Bosch Spare Parts for Percussion Drill PSB 800-2 RA

SKU: Bosch PSB 800-2 RA - 3603A72700
€1.69
VAT included

Bosch Spare Parts for Percussion Drill PSB 800-2 RA

Bosch original spare parts to replace worn components or repair damaged parts of the Percussion Drill PSB 800-2 RA - 3603A72700.

Bosch PSB 800-2 RA - 3603A72700
Bosch Spare Parts for Percussion Drill PSB 800-2 RA
  • Bosch Spare Parts for Percussion Drill PSB 800-2 RA
  • Bosch Spare Parts for Percussion Drills PSB 650 RE - PSB 800-2 RA
Bosch

Bosch Spare Parts for Percussion Drill PSB 800-2 RA

SKU: Bosch PSB 800-2 RA - 3603A72700 Condition: New
€1.69
VAT included

Bosch Spare Parts for Percussion Drill PSB 800-2 RA

Bosch original spare parts to replace worn components or repair damaged parts of the Percussion Drill PSB 800-2 RA - 3603A72700.

Bosch PSB 800-2 RA - 3603A72700
settings 58 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 10 Business Days Approx

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:: BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
58 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
Ball DIN 5401-5,5 mm for Bosch Impact Drills GSB16-18-20-22 1903230010 Ball DIN 5401-5,5 mm for Bosch Impact Drills GSB16-18-20-22 €1.91
photo_cameraImage coming soon 2600000030 Shim washer 1,35 MM €2.18
photo_cameraImage coming soon 2600000031 Shim washer 1,7 MM €2.18
photo_cameraImage coming soon 2603230007 Ball 5,25 MM €1.43
photo_cameraImage coming soon 2609002038 Manufacturer's nameplate PSB 780-2 RE €2.51
1
 photo_cameraImage coming soon 2605105081 Housing Section €27.47
2
 photo_cameraImage coming soon 2604220669 Field 230V €27.47
3
 photo_cameraImage coming soon 2604011329 Armature 230V €50.16
4
 photo_cameraImage coming soon 2607200601 Switch €27.47
5
 photo_cameraImage coming soon 1607000387 Power supply cord EU 2,65m 2 x 0,75mm €10.76
6
 Grommet for Sander BOSCH PSS 300 AE 2609002019 Grommet for Sander BOSCH PSS 300 AE €2.64
9
 photo_cameraImage coming soon 2601116998 Manufacturer's nameplate PSB 800-2 RA €3.70
16
 Brushes Holder for Percussion Drills Bosch PSB 650 RE - 800-2 RA 2604337059 Brushes Holder for Percussion Drills Bosch PSB 650 RE - 800-2 RA €22.72
21
 Tapping Screw DIN 7981 for Percussion Drill Bosh GSB-PSB 2910611002 Tapping Screw DIN 7981 for Percussion Drill Bosh GSB-PSB €1.20
22
 photo_cameraImage coming soon 2603490022 Torx Oval-Head Screw 4x16 €1.66
23
 photo_cameraImage coming soon 1900210000 O-Ring 5,0x1,5 MM  €2.13
24
 photo_cameraImage coming soon 2601099146 Protection cover €5.77
27
 photo_cameraImage coming soon 2609001247 Reversing Switch €0.24
30
 photo_cameraImage coming soon 2606135130 Drilling Spindle €27.47
31
 photo_cameraImage coming soon 2608572242 Keyless Chuck €84.30
32
 photo_cameraImage coming soon 1900905163 Deep-Groove Ball Bearing 17x35x10 €14.25
33
 photo_cameraImage coming soon 2916650008 Spring retaining ring DIN 471 17x1 MM €2.18
34
 photo_cameraImage coming soon 2916660014 Spring retaining ring DIN 472 35x1,5 MM €2.18
35
 photo_cameraImage coming soon 2600100695 Shim 0,5 MM €2.18
36
 photo_cameraImage coming soon 2606317084 Cylindrical Gear €17.81
37
 photo_cameraImage coming soon 2606317098 Cylindrical Gear €16.04
38
 photo_cameraImage coming soon 2600190105 Catch Disk €3.24
39
 photo_cameraImage coming soon 2604616013 Compression Spring €3.24
42
 photo_cameraImage coming soon 2600000021 Shim washer 1,0 MM €2.18
43
 photo_cameraImage coming soon 1903230009 Ball DIN 5401-5 G28  €1.43
44
 photo_cameraImage coming soon 1600100632 Shim 0,2 MM THICK €1.57
46
 photo_cameraImage coming soon 2606440017 Carrier €18.14
47
 photo_cameraImage coming soon 2602210043 Eccentric €3.01
48
 Shim Washer 0,3 mm for Hammer Drill Bosch GSB 18-2 RE 2600100607 Shim Washer 0,3 mm for Hammer Drill Bosch GSB 18-2 RE €2.09
50
 photo_cameraImage coming soon 2600202008 Retaining snap ring €4.78
65
 photo_cameraImage coming soon 2601990045 Fork Lever €1.57
66
 photo_cameraImage coming soon 2600101671 Retaining Washer €2.18
67
 photo_cameraImage coming soon 2602300032 Flat Key €4.56
68
 photo_cameraImage coming soon 2604616014 Compression Spring €1.43
69
 photo_cameraImage coming soon 2602026137 Rotary Knob €3.70
70
 photo_cameraImage coming soon 3600210003 O-Ring 15,6x1,8 MM €1.57
71
 Ratchet Cap for Hammer Drill Bosch GSB 20-2 RE 2600590006 Ratchet Cap for Hammer Drill Bosch GSB 20-2 RE €2.09
77
 photo_cameraImage coming soon 2602123007 Rocker €0.24
78
 photo_cameraImage coming soon 2601329043 Contact Strap  €1.57
80
 photo_cameraImage coming soon 2601990044 Guiding Plate €1.57
83
 photo_cameraImage coming soon 2604610056 Compression Spring €1.57
91
 photo_cameraImage coming soon 2603435088 Thread-forming tap. Screw €2.12
92
 Carbon Brushes Holder White Wire for Impact Drills Bosch GSB 13 RE 1614431025 Carbon Brushes Holder White Wire for Impact Drills Bosch GSB 13 RE €3.04
94
 photo_cameraImage coming soon 2601116906 Reference Plate €3.70
96
 Carbon Brushes Holder Blu Wire for Impact Drills Bosch GSB 13 RE 2604448228 Carbon Brushes Holder Blu Wire for Impact Drills Bosch GSB 13 RE €3.04
808
 photo_cameraImage coming soon 2601115034 Nameplate €3.70
829
 photo_cameraImage coming soon 2605806886 Gear Housing €44.93
845
 photo_cameraImage coming soon 2606309940 Transmission €27.47
855
 photo_cameraImage coming soon 2602025904 Handle €10.11
860
 photo_cameraImage coming soon 2605807940 Bearing Bracket €39.90
880
 photo_cameraImage coming soon 2605190921 Box €14.35
883
 photo_cameraImage coming soon 2607030901 Filter €12.87
890
 photo_cameraImage coming soon 2607001305 Fastening parts kit  €6.01

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Bosch Spare Parts for Percussion Drill PSB 800-2 RA

Bosch original spare parts to replace worn components or repair damaged parts of the Percussion Drill PSB 800-2 RA - 3603A72700.

In the following table, look for the model of the Percussion Drill and the respective parts of the code.
Bosch PSB 800-2 RA - 3603A72700

Percussion Drill PSB 800-2 RA/3 603 A72 700
# Part Num. Description
1 2605105081 Housing Section
2 2604220669 Field 230V
3 2604011329 Armature 230V
4 2607200601 Switch
5 1607000387 Power supply cord EU 2,65m 2 x 0,75mm
6 2609002019 Grommet
9 2601116998 Manufacturer's nameplate PSB 800-2 RA
2609002038 Manufacturer's nameplate PSB 780-2 RE
16 2604337059 Brush Plate
21 2910611002 Tapping Screw DIN 7981-ST2,2x9,5-C-H
22 2603490022 Torx Oval-Head Screw 4x16
23 1900210000 O-Ring 5,0x1,5 MM
24 2601099146 Protection cover
27 2609001247 Reversing Switch
30 2606135130 Drilling Spindle
31 2608572242 Keyless Chuck
32 1900905163 groove ball bearing 17x35x10
33 2916650008 Spring retaining ring DIN 471 17x1 MM
34 2916660014 Spring retaining ring DIN 472 35x1,5 MM
35 2600100695 Shim 0,5 MM
36 2606317084 Cylindrical Gear
37 2606317098 Cylindrical Gear
38 2600190105 Catch Disk
39 2604616013 Compression Spring
42 2600000021 Shim washer 1,0 MM
2600000030 Shim washer 1,35 MM
2600000031 Shim washer 1,7 MM
43 1903230009 Ball DIN 5401-5 G28
1903230010 Ball DIN 5401-5,5MM-III-ST
2603230007 Ball 5,25 MM
44 1600100632 Shim 0,2 MM THICK
46 2606440017 Carrier
47 2602210043 Eccentric
48 2600100607 Shim 0,3 MM
49 2609007376 Roller Body
50 2600202008 Retaining snap ring
63 2601328003 Holding Plate
64 2602033017 Link Guide
65 2601990045 Fork Lever
66 2600101671 Retaining Washer
67 2602300032 Flat Key
68 2604616014 Compression Spring
69 2602026137 Rotary Knob
70 3600210003 O-Ring 15,6x1,8 MM
71 2600590006 Ratchet Cap
77 2602123007 Rocker
78 2601329043 Contact Strap
80 2601990044 Guiding Plate
81 2602098021 Changeover Lever
82 2601290030 Leaf Spring
83 2604610056 Compression Spring
84 2603105115 Bolt
85 2605510222 Sealing cap
90 2603435087 Headless Screw
91 2603435088 Thread-forming tap. Screw
92 1614431025 Pvc-Insulated Cable L=95 MM
93 2601328077 Air Path
94 2601116906 Reference Plate
95 2601250010 Pickup Clip
96 2604448228 Pvc-Insulated Cable L=120 MM BLUE
657/1 2600206003 Friction Ring
808 2601115034 Nameplate
829 2605806886 Gear Housing
845 2606309940 Transmission
855 2602025904 Handle
860 2605807940 Bearing Bracket
883 2607030901 Filter
880 2605190921 Box
890 2607001305 Fastening parts kit

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Bosch websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Bosch brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
