Compa-OMS Spare Parts for Portable Saws 250 E-ET Super

SKU: Compa 250E-ET Super
€3.48
VAT included

Compa-OMS Spare Parts for Portable Saws 250 E-ET Super

We have the original Spares COMPA for Mitre Saws 250 E Super - 250 E.T. Super, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.
Compa-OMS Spare Parts for Portable Saws 250 E-ET Super
  • Compa-OMS Spare Parts for Portable Saws 250 E-ET Super
  • Compa-OMS Spare Parts for Portable Saws 250 E-ET Super - Drawing
  • Compa-OMS Spare Parts for Portable Saws 250 E-ET Super - Drawing - 1
COMPA TECH-OMS

Compa-OMS Spare Parts for Portable Saws 250 E-ET Super

SKU: Compa 250E-ET Super Condition: New
€3.48
VAT included

Compa-OMS Spare Parts for Portable Saws 250 E-ET Super

We have the original Spares COMPA for Mitre Saws 250 E Super - 250 E.T. Super, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.
settings 78 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
MORE INFO:: [email protected]
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
78 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
Esploso pagina 2
1 / 2
Pos. Item Price Buy
photo_cameraImage coming soon 0277-01 Return spring release lever €2.38
photo_cameraImage coming soon 0386LAVORATO Extruded support sq.tagl. and worked €12.75
Divider Knife For Miter Saw Compa 250 E Super - 250 E.T. Super 20030060 Divider Knife For Miter Saw Compa 250 E Super - 250 E.T. Super €13.80
photo_cameraImage coming soon 800032-00LAV crankcase worked €246.93
photo_cameraImage coming soon 800051-00LAV Arm selector degrees worked €79.01
photo_cameraImage coming soon 800054-00LAV Sector grooved worked €48.11
photo_cameraImage coming soon 800057-01 Plastic catch €3.78
photo_cameraImage coming soon 800057-02 Rodd.10x300 €7.58
photo_cameraImage coming soon 800058-00 binoculars €6.32
Degrees Handle Lever for Miter Saws Compa TC 10-14 800078-00 Degrees Handle Lever for Miter Saws Compa TC 10-14 €6.77
photo_cameraImage coming soon 800086-00 Cap for tube €2.52
photo_cameraImage coming soon 800099-00 Spring incl. DM8.7 DF1.8 H38.5 €2.32
Degrees Handle Fork M6 for Miter Saw Compa FC 300 RAP 800127-00 Degrees Handle Fork M6 for Miter Saw Compa FC 300 RAP €6.82
photo_cameraImage coming soon 800154-00LAV Right bracket machined €25.31
photo_cameraImage coming soon 800213-01 selector €8.85
Degrees Handle Fork M6 Tie Rod for Miter Saw Compa FC 300 RAP 800214-00 Degrees Handle Fork M6 Tie Rod for Miter Saw Compa FC 300 RAP €5.57
photo_cameraImage coming soon 800244-00 graduated plate €3.78
photo_cameraImage coming soon 800245-00 nameplate index €3.78
photo_cameraImage coming soon 800293-01 Turntable 3552 (sp. 1mm.) €3.78
photo_cameraImage coming soon 800293-02 Thrust AXF 3552 €8.85
photo_cameraImage coming soon 800507-00 Rod d.12x400 €7.58
photo_cameraImage coming soon 800686-00 Locking pawl €8.85
photo_cameraImage coming soon 800963-00 OBSOLETE! Knob M6x15 SOST.DA COD.0188 €3.78
photo_cameraImage coming soon 801333-00 support base €3.78
KIT001001
 photo_cameraImage coming soon KIT001001 Group stand FC 300 RAP €683.85
KIT002001
 Degrees Complete Handle for Miter Saws Compa TC 10-14 KIT002001 Degrees Complete Handle for Miter Saws Compa TC 10-14 €62.67
KIT0950/0971
 photo_cameraImage coming soon KIT0950/0971 Shaft + rotor 47x90 x 250 €41.78
KITLEVCART250
 Blade Guard with Kit Levers For Miter Saw Compa 250 E Super - 250 E.T. Super KITLEVCART250 Blade Guard with Kit Levers For Miter Saw Compa 250 E Super - 250 E.T. Super €16.60
KITLEVPULS250
 Unlock Levers Kit For Mitre Saws Compa 250 E Super - 250 E.T. Super KITLEVPULS250 Unlock Levers Kit For Mitre Saws Compa 250 E Super - 250 E.T. Super €11.01
KITMOT250MONO
 Compa Motor 250 SiglePhase Brushless KITMOT250MONO Compa Motor 250 SiglePhase Brushless €136.77 Not available for order
0118
 Brass Washer d.24x10,5x2 for Mitre Saws Compa 300/JE-JET 0118 Brass Washer d.24x10,5x2 for Mitre Saws Compa 300/JE-JET €3.47
0163
 photo_cameraImage coming soon 0163 Knob d.20 M6x10 (01TBP20C10) €4.98
0207
 photo_cameraImage coming soon 0207 Bearing 6201 2Z (CTK) (HCH) mm.12x32x10 €6.32
0213
 photo_cameraImage coming soon 0213 12.5 mF capacitor V450 2 wires 200 mm €16.26
0214
 photo_cameraImage coming soon 0214 rubber grommet €2.52
0215PULSANTE
 Green Button for Miter Saws Compa 250 E Super - 250 E.T. Super 0215PULSANTE Green Button for Miter Saws Compa 250 E Super - 250 E.T. Super €13.94
0222
 Ball Bearing 51100 for Mitre Saws Compa 300/JE-JET 0222 Ball Bearing 51100 for Mitre Saws Compa 300/JE-JET €9.61
0228
 photo_cameraImage coming soon 0228 Brug. f. Saw HEX SOCKET HEAD M10x25 SX Zn €4.37
0244
 photo_cameraImage coming soon 0244 Shim washer torsion spring €3.15
0252
 photo_cameraImage coming soon 0252 Cable T.g. / v.1x1 cm.21 anel.d.3 €2.32
0262
 photo_cameraImage coming soon 0262 handle €13.79
0278
 photo_cameraImage coming soon 0278 Pin hinged arm NEW €18.47
0279
 photo_cameraImage coming soon 0279 Washer spring preload GALVANIZED €6.32
0283
 photo_cameraImage coming soon 0283 Brake pad €11.15
0284
 photo_cameraImage coming soon 0284 Spring 'CO.MEC 720 P.32'x brake €4.18
0288
 photo_cameraImage coming soon 0288 Washer vent. UNI8842 screw M14 x €2.52
0291
 Arm Spring for Miter Saw Compa 250-300JE-JET 0291 Arm Spring for Miter Saw Compa 250-300JE-JET €22.18
0308
 photo_cameraImage coming soon 0308 Colonn.pianetto d.14 Galvanized €11.80
0313
 photo_cameraImage coming soon 0313 Wing Nut (Chiavet.di Serr.CSP M5x15 iron €3.91
0313/OTT
 Brass Wing Bolt M5x15 for Miter Saws Compa 250-300 JET-E-ET Super 0313/OTT Brass Wing Bolt M5x15 for Miter Saws Compa 250-300 JET-E-ET Super €4.03
0322
 photo_cameraImage coming soon 0322 Column. d.12 hole etc. GALVANIZED €10.11
0330
 Lower Blade Protection for Mitre Saws Compa 2300-300 JET 0330 Lower Blade Protection for Mitre Saws Compa 2300-300 JET €12.41
0335
 photo_cameraImage coming soon 0335 Upper guard release levers spring €3.01
0339
 photo_cameraImage coming soon 0339 Knob NPT d.32 M8x30 01TNO32D30 €2.38
0341
 photo_cameraImage coming soon 0341 Lever maneuver plan sup. €2.19
0348
 photo_cameraImage coming soon 0348 Knob d.20 M5 (01TBB20B) €2.45
0355
 photo_cameraImage coming soon 0355 Push stick €9.55
0357
 Degrees Row for Miter Saw Compa 2300-300-305 0357 Degrees Row for Miter Saw Compa 2300-300-305 €2.77
0366
 photo_cameraImage coming soon 0366 Foil blocking €5.05
0387
 photo_cameraImage coming soon 0387 Return spring shelf 250-300 €3.78
0805
 photo_cameraImage coming soon 0805 Sacco asp.C216 / G d.60 int + Hinge €15.01
0806
 photo_cameraImage coming soon 0806 Clamp HOP9 d.40-70 €3.15
0851
 photo_cameraImage coming soon 0851 Support for lots aspiration €3.52
0901LAVORATO
 photo_cameraImage coming soon 0901LAVORATO Arm 250 worked €53.52
0908
 photo_cameraImage coming soon 0908 Plastic lid sup.x 250 €7.58
0912
 photo_cameraImage coming soon 0912 Copriv. mot. picc. Transp. 250/300/2300 €12.42
0913
 photo_cameraImage coming soon 0913 Fan motor. picc. 250/300/2300 €10.31
0940
 photo_cameraImage coming soon 0940 Special nut x 250 F / C high collar €3.28
0943
 Button Relase Carter for Miter Saw Compa 250 E Super 0943 Button Relase Carter for Miter Saw Compa 250 E Super €2.77
0944LAVORATA
 Upper Washer for Miter Saw Compa TC10-14 0944LAVORATA Upper Washer for Miter Saw Compa TC10-14 €16.73
0954LAV.TA
 photo_cameraImage coming soon 0954LAV.TA Ring dist.sega 250 FC restatement €5.79
20020120
 Spacer Washer 0.6 mm for Mitre Saws Compa 300JE/JET 20020120 Spacer Washer 0.6 mm for Mitre Saws Compa 300JE/JET €4.17
23010240
 Spring Pin Arm Locking for Miter Saw Compa 250-300E.T. 23010240 Spring Pin Arm Locking for Miter Saw Compa 250-300E.T. €2.77
23010390
 Crossbow Spring for Miter Saw Compa 2300-2301 23010390 Crossbow Spring for Miter Saw Compa 2300-2301 €2.77
23010400
 Sleeve for Carter Lever Lift for Miter Saw Compa 2300-2301 23010400 Sleeve for Carter Lever Lift for Miter Saw Compa 2300-2301 €4.17
23020440
 SCHURTER ABCW Switch for Miter Saws Compa 2300 23020440 SCHURTER ABCW Switch for Miter Saws Compa 2300 €40.47
23030030
 photo_cameraImage coming soon 23030030 Saw GUARD p. sup. (parts : 23,030,030 COM) €26.34
23030040
 photo_cameraImage coming soon 23030040 Language post. x protect. sup. (C ric.23030030 €3.78

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Compa-OMS Spare Parts for Portable Saws 250 E-ET Super

We have the original Spares COMPA for Mitre Saws 250 E Super - 250 E.T. Super, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.

In the following table, look for the model of the Professional Saws and their spare part.
Compa 250 E-ET Super
Professional Saws 250 E Super - 250 E.T. Super
Part Num. Description
0118 Washer Brass d.24x10,5x2
0163 Knob d.20 M6x10 (01TBP20C10)
0207 Bearing 6201 2Z (CTK) (HCH) mm.12x32x10
0213 12.5 mF capacitor V450 2 wires 200 mm
0214 rubber grommet
0215PULSANTE Button 82L5 2 TERMINALS GREEN + PR.
0222 thrust 51100
0228 Allen stops saw HEX SOCKET HEAD M10x25 SX Zn
0244 Shim washer torsion spring
0252 Cable T.g. / v.1x1 cm.21 anel.d.3
0262 handle
0277-01 Return spring release lever
0278 Jack incern. NEW arm
0279 Washer spring preload GALVANIZED
0283 brake pad
0284 Spring 'CO.MEC 720 P.32'x brake
0288 Washer vent.UNI8842 x M14 screw
0291 Spring f.5,5 d.e.50,5 x arm
0308 OBSOLETE Column shelf d.14 Galvanized
0313 Wing Nut (Chiavet.di Serr.CSP M5x15 iron
0313/OTT Wing Nut M5x15 Brass (CSPM5x15)
0322 Column d.12 hole etc. GALVANIZED
0330 Removable lower protective plastic
0335 Return spring prot.sup. and release levers
0339 Knob NPT d.32 M8x30 01TNO32D30
0341 Lever maneuver plan sup.
0348 Knob d.20 M5 (01TBB20B)
0355 Push stick
0357 Dipstick raising shelf
0366 Foil blocking
0386LAVORATO Extruded support sq.tagl. and worked
0387 Return spring shelf 250-300
0805 Sacco asp.C216 / G d.60 int + Hinge
0806 Clamp HOP9 d.40-70
0851 Support for lots aspiration
0901LAVORATO Arm 250 worked
0908 Plastic lid sup.x 250
0912 Motor fan cover small transp. 250/300/2300
0913 Fan motor small 250/300/2300
0940 Special nut x 250 F / C high collar
0943 Button release crankcase 250 FC
0944LAVORATA Flange stops saw RETTIF.250-300 + TC10
0954LAV.TA Ring dist.sega 250 FC restatement
955 Ring UNI7435 d36 x 250 FCT
960 Conveyor / lower protection 250 IRON
961 Shelter undercounter x 250
967 Prisoner engine x 250 FC M5x153
972 Bearing 6004 2z x 250 F / C mm20x42x12
974 Knob THP30M10x35 p. conical locking 250
978 I raise lever housing 250 SIT (KITLEVCART250)
20020120 Washer thickness crankcase Sp.0.6
20030060 Riving knife 250 NEW TYPE
23010240 pring pin x locking arm
23010390 Leaf spring X 2300/1
23010400 Bush to get up lever cover 2300
23020440 Switch SCHURTER ABCWF00-U3-AZM02 X2300/250
23030030 Saw guard uppper (spare: 23,030,030 COM
23030040 Language rear x superior protection (ric.23030030 C
800032-00LAV crankcase worked
800040-00LAV Turntable worked
800051-00LAV Arm selector degrees worked
800052-00LAV Hose handle worked
800054-00LAV Sector grooved worked
800057-01 Plastic catch
800057-02 Rodd.10x300
800058-00 binoculars
800078-00 lever
800086-00 Cap for tube
800099-00 Spring incl. DM8.7 DF1.8 H38.5
800127-00 fork M6
800154-00LAV Right bracket machined
800213-01 selector
800214-00 Tie M6
800244-00 graduated plate
800245-00 nameplate index
800293-01 Turntable 3552 (sp. 1mm.)
800293-02 Thrust AXF 3552
800507-00 Rod d.12x400
800686-00 Locking pawl
800963-00 OBSOLETE! Knob M6x15 SOST.DA COD.0188
801333-00 support base
KIT001001 Group stand FC 300 RAP
KIT002001 Group selection handle degrees
KIT0950/0971 Tree + rotor 47x90 x 250
KITLEVCART250 Group housing + levers x250 (cod.0978 + 0942)
KITLEVPULS250 Mounted release levers 250 (0926/7)
KITMOT250MONO Motor 250 mono (pack st.+ Avv.to + carc.)
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Compa-OMS websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Compa-OMS brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Compa 250E-ET Super
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
MORE INFO:
[email protected]
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT

Specific References

New

Download

Compa 250 E-ET Super Drawing

Compa 250 E-ET Super Drawing

Download (1.12MB)

You might also like

Upper Guide Assy for Miter Saws Compa 2300-300-305
COMPA TECH-OMS SKU: 0395LAV
Upper Guide Assy for Miter Saws Compa 2300-300-305
Upper Guide Assy for Miter Saws Compa 2300-300-305 Original spare Compa-OMS, Upper Guide Assembly for Wood Mitre Saws Compa 2300 - 2300MAXIMA - 300JET - SUPER 300E - 300 ET SUPER - MAX 305 100 - 3051 100 MAX. Part...
Usually Ships in: 7/10 Business Days Approx. €48.71
Details
Aluminium Upper Bench for miter Compa 250/300/2300JET-Maxima
COMPA TECH-OMS SKU: 0360/01 LAV
Aluminium Upper Bench for miter Compa 250/300/2300JET-Maxima
Aluminium Upper Bench for miter Compa 250/300/2300JET-Maxima Original spare part Compa-OMS, Upper Bench Extruded Aluminium Assembled for 250 JET 01-300 JET - 300 Super E - 300 ET Super - 305 MAX 100-3051 MAX 100 - Compa 2300-2300...
AVAILABLE €75.90
Details
Arm Spring for Miter Saw Compa 250-300JE-JET
COMPA TECH-OMS SKU: 0291
Arm Spring for Miter Saw Compa 250-300JE-JET
Arm Spring for Miter Saw Compa 250-300JE-JET Original spare part Compa-OMS, Arm Spring for Mitre Saw  250 E Super - 250 E.T. Super - 300 JE - 300 JET - 300 E Super - 350 E.T. Super Part for the following products: - Mitre...
Usually Ships in: 7/10 Business Days Approx. €22.18
Details
Sleeve for Carter Lever Lift for Miter Saw Compa 2300-2301
COMPA TECH-OMS SKU: 23010400
Sleeve for Carter Lever Lift for Miter Saw Compa 2300-2301
Sleeve for Carter Lever Lift for Miter Saw Compa 2300-2301 Genuine spare Compa-OMS, Sleeve for Lever Lift Carter miter saw  Compa 2300 - 2300XL - 2301 - 2301XL - 2301 MAXIMA - MAXIMA 2301XL. Part for the following items: -...
Last items in stock €4.17
Details
Crossbow Spring for Miter Saw Compa 2300-2301
COMPA TECH-OMS SKU: 23010390
Crossbow Spring for Miter Saw Compa 2300-2301
Crossbow Spring for Miter Saw Compa 2300-2301 Genuine spare Compa-OMS, Crossbow spring for miter saw Compa 2300 - 2300XL - 2301 - 2301XL - 2301 MAXIMA - MAXIMA 2301XL. Part for the following items: - Miter Saw 2301 - Miter Saw 2301...
AVAILABLE €2.77
Details
Motor Fan Cover for Miter Saws Compa 2300-2301
COMPA TECH-OMS SKU: Compa-0912
Motor Fan Cover for Miter Saws Compa 2300-2301
Motor Fan Cover for Miter Saws Compa 2300-2301 Genuine spare Compa-OMS, Polycarbonate Fan Motor Cover for Miter Saws Compa 2300 - 2300XL - 2301 - 2301XL - 2300 MAXIMA - MAXIMA 2301 - 300 JE/JET. Part for the following items:...
AVAILABLE €12.41
Details
Motor Fan for Miter Saws Compa 2300-2301
COMPA TECH-OMS SKU: Compa-0913
Motor Fan for Miter Saws Compa 2300-2301
Motor Fan for Miter Saws Compa 2300-2301 Genuine spare Compa-OMS, Polycarbonate Fan Motor for Miter Saws Compa 2300 - 2300XL - 2301 - 2301XL - 2300 MAXIMA - MAXIMA 2301 - 300 JE/JET. Part for the following items: - Mitre Saw 2300 -...
Last items in stock €10.31
Details
Spacer Washer 0.6 mm for Mitre Saws Compa 300JE/JET
COMPA TECH-OMS SKU: 20020120
Spacer Washer 0.6 mm for Mitre Saws Compa 300JE/JET
Spacer Washer 0.6 mm for Mitre Saws Compa 300JE/JET Original part Compa-OMS, Spacer Washer 0.6 mm for Mitre Saws JET 250 01-250 E Super - 250 E. T. Super - Super 300 E - 300 E. T. Super - JE-300 Jet. Part for the following products:...
on 7/10 Business Days Approx €4.17
Details
Lower Blade Protection for Mitre Saws Compa 2300-300 JET
COMPA TECH-OMS SKU: 0330
Lower Blade Protection for Mitre Saws Compa 2300-300 JET
Lower Blade Protection for Mitre Saws Compa 2300-300 JET Genuine parts Compa-OMS, Lower Removable Plastic Protection for Mitre Saws 2300 - 300 JET - 250 E Super - 250 E. T. Super - Super 300 E - 300 E. T. Super - 305 MAX 100-3051 MAX 100
AVAILABLE €12.41
Details
Button Relase Carter for Miter Saw Compa 250 E Super - 250 E.T. Super
COMPA TECH-OMS SKU: 0943
Button Relase Carter for Miter Saw Compa 250 E Super
Button Relase Carter for Miter Saw Compa 250 E Super Original spare Compa-OMS, Button Relase Carter for Miter Saw Compa 250 E Super - 250 E.T. Super. Part for the following article : - Miter Saw 250 E Super - Miter Saw 250 E.T. Super...
AVAILABLE €2.77
Details
Green Button for Miter Saws Compa 250 E Super - 250 E.T. Super
COMPA TECH-OMS SKU: 0215PULSANTE
Green Button for Miter Saws Compa 250 E Super - 250 E.T. Super
Green Button for Miter Saws Compa 250 E Super - 250 E.T. Super Genuine parts Compa-OMS, Green Button 82L5 2 MORS.VERDE+PR. for Mitre Saws Compa 250 E Super - 250 E.T. Super. - 300 JE - 305 MAX 100 - 3051 MAX 100 - 2301. Part for the...
AVAILABLE €13.94
Details
Degrees Handle Fork M6 for Miter Saw Compa FC 300 RAP Sale
COMPA TECH-OMS SKU: 800127-00
Degrees Handle Fork M6 for Miter Saw Compa FC 300 RAP
Degrees Handle Fork M6 for Miter Saw Compa FC 300 RAP Original spare Compa-OMS, Degrees Handle Fork M6 for Mitre Saws Compa TC 10 - TC 14 - FC 300 RAP - 250 E Super - 250 E.T. Super Part for the following article : - Mitre Saws Compa...
AVAILABLE €6.82
Details
Degrees Handle Fork M6 Tie Rod for Miter Saw Compa FC 300 RAP Sale
COMPA TECH-OMS SKU: 800214-00
Degrees Handle Fork M6 Tie Rod for Miter Saw Compa FC 300 RAP
Degrees Handle Fork M6 Tie Rod for Miter Saw Compa FC 300 RAP Original spare part Compa-OMS, Degrees Handle Fork M6 Tie Rod for Mitre Saws Compa TC 10 - TC 14 - FC 300 RAP - 250 E Super - 250 E.T. Super Part for the following article...
AVAILABLE €5.57
Details
Push Stick for Mitre Saw Compa 300 JET
COMPA TECH-OMS SKU: Compa 0355
Push Stick for Mitre Saw Compa 300 JET
Push Stick for Mitre Saw Compa 300 JET Original spare Compa-OMS, Push Stick for Professional Mitre Saws 300 JET - 2300 - 250 E Super - 250 E.T. Super - 305 MAX 100 - 250 JET...
AVAILABLE €9.55
Details
Compa Motor 250 SiglePhase Brushless
COMPA TECH-OMS SKU: KITMOT250MONO
Compa Motor 250 SiglePhase Brushless
Compa Motor 250 SiglePhase Brushless Original spare part Compa-OMS, Motor 250 SiglePhase Brushless(Pack Field+Electrical Winding+Housing) V.230/50Hz. for Professional Mitre Saw 250 SIT - 250 E.T. Super. Part for the following items:...
Out-of-Stock €136.77
Details
Comments (0)
