CM snc

CM Motori Spare Parts for Gasoline Motors 4T LT160-200

€164.31
VAT included

CM Motori Spare Parts for Gasoline Engines 4T LT160-200

CM Motori genuine parts for replacement or repair Gasoline Engines 4T LT160-LT200, for Engine pumps, rotary tiller, tillers.
CM Motori Spare Parts for Motor Geotec
  • CM Motori Spare Parts for Motor Geotec
  • CM Motori Spare Parts for Motor Geotec
CM snc

CM Motori Spare Parts for Gasoline Motors 4T LT160-200

Condition: New
€164.31
VAT included

CM Motori Spare Parts for Gasoline Engines 4T LT160-200

CM Motori genuine parts for replacement or repair Gasoline Engines 4T LT160-LT200, for Engine pumps, rotary tiller, tillers.
settings 7 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
AVAILABLE

verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
7 spare parts
Page 1 zoom_in View exploded
Esploso pagina 1
Pos. Item Price Buy
101
 photo_cameraImage coming soon 20001001 CABINET €146.60 Not available for order
306
 photo_cameraImage coming soon 20003004 AIR HAMMER €20.05 Not available for order
309
 photo_cameraImage coming soon 20003300 SERIES RINGS €34.64 Not available for order
401
 photo_cameraImage coming soon 20004100 TESTA Motor NUDA €138.63 Not available for order
501
 photo_cameraImage coming soon 20005100 SHAFT CAMMES €40.09 Not available for order
502
 photo_cameraImage coming soon 20005001 SHORT VALVE €3.85 Not available for order
702
 Carburator for 4 T Engine CM LT 200 20007200 Carburator for 4 T Engine CM LT 200 €92.70 Not available for order

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

CM Motori Spare Parts for Gasoline Engines 4T LT160-200

CM Motori genuine parts for replacement or repair Gasoline Engines 4T LT160-LT200, for Engine pumps, rotary tiller, tillers.

In the following table, look for the model of the Motor Pump and the respective parts of the code.
Ordered items will be shipped within 7/10 working days approx.

GASOLINE ENGINE PARTS LT 160 - 200
LT160 LT200
101 16001001 20001001 CRANKCASE
102 YF254125 RING SEAL OIL
103 ZC6205 BEARING SHAFT
104 16001002 LEVER CONTROLLER
105 16001003 SPRING FIXING LEVER
106 16001004 FLAT WASHER
107 LSB10015 PLUG OIL DRAIN
108 16001005 SEAL PLUG OIL DRAIN
109 16001100 KIT SPEED CONTROL
110 16001006 POST SPEED CONTROL
111 16001007 RING BENZING
112 16001008 Ferrule SPEED CONTROL
113 16001009 FLAT WASHER
201 16002001 CLOSING FLANGE MOTOR CARTER
202 YF25412506 RING SEAL OIL
203 ZC6205 BEARING SHAFT
204 16002002 PLUG THE OIL
205 16002003 SEAL PLUG THE OIL
206 XA0814 PLUG DICENTRAGGIO
208 LCS080335 BOLT FAlNGIA COVER CARTER
301 16003101 SHAFT
302 16003102 GEAR SPEED CONTROL
303 16003103 GEAR TRANSMISSION
304 YJA0418 KEY FLY
305 16003200 ROD
306 16003004 20003004 PISTON
307 16003005 PISTON PIN
308 16003006 PIN LOCKING RING
309 16003300 20003300 SET RINGS
401 16004100 20004100 MOTOR HEAD BARE
402 LZA0842 PRISONER
403 LZA06110 SPINA
405 16004200 SPARK PLUG
407 16004300 COVER VALVE
409 16004003 TIUBO BREATHER
410 LSB06012 BOLT COVER VALVE
411 16004004 BOLT 8 x 60
412 16004005 COVER BREATHER
413 LSB06012 BOLT COVER BREATHER
501 16005100 20005100 SHAFT CAMMES
502 16005001 20005001 SHORT VALVE
503 16005002 AUCTION ROCKER
504 16005003 GUIDE ROD ROCKER
505 16005201 ROCKER
506 16005202 STUD ROCKER
507 16005203 BOLT LOG VALVES
508 16005204 NUT LOG VALVES
509 16005004 VALVE INTAKE
510 16005005 EXHAUST VALVE
511 16005006 SPRING VALVES
512 16005007 PLATE VALVE INTAKE
513 16005008 PIATIELLO VALVE DRAIN
514 16005009 STOP VALVE
601 16006100 CONVOGLIATORE AIR
602 LSB06012 SCREW CONVEYOR AIR
603 16020014 AUTOAWOLGENTE COMPLETE
604 16006202 SPRING RETURN CABLE REWIND
605 16006203 PULLEY CABLE REWIND
606 16006204 RATCHET SPRING REWIND
607 16006205 Ratchet REWIND
606 16006206 CLUTCH SPRING RATCHET
609 16006207 DISCO POWLS
610 16006208 SCREW DISCO POWLS
611 16006209 CABLE REWIND
612 16006210 REWIND HANDLE
614 16006001 AIR DEFLECTOR
615 LSB06012 SCREW BAFFLE
701 16007100 CARB MOTOR - Economic Generator
702 16007200 CARB LT 2500 CL
702 20007200 CARB LT 3000 CL
7()4 16007003 CARB HEAT SHIELD
801 16008100 AIR FILTER COMPLETE
802 16008200 AIR FILTER COMPLETE GENERATOR TYPE LUXURY
819 16008107 AIR FILTER CARTRIDGE
16006110 FLI TRO BATH OIL
901 16009100 FULL THROTTLE LEVER REOLAZIONE
903 16009001 AUCTION REGULATOR
904 16009002 RETURN SPRING THROTTLE
905 16009003 SPRING THROTTLE
906 16009004 LEVER CONTROLLER
1001 16010100 EXHAUST COMPLETE
1101 16011100 TANK
1102 16011200 TANK CAP
1103 16011001 FILTER TANK
1105 16011003 FILTER TANK TAP
1106 16011004 FUEL PIPE
1106 16011006 RING TUBE FUEL
1201 16012100 FLYWHEEL
1202 16012001 FAN
1203 16012002 STARTING PULLEY
1204 16012003 NUT FLY
1205 16012004 IGNITION COIL
1206 LSB06022 BOLT COIL
1207 16012005 OIL STOP
1208 LSB06012 BOLT OILSTOP
1209 LMB10 NUT OILSTOP
1210 16012006 SWITCH STOP ENGINE
1211 16012007 DIODE
4012 16004102 VALVE GUIDE INTAKE
4013 16004103 EXHAUST VALVE GUIDE
4014 16004104 RING RETAINING VALVE GUIDE
4015 16004105 VALVE SEAT INTAKE
4016 16004106 VALVE SEAT DRAIN
16020010 SET GASKETS

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s CM Motori snc websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to CM Motori snc brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.

Specific References

New

Download

Diagram LT160-200

Diagram LT160-200

Download (105.75KB)
