Bosch Spare Parts for Mitre Saw PCM 7
€15.52
VAT included
Bosch Spare Parts for Mitre Saw PCM 7
Bosch original spare parts for to replace broken parts for to fix Mitre Saw PCM 7 - 3603M01200.Fix Your Mitre Saw PCM 7 - 3603M01200. All Spares are Ready For Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
Bosch Spare Parts for Mitre Saw PCM 7
€15.52
VAT included
Bosch Spare Parts for Mitre Saw PCM 7
Bosch original spare parts for to replace broken parts for to fix Mitre Saw PCM 7 - 3603M01200.Fix Your Mitre Saw PCM 7 - 3603M01200. All Spares are Ready For Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
settings
37 spare parts
description
3 exploded views
verified_user
Original Product
Manufacturer warranty included
support_agent
Technical Support
Our team helps you choose
Secure and guaranteed payments
37 spare parts
Page 1
zoom_in View exploded
local_shipping Usually Ships in: 10 BUSYNESS DAYS
Page 2
zoom_in View exploded
local_shipping Usually Ships in: 10 BUSYNESS DAYS
Page 3
zoom_in View exploded
local_shipping Usually Ships in: 10 BUSYNESS DAYS
| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
4
|
photo_cameraImage coming soon | 1609BP7160 Switch | €11.25 | |
|
12
|
photo_cameraImage coming soon | 1609BP7165 Motor Capacitor | €1.88 | |
|
129
|
photo_cameraImage coming soon | 1609BP7059 Connection Block | €1.32 | |
|
138
|
photo_cameraImage coming soon | 1609BP7109 Cover | €1.57 | |
|
149
|
photo_cameraImage coming soon | 1609BP7021 Dust Bag | €12.93 | |
|
805
|
photo_cameraImage coming soon | 1609BP7173 Power supply cord | €18.86 | |
|
8110
|
photo_cameraImage coming soon | 1609BP7197 Gear | €27.73 | |
|
8121
|
photo_cameraImage coming soon | 1609BP7198 Flange | €11.06 | |
|
8123
|
photo_cameraImage coming soon | 1609BP7199 Safety Cover | €18.49 | |
|
8126
|
photo_cameraImage coming soon | 1609BP7200 Trigger | €1.32 | |
|
8127
|
photo_cameraImage coming soon | 1609BP7219 Set Of Handles | €16.12 |
Informazioni sulle spedizioni e consegne saranno disponibili a breve.
Bosch Spare Parts for Mitre Saw PCM 7
Bosch original spare parts for to replace broken parts for to fix Mitre Saw PCM 7 - 3603M01200.In the following table, look for the model of the Miter Saw and the respective parts of the code.
| BOSCH Mitre Saw PCM 7 - 3603M01200 | ||
| # | Part NUm. | Description |
| 4 | 1609BP7160 | Switch |
| 12 | 1609BP7165 | Motor Capacitor |
| 37 | 1609BP7026 | Hexagon Socket Screw Key |
| 53 | 1609BP7215 | Wear Plate |
| 129 | 1609BP7059 | Connection Block |
| 130 | 1609BP7064 | Cable |
| 138 | 1609BP7109 | Cover |
| 149 | 1609BP7021 | Dust Bag |
| 801 | 1609BP7170 | Motor Housing |
| 802 | 1609BP7171 | Stator 230V |
| 803 | 1609BP7172 | Armature 230V |
| 805 | 1609BP7173 | Power supply cord |
| 807 | 1609BP7174 | Strain-Relief Clamp |
| 810 | 1609BP7209 | Carbon-Brush Set |
| 822 | 1609BP7175 | Base |
| 823 | 1609BP7176 | Saw Table |
| 824 | 1609BP7177 | Mitre Fence |
| 825 | 1609BP7210 | Rubber Bushing |
| 826 | 1609BP7178 | Ball |
| 834 | 1609BP7179 | Locking Lever |
| 840 | 1609BP7180 | Sliding Plate |
| 842 | 1609BP7181 | Pointer |
| 844 | 1609BP7182 | Insert |
| 846 | 1609BP7183 | Fastening parts kit |
| 850 | 1609BP7184 | Handle Bar |
| 856 | 1609BP7185 | Shaft |
| 861 | 1609BP7186 | Pointer |
| 867 | 1609BP7187 | Lever |
| 869 | 1609BP7188 | Detent Pin |
| 871 | 1609BP7189 | Support Element |
| 873 | 1609BP7190 | Laser module |
| 884 | 1609BP7191 | Torsion Spring |
| 885 | 1609BP7192 | Clamping Piece |
| 892 | 1609BP7193 | Locking Device |
| 896 | 1609BP7211 | Tapping Screw |
| 897 | 1609BP7212 | Cover |
| 899 | 1609BP7194 | Locking Device |
| 8102 | 1609BP7195 | Baffle |
| 8103 | 1609BP7196 | Housing |
| 8110 | 1609BP7197 | Gear |
| 8121 | 1609BP7198 | Flange |
| 8123 | 1609BP7199 | Safety Cover |
| 8126 | 1609BP7200 | Trigger |
| 8127 | 1609BP7219 | Set Of Handles |
| 8142 | 1609BP7203 | Protective Cover |
| 8146 | 1609BP7204 | Linkage |
| 8150 | 1609BP7164 | Clamp |
