Castelgarden Spare Parts for XP 35 Lawn Mower
€0.12
VAT included
Castelgarden Spare Parts for Lawnmower XP 35
We are Distributors of original CASTELGARDEN Spare Parts and an authorized service center. We guarantee low prices and a professional repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance and repair issue for the Lawnmower XP 35/297330063/C19.
Castelgarden Spare Parts for XP 35 Lawn Mower
€0.12
VAT included
Castelgarden Spare Parts for Lawnmower XP 35
We are Distributors of original CASTELGARDEN Spare Parts and an authorized service center. We guarantee low prices and a professional repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance and repair issue for the Lawnmower XP 35/297330063/C19.
settings
33 Spare parts
description
3 exploded views
verified_user
Original Product
Manufacturer warranty included
support_agent
Technical Support
Our team helps you choose
Secure and guaranteed payments
33 spare parts
Page 1
zoom_in View exploded
local_shipping Usually Ships in 10/15 BUSINESS DAYS
Page 2
zoom_in View exploded
local_shipping Usually Ships in 10/15 BUSINESS DAYS
Page 3
zoom_in View exploded
local_shipping Usually Ships in 10/15 BUSINESS DAYS
Shipping and delivery information will be available shortly.
Castelgarden Spare Parts for Lawn Mower XP 35
We are Distributors of Original CASTELGARDEN Spare Parts and an authorized service center. We guarantee low prices and a professional repair service able to advise you on purchasing the most suitable spare part to quickly resolve any maintenance and repair problem of the Lawn Mower XP 35/297330063/C19.
| Lawn Mower XP 35/297330063/C19 | ||
|---|---|---|
| Wheels, Blade, Body, Motor Pag.1 | ||
| # | Part Num. | Description |
| 1 | 322108326/0 | Conveyor |
| 2 | 112728714/0 | Screw |
| 3 | 112735410/0 | Screw |
| 4 | 322720360/2 | Screen |
| 5 | 122167700/0 | Spacer |
| 6 | 112819203/0 | Screw |
| 7 | 322055619/0 | Red Cover |
| 8 | 322055581/0 | Grey Motor Cover |
| 9 | 181004115/1 | Blade |
| 10 | 381004352/1 | Screw |
| 11 | 322465663/0 | Blade Hub |
| 12 | 118563725/0 | Electric Motor 1000W |
| 13 | 112604911/0 | Crown Fastener |
| 14 | 122033443/1 | Wheel Axle |
| 15 | 122033443/1 | Wheel Axle |
| 16 | 122446196/0 | Spring |
| 17 | 322686108/0 | Wheel |
| 18 | 322110685/0 | Grey Hub Cap |
| Handle Pag.2 | ||
| # | Part Num. | Description |
| 19 | 381006941/4 | Handle, Upper Part |
| 20 | 381007597/0 | Right Lower Handle |
| 21 | 381007598/0 | Left Lower Handle |
| 22 | 112728701/0 | Screw |
| 23 | 122450115/0 | Spring |
| 24 | 322230350/2 | Fulcrum |
| 25 | 322785144/1 | Support |
| 26 | 381008790/0 | Screw Set |
| 27 | 381600564/0 | Motor Protector Assy |
| 28 | 322322883/2 | Yellow Motor Brake Lever |
| Grass Catcher Pag.3 | ||
| # | Part Num. | Description |
| 29 | 122450250/0 | Spring |
| 30 | 122512603/0 | Pin |
| 31 | 322600344/0 | Yellow Stone Guard |
| 32 | 322486493/0 | Grass Catcher, Lower Right Grey Part |
| 33 | 322486492/0 | Grass Catcher, Lower Left Grey Part |
| 34 | 322486479/0 | Grass Catcher Upper Grey Part |
All technical product information in this catalog is based on information taken from official sources, including the manufacturer Castelgarden websites, which we consider reliable. Unfortunately, even official documents may contain errors or misprints - we are unable to confirm that all of this data is accurate and truly represents the facts. Most manufacturers reserve the right to modify product specifications or supplement descriptions without prior notice. It is strongly recommended to use the published information as baseline information subject to revision by the Castelgarden brand. Please confirm important parameters with a sales assistant at the time of purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or reproduction (total or partial) without a reference to the source page is strictly prohibited.
297330063/C19-2019
Data sheet
- SHIPPING IN
- Usually Ships in 10/15 BUSINESS DAYS
- CHECK ITEM CODE OR S/N
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- Machine Type
- Lawn Mowers
