CM snc

CM Motori Spare Parts for Motor Pumps CM70

€12.04
VAT included

CM Motori Spare Parts for Engine Pumps CM70

CM Motori genuine parts or replacement parts for to repair Engine PUMPS CM70.

Engine characteristics
Model: CM 70
Type: 4 Stroke
Displacement: 70 cc
Fuel: Gasoline
Pump features
Aspiration: 1"1/2
Flow: 1"1/2
Maximum suction height: 8 m
Max capacity: 230 lt
Max head: 25 mt
CM Motori Spare Parts for Motor Pumps CM70
  • CM Motori Spare Parts for Motor Pumps CM70
  • CM Motori Spare Parts for Motor Pumps CM70
  • CM Motori Spare Parts for Motor Pumps CM70
  • CM Motori Spare Parts for Motor Pumps CM70
  • CM Motori Spare Parts for Motor Pumps CM70
  • CM Motori Spare Parts for Motor Pumps CM70
  • CM Motori Spare Parts for Motor Pumps CM70
CM snc

CM Motori Spare Parts for Motor Pumps CM70

Condition: New
€12.04
VAT included

CM Motori Spare Parts for Engine Pumps CM70

CM Motori genuine parts or replacement parts for to repair Engine PUMPS CM70.

Engine characteristics
Model: CM 70
Type: 4 Stroke
Displacement: 70 cc
Fuel: Gasoline
Pump features
Aspiration: 1"1/2
Flow: 1"1/2
Maximum suction height: 8 m
Max capacity: 230 lt
Max head: 25 mt
settings 127 spare parts
description 5 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
AVAILABLE

verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
127 spare parts
Page 1 zoom_in View exploded
Esploso pagina 1
Pos. Item Price Buy
3
 photo_cameraImage coming soon M2T075F00 AIR CLEANER COVER €1.33 Not available for order
4
 photo_cameraImage coming soon M2T074F00 AIR FILTER CARTRIDGE €1.33 Not available for order
8
 photo_cameraImage coming soon M2T072F00 BODY AIR €3.51 Not available for order
9a
 photo_cameraImage coming soon M2T045F00 SEGMENT 49x1 €4.31 Not available for order
9
 photo_cameraImage coming soon M2T073F00 AIR BAFFLEINTAKE €1.33 Not available for order
25
 photo_cameraImage coming soon M2T108F00 THROTTLE LEVER €13.52 Not available for order
27
 photo_cameraImage coming soon 4106620F00 RING OR 4700 €2.14 Not available for order
29
 Cylinder Group Complete for Engine Pump CM70 M2T222F00 Cylinder Group Complete for Engine Pump CM70 €237.94 Not available for order
30
 photo_cameraImage coming soon M2T061F00 COVER €1.60 Not available for order
32
 photo_cameraImage coming soon M2T049F00 MUFFLER PROTECTION €3.36 Not available for order
33
 photo_cameraImage coming soon M2T048F00 BODY, MUFFLER €24.36 Not available for order
35
 photo_cameraImage coming soon M2T053F00 DISTANCE FLY €8.78 Not available for order
38
 Gasoline Tap for Motor Pump CM70 7800110F00 Gasoline Tap for Motor Pump CM70 €10.19 Not available for order
39
 Gasoline Tap O-Ring Washer for Motor Pump CM70 8010050F00 Gasoline Tap O-Ring Washer for Motor Pump CM70 €0.25 Not available for order
40
 Petrol Tap Gasket O-R 8x15x3 for Motorpump CM70 4108570F00 Petrol Tap Gasket O-R 8x15x3 for Motorpump CM70 €0.50 Not available for order
42
 photo_cameraImage coming soon M2T440F00 SCREW TC CR 5x15 9709 €1.33 Not available for order
44
 photo_cameraImage coming soon M2T068F00 SUPPORT TANK €1.33 Not available for order
47
 photo_cameraImage coming soon 9110850F00 TANK CAP €4.93 Not available for order
48
 photo_cameraImage coming soon M2T08BF00 TANK ENGINE €16.23 Not available for order
49
 photo_cameraImage coming soon M2T083F00 AIR FAN €6.75 Not available for order
50
 photo_cameraImage coming soon M2T234F00 GROUP FLY €29.78 Not available for order
52
 photo_cameraImage coming soon M2T076F00 TIMING BELT 450 €9.35 Not available for order
53
 photo_cameraImage coming soon M2T070F00 CARB €56.88 Not available for order
54
 Spark Plug Joint Ass'y for Motorpumps CM70 0202000F00 Spark Plug Joint Ass'y for Motorpumps CM70 €4.06 Not available for order
55
 photo_cameraImage coming soon M2T055F00 Armature-Magneto €42.60 Not available for order
58
 photo_cameraImage coming soon M2T087F00 CONTROL SWITCH €1.33 Not available for order
60
 photo_cameraImage coming soon M2T001F00 BADMINTON €10.14 Not available for order
62
 photo_cameraImage coming soon M2T050F00 WHEEL DRIVE €2.14 Not available for order
65
 photo_cameraImage coming soon M2T052F00 INSERT FLY €8.10 Not available for order
70
 photo_cameraImage coming soon M2T030F00 HEADSET RECOIL €3.09 Not available for order
71
 photo_cameraImage coming soon M2T031F00 BUSH PULLEY €3.23 Not available for order
72
 photo_cameraImage coming soon M2T040F00 SPRING RIAVVOLGMENTO €8.10 Not available for order
73
 photo_cameraImage coming soon M2T038F00 CABLE STARTER PULLEY €2.68 Not available for order
77
 photo_cameraImage coming soon M2T036F00 BOX SPRING RATCHET €2.75 Not available for order
78
 photo_cameraImage coming soon M2T034F00 BUSH BRASS €2.68 Not available for order
80
 photo_cameraImage coming soon 1600000F00 CABLE REWIND €3.33 Not available for order
90
 photo_cameraImage coming soon M2T058F00 PLUG OIL FILTER €3.77 Not available for order
92
 photo_cameraImage coming soon M2T059F00 BOAT OIL FILTER €3.77 Not available for order
93
 photo_cameraImage coming soon M2T060F00 NETWORK FILTER €2.01 Not available for order
94
 photo_cameraImage coming soon M2T056F00 CARTER SEMI SIDE CLUTCH €24.36 Not available for order
95
 Oil Sealing Ring 15x30x7 TC for Motorpump CM 70 M2T700F00 Oil Sealing Ring 15x30x7 TC for Motorpump CM 70 €3.21 Not available for order
96
 photo_cameraImage coming soon M2T608F00 BEARING 6302 C3 €3.36 Not available for order
97A
 photo_cameraImage coming soon M2T039F00 GRUPPO Shaft M2Z €78.56 Not available for order
97B
 photo_cameraImage coming soon M2T041F00 GRUPPO Shaft P25 €78.56 Not available for order
97-I
 photo_cameraImage coming soon M2T043F00 GRUPPO Shaft MTP €78.56 Not available for order
97C
 photo_cameraImage coming soon M2T125F00 GRUPPO Shaft Udor €78.56 Not available for order
97D
 photo_cameraImage coming soon M2T126F00 GRUPPO Shaft 20 S €78.56 Not available for order
97E
 photo_cameraImage coming soon M2T127F00 GRU0PO Shaft Bertolini €78.56 Not available for order
97F
 photo_cameraImage coming soon M2T128F00 GRUPPO Shaft Carpi €78.56 Not available for order
97G
 photo_cameraImage coming soon M2T129F00 GRUPPO Shaft Trial €78.56 Not available for order
97H
 photo_cameraImage coming soon M2T130F00 GRUPPO Shaft Cono 12 €78.56 Not available for order
98-1
 photo_cameraImage coming soon M2T045F01 SEGMENTO CROMATO €6.75 Not available for order
99
 photo_cameraImage coming soon M2T046F00 OIL SCRAPER RING 49x2 €4.72 Not available for order
100
 photo_cameraImage coming soon M2T051F00 PISTON D.49 €20.30 Not available for order
101
 photo_cameraImage coming soon M2T047F00 PISTON PIN €3.08 Not available for order
102
 Piston Pin Circlip mm 12 for Motorpump CM 70 0092000F00 Piston Pin Circlip mm 12 for Motorpump CM 70 €0.50 Not available for order
103
 photo_cameraImage coming soon M2T054F00 PISTON COMPLETE €39.85 Not available for order
106
 photo_cameraImage coming soon M2T065F00 PLUG OIL BREATHER €1.60 Not available for order
107
 photo_cameraImage coming soon 29320041 CAP LEVEL ouo €2.57 Not available for order
110
 photo_cameraImage coming soon M2T106F00 OIL PIPE €2.68 Not available for order
111
 photo_cameraImage coming soon M2T410F00 PRISONER 5x30 ROOT 15 12 9 €1.33 Not available for order
113
 photo_cameraImage coming soon M2T077F00 M.5 0.4 FITTING STRAIGHT €2.68 Not available for order
115
 photo_cameraImage coming soon M2T780F00 STUD 6x16 €1.33 Not available for order
116
 photo_cameraImage coming soon M2T062F00 BLADE CARTER €1.33 Not available for order
117
 photo_cameraImage coming soon M2T063F00 STILL REED €1.33 Not available for order
120
 photo_cameraImage coming soon M2T057F00 HALF CARTER SIDE FLYWHEEL €60.95 Not available for order
121
 photo_cameraImage coming soon M2T248F00 BREATHER PIPE FITTING €1.60 Not available for order
125
 photo_cameraImage coming soon M2T096F00 FITTING M 5-0RmO 0.5 €2.68 Not available for order
132
 photo_cameraImage coming soon M2T003F00 CAP REGULATOR €3.36 Not available for order
134
 photo_cameraImage coming soon M2T014F00 PUSHER REGULATOR DIGIRI €3.36 Not available for order
137
 photo_cameraImage coming soon M2T237F00 HOLDER MASSE €2.14 Not available for order
140
 photo_cameraImage coming soon M2T703F00 RING OIL SEAL SHIELD 6x12x2,5 €1.33 Not available for order
141
 photo_cameraImage coming soon M2T091F00 LEVER CONTROLLER €1.33 Not available for order
144
 photo_cameraImage coming soon M2T009F00 MASS CENTRIFUGAL €1.33 Not available for order
145
 photo_cameraImage coming soon M2T021F00 VALVE COVER €2.41 Not available for order
146
 photo_cameraImage coming soon M2T018F00 ARM , VALVE ROCKER €1.33 Not available for order
147
 photo_cameraImage coming soon M2T004F00 FULCRUM ROCKER €4.04 Not available for order
149
 photo_cameraImage coming soon M2T010F00 PLATE VALVE SPRING €8.10 Not available for order
150
 photo_cameraImage coming soon M2T006F00 VALVE SPRING €1.33 Not available for order
151
 photo_cameraImage coming soon 2000190F00 NUT PUMP €5.78 Not available for order
152
 photo_cameraImage coming soon M2T005F00 VALVE INTAKE €7.02 Not available for order
153
 photo_cameraImage coming soon M2T015F00 EXHAUST VALVE €7.02 Not available for order
154
 photo_cameraImage coming soon M2T016F00 VALVE SEAT INTAKE €4.72 Not available for order
155
 photo_cameraImage coming soon M2T019F00 VALVE SEAT DRAIN €4.72 Not available for order
156
 photo_cameraImage coming soon 2000210F00 NUT PUMP €7.98 Not available for order
156
 photo_cameraImage coming soon M2T078F00 ELBOW FITTING M.5 D.4 €2.68 Not available for order
158
 photo_cameraImage coming soon M2T027F00 LEVER DECOMPRESSOR €1.33 Not available for order
159
 photo_cameraImage coming soon M2T105F00 Shaft A CAMMES €13.52 Not available for order
160
 photo_cameraImage coming soon M2T610F00 ROLLER CASE HK 10x12 €2.68 Not available for order
161
 photo_cameraImage coming soon M2T706F00 RING SEAL OIL 10x14X3 €1.33 Not available for order
163
 photo_cameraImage coming soon M2T013F00 WHEEL CONDUCT €2.14 Not available for order
165
 photo_cameraImage coming soon M2T071F00 BARREL €162.57 Not available for order
166
 photo_cameraImage coming soon M2T023F00 CANCELA €5.15 Not available for order
167
 photo_cameraImage coming soon M2T609F00 BEARING 6000 10x26X8 €1.33 Not available for order
168
 photo_cameraImage coming soon M2T002F00 DRIVE PIN DECOMPRESSOR €6.75 Not available for order
169
 photo_cameraImage coming soon M2T833F00 OR 3206 €1.60 Not available for order
175
 photo_cameraImage coming soon M2T085F00 BARREL €1.60 Not available for order
181
 photo_cameraImage coming soon M2T250F00 AIR CLEANER COVER €4.72 Not available for order
182
 Air Filter for Motor CM GEOTEC-CM70 23410061 Air Filter for Motor CM GEOTEC-CM70 €15.35 Not available for order
183
 photo_cameraImage coming soon M2T243F00 SUPPORT AIR €2.14 Not available for order
187
 photo_cameraImage coming soon 2400100F00 STAND IN SEAL 17/38/8 €4.58 Not available for order
190
 photo_cameraImage coming soon 23410062 Filter Element €4.36 Not available for order
191
 photo_cameraImage coming soon M2T232F00 THROTTLE LEVER €1.33 Not available for order
193
 photo_cameraImage coming soon M2Z062F00 TANK MTZ €14.20 Not available for order
197
 photo_cameraImage coming soon M2Z095F00 DISTANCE TANK BUMPER €1.33 Not available for order
199
 photo_cameraImage coming soon M2T225F00 CARTER SEMI SIDE FLYWHEEL MTZ €60.95 Not available for order
200
 photo_cameraImage coming soon M2T226F00 CARTER SEMI CLUTCH SIDE MTZ €24.36 Not available for order
201
 photo_cameraImage coming soon M2T092F00 AIR BAFFLE PIN €1.60 Not available for order
207
 photo_cameraImage coming soon M2T096F00 FITTING M 5-0RmO 0.5 €2.68 Not available for order
225
 photo_cameraImage coming soon 2860610F00 BODY PUMP CM 70/2 €82.71 Not available for order
228
 photo_cameraImage coming soon 2850900F00 BODY PUMP 70 CM / 1A €58.81 Not available for order
230
 photo_cameraImage coming soon 2851100F00 BODY PUMP CM70 / 1A €65.64 Not available for order
300
 Suction Flange 1" for Engine Pump CM70 3500200F00 Suction Flange 1" for Engine Pump CM70 €19.78 Not available for order
303
 Pump Support Flange 1" for Engine Pump CM70 3500300F00 Pump Support Flange 1" for Engine Pump CM70 €35.00 Not available for order
305
 photo_cameraImage coming soon 3500750F00 Flange PUMP SUPPORT €36.45 Not available for order
306
 photo_cameraImage coming soon 3500600F00 FLANGE DISCHARGE €22.90 Not available for order
307
 photo_cameraImage coming soon 3500500F00 FLANGE INTAKE €6.49 Not available for order
316
 Pump Impeller for Motor Pump CM70 3750310F00 Pump Impeller for Motor Pump CM70 €12.88 Not available for order
327
 photo_cameraImage coming soon 3750300F00 Armature €17.24 Not available for order
331
 photo_cameraImage coming soon 3750710F00 Armature €40.15 Not available for order
343
 Pump Body Gasket for Motorpump CM 70 4102620F00 Pump Body Gasket for Motorpump CM 70 €1.48 Not available for order
344
 Pump Intake Gasket for Motor Pump CM 70/1A 4100310F00 Pump Intake Gasket for Motor Pump CM 70/1A €13.41 Not available for order
371
 Pump 70/1A Snail Gasket for Motorpump CM70 4102500F00 Pump 70/1A Snail Gasket for Motorpump CM70 €1.66 Not available for order
372
 Pump 70/1A Body Pump Gasket for Motorpump CM70 4102600F00 Pump 70/1A Body Pump Gasket for Motorpump CM70 €1.66 Not available for order
646
 photo_cameraImage coming soon 9000910F00 PUMP SUPPORT €36.20 Not available for order
662
 photo_cameraImage coming soon 9120300F00 CAP LOADING AND DISCHARGE €1.45 Not available for order
668
 photo_cameraImage coming soon 9120750F00 PLUG AND EXHAUST CARlCO €3.63 Not available for order
672
 photo_cameraImage coming soon 9170300F00 SEAL €7.70 Not available for order
Page 2 zoom_in View exploded
Esploso pagina 2
Pos. Item Price Buy
70
 photo_cameraImage coming soon M2T030F00 HEADSET RECOIL €3.09 Not available for order
71
 photo_cameraImage coming soon M2T031F00 BUSH PULLEY €3.23 Not available for order
72
 photo_cameraImage coming soon M2T040F00 SPRING RIAVVOLGMENTO €8.10 Not available for order
73
 photo_cameraImage coming soon M2T038F00 CABLE STARTER PULLEY €2.68 Not available for order
77
 photo_cameraImage coming soon M2T036F00 BOX SPRING RATCHET €2.75 Not available for order
78
 photo_cameraImage coming soon M2T034F00 BUSH BRASS €2.68 Not available for order
80
 photo_cameraImage coming soon 1600000F00 CABLE REWIND €3.33 Not available for order
132
 photo_cameraImage coming soon M2T003F00 CAP REGULATOR €3.36 Not available for order
134
 photo_cameraImage coming soon M2T014F00 PUSHER REGULATOR DIGIRI €3.36 Not available for order
137
 photo_cameraImage coming soon M2T237F00 HOLDER MASSE €2.14 Not available for order
140
 photo_cameraImage coming soon M2T703F00 RING OIL SEAL SHIELD 6x12x2,5 €1.33 Not available for order
141
 photo_cameraImage coming soon M2T091F00 LEVER CONTROLLER €1.33 Not available for order
144
 photo_cameraImage coming soon M2T009F00 MASS CENTRIFUGAL €1.33 Not available for order
145
 photo_cameraImage coming soon M2T021F00 VALVE COVER €2.41 Not available for order
146
 photo_cameraImage coming soon M2T018F00 ARM , VALVE ROCKER €1.33 Not available for order
147
 photo_cameraImage coming soon M2T004F00 FULCRUM ROCKER €4.04 Not available for order
149
 photo_cameraImage coming soon M2T010F00 PLATE VALVE SPRING €8.10 Not available for order
150
 photo_cameraImage coming soon M2T006F00 VALVE SPRING €1.33 Not available for order
151
 photo_cameraImage coming soon 2000190F00 NUT PUMP €5.78 Not available for order
152
 photo_cameraImage coming soon M2T005F00 VALVE INTAKE €7.02 Not available for order
153
 photo_cameraImage coming soon M2T015F00 EXHAUST VALVE €7.02 Not available for order
154
 photo_cameraImage coming soon M2T016F00 VALVE SEAT INTAKE €4.72 Not available for order
155
 photo_cameraImage coming soon M2T019F00 VALVE SEAT DRAIN €4.72 Not available for order
156
 photo_cameraImage coming soon 2000210F00 NUT PUMP €7.98 Not available for order
156
 photo_cameraImage coming soon M2T078F00 ELBOW FITTING M.5 D.4 €2.68 Not available for order
158
 photo_cameraImage coming soon M2T027F00 LEVER DECOMPRESSOR €1.33 Not available for order
159
 photo_cameraImage coming soon M2T105F00 Shaft A CAMMES €13.52 Not available for order
160
 photo_cameraImage coming soon M2T610F00 ROLLER CASE HK 10x12 €2.68 Not available for order
161
 photo_cameraImage coming soon M2T706F00 RING SEAL OIL 10x14X3 €1.33 Not available for order
163
 photo_cameraImage coming soon M2T013F00 WHEEL CONDUCT €2.14 Not available for order
165
 photo_cameraImage coming soon M2T071F00 BARREL €162.57 Not available for order
166
 photo_cameraImage coming soon M2T023F00 CANCELA €5.15 Not available for order
167
 photo_cameraImage coming soon M2T609F00 BEARING 6000 10x26X8 €1.33 Not available for order
168
 photo_cameraImage coming soon M2T002F00 DRIVE PIN DECOMPRESSOR €6.75 Not available for order
169
 photo_cameraImage coming soon M2T833F00 OR 3206 €1.60 Not available for order
175
 photo_cameraImage coming soon M2T085F00 BARREL €1.60 Not available for order
Page 3 zoom_in View exploded
Esploso pagina 3
Pos. Item Price Buy
60
 photo_cameraImage coming soon M2T001F00 BADMINTON €10.14 Not available for order
62
 photo_cameraImage coming soon M2T050F00 WHEEL DRIVE €2.14 Not available for order
65
 photo_cameraImage coming soon M2T052F00 INSERT FLY €8.10 Not available for order
181
 photo_cameraImage coming soon M2T250F00 AIR CLEANER COVER €4.72 Not available for order
182
 Air Filter for Motor CM GEOTEC-CM70 23410061 Air Filter for Motor CM GEOTEC-CM70 €15.35 Not available for order
183
 photo_cameraImage coming soon M2T243F00 SUPPORT AIR €2.14 Not available for order
190
 photo_cameraImage coming soon 23410062 Filter Element €4.36 Not available for order
191
 photo_cameraImage coming soon M2T232F00 THROTTLE LEVER €1.33 Not available for order
193
 photo_cameraImage coming soon M2Z062F00 TANK MTZ €14.20 Not available for order
197
 photo_cameraImage coming soon M2Z095F00 DISTANCE TANK BUMPER €1.33 Not available for order
199
 photo_cameraImage coming soon M2T225F00 CARTER SEMI SIDE FLYWHEEL MTZ €60.95 Not available for order
200
 photo_cameraImage coming soon M2T226F00 CARTER SEMI CLUTCH SIDE MTZ €24.36 Not available for order
Page 4 zoom_in View exploded
Esploso pagina 4
Pos. Item Price Buy
187
 photo_cameraImage coming soon 2400100F00 STAND IN SEAL 17/38/8 €4.58 Not available for order
228
 photo_cameraImage coming soon 2850900F00 BODY PUMP 70 CM / 1A €58.81 Not available for order
230
 photo_cameraImage coming soon 2851100F00 BODY PUMP CM70 / 1A €65.64 Not available for order
300
 Suction Flange 1" for Engine Pump CM70 3500200F00 Suction Flange 1" for Engine Pump CM70 €19.78 Not available for order
303
 Pump Support Flange 1" for Engine Pump CM70 3500300F00 Pump Support Flange 1" for Engine Pump CM70 €35.00 Not available for order
305
 photo_cameraImage coming soon 3500750F00 Flange PUMP SUPPORT €36.45 Not available for order
307
 photo_cameraImage coming soon 3500500F00 FLANGE INTAKE €6.49 Not available for order
316
 Pump Impeller for Motor Pump CM70 3750310F00 Pump Impeller for Motor Pump CM70 €12.88 Not available for order
344
 Pump Intake Gasket for Motor Pump CM 70/1A 4100310F00 Pump Intake Gasket for Motor Pump CM 70/1A €13.41 Not available for order
371
 Pump 70/1A Snail Gasket for Motorpump CM70 4102500F00 Pump 70/1A Snail Gasket for Motorpump CM70 €1.66 Not available for order
372
 Pump 70/1A Body Pump Gasket for Motorpump CM70 4102600F00 Pump 70/1A Body Pump Gasket for Motorpump CM70 €1.66 Not available for order
662
 photo_cameraImage coming soon 9120300F00 CAP LOADING AND DISCHARGE €1.45 Not available for order
668
 photo_cameraImage coming soon 9120750F00 PLUG AND EXHAUST CARlCO €3.63 Not available for order
672
 photo_cameraImage coming soon 9170300F00 SEAL €7.70 Not available for order
Page 5 zoom_in View exploded
Esploso pagina 5
Pos. Item Price Buy
225
 photo_cameraImage coming soon 2860610F00 BODY PUMP CM 70/2 €82.71 Not available for order
331
 photo_cameraImage coming soon 3750710F00 Armature €40.15 Not available for order
343
 Pump Body Gasket for Motorpump CM 70 4102620F00 Pump Body Gasket for Motorpump CM 70 €1.48 Not available for order
646
 photo_cameraImage coming soon 9000910F00 PUMP SUPPORT €36.20 Not available for order

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

CM Motori Spare Parts for Engine Pumps CM70

CM Motori genuine parts or replacement parts for to repair Engine PUMPS CM70.

In the following table, look for the model of the Motor Pump and the respective parts of the code.
Items will be shipped within 7/10 working days approx.

Engine PUMP 70 CM
1 M2T428F00 TAPPING SCREWTC4,5X 15
3 M2T075F00 AIR CLEANER COVER
4 M2T074F00 AIR FILTER CARTRIDGE
5 9400160F00 SCREW TCEI 5x20 5931
6 M2T550F00 WASHER GEAR 5 · 10
7 M4ZSS3F00 FLAT WASHER D.Sx15x1,5
8 M2T072F00 BODY AIR
9 M2T073F00 AIR BAFFLEINTAKE
10 M2T119F00 CARB SEAL FILTER
11 M2T227F00 OIL BREATHER PIPE
12 3100090F00 SELF-LOCKING NUT M5 7474
14 7400590F00 SPRING WASHER D.6
15 1700000F00 KEY FLY
18 M2T099F00 DELIVERY PIPE OIL
17 M2T100F00 OIL RETURN PIPE
18 3100300F00 SELF-LOCKING NUT M6 UNI7474
19 7100800F00 FLAT WASHER D 6 6592
20 M2T228F00 SPRING SHOOT GAME
21 M2T223F00 SPRING SPEED GOVERNOR MTZ
22 M2T114F00 AUCTION THROTTLE
23 M2T355F00 SCREW TC CR 4x35 UNI7687
24 M2Z120F00 SPRING REGISTRATION ACCELERATOR
25 M2T108F00 THROTTLE LEVER
26 M2T632F00 OR 132
27 M2T066F00 DUCT INTAKE
28 M2T631F00 OR 121
29 M2T222F00 GROUP CYLINDER COMPLETE
30 M2T061F00 HEADPHONES
31 9400600F00 SCREW TCEI 5x25 5931
32 M2T049F00 MUFFLER PROTECTION
33 M2T048F00 MUFFLER
34 3100100F00 NUT M5 5587
35 M2T053F00 DISTANCE FLY
36 3100500F00 NUT M 10xH8
37 M2T233F00 FUEL PIPE
38 7800110F00 FUEL COCK UT
39 8010050F00 CUP OR
40 4108570F00 RING OR 4028
41 M2T220F00 GROUP REWIND COMPLETE
42 M2T440F00 SCREW TC CR 5x15 9709
43 M2T084F00 ANTIVIBRANTE
44 M2T068F00 SUPPORT TANK
45 M2T429F00 TAPPING SCREW TC 4,8x25
47 9110850F00 TANK CAP
48 M2T08BF00 TANK ENGINE
49 M2T083F00 CONVOGLIATORE
50 M2T234F00 GROUP FLY
52 M2T076F00 TIMING BELT 450
53 M2T070F00 CARBURATOR
54 0202000F00 CANDLE JOINT COMPLETE
55 M2T055F00 REEL
56 9402500F00 SCREW TCEI 4X16
57 5200100F00 CABLE
58 M2T087F00 SWITCH
60 M2T001F00 FLYWHEEL
61 2350000F00 FLY COUNTERWEIGHT CM46 / 80/90
62 M2T050F00 WHEEL DRIVE
65 M2T052F00 INSERT FLY
66 3270200F00 POLAR ESPANSlON
67 4280100F00 MAGNET
70 M2T030F00 HEADSET RECOIL
71 M2T031F00 BUSH PULLEY
72 M2T040F00 SPRING RIAVVOLGMENTO
73 M2T038F00 CABLE STARTER PULLEY
74 M2T037F00 SPRING CAM Ratchet
75 M2T032F00 Ratchet START
76 M2T033F00 CAM OPENING Ratchet
77 M2T036F00 BOX SPRING RATCHET
78 M2T034F00 BUSH BRASS
79 24230020 HANDLE
80 1600000F00 CABLE REWIND
90 M2T058F00 PLUG OIL FILTER
91 M2T554F00 WASHER ALUMINIUM 12X1
92 M2T059F00 BOAT OIL FILTER
93 M2T060F00 NETWORK FILTER
94 M2T056F00 CARTER SEMI SIDE CLUTCH
95 M2T700F00 RING SEAL OIL 15x30.7 TC
96 M2T608F00 BEARING 6302 C3
97A M2T039F00 SHAFT ASSEMBLY M2Z
97B M2T041F00 SHAFT ASSEMBLY P25
97C M2T125F00 SHAFT ASSEMBLY Udor
97D M2T126F00 SHAFT ASSEMBLY 20 S
97E M2T127F00 SHAFT ASSEMBLY Bertolini
97F M2T128F00 SHAFT ASSEMBLY Carpi
97G M2T129F00 SHAFT ASSEMBLY Trial
97H M2T130F00 SHAFT ASSEMBLY Cone 12
97-I M2T043F00 SHAFT ASSEMBLY MTP
9a M2T045F00 SEGMENT 49x1
98-1 M2T045F01 RING CHROME
99 M2T046F00 OIL SCRAPER RING 49x2
100 M2T051F00 PISTON D.49
101 M2T047F00 PISTON PIN
102 0092000F00 PIN LOCKING RING D.12
103 M2T054F00 PISTON COMPLETE
104 M2T847F00 RING OR 209
105 M2T830F00 OR 2100
106 M2T065F00 PLUG OIL BREATHER
107 29320041 CAP LEVEL ouo
108 MU095F00 CENTERING BUSH CARTER
109 M2T064F00 SEAL CARTER
110 M2T106F00 OIL PIPE
111 M2T410F00 PRISONER 5x30 ROOT 15 12 9
113 M2T077F00 M.5 0.4 FITTING STRAIGHT
114 M2T785F00 STUD 5x26
115 M2T780F00 STUD 6x16
116 M2T062F00 BLADE CARTER
117 M2T063F00 STILL REED
118 M2T433F00 SCREW TCEI 4x8
119 7401120F00 SPRING WASHER D.4
120 M2T057F00 HALF CARTER SIDE FLYWHEEL
121 M2T248F00 BREATHER PIPE FITTING
122 P25837F00 RING OR 012
123 7400100F00 WASHER 5.3x10x1 6592
124 7400500F00 WASHER D.5 Schnor
125 M2T096F00 FITTING M 5-0RmO 0.5
130 M2T239F00 SPRING OUTER DECOMPRESSOR
131 M2T656F00 RING BENZING 0.5 6799
132 M2T003F00 CAP REGULATOR
133 M2T022F00 SPRING INSIDE DECOMPRESSOR
134 M2T014F00 PUSHER REGULATOR DIGIRI
135 M2T844F00 OR 2137
136 M2T560F00 BALL D.6
137 M2T237F00 HOLDER MASSE
138 M2T662F00 ELASTIC RING 30-1
139 M2T113F00 JUMPER WEIGHTS HOLDER
140 M2T703F00 RING OIL SEAL SHIELD 6x12x2,5
141 M2T091F00 LEVER CONTROLLER
142 M2T561F00 ROLLER 4x12 1707
143 MZT577F00 ROLLER 2.5x13,8
144 M2T009F00 MASS CENTRIFUGAL
145 M2T021F00 VALVE COVER
146 M2T018F00 ROCKER
147 M2T004F00 FULCRUM ROCKER
148 M2T082F00 NUT FULCRUM 6x0,75
149 M2T010F00 PLATE VALVE SPRING
150 M2T006F00 VALVE SPRING
151 M2T238F00 OIL SCRAPER ROD
152 M2T005F00 VALVE INTAKE
153 M2T015F00 EXHAUST VALVE
154 M2T016F00 VALVE SEAT INTAKE
155 M2T019F00 VALVE SEAT DRAIN
156 M2T078F00 ELBOW FITTING M.5 D.4
157 M2T576F00 PLUG SPIROL 3x28
158 M2T027F00 LEVER DECOMPRESSOR
159 M2T105F00 Camshaft
160 M2T610F00 ROLLER CASE HK 10x12
161 M2T706F00 RING SEAL OIL 10x14X3
163 M2T013F00 WHEEL CONDUCT
164 M2T509F00 NUT M 8 x1 5588
165 M2T071F00 CYLINDER
166 M2T023F00 CANCELA
167 M2T609F00 BEARING 6000 10x26X8
168 M2T002F00 DRIVE PIN DECOMPRESSOR
169 M2T833F00 OR 3206
170 M2T557F00 Shim 6x12x04
171 M2T028F00 RING CORE
172 M2T653F00 The SNAP RING 40X1,75
173 M2T660F00 SEEGER 10
174 1000800F00 BOLT TE 5x10
175 M2T085F00 DISTANCE
181 M2T250F00 AIR CLEANER COVER
182 23410061 FILTER PAPER
183 M2T243F00 SUPPORT AIR
184 M2T245F00 PIPE RECOVERY OIL
185 M2T246F00 BUSH REDUCTION TUBE
186 M2T247F00 PIPE VENT D.6
188 M2T240F00 SPRING ROD ACCELERATOR
189 M2T241F00 SPRING THROTTLE ENGINE
190 23410062 FILTER DISPUGNA
191 M2T232F00 THROTTLE LEVER
192 M2Z529F00 NUT PANEL M, 4 DIN 557
193 M2Z062F00 TANK MTZ
194 M2T249F00 FUEL PIPE
195 7400700F00 WASHER 6X18
196 M2T375F00 SCREW TCEI 6X80 5931
197 M2Z095F00 DISTANCE TANK
198 7400300F00 WASHER 6X24
199 M2T225F00 CARTER SEMI SIDE FLYWHEEL MTZ
200 M2T226F00 CARTER SEMI CLUTCH SIDE MTZ
201 M2T092F00 AIR BAFFLE PIN
202 M2T855F00 FASTON TYPE SABA
203 9402090F00 TAPPING SCREW 2,9X13 TCTC
204 M2T548F00 WASHER D.3 6592
205 7400630F00 WAVY WASHER D10 DIN 137 / B
206 M2T102F00 RING shim DOOR MASSE
207 M2T096F00 FITTING STRAIGHT M 5 D.5
208 M2T856F00 FASTON MALE
209 M2T857F00 FASTON FEMALE
210 M2Z117F00 SPRING RETURN GAS
BODY PUMP 70/1A - 70/2A - 70/2
25 0104510F00 RING OR 123
26 0104400F00 RING OR 4162
27 4106620F00 RING OR 4700
96 1000300F00 BOLT TE 6x16
100 1000700F00 BOLT TE 8x14
151 2000190F00 NUT PUMP
156 2000210F00 NUT PUMP
187 2400100F00 STAND IN SEAL 17/38/8
225 2860610F00 BODY PUMP CM 70/2
228 2850900F00 BODY PUMP 70 CM / 1A
230 2851100F00 BODY PUMP CM70 / 1A
260 3100100F00 NUT M5 UNI 5567
300 3500200F00 Suction flange 1"
303 3500300F00 Flange PUMP SUPPORT
305 3500750F00 Flange PUMP SUPPORT
307 3500500F00 FLANGE INTAKE
306 3500600F00 FLANGE DISCHARGE
316 3750310F00 IMPELLER
327 3750300F00 IMPELLER
331 3750710F00 IMPELLER
343 4102620F00 SEAL BODY PUMP
344 4100310F00 SEAL ASPRIRAZIONE CM 70 / 1A
345 4100400F00 OR 119
371 4102500F00 SEAL NUT
372 4102600F00 SEAL BODY PUMP
390 4109800F00 SEAL INTAKE
391 4103810F00 WOE \ nition DELIVERY
494 6800300F00 STUD BOLT 5x25
530 7400100F00 FLAT WASHER D.5
535 7400020F00 FLAT WASHER D.8
646 9000910F00 PUMP SUPPORT
662 9120300F00 CAP LOADING AND DISCHARGE
668 9120750F00 PLUG AND EXHAUST CARlCO
672 9170300F00 SEAL
711 9400220F00 SCREW TCEI 8x22
729 9401390F00 SCREW TCEI 6x60
730 9401700F00 SCREW TCEI 6X40
731 9401800F00 SCREW TCEI 6X18

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s CM Motori snc websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to CM Motori snc brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.

Specific References

New

Download

Diagram CM70

Diagram CM70

Download (512.95KB)

You might also like

Air Filter for Motor CM GEOTEC-CM70
CM snc SKU: 23410061
Air Filter for Motor CM GEOTEC-CM70
Air Filter for Engines CM GEOTEC-CM70 Genuine part CM Motors, Air Filter for Engines GEOTEC - CM70 Part for the following products: - Engine CM GEOTEC - Engine CM CM70 - Code: 23410061
Last items in stock €15.35
Details
Pump Intake Gasket for Motor Pump CM 70/1A
CM snc SKU: 4100310F00
Pump Intake Gasket for Motor Pump CM 70/1A
Pump Intake Gasket for Motor Pump CM 70/1A Genuine parts CM Motors, Intake Gasket with Counterweight for 1'' Self-Priming Pump of Motor Pumps CM 70/1A. Part for the following article : - Motor Pump CM 70/1A - Code: 4100310F00
AVAILABLE €13.41
Details
Spark Plug Joint Ass'y for Motorpumps CM70
CM snc SKU: 0202000F00
Spark Plug Joint Ass'y for Motorpumps CM70
Spark Plug Cap Ass'y for Motorpumps CM70 Genuine replacement part CM MOTORI, Spark Plug Cap Ass'y for Motorpumps CM 70. Parts for the following products:  - MOTORPUMP CM70 - Code: 0202000F00
AVAILABLE €4.06
Details
Pump Body Gasket for Motorpump CM 70 Sale
CM snc SKU: 4102620F00
Pump Body Gasket for Motorpump CM 70
Pump Body Gasket for Motorpump CM 70 Genuine part CM Motori, Pumps Body Gasket, for Motor Pumps CM 70/1A - 70/2A - 70/2 Part for the following products: - Motor Pumps CM 70/1A - 70/2A - 70/2 - Code: 4102620F00
AVAILABLE €1.48
Details
1" Self-Priming Snail Gasket for Motor Pump CM 46 N Sale
CM snc SKU: 410250
1" Self-Priming Snail Gasket for Motor Pump CM 46/N
1" Self-Priming Snail Gasket for Motor Pump CM 46/N Genuine part CM Motors, 1" Self-Priming Snail Gasket for Motor Pumps 2 Stroke CM 46/N - Motor Pump CM70 Part for the following products: - Motor Pump 2 Stroke CM 46/N - Motor Pump...
AVAILABLE €1.35
Details
Gasoline Tap for Motor Pump CM70 Sale
CM snc SKU: 7800110F00
Gasoline Tap for Motor Pump CM70
Gasoline Tap for Motor Pump CM70 Original parts CM, Gasoline Tap for Motor Pump CM70 Parts for the following products: - Motor Pump CM70 - Code: 7800110F00
AVAILABLE €10.19
Details
Gasoline Tap O-Ring Washer for Motor Pump CM70 Sale
CM snc SKU: 8010050F00
Gasoline Tap O-Ring Washer for Motor Pump CM70
Gasoline Tap O-Ring Washer for Motor Pump CM70 Original parts CM, Gasoline Tap O-Ring Washer for Motor Pump CM70 Parts for the following products: - Motor Pump CM70 - Code: 8010050F00
AVAILABLE €0.25
Details
Petrol Tap Gasket O-R 8x15x3 for Motorpump CM70 Sale
CM snc SKU: 4108570F00
Petrol Tap Gasket O-R 8x15x3 for Motorpump CM70
Petrol Tap Gasket O-R 8x15x3 for Motorpump CM70 Original part CM Motori, Petrol Tap Gasket O-R mm 8x15x3 for Motorpump CM70 Replacement for the following products: - Motorpump CM70 - Code: 4108570F00
AVAILABLE €0.50
Details
Piston Pin Circlip mm 12 for Motorpump CM 70 Sale
CM snc SKU: 0092000F00
Piston Pin Circlip mm 12 for Motorpump CM 70
Piston Pin Circlip mm 12 for Motorpump CM 70 Genuine parts CM MOTORI, Piston Pin Circlip mm 12 for Motor Pump CM 70 Part for the following products: - Motor Pump CM 70 - Code: 0092000F00
AVAILABLE €0.50
Details
Pump 70/1A Snail Gasket for Motorpump CM70 Sale
CM snc SKU: 4102500F00
Pump 70/1A Snail Gasket for Motorpump CM70
Pump 70/1A Snail Gasket for Motorpump CM70 Original part CM Motori, Pump 70/1A Snail Gasket for Motorpump CM70 Replacement for the following products: - Motorpump CM70 - Code: 4102500F00
AVAILABLE €1.66
Details
Pump 70/1A Body Pump Gasket for Motorpump CM70 Sale
CM snc SKU: 4102600F00
Pump 70/1A Body Pump Gasket for Motorpump CM70
Pump 70/1A Body Pump Gasket for Motorpump CM70 Original part CM Motori, Pump 70/1A Body Pump Gasket for Motorpump CM70 Replacement for the following products: - Motorpump CM70 - Code: 4102600F00
AVAILABLE €1.66
Details
Oil Sealing Ring 15x30x7 TC for Motorpump CM 70 Sale
CM snc SKU: M2T700F00
Oil Sealing Ring 15x30x7 TC for Motorpump CM 70
Oil Sealing Ring 15x30x7 TC for Motorpump CM 70 Genuine part CM Motori, Oil Sealing Ring 15x30x7 TC for Motor Pumps CM 70 Part for the following products: - Motor Pump CM 70 - Code: M2T700F00
AVAILABLE €3.21
Details
Pump Impeller for Motor Pump CM70
CM snc SKU: 3750310F00
Pump Impeller for Motor Pump CM70
Pump Impeller for Motor Pump CM70 CM Motori Original replacement part, Pump Impeller for Motor Pump CM70. Part for the following products: - Motor Pump CM70 - Code: 33750310F00
Last items in stock €12.88
Details
Cylinder Group Complete for Engine Pump CM70
CM snc SKU: M2T222F00
Cylinder Group Complete for Engine Pump CM70
Cylinder Ass'y for Motorpump Engine CM70 Original replacement part CM Motori, Cylinder Assembly for Motorpump Engine CM70. Replacement for the following products: -  Motorpump Engine CM70 - Code: M2T222F00
AVAILABLE €237.94
Details
Pump Support Flange 1" for Engine Pump CM70
CM snc SKU: 3500300F00
Pump Support Flange 1" for Engine Pump CM70
Pump Support Flange 1" for Engine Pump CM70 Genuine replacement part CM Motori, Pump Support Flange 1" for Engine Pump CM70. Part for the following products: - Engine Pump CM70 - Code : 3500300F00
AVAILABLE €35.00
Details
Suction Flange 1" for Engine Pump CM70
CM snc SKU: 3500200F00
Suction Flange 1" for Engine Pump CM70
Suction Flange 1" for Engine Pump CM70 Genuine replacement part CM Motori, Suction Flange 1" for Engine Pump CM70. Part for the following products: - Engine Pump CM70 - Code : 3500200F00
AVAILABLE €19.78
Details
Comments (0)
