Compa-OMS Spare Parts for Professional Mitre Saw TC 14
We supply
Compa-OMS original spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for
Professional Mitre Saw for Wood TC 14.
In the following table, look for the model of the Professional Saws and their spare part.
| Professional Mitre Saw TC 14 |
| # |
Description |
Part Num. |
| 1 |
Carter complete upper |
KIT23030030COM |
| 1a |
Headset saw protection |
23030030 |
| 1b |
Spring locking pin for protection |
23010240 |
| 1c |
Return spring protection |
0335 |
| 1d |
Knob lock protection |
0348 |
| 1e |
Protective inner blade |
23030040 |
| 2 |
upper bracket |
KIT0395 |
| 2a |
Bracket upper shelf |
0365 |
| 2b |
Support bracket |
0386 |
| 2c |
sheet |
0366 |
| 2d |
Knob locking bracket |
23030240 |
| 3 |
fixed arm |
800019-01 |
| 4 |
dividing knife |
801714-00 |
| 5 |
Knuckle pin head |
800170-00 |
| 6 |
Axial bearing 51106 (30x47x11) |
800289-03 |
| 7 |
Overall lever release |
KIT012001 |
| 7a |
Support release lever |
402448-00 |
| 7b |
Release lever |
402446-00 |
| 7c |
clothespin |
402445-00 |
| 35 |
Stop plate |
402447-00 |
| 8 |
arm holder |
800020-01 |
| 9 |
cable |
0216 Mono |
| 10 |
motor pulley |
800176-01 |
| 11 |
Poly - V - J5 - SV.864 |
800119-00 |
| 12 |
Cable Box |
801031-01 |
| 13 |
Washer for pulley |
800187-00 |
| 14 |
Group tree blade |
KIT005008 |
| 14a |
Tree holder |
800166-02 |
| 14b |
external spacer |
800191-01 |
| 14c |
internal spacer |
800190-01 |
| 14d |
bearing 6203-2Z |
2080 |
| 14e |
driven pulley |
800177-00 |
| 15 |
belt cover |
800028-00 |
| 16 |
handle ass'y |
KIT013002 |
| 16a |
Semimpugnatura Left |
800080-02 |
| 16b |
Semimpugnatura tube |
800080-00 |
| 17 |
switch Triphase = 401318-05 |
800682-10 |
| 18 |
61904 2RS Bearing for Mobile blade shelter |
801327-00 |
| 19 |
blade shelter |
801311-00LAV |
| 20 |
inner flange |
0944-01_LAV |
| 21 |
blade |
vedi acessori |
| 22 |
outer flange |
0944 |
| 23 |
Fixing screw blade |
0228 |
| 24 |
L-shaped Protection Left |
801273-01 |
| 25 |
Cam for moving away |
801337-01 |
| 26 |
The Right to Protection |
801272-01 |
| 27 |
nameplate graph |
800249-00 |
| 28 |
fan |
801659-01 |
| 29 |
Fan cover |
801459-00 |
| 30 |
complete engine |
801506-00 |
| 31 |
box capacitor holder |
801287-00 |
| 32 |
condenser |
800091-00 |
| 33 |
Terminal block |
| 34 |
tension release Board |
401622-01 |
| 36 |
Couple gibs |
KIT003001 |
| 37 |
Thrust bearing |
| 37a |
Cage AXK axial 3552 |
800293-02 |
| 37b |
Turntable AS 3552 |
800293-01 |
| 38 |
full basement |
KIT001006 |
| 38a |
base |
800043-00 |
| 38b |
turntable |
800044-00 |
| 50 |
Axial bearing 51114 |
800289-02 |
| 39 |
Grain UNI 5923 M8x16 |
| 40 |
nameplate index |
800245-00 |
| 41 |
Locking pawl |
800686-00 |
| 42 |
graduated plate |
800257-00 |
| 43 |
Foot log |
801333-00 |
| 44 |
Overall arm displacement degrees |
800053-00 |
| 45 |
Complete handle displacement degrees |
KIT002001 |
| 45a |
Hose handle |
800052-00 |
| 45b |
lever |
800078-00 |
| 45c |
fork |
800127-00 |
| 45d |
tie rod M6 |
800214-00 |
| 45e |
spring |
800099-01 |
| 45f |
fattener |
800139-00 |
| 45g |
selector |
800213-01 |
| 45h |
Cap for tube |
800086-00 |
| 46 |
Rods Ass'y |
KIT004001 |
| 46a |
rod 012x400 |
800507-00 |
| 46b |
Plastic catch |
800057-01 |
| 46c |
rod 010x300 |
800057-02 |
| 46d |
binoculars |
800058-00 |
| 46e |
knob M6x15 |
800693-00 |
| 47 |
sector grooved |
800055-00 |
| 48 |
Tapered roller bearing |
800291-02 |
| 49 |
rectifier |
801462-00 |
| 51 |
Base Insert |
800075-00 |
| 52 |
Upper Support protection |
801313-01 |
| 53 |
Guide to the upper bracket |
800205-00 |
| 59 |
Blade Case Protection |
800653-01 |
