM 48S €1.32
D1
Image coming soon 664608600 SEEGER PM 48S €1.32
D12
Image coming soon 664645705 PIN X PM 48S €1.51
A68
Image coming soon 664672151 WASHER €2.93 Not available for order
A65
Image coming soon 664672152 WASHER €2.93 Not available for order
D16
Image coming soon 664680009 WASHER X PM 48S €2.03
C24
Image coming soon 664680017 SUPPORT €3.83 Not available for order
E9
Image coming soon 664691800 SCREW X PM 43 €3.61
C11
Image coming soon 664727786 SCREW €8.14 Not available for order
C16
Image coming soon 664727812 SCREW €2.93 Not available for order
A11
Image coming soon 664728520 SCREW €2.93 Not available for order
A5
Image coming soon 664728522 SCREW €3.83 Not available for order
C10
Image coming soon 664728721 SCREW €4.87 Not available for order
A71
Image coming soon 664729600 SCREW €1.24 Not available for order
A7
Image coming soon 664729600 SCREW €1.24 Not available for order
A25
Image coming soon 664729600 SCREW €1.24 Not available for order
A34
Image coming soon 664731350 SCREW X PM 48S €2.93
A30
Image coming soon 664731350 SCREW X PM 48S €2.93
A2
Image coming soon 664735420 SCREW €2.93 Not available for order
C7
Image coming soon 664735662 SCREW €4.18 Not available for order
E5
Image coming soon 664735698 SCREW X PM 43 €5.16
D9
Image coming soon 664753000 PIN X PM 48S €1.32
A20
Image coming soon 664778396 BRACKET, RIGHT €29.04 Not available for order
A17
Image coming soon 664778397 BRACKET, LEFT €29.04 Not available for order
A69
Image coming soon 664785115 BRACKET €31.66
A27
Image coming soon 664789000 SCREW X PM 43 €2.03
A72
Image coming soon 664793101 SCREW €1.32
A23
Image coming soon 664793102 SCREW €2.93 Not available for order
C25
Image coming soon 664793102 SCREW €2.93 Not available for order
C15
Image coming soon 664806644 PROTECTION €9.49 Not available for order

Shipping and delivery information will be available shortly.

Dolmar Spare Parts for Lawn Mower PM-4660S1

Fix Your Lawn Mower PM-4660S1. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Lawn Mower and the respective parts of the code.
Dolmar PM-4660S1

Lawn Mower Dolmar PM-4660S1
# Part Num. Description
A1 664003506 xxxx
A2 664735420 SCREW
A3 664226109 FRONT PANEL
A5 664728522 SCREW
A6 664060221 GUARD
A7 664729600 SCREW
A8 664523040 WASHER
A9 664034000 WATER COUPLING
A10 664035000 RING
A11 664728520 SCREW
A12 664060146 HOUSING PM4660S1
A13 664546070 PLATE
A14 664203854 GUARD
A15 664521350 WASHER FOR PM 43
A17 664778397 LEFT SUPPORT
A20 664778396 RIGHT SUPPORT
A22 664155000 NUT FOR PM 43
A23 664793102 SCREW
A24 664595352 CLOSED FLAP FOR PM4850S
A25 664729600 SCREW
A26 664108205 PLATE
A27 664789000 SCREW FOR PM 43
A28 664523020 WASHER
A29 664154330 NUT FOR PM 43
A30 664731350 SCREW FOR PM 48S
A31 664545147 PLATE
A33 664038407 BUSHING
A34 664731350 SCREW FOR PM 48S
A35 664545156 PLATE
A36 664038400 BUSHING FOR PM4850S
A51 664302847 FRONT AXLE
A58 664002039 ADJUSTMENT ROD
A59 664000930 SNAP RING FOR EM-4816
A60 664000930 SNAP RING FOR EM-4816
A61 664446187 SPRING
A62 664436050 PLATE FOR PM4850S
A63 664446176 SPRING FOR PM4850S
A64 664517880 PIN
A65 664672152 WASHER
A66 664322829 ADJUSTMENT LEVER
A67 664602000 CAP
A68 664672151 WASHER
A69 664785115 SUPPORT
A70 664155000 NUT FOR PM 43
A71 664729600 SCREW
A72 664793101 SCREW FOR EM-4816
A73 664293201 NUT FOR PM 43
A74 664154510 NUT FOR PM 48S
A75 664519746 PIN
A171 322140224/0 MULCHING PLUG FOR PLM4811
B1 664110653 HUB CAP
B2 664007487 WHEEL
B3 664216035 BEARING FOR PM4850S
B4 664521350 WASHER FOR PM 43
B5 664155000 NUT FOR PM 43
C1 664006670 GRIP
C2 664003349 DRIVE LEVER
C3 664003344 ENGINE BRAKE LEVER
C4 664430309 GUIDE
C5 664154330 NUT FOR PM 43
C6 664007046 HANDLE
C7 664735662 SCREW
C8 664041967 BUSHING
C9 664154510 NUT FOR PM 48S
C10 664728721 SCREW
C11 664727786 SCREW
C12 664030077 ENGINE BRAKE CABLE
C13 664030078 DRIVE CABLE
C14 664007145 THROTTLE LEVER
C15 664806644 GUARD
C16 664727812 SCREW
C17 664523000 WASHER
C19 664488301 SUPPORT RIGHT
C20 664488303 LEFT SUPPORT
C21 664131750 NUT
C22 664399835 KNOB
C23 664003253 LEVER
C24 664680017 SUPPORT
C25 664793102 SCREW
C26 664155000 NUT FOR PM 43
C27 664203854 GUARD
D1 664608600 SNAP RING FOR PM 48S
D2 664570120 LEFT PINION FOR PM 48S
D3 664120105 SPROCKET FOR PM 48S
D4 664600268 GUARD
D5 664570110 RIGHT PINION FOR PM 48S
D6 664608600 SNAP RING FOR PM 48S
D7 664216035 BEARING FOR PM4850S
D8 664302845 REAR AXLE
D9 664753000 PIN FOR PM 48S
D10 664003079 GEARBOX ASSEMBLY PM4860S
D11 664601909 PULLEY FOR PM4850S
D12 664645705 PIN FOR PM 48S
D13 664033281 LINKAGE PM4860S
D14 664041957 BUSHING FOR PM 48S
D15 664450063 SPRING FOR PM 48S
D16 664680009 WASHER FOR PM 48S
D17 664154510 NUT FOR PM 48S
D18 664110230 CAP FOR PM48S-4850S
D19 664064150 BELT Z 32 FOR PM4850S
E1 664465607 BLADE HUB EUM 430-480
E2 181004366/2 BLADE FOR PLM4811
E3 664160400 SPRING WASHER FOR PM43
E4 664523080 WASHER FOR PM 43
E5 664735698 SCREW FOR PM 43
E6 664139100 KEY PM 43
E7 664155000 NUT FOR PM 43
E8 664521350 WASHER FOR PM 43
E9 664691800 SCREW FOR PM 43
F1 664008114 STONE GUARD
F2 664450270 SPRING
F3 664517907 PIN
F11 664002124 GRASS CATCHER BAG PLM5114/5
F12 664006430 BAG FRAME
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Dolmar websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Dolmar brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
PM4660S1

Data sheet

Machine Type
Lawn Mowers
MORE INFO:
[email protected]
SHIPPING IN
Usually Ships in 7/10 BUSINESS DAYS

Specific References

New

Download

Dolmar PM-4660S1

Dolmar PM-4660S1

Download (463.65KB)

You might also like

Makita SKU: 671002448
Blade Boss for Lawnmower Dolmar PM-46SBC Genuine replacement part Dolmar, Blade Boss for Lawnmowers PM-46SB - PM-46SBC - PM-46NB - PM-46NBC. Parts for the following...
Usually Ships in: 7/10 Business Days Approx. €21.91
Makita SKU: 671014610
Blade for Lawnmower Dolmar PM-46SBC Genuine replacement part Dolmar, Blade for Lawnmowers PM-46SB - PM-46SBC - PM-46NB - PM-46NBC. Part for the following products: -  PM-46SBC - LAWNMOWER 140CC 46CM DOLMAR - PM-46NB - RASAERBA 140CC...
Makita SKU: 671001258
Dolmar Throttle cable - engine start / stop for PM-46SBC Genuine replacement part Dolmar, Control Cable for Lawnmowers PLM4628N - PM-46SBC Parts for the following products: - PLM4628N - LAWNMOWER 140CC 46CM...
Usually Ships in: 7/10 Business Days Approx. €37.93
Makita SKU: 671501028
Original Makita spare part - TRACTION GROUP. Part number: 671501028 PRODUCT DESCRIPTION The part number 671501028 identifies the Original Traction Group (Gearbox / Drive Assembly complete with pulley) for Makita and Dolmar petrol...
Last items in stock €164.90
Comments (0)
No customer reviews for the moment.
