CM Motori Spare Parts for Motor Pump CM80
CM Motori Genuine spare parts or replacement parts for to repair Engine pump CM80.
In the following table, look for the model of the Motor Pump and the respective parts of the code.
Items will be shipped within 10 working days approx.
| Engine pump CM80 |
|
001000 |
Equipements |
| 4 |
004320 |
Crankshaft |
| 4 |
004310 |
Crankshaft |
| 4 |
004300 |
Crankshaft |
| 7 |
005000 |
Circlip |
| 11 |
009300 |
Circlip |
| 21 |
010300 |
Oil seal |
| 25 |
010451 |
Seal OR 123 |
| 26 |
010440 |
Seal OR 4162 |
| 27 |
410652 |
Seal |
| 33 |
018310 |
Shaft |
| 40 |
020200 |
Plug cap assy |
| 46 |
022020 |
Starter recoil |
| 64 |
027300 |
Connecting |
| 71 |
028310 |
Connecting complete |
| 76 |
035010 |
Ignition coil |
| 81 |
036000 |
Bush |
| 85 |
045003 |
Stop button |
| 88 |
050300 |
Bushing |
| 96 |
100030 |
Hexagonal head bolt |
| 102 |
100090 |
Hexagonal head bolt |
| 107 |
100113 |
Hexagonal head bolt |
| 108 |
100114 |
Hexagonal head bolt |
| 109 |
100115 |
Hexagonal head bolt |
| 135 |
140010 |
Spark plug NGK BPMR7A |
|
150301 |
Carburettor |
| 141 |
150300 |
Carburettor |
| 148 |
160005 |
Pulling rope |
|
170010 |
Key |
| 150 |
170000 |
Key |
| 153 |
200030 |
Nut pump |
| 168 |
216400 |
Cylinder |
| 172 |
216520 |
Complete cylinder with piston |
| 181 |
220020 |
Intake cooler |
| 188 |
240020 |
Stand - in seal |
| 198 |
250400 |
Fan case |
| 222 |
285020 |
Body pump |
| 224 |
285030 |
Body pump |
| 230 |
285110 |
Body pump |
| 238 |
295005 |
Drivel pawl |
| 241 |
298020 |
Cover air filter |
| 251 |
298200 |
Starter recoil cover |
|
299001 |
Curve air filter MTZ |
| 254 |
300020 |
Val bearing |
| 260 |
310010 |
Nut |
| 261 |
310020 |
Nut |
| 264 |
310050 |
Nut |
| 265 |
310080 |
Nut |
| 277 |
310030 |
Nut |
|
315000 |
Spacer carry |
| 283 |
325010 |
Filtering element |
| 288 |
327020 |
Pole shoe |
| 289 |
330010 |
Clamp fissing air filter |
| 293 |
340010 |
Benzin filter |
| 296 |
350010 |
Flange |
| 307 |
350050 |
Flange |
| 308 |
350060 |
Flange |
| 309 |
350070 |
Flange |
| 312 |
360030 |
Roll - cage |
| 315 |
366010 |
Float carburettor |
| 319 |
369020 |
Casting carburettor |
| 325 |
375045 |
Impeller |
| 326 |
375040 |
Impeller |
| 330 |
375070 |
Impeller |
| 338 |
405010 |
Rubber shock absorber |
|
405020 |
Rubber shock absorber |
| 347 |
410060 |
Gasket |
| 350 |
410090 |
Gasket |
| 352 |
410110 |
Gasket |
| 361 |
410160 |
Gasket |
| 364 |
410180 |
Gasket |
| 367 |
410210 |
Gasket |
| 368 |
410220 |
Gasket |
| 380 |
410281 |
Gasket |
| 381 |
410300 |
Gasket |
| 390 |
410380 |
Gasket |
| 391 |
410381 |
Gasket |
|
410657 |
Gasket |
| 397 |
425000 |
Starter handle |
| 405 |
428010 |
Magnet |
| 411 |
435030 |
Muffler |
| 416 |
500007 |
Spring |
| 417 |
500006 |
Spring |
| 425 |
500060 |
Spring |
| 426 |
500005 |
Spring |
| 431 |
520010 |
Cable holder |
| 452 |
620300 |
Piston |
| 452 |
620301 |
Piston |
| 453 |
620310 |
Piston |
| 453 |
620320 |
Piston |
|
650310 |
Complete pump |
|
650311 |
Complete pump |
|
650300 |
Complete pump |
| 492 |
680010 |
Stud |
| 493 |
680019 |
Stud |
| 495 |
680020 |
Stud |
|
705051 |
Pulley starter |
| 508 |
705050 |
Pulley starter |
| 512 |
705001 |
Pulley starter |
| 527 |
727002 |
Carburettor register with spring |
| 528 |
740121 |
Washer |
| 531 |
740020 |
Washer |
| 532 |
740030 |
Washer |
| 534 |
740060 |
Washer |
| 535 |
740002 |
Washer |
| 537 |
740070 |
Washer |
| 538 |
740080 |
Washer |
| 539 |
740100 |
Washer |
| 540 |
740100 |
Washer |
| 546 |
780010 |
Fuel tap |
| 551 |
810050 |
Piston rings mm 48,5x2 |
| 551 |
810020 |
Piston rings mm 48x2 |
| 584 |
820300 |
Crankshaft |
| 585 |
820330 |
Crankshaft |
| 585 |
820320 |
Crankshaft |
| 585 |
820310 |
Crankshaft |
| 606 |
850300 |
Crankcase |
| 607 |
850310 |
Crankcase |
|
880311 |
Tank |
|
880310 |
Tank |
| 618 |
880400 |
Tank |
|
880301 |
Tank |
|
890031 |
Gasket series |
|
890032 |
Gasket series |
|
890033 |
Gsket series |
|
890030 |
Gasket series |
| 630 |
891001 |
Tightening carburettor |
| 635 |
893010 |
Pin closing benzin carburettor |
| 640 |
895010 |
Piston spin |
| 645 |
900100 |
Holder |
| 651 |
900050 |
Holder |
| 653 |
900080 |
Holder |
| 660 |
912010 |
Cap |
| 661 |
912020 |
Cap |
| 664 |
912050 |
Cap |
| 667 |
912065 |
Cap |
| 668 |
912075 |
Cap |
| 670 |
917010 |
Seal |
| 675 |
917060 |
Complete mecanical seal |
| 681 |
920300 |
Head |
| 683 |
923030 |
Fuel hose |
| 695 |
926010 |
Chamber carburettor SHA |
| 702 |
930030 |
Ventilating fan |
| 705 |
940005 |
Screw |
| 711 |
940022 |
Screw |
| 714 |
940030 |
Screw |
| 715 |
940040 |
Screw |
| 716 |
940050 |
Screw |
| 717 |
940060 |
Screw |
| 718 |
940070 |
Screw |
| 720 |
940090 |
Screw |
| 721 |
940100 |
Screw |
| 732 |
940190 |
Screw |
| 743 |
940230 |
Screw |
| 744 |
940250 |
Screw |
| 745 |
940270 |
Screw |
| 751 |
980010 |
Flywheel |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s CM Motori snc websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to CM Motori snc brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
