Bosch Spare Parts for Angle Grinder PWS PWS 10-125 CE
SKU: PWS 10-125 CE - 0603321703
€3.89
VAT included
Bosch Spare Parts for Angle Grinder PWS PWS 10-125 CE
We are BOSCH original spare parts and Accessories Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Angle Grinder PWS 10-125 CE - 0603321703.
Bosch Spare Parts for Angle Grinder PWS PWS 10-125 CE
SKU: PWS 10-125 CE - 0603321703
Condition:
New
€3.89
VAT included
Bosch Spare Parts for Angle Grinder PWS PWS 10-125 CE
We are BOSCH original spare parts and Accessories Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Angle Grinder PWS 10-125 CE - 0603321703.
Informazioni sulle spedizioni e consegne saranno disponibili a breve.
Bosch Spare Parts for Angle Grinder PWS PWS 10-125 CE
We are BOSCH original spare parts and Accessories Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Angle Grinder PWS 10-125 CE - 0603321703.
In the following table, look for the model of the Angle Grinder and the respective parts of the code.
Angle Grinder PWS 10-125 CE/0 603 321 703
1
1 605 108 171
Motor Housing GREEN
2
1 604 220 301
Field 220-240V
3/50
1 606 610 129
Fan
6
1 600 703 030
Grommet Ø6,4-Ø7,2x67 MM
1 600 703 031
Grommet Ø7,3-Ø8,6x67 MM
1 600 703 032
Grommet Ø8,7-Ø9,5x67 MM
7
1 601 302 017
Fastening Clamp
9
1 601 118 188
Manufacturer's nameplate
13
2 600 905 032
Deep-Groove Ball Bearing 7x19x6
14
1 600 905 032
Deep-Groove Ball Bearing 8x22x7
17
1 604 652 013
Spiral Spring
18
1 602 319 013
Switch-Pawl BLACK
19
1 604 611 024
Compression Spring
20
1 602 319 007
Shift-Lever Knob BLACK
25
1 605 500 179
Housing Cover GREEN
26
1 600 206 036
Rubber Ring
27
1 600 206 025
Rubber Ring
29
1 600 591 013
Air-Deflector Ring
30
1 600 591 014
Air-Deflector Ring
31
1 601 290 007
Clamping Spring
32
1 603 523 110
Grinding Spindle M14, SW17
33
1 600 210 035
O-Ring 46,0x1,1 MM
35
1 600 136 013
Shim 0,1 MM THICK
1 600 136 020
Shim 0,15 MM THICK
1 600 136 014
Shim 0,2 MM THICK
1 600 136 015
Shim 0,3 MM THICK
37
1 600 290 016
Rotary shaft lip seal
40
1 600 119 011
Spring retaining ring
41
1 600 910 018
Needle bearing Ø8xØ12x8 MM
45
1 603 300 016
Hex Nut M7, SW10
47
2 912 401 018
Tapping Screw DIN7981-ST3,9x13-C-Z
49
1 603 435 026
Thread-forming tap. Screw
50
1 603 435 037
Plastic-Cutting Screw
51
1 607 233 065
Speed governor 230-240V
55
2 912 401 022
Tapping Screw DIN 7981-ST3,9x25-C-Z
56
1 603 435 044
Plastic-Cutting Screw
57
1 603 429 002
Socket head cap screw M3,5x7 MM
80
3 600 150 021
Sealing disk
104
1 600 210 044
O-Ring 4,5x1,0 MM BLUE
650/50/20
1 600 210 039
O-Ring 20,35x1,78 MM
700
2 607 001 188
Parts Set Ø 125 MM
700/10
2 605 510 101
Protective Cover Ø 125MM
700/20
1 608 135 004
Guide Block
700/20/30
2 910 281 158
Round-Head Bolt DIN 603-M 5x16
700/20/40
2 915 191 105
Wing Nut M 5 DIN 315-G-5
700/20/50
1 604 643 004
Compression Spring
750/10
2 602 025 067
Auxiliary Handle M10, Ø32,5x105 MM
750/20
1 603 340 040
Clamping Nut M14
750/30
1 607 950 043
Pin-Type Face-Wrench
750/50
1 605 703 099
Clamping-Flange Ø22,2x42 MM
751
2 605 510 104
Protective Cover Ø 125MM SILVER
752
1 603 340 031
Fast Locking Flange M14
753
1 605 438 089
Carrying Case
767
2 605 510 107
Suction Hood Ø115-125MM
767/703
2 605 730 036
Brush
803
1 604 010 473
Armature With Fan 230V
804
1 607 200 115
Switch
805
1 607 000 228
Power supply cord EU 4,15m 2 x 1,5mm H07 RN-F
808
1 601 106 032
Nameplate 26x52 MM
810
1 607 014 176
Carbon-Brush Set
816
1 604 336 031
Brush Holder
821
1 605 806 451
Gear Housing
821/010
1 607 000 253
Push-Button BLACK
828
1 605 805 079
Bearing Flange BLACK
838
1 600 A00 22W
Gear Unit
