Dolmar parts for AT3726L Cordless Grass Trimmer

Name: Dolmar parts for AT3726L Cordless Grass Trimmer
Brand: Makita
SKU: Dolmar PS220TH - PS220THC
Availability: InStock

SKU: Dolmar PS220TH - PS220THC

€0.10

VAT included

Dolmar Genuine spare parts for AT3726L Cordless Grass Trimmer

Dolmar AT3726L / Cordless Grass Trimmer
Professional cordless trimmer featuring a loop handle and high-efficiency motor. Equipped with a battery guard, electronic controller, and a versatile cutting system compatible with trimmer heads and blades. Designed for maximum maneuverability and precision trimming.

New
Out-of-Stock

Dolmar parts for AT3726L Cordless Grass Trimmer

SKU: Dolmar PS220TH - PS220THC Condition: New

€0.10

VAT included

Dolmar Genuine spare parts for AT3726L Cordless Grass Trimmer

72 spare parts

1 exploded view

Download Exploded PDF

Quantity

Out-of-Stock

SHIPPING IN:: Usually Ships in: 7/10 BUSINESS DAYS

MORE INFO:: [email protected]

Original Product Manufacturer warranty included

Technical Support Our team helps you choose

Secure and guaranteed payments

72 spare parts

Page 1 View exploded Usually Ships in: 7/10 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
A01		125516-5 Makita Band Assembly	€6.50
A04	Image coming soon	144392-8 TOOL COVER 2T	€4.56
A06	Image coming soon	782238-6 HEX WRENCH 17	€2.54
1	Image coming soon	123853-1 GEAR CASE ASSEMBLY	€87.55
2	Image coming soon	265590-2 HEX BOLT M8x10 EBH253L/EBH341U	€1.32
3	Image coming soon	232350-7 RING SPRING 6	€1.32
4	Image coming soon	210030-5 BEARING 627ZZ X MT601	€1.92
5	Image coming soon	221484-1 SPIRAL BEVEL GEAR 19	€24.95
6	Image coming soon	136233-2 CUTTER SHAFT ASS'Y	€70.77
7		211228-7 Ball Bearing 6202DD for Demolition Hammer Makita HM1800	€8.63
8	Image coming soon	257432-4 RETAINING RING R-35	€1.32
9	Image coming soon	144312-2 RECEIVE WASHER COMPLETE	€22.06
10	Image coming soon	347104-0 CLAMP WASHER	€6.70
11	Image coming soon	457274-8 CUP US	€5.16
12	Image coming soon	252236-9 HEX. LOCK NUT M10-17	€3.83
13	Image coming soon	136235-8 SPIRAL BEVEL GEAR ASS'Y	€36.71
14	Image coming soon	210049-4 BEARING 609ZZ EBH252L	€5.66
15	Image coming soon	257986-1 RETAINING RING S9 RBC2510	€2.50
16	Image coming soon	257987-9 RETAINING RING R24 RBC2510	€1.24
17	Image coming soon	191854-1 PROTECTOR U 430 SET MG	€43.15
18	Image coming soon	922216-6 SCREW ESAG. M5x14	€1.32
19	Image coming soon	922242-5 HEX. SOCKET HEAD BOLT M5X25	€1.32
20	Image coming soon	327056-1 SHAFT	€10.07
21	Image coming soon	251513-6 H.S.H.BOLT M5X25	€1.32
22	Image coming soon	347107-4 PROTECTOR CLAMP 24	€3.11
23	Image coming soon	922216-6 SCREW ESAG. M5x14	€1.32
24	Image coming soon	457271-4 PROTECTOR U 450	€14.64
25	Image coming soon	140P10-2 SHAFT PIPE COMPLETE H	€36.71
26	Image coming soon	457267-5 LOOP HANDLE	€17.02
27	Image coming soon	922234-4 H.S.H.BOLT M5X20 WITH WG	€1.32
28	Image coming soon	347113-9 UPPER CLAMP 35	€1.32
29	Image coming soon	457269-1 PIPE HOLDER 24	€2.65
30	Image coming soon	144315-6 BARRIER COMPLETE	€6.00
31	Image coming soon	347114-7 LOWER CLAMP 35	€2.03
32	Image coming soon	424942-8 DAMPER	€2.03
33	Image coming soon	451601-1 SPACER EBH252L	€3.83
34		266326-2 Strain Relief Screw M4x16 for Angle Grinder Makita GA4530	€1.27
35	Image coming soon	183N28-8 GRIP SET	€24.95
36	Image coming soon	140K37-2 DISPLAY E	€33.57
37	Image coming soon	140K35-6 SWITCH CIRCUIT COMPLETE G	€24.95
38	Image coming soon	459758-2 SWITCH LEVER	€2.65
40	Image coming soon	233622-3 TORSION SPRING 12	€1.32
41	Image coming soon	459759-0 LOCK OFF LEVER	€2.65
42	Image coming soon	233101-1 COMPRESSION SPRING 4	€1.32
44	Image coming soon	651436-2 SWITCH C3JW-1A-P-2	€22.06
45	Image coming soon	922244-1 SCREW M5X25	€2.65
47		922233-6 Hex Socket HD Bolt M5x20 for Chainsaw Makita DCS230T	€1.32
54	Image coming soon	183N24-6 HOUSING SET	€57.57
55	Image coming soon	911233-1 HEAD SCREW M5X20 3600H	€1.32
56		263002-9 Rubber Pin for Hammer SDS-Max Makita HR4000C	€1.32
57	Image coming soon	319919-5 PIPE BRACKET	€19.42
58	Image coming soon	325811-5 SPINDLE HUB BBC231U/BBC300L/BU	€17.02
59		211131-2 Ball Bearing 6001DD for Makita 9218S	€6.00
60	Image coming soon	226931-7 HELICAL GEAR 29	€6.00
61	Image coming soon	266459-3 SCREW 5x25 PC5000C	€1.32
62	Image coming soon	211150-8 BALL BEARING 6901ZZ/BUR360/BUX	€5.16
63	Image coming soon	226932-5 HELICAL GEAR 10	€5.16
64	Image coming soon	213961-7 O RING 22 HM1111C	€1.32
65	Image coming soon	136230-8 BODY GEAR	€12.96
66		210005-4 Ball Bearing 608DDW for Jigsaw Makita 4327	€5.16
67	Image coming soon	519587-6 ROTOR ASS'Y	€57.57
68		210062-2 Ball Bearing 607 ZZ for Impact Drill Maktek MT601	€2.03
69	Image coming soon	459764-7 BAFFLE PLATE	€2.65
70		266326-2 Strain Relief Screw M4x16 for Angle Grinder Makita GA4530	€1.27
72	Image coming soon	629471-8 STATOR	€57.57
73	Image coming soon	644809-6 TERMINAL X BLS713-BHP451	€6.00
74	Image coming soon	459763-9 MOTOR HOUSING	€7.67
76	Image coming soon	911102-6 SCREW M4X6	€1.32
77	Image coming soon	620C09-0 CONTROLLER	€225.50
81		922233-6 Hex Socket HD Bolt M5x20 for Chainsaw Makita DCS230T	€1.32
82	Image coming soon	183N24-6 HOUSING SET	€57.57
85	Image coming soon	251314-2 SCREW M4X12	€1.32
86	Image coming soon	347563-8 BATTERY GUARD	€7.67
87	Image coming soon	144316-4 PROTECTOR U EXT. 420-450 COMP	€10.07
88	Image coming soon	459765-5 CUTTER EXTENSION	€2.03
89	Image coming soon	347115-5 CUTTER	€2.65
90	Image coming soon	266459-3 SCREW 5x25 PC5000C	€1.32

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Dolmar Genuine spare parts for AT3726L Cordless Grass Trimmer

DOLMAR AT3726L / CORDLESS GRASS TRIMER PARTS LIST
#	Part Num.	Description
1	123853-1	GEAR CASE ASSEMBLY
2	265590-2	+HEX.BOLT M8X10 WITH R
3	232350-7	RING SPRING 6
4	210030-5	BALL BEARING 627ZZ
5	221484-1	SPIRAL BEVEL GEAR 19
6	136233-2	CUTTER SHAFT ASS'Y
7	211228-7	BALL BEARING 6202DDW
8	257432-4	RETAINING RING R-35
9	144312-2	RECEIVE WASHER COMPLETE
10	347104-0	CLAMP WASHER
11	457274-8	CUP US
12	252236-9	HEX. LOCK NUT M10-17
13	136235-8	SPIRAL BEVEL GEAR ASS'Y
14	210049-4	BALL BEARING 609ZZ
15	257986-1	RETAINING RING (EXT) S-9
16	257987-9	RETAINING RING (INT) R-24
17	191854-1	PROTECTOR U 430 SET MG
18	922216-6	H.S.H.BOLT M5X14 WITH W
19	922242-5	HEX. SOCKET HEAD BOLT M5X25
20	327056-1	SHAFT
21	251513-6	H.S.H.BOLT M5X25
22	347107-4	PROTECTOR CLAMP 24
23	922216-6	H.S.H.BOLT M5X14 WITH W
24	457271-4	PROTECTOR U 450
25	140P10-2	SHAFT PIPE COMPLETE H
26	457267-5	LOOP HANDLE
27	922234-4	H.S.H.BOLT M5X20 WITH WG
28	347113-9	UPPER CLAMP 35
29	457269-1	PIPE HOLDER 24
30	144315-6	BARRIER COMPLETE
31	347114-7	LOWER CLAMP 35
32	424942-8	DAMPER
33	451601-1	SPACER 24
34	266326-2	TAPPING SCREW 4X18
35	183N28-8	GRIP SET
36	140K37-2	INDICATION CIRCUIT COMPLETE E
37	140K35-6	SWITCH CIRCUIT COMPLETE G
38	459758-2	SWITCH LEVER
40	233622-3	TORSION SPRING 12
41	459759-0	LOCK OFF LEVER
42	233101-1	COMPRESSION SPRING 4
44	651436-2	SWITCH C3JW-1A-P-2
45	922244-1	H.S.H.BOLT M5X25 WITH WG
47	922233-6	H.S.H.BOLT M5X20 WITH WR
54	183N24-6	HOUSING SET
55	911233-1	PAN HEAD SCREW M5X20
56	263002-9	RUBBER PIN 4
57	319919-5	PIPE BRACKET
58	325811-5	SPINDLE HUB
59	211131-2	BALL BEARING 6001DDW
60	226931-7	HELICAL GEAR 29
61	266459-3	TAPPING SCREW 5X25
62	211150-8	BALL BEARING 6901ZZ
63	226932-5	HELICAL GEAR 10
64	213961-7	O RING 22
65	136230-8	GEAR BOX ASS'Y
66	210005-4	BALL BEARING 608DDW
67	519587-6	ROTOR ASS'Y
68	210062-2	BALL BEARING 607ZZ
69	459764-7	BAFFLE PLATE
70	266326-2	TAPPING SCREW 4X18
71	856J23-4	AT3726L SERIAL NO. LABEL
72	629471-8	STATOR
73	644809-6	TERMINAL
74	459763-9	MOTOR HOUSING
75	654887-8	EARTH PLATE
76	911102-6	PAN HEAD SCREW M4X6
77	620C09-0	CONTROLLER
81	922233-6	H.S.H.BOLT M5X20 WITH WR
82	183N24-6	HOUSING SET
84	856J14-5	AT3726L NAME PLATE
85	251314-2	#NOME?
86	347563-8	BATTERY GUARD
87	144316-4	PROTECTOR U EXT. 420-450 COMP
88	459765-5	CUTTER EXTENSION
89	347115-5	CUTTER
90	266459-3	TAPPING SCREW 5X25
A01	125516-5	BAND ASSEMBLY
A02	197994-9	TRIMMER HEAD 95-M10L SET DE
A03	126642-3	PLASTIC BLADE ASSEMBLY 255-M10L
A04	144392-8	TOOL COVER 2T
A05	198347-5	CUTTER BLADE 255-2 SET DE
A06	782238-6	BOX WRENCH 17
A07	783202-0	HEX. WRENCH 4
A08	831315-2	ACCESSORY BAG

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Dolmar websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Dolmar brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
