Compa-OMS Original spare parts at attractive and competitive prices on the web, we are a licensed service center with a repair service able to quickly solve the maintenance or repair any issues for Portable Mitre Saw Orange 305-90/100.
Compa-OMS Original spare parts at attractive and competitive prices on the web, we are a licensed service center with a repair service able to quickly solve the maintenance or repair any issues for Portable Mitre Saw Orange 305-90/100.
Informazioni sulle spedizioni e consegne saranno disponibili a breve.
Compa-OMS Original spare parts at attractive and competitive prices on the web, we are a licensed service center with a repair service able to quickly solve the maintenance or repair any issues for Portable Mitre Saw Orange 305-90/100.
In the following table, find spare parts of the Portable Saws and code.
![]()
| MITRE SAW ORANGE 305-90/100 | ||
| # | Part Num | Description |
| 1 | ORANG3059/001 | Blade attachment bolt |
| 2 | ORANG3059/002 | external flange |
| 4 | ORANG3059/004 | internal flange |
| 5 | ORANG3059/005 | M5 x 20 mm |
| 6 | ORANG3059/006 | M5 x 20 mm |
| 7 | ORANG3059/007 | Semi-left arm |
| 9 | ORANG3059/009 | Rivet d.4 x 8 mm |
| 10 | ORANG3059/010 | Bushing d.16 x d.10 x 12 mm |
| 11 | ORANG3059/011 | nut M5 |
| 12 | ORANG3059/012 | Connecting rod |
| 13 | ORANG3059/013 | Mobile Security |
| 14 | ORANG3059/014 | Sealing ring d.36 mm |
| 15 | ORANG3059/015 | Bushing d.14 x d.7.8 x 7.5 mm |
| 16 | ORANG3059/016 | M5 x 12 mm |
| 19 | ORANG3059/019 | Ball Bearing (6202) |
| 20 | ORANG3059/020 | Spring d.10.6 22 x 1.2 mm |
| 21 | ORANG3059/021 | stator |
| 22 | ORANG3059/022 | Bolt d.6 x M5 x 26 mm |
| 23 | ORANG3059/023 | Bushing d.23.5 x 25 mm |
| 24 | ORANG3059/024 | Ball Bearing (6203) |
| 25 | ORANG3059/025 | Copricusinetto |
| 26 | ORANG3059/026 | Riving knife locking plate |
| 27 | ORANG3059/027 | Screw M6 x 15 mm |
| 28 | ORANG3059/028 | Spring washer M6 |
| 29 | ORANG3059/029 | motor cover |
| 30 | ORANG3059/030 | Aluminum casing of the engine |
| 31 | ORANG3059/031 | Semi-right arm |
| 32 | ORANG3059/032 | riving knife |
| 33 | ORANG3059/033 | Screw M4 x 30 mm |
| 34 | ORANG3059/034 | Flat washer d.16 mm |
| 35 | ORANG3059/035 | Sealing ring d.16 |
| 36 | ORANG3059/036 | Armature, Brushless |
| 37 | ORANG3059/037 | Semi-left handle |
| 38 | ORANG3059/038 | Start button |
| 39 | ORANG3059/039 | The tripping device start button |
| 40 | ORANG3059/040 | spring |
| 41 | ORANG3059/041 | Release button arm |
| 42 | ORANG3059/042 | Kit levers release arm |
| 43 | ORANG3059/043 | Switch x mod. Orange 305-90 |
| 44 | ORANG3059/044 | Kit release levers arm |
| 45 | ORANG3059/045 | Spring d.7 x 45 mm x d.1 |
| 46 | ORANG3059/046 | Block release blade |
| 47 | ORANG3059/047 | Sealing ring d.10 mm |
| 48 | ORANG3059/048 | Pin release blade d.10 x 54 mm |
| 49 | ORANG3059/049 | fan |
| 50 | ORANG3059/050 | Semimpugnatura Dx |
| 51 | ORANG3059/051 | Screw M4 x 20 mm |
| 52 | ORANG3059/052 | Fan cover |
| 53 | ORANG3059/053 | Screw M4 x 20 mm |
| 54 | ORANG3059/054 | M5 x 160 mm |
| 55 | ORANG3059/055 | Locking pawl M6 x 30 mm |
| 56 | ORANG3059/056 | Screw M4 x 10 mm |
| 57 | ORANG3059/057 | Flat washer d.4 mm |
| 58 | ORANG3059/058 | Spring D.11 x 140 mm x d.2 |
| 59 | ORANG3059/059 | clamp bracket |
| 60 | ORANG3059/060 | Colonetta driving raising plan |
| 61 | ORANG3059/061 | Colonetta driving raising plan |
| 62 | ORANG3059/062 | Screw M6 x 25 mm |
| 63 | ORANG3059/063 | Upper clamp bracket top |
| 64 | ORANG3059/064 | nut M6 |
| 65 | ORANG3059/065 | Support bracket top |
| 66 | ORANG3059/066 | Caps upper bracket |
| 67 | ORANG3059/067 | Language protection headphones |
| 68 | ORANG3059/068 | nut M8 |
| 69 | ORANG3059/069 | Headphone blade guard |
| 70 | ORANG3059/070 | Lower guard upstairs |
| 71 | ORANG3059/071 | Locking knob headset |
| 72 | ORANG3059/072 | Spring d.7 x 7.5 x d. 0.6 mm |
| 73 | ORANG3059/073 | Sealing ring d.6 mm |
| 74 | ORANG3059/074 | Pin D.3 x 30 mm |
| 75 | ORANG3059/075 | Locking pin d.10 x 43 mm |
| 76 | ORANG3059/076 | locking lever carousel |
| 77 | ORANG3059/077 | Spring d.8 x 21 x d. 0.7 mm |
| 78 | ORANG3059/078 | Nut M12 closed |
| 79 | ORANG3059/079 | Flat washer M12 |
| 80 | ORANG3059/080 | Locking pawl carousel M6 x 35 |
| 81 | ORANG3059/081 | Foot-slip rubber and |
| 82 | ORANG3059/082 | base |
| 83 | ORANG3059/083 | Locking pawl M6 x 20 mm |
| 84 | ORANG3059/084 | M8 x 40 mm |
| 85 | ORANG3059/085 | carousel |
| 86 | ORANG3059/086 | bracket |
| 87 | ORANG3059/087 | fifth wheel |
| 88 | ORANG3059/088 | Cage portarullini complete |
| 89 | ORANG3059/089 | roll |
| 90 | ORANG3059/090 | lower protection |
| 91 | ORANG3059/091 | nut M6 |
| 92 | ORANG3059/092 | Threaded bolt M6 x 30 mm |
| 93 | ORANG3059/093 | Screw M12 x 85 mm |
| 94 | ORANG3059/094 | M5 x 10 mm |
| 95 | ORANG3059/095 | OBSOLETE new: ORANG3059 / 135 |
| 96 | ORANG3059/096 | spring |
| 97 | ORANG3059/097 | M8 x 15 mm |
| 98 | ORANG3059/098 | Flat washer d.8 mm |
| 99 | ORANG3059/099 | Guide plastic blade |
| 100 | ORANG3059/100 | M4 screw |
| 101 | ORANG3059/101 | Handle unlocks arm R80 M12 |
| 102 | ORANG3059/102 | Threaded bolt M6 x 45 mm |
| 103 | ORANG3059/103 | tree arm |
| 104 | ORANG3059/104 | Sealing ring d.16 mm |
| 105 | ORANG3059/105 | Support arm |
| 106 | ORANG3059/106 | Ball Bearing 6002 |
| 107 | ORANG3059/107 | Upper Working Table |
| 108 | ORANG3059/108 | upper bracket |
| 109 | ORANG3059/109 | Push stick |
| 110 | ORANG3059/110 | nut M6 |
| 112 | ORANG3059/112 | Chip collection bag |
| 113 | ORANG3059/113 | Retaining bar piece |
| 114 | ORANG3059/114 | hex wrench |
| 115 | ORANG3059/115 | Allen key |
| 116 | ORANG3059/116 | Vertical vice x Orange 305-90 / 100 |
| 117 | ORANG3059/117 | USE BRAKE ORANGE |
| 118 | ORANG3059/118 | Capacitor x Orange 305-90 / 100 |
| 119 | ORANG3059/119 | Plastic cover |
| 120 | ORANG3059/120 | electrical cable |
| 121 | ORANG3059/121 | belt |
| 122 | ORANG3059/122 | Sealing ring d.15 mm |
| 123 | ORANG3059/123 | Flat washer d.15 mm |
| 124 | ORANG3059/124 | pulley |
| 125 | ORANG3059/125 | engine cover |
| 126 | ORANG3059/126 | Ball Bearing (6003) |
| 127 | ORANG3059/127 | crankshaft |
| 128 | ORANG3059/128 | key |
| 129 | ORANG3059/129 | Ball Bearing (6203) |
| 130 | ORANG3059/130 | bearing cover |
| 131 | ORANG3059/131 | pulley |
| 132 | ORANG3059/132 | Flat washer d.15 mm |
| 133 | ORANG3059/133 | nut M15 |
| 134 | ORANG3059/134 | Plastic Cover |
| 135 | ORANG3059/135 | Conveyor OR.305 / 100 |
| 136 | ORANG3059/136 | OR D.1.5 x 35 mm |
| 138 | ORANG3059/138 | Threaded bolt M6 x 30 mm |
| 139 | ORANG3059/139 | nut M6 |
| 140 | ORANG3059/140 | key |
| 141 | ORANG3059/141 | key |
| 142 | ORANG3059/142 | Protection lower upper shelf |
| 144 | ORANG3059/144 | Motor Assembly 305/90/100 (125 to 140) |
| 145 | ORANG3059/145 | Accessories complete (113-114-115 - 106-109) |
| 146 | ORANG3059/146 | Shaft Assembly (126-133) |
