Bosch Spare Parts for Percussion Drill PSB 550 RA

SKU: Bosch PSB550RA - 3603C97400
€16.19
VAT included

Bosch Spare Parts for Percussion Drill PSB 550 RA

Distribution and Sale at attractive prices of BOSCH Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Percussion Drill PSB550RA - 3603C97400.

Bosch PSB 550 RA - 3603C97400
Bosch Spare Parts for Percussion Drills PSB 500 RE - PSB 550 RA
  • Bosch Spare Parts for Percussion Drills PSB 500 RE - PSB 550 RA
  • Bosch Spare Parts for Percussion Drill PSB 550 RA

Bosch Spare Parts for Percussion Drill PSB 550 RA

SKU: Bosch PSB550RA - 3603C97400 Condition: New
€16.19
VAT included

Bosch Spare Parts for Percussion Drill PSB 550 RA

Distribution and Sale at attractive prices of BOSCH Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Percussion Drill PSB550RA - 3603C97400.

Bosch PSB 550 RA - 3603C97400
settings 36 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:: BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

28 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Pos. Item Price Buy
1
photo_cameraImage coming soon 2609000625 Housing Section GREEN  €18.81
2
photo_cameraImage coming soon 2604220601 Field 220-240V  €23.73
3/50
Fan for Percussion Drill Bosch GSB 13 RE 2606610097 Fan for Percussion Drill Bosch GSB 13 RE €5.94
3/14
Ball Bearing 608-2Z/C3 for Percussion Drill Bosch PSB 500 RE 3130900020 Ball Bearing 608-2Z/C3 for Percussion Drill Bosch PSB 500 RE €6.00
4
photo_cameraImage coming soon 2607200594 Switch  €16.40
6
Grommet for Drills Bosch PSB550-650-700/2-1000 2600707066 Grommet for Drills Bosch PSB550-650-700/2-1000 €2.28
9
photo_cameraImage coming soon 2609000864 Manufacturer's nameplate PSB 550 RA  €2.84
16
photo_cameraImage coming soon 2609001006 Brush Holder  €11.26
19
photo_cameraImage coming soon 2603490022 Torx Oval-Head Screw 4x16 €1.66
25
photo_cameraImage coming soon 2609000637 Change-Over Switch  €1.60
31
photo_cameraImage coming soon 2609000684 Change-Over Switch  €1.73
32
photo_cameraImage coming soon 2609000629 Retaining Plate  €2.30
33
Indexing Disk for Percussion Drill Bosch PSB 550 RA 2601901012 Indexing Disk for Percussion Drill Bosch PSB 550 RA €6.58 Not available for order
36
photo_cameraImage coming soon 2609000632 Drilling Spindle  €7.91
38
photo_cameraImage coming soon 2609000603 Sintered-Metal Bushing  €2.30
41
Compression Spring for Bosch Impact Drills GSB13-16/PSB500-650-700 2604616006 Compression Spring for Bosch Impact Drills GSB13-16/PSB500-650-700 €1.91
212
photo_cameraImage coming soon 2601119602 Reference Plate RED  €2.99
653
photo_cameraImage coming soon 2607030115 Lock RED  €1.73
654
photo_cameraImage coming soon 2602025125 Auxiliary Handle BLACK €8.38
654
photo_cameraImage coming soon 2602025137 Auxiliary Handle Power Light  €21.62
655/880
photo_cameraImage coming soon 2605190920 Intake manifold module BLACK  €14.61
655/830
photo_cameraImage coming soon 2605411902 Dust Bag BLACK  €5.65
655/10
photo_cameraImage coming soon 2605510217 Impulse Starting Device RED  €1.60
655
photo_cameraImage coming soon 2609000636 Exhauster BLACK  €27.77
805
photo_cameraImage coming soon 1607000388 Power supply cord EU 2,65m 2 x 1,0mm €15.27
808
photo_cameraImage coming soon 2609000626 Nameplate  €2.84
810
Carbon Brushes for Orbital Sanders PSS 200-250-300 AE 2610391290 Carbon Brushes for Orbital Sanders PSS 200-250-300 AE €9.44
836
Drilling Spindle for Impact Drill Bosch PSB 550 2609000771 Drilling Spindle for Impact Drill Bosch PSB 550 €31.87

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Bosch Spare Parts for Percussion Drill PSB 550 RA

Distribution and Sale at attractive prices of BOSCH Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Percussion Drill PSB550RA - 3603C97400.

In the following table, look for the model of the Percussion Drill and the respective parts of the code.
Bosch PSB 550 RA - 3603C97400

Percussion Drill PSB 550 RA/3 603 C97 400
# Part Num. Description
1 2609000625 Housing Section GREEN
2 2604220601 Field 220-240V
3 2604011315 Armature 230-240V
3/50 2606610097 Fan
3/14 3130900020 Deep-Groove Ball Bearing 8x22x7 608-2Z/C3
4 2607200594 Switch
6 2600707066 Grommet Ø6,2-Ø6,9x90 MM
9 2609000864 Manufacturer's nameplate PSB 550 RA
16 2609001006 Brush Holder
19 2603490022 Torx Oval-Head Screw 4x16
25 2609000637 Change-Over Switch
30 2609000630 Push-Button
31 2609000684 Change-Over Switch
32 2609000629 Retaining Plate
33 2601901012 Indexing Disk
34 2605807107 Bearing Bracket
35 2609000631 Lock Spring
36 2609000632 Drilling Spindle
37 2609000602 Cylindrical Gear
38 2609000603 Sintered-Metal Bushing
39 2608572173 Keyless Chuck
41 2604616006 Compression Spring
42 2609001005 Shut-off Valve
212 2601119602 Reference Plate RED
653 2607030115 Lock RED
654 2602025125 Auxiliary Handle BLACK
654 2602025137 Auxiliary Handle Power Light
655 2609000636 Exhauster BLACK
655/10 2605510217 Impulse Starting Device RED
655/830 2605411902 Dust Bag BLACK
655/880 2605190920 Intake manifold module BLACK
655/880/16 2600206003 Friction Ring
805 1607000388 Power supply cord EU 2,65m 2 x 1,0mm
808 2609000626 Nameplate
810 2610391290 Carbon-Brush Set
836 2609000771 Spindle
