| Baby-KOMPACTA 250-TV Pag.1 |
| # |
Part Num. |
Description |
| 1 |
K250TV.00.001 |
Caliber records knives K250TV |
| 10 |
K250TV.01.010 |
Protection planer x K250TV |
| 11 |
K250TV.01.011 |
Pin opening plan K250TV |
| 12 |
K250TV.01.012 |
Holder open plan K250TV |
| 15 |
K250TV.01.015 |
Cursor to line planer K250TV |
| 16 |
K250TV.01.016 |
Lever M8x20 |
| 17 |
K250TV.01.017 |
Pin fixation line K250TV |
| 20 |
K250TV.01.020 |
Riga aluminum x team planer / saw 250 TV |
| 23 |
K250TV.01.023 |
Holder closure plan K250TV |
| 25 |
K250TV.01.025 |
plate |
| B01 |
K250TV.01.B01 |
Locking knob auction floors K250TV |
| B03 |
K250TV.01.B03 |
Lever M8x40 K250TV |
| Pag.2 |
| 1 |
K250TV.02.001 |
Protection for spindle mortiser K250TV |
| 3 |
K250TV.02.003 |
Wescott chuck for bits 3-16 |
| 10 |
K250TV.02.010 |
Gib lock knives |
| 11 |
K250TV.02.011 |
Spring x planer knives K250TV |
| 16 |
K250TV.02.016 |
Auction door lugs backstop K250TV |
| 17 |
K250TV.02.017 |
Toothed roller drag K250TV |
| 18 |
K250TV.02.018 |
Holder plastic planer |
| 19 |
K250TV.02.019 |
prisoner M8 |
| 22 |
K250TV.02.022 |
Planer Shaft K250TV |
| 23 |
K250TV.02.023 |
Smooth roller drag K250TV |
| 25 |
K250TV.02.025 |
Exhaust hood mod.K250TV |
| 26 |
K250TV.02.026 |
Spring planer |
| 27 |
K250TV.02.027 |
Supp.interno planer K250TV |
| 29 |
K250TV.02.029 |
Flange bearing stops K250TV |
| 32 |
K250TV.02.032 |
Pinion rollers towing |
| B01 |
K250TV.02.B01 |
Tip for mortiser d.10 K250TV |
| B02 |
K250TV.02.B02 |
bearing |
| Pag.3 |
| 4 |
K250TV.03.004 |
Floor thickness K250TV |
| 6 |
K250TV.03.006 |
DIN rail wood K250TV |
| 8 |
K250TV.03.008 |
Screw lifting floor thickness K250TV |
| 30 |
K250TV.03.030 |
Group lifting plan K250TV |
| 0B1 |
K250TV.03.0B1 |
(OBSOLETE) Adjustable handle |
| B01 |
K250TV.03.B01 |
Lever |
| Pag.4 |
| 16 |
K250TV.04.016 |
Bloc.selett plate. K250TV |
| 18 |
K250TV.04.018 |
shift Lever |
| 22 |
K250TV.04.022 |
Carter lower front K250TV |
| 23 |
K250TV.04.023 |
Plate fixing sc. emergency K250TV |
| B02 |
K250TV.04.B02 |
Locking knob selector K250TV |
| B03 |
K250TV.04.B03 |
Box Emergency K250TV |
| Pag.5 |
| 20 |
K250TV.05.020 |
Group complete change K250TV |
| B10 |
K250TV.05.B10 |
Engine H90L 2.P 230 / 50Hz. B3 Kw.2,2 |
| B12 |
K250TV.05.B12 |
Capacitor paper 300 MY |
| B13 |
K250TV.05.B13 |
Capacitor 60 MY K250TV |
| Pag.6 |
| 15 |
K250TV.06.015 |
Bearing support and exchange |
| 17 |
K250TV.06.017 |
Pinion |
| 25 |
K250TV.06.025 |
Reduction unit K250TV |
| B08 |
K250TV.06.B08 |
Transmission roller chain thickness 250 T.V. |
| B09 |
K250TV.06.B09 |
V-belt feed thickness (Z-900) .250TV |
| B10 |
K250TV.06.B10 |
V-belt planer (A-900) x250TV |
| Pag.7 |
| 7 |
K250TV.07.007 |
Divider knife |
| 9 |
K250TV.07.009 |
Nut locking blade M18sx 250TV |
| 10 |
K250TV.07.010 |
Front flange locking saw K250TV |
| 11 |
K250TV.07.011 |
Rear flange locking saw |
| 12 |
K250TV.07.012 |
Tree saw K250TV |
| 13 |
K250TV.07.013 |
spacer K250TV |
| 19 |
K250TV.07.019 |
Pulley shaft saw K250TV |
| 20 |
K250TV.07.020 |
Washer d.8,5x16x3 K250TV |
| 21 |
K250TV.07.021 |
Holder selector K250TV |
| 30 |
K250TV.07.030 |
Sleeve belt tensioning |
| 37 |
K250TV.07.037 |
Lever get up saw K250TV |
| 50 |
K250TV.07.050 |
Kit saw protection |
| B03 |
K250TV.07.B03 |
Seegeer x internal D.42 K250TV |
| B04 |
K250TV.07.B04 |
Key 6x6x16 K250TV |
| B05 |
K250TV.07.B05 |
bearing d.20x42 |
| B06 |
K250TV.07.B06 |
Seegeer x external d.55 K250TV |
| B07 |
K250TV.07.B07 |
Trap.albero belt saw (A-560) x 250TV |
| Pag.8 |
| 5 |
K250TV.08.005 |
Extruded Shopping Guide |
| 6 |
K250TV.08.006 |
Cart x K250TV |
| 7 |
K250TV.08.007 |
Plate positioning x K250TV |
| 8 |
K250TV.08.008 |
Rollers x K250TV |
| 9 |
K250TV.08.009 |
Holder x K250TV |
| 10 |
K250TV.08.010 |
Spacer x K250TV |
| 11 |
K250TV.08.011 |
Sheet rollover x K250TV |
| 12 |
K250TV.08.012 |
Spacer x K250TV |
| 13 |
K250TV.08.013 |
Spacer x K250TV |
| 14 |
K250TV.08.014 |
Goniometer for squaring K250TV |
| 15 |
K250TV.08.015 |
Colonnetta pressure squaring K250TV |
| 16 |
K250TV.08.016 |
Tubular guide cart |
| 20 |
K250TV.08.020 |
spacer |
| 21 |
K250TV.08.021 |
Worktop saw tuopiŠ K250TV |
| 25 |
K250TV.08.025 |
Vertical clamp complete K250TV |
| 26 |
K250TV.08.026 |
Riga cart full K250TV |
| 27 |
K250TV.08.027 |
Group cart full K250TV |
| B02 |
K250TV.08.B02 |
Bearing 6000-2RS d.10x26x8 |
| B03 |
K250TV.08.B03 |
Knob locking protractor d.30M8x30 |
| B2 |
K250TV.08.B2 |
(OBSOLETE) Bearing 6000-2RS d.10x26x8 |
| Pag.9 |
| 1 |
K250TV.09.001 |
Cover hole toupiŠ K250TV / 09 |
| 3 |
K250TV.09.003 |
Protection blade passage |
| 10 |
K250TV.09.010 |
Washer d.i.12 K250TV |
| 19 |
K250TV.09.019 |
Pulley shaft toupiŠ K250TV |
| 20 |
K250TV.09.020 |
Motor pulley toupiŠ |
| 21 |
K250TV.09.021 |
Dinghy tree toupiŠ K250TV |
| 22 |
K250TV.09.022 |
Motor support toupiŠ K250TV |
| 30 |
K250TV.09.030 |
Reduction Bushing tree toupiŠ K250TV |
| B06 |
K250TV.09.B06 |
Poly-V belt moulder 4PJ236 (240) K250TV |
| B07 |
K250TV.09.B07 |
Moulder Motor brush kW. 1.2 mod.250TV |
| B08 |
K250TV.09.B08 |
Start button K250TV |
| B09 |
K250TV.09.B09 |
Emergency button K250TV |
| B10 |
K250TV.09.B10 |
Selector 0-1 K250TV |
| B11 |
K250TV.09.B11 |
On-off switch engine toupiŠ K250TV |
| B12 |
K250TV.09.B12 |
Thermal Q.E. K250TV |
| B13 |
K250TV.09.B13 |
Tele-breaker Q.E. 250TV |
| B14 |
K250TV.09.B14 |
Green light Q.E. 250TV |
| B15 |
K250TV.09.B15 |
(OBSOLETE) Tele-breaker x K250TV |
| B20 |
K250TV.09.B20 |
Head door knives d.80 K250TV |
| Pag.10 |
| 2 |
K250TV.10.002 |
Front pressure cover toupie K250TV |
| 5 |
K250TV.10.005 |
Clamp protections cover toupie |
| 16 |
K250TV.10.016 |
Security Support tilting cover toupie |
| 17 |
K250TV.10.017 |
clamp cover |
| 20 |
K250TV.10.020 |
Toupie complete Cover K250TV |
| B02 |
K250TV.10.B02 |
Handle recovery M8x30 |
| B05 |
K250TV.10.B05 |
Knob d.30 M8x30 |
| B06 |
K250TV.10.B06 |
Knob fixing headphones toupiŠ |
| Pag.11 |
| 50 |
K250TV.11.050 |
Group mortiser complete K250TV |
| B03 |
K250TV.11.B03 |
Flyer sollev.piano mortiser K250TV |
| 25 |
K250TV.2A.025 |
(OBSOLETE) Suction planer co |
| B11 |
K250TV.9A.B11 |
(OBSOLETE) Switch 0-1 toupiŠ x com |
| 501 |
ACC.33/1 |
Tool set for Surfacer and Planer |
| 502 |
0242AWZ36 |
Circular saw blade D.250Z36 |
| 503 |
ACC.33/2 |
6 pcs. mortiser tool set |
| 504 |
ACC.33/4-B |
Tools holding chuck + 7 milling knives |
