Bosch Spare Parts for Mitre Saw PCM 7 S
€15.34
VAT included
Bosch Spare Parts for Mitre Saw PCM 7 S
We are BOSCH original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Mitre Saw PCM 7 S - 3603M01300.
Bosch Spare Parts for Mitre Saw PCM 7 S
€15.34
VAT included
Bosch Spare Parts for Mitre Saw PCM 7 S
We are BOSCH original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Mitre Saw PCM 7 S - 3603M01300.
settings
46 Spare parts
description
3 exploded views
verified_user
Original Product
Manufacturer warranty included
support_agent
Technical Support
Our team helps you choose
Secure and guaranteed payments
46 spare parts
Page 1
zoom_in View exploded
local_shipping ON DEMAND ONLY
Page 2
zoom_in View exploded
local_shipping ON DEMAND ONLY
Page 3
zoom_in View exploded
local_shipping ON DEMAND ONLY
| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
4
|
photo_cameraImage coming soon | 1609BP7160 Switch | €10.92 | |
|
12
|
photo_cameraImage coming soon | 1609BP7165 Motor Capacitor | €2.38 | |
|
129
|
photo_cameraImage coming soon | 1609BP7059 Connection Block | €1.16 | |
|
138
|
photo_cameraImage coming soon | 1609BP7109 Cover | €1.16 | |
|
155
|
photo_cameraImage coming soon | 1609BP7021 Dust Bag | €13.36 | |
|
805
|
photo_cameraImage coming soon | 1609BP7173 Power supply cord | €19.46 | |
|
8111
|
photo_cameraImage coming soon | 1609BP7197 Gear | €28.00 | |
|
8121
|
photo_cameraImage coming soon | 1609BP7198 Flange | €10.92 | |
|
8123
|
photo_cameraImage coming soon | 1609BP7389 Safety Cover | €15.80 | |
|
8126
|
photo_cameraImage coming soon | 1609BP7200 Trigger | €1.16 | |
|
8127
|
photo_cameraImage coming soon | 1609BP7219 Set Of Handles | €15.80 | |
|
8142
|
photo_cameraImage coming soon | 1609BP7390 Protective Cover | €14.58 |
Informazioni sulle spedizioni e consegne saranno disponibili a breve.
Bosch Spare Parts for Mitre Saw PCM 7 S
We are BOSCH original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Mitre Saw PCM 7 S - 3603M01300.
In the following table, look for the model of the Miter Saw and the respective parts of the code.
| Bosch Miter Saw PCM 7 S/3 603 M01 300 | ||
| # | Part Num. | Description |
| 4 | 1609BP7160 | Switch |
| 12 | 1609BP7165 | Motor Capacitor |
| 37 | 1609BP7026 | Hexagon Socket Screw Key |
| 42 | 1609BP7313 | Handle |
| 44 | 1609BP7312 | Insert |
| 45 | 1609B00634 | Screw |
| 72 | 1609BP7351 | Wear Plate |
| 97 | 1609BP7072 | Cover |
| 129 | 1609BP7059 | Connection Block |
| 130 | 1609BP7064 | Cable |
| 138 | 1609BP7109 | Cover |
| 141 | 1609BP7063 | Contact strap |
| 145 | 1609BP7049 | Spring retaining ring |
| 155 | 1609BP7021 | Dust Bag |
| 156 | 1609BP7164 | Clamp |
| 801 | 1609BP7370 | Motor Housing |
| 802 | 1609BP7171 | Stator 230V |
| 803 | 1609BP7172 | Armature 230V |
| 805 | 1609BP7173 | Power supply cord |
| 807 | 1609BP7174 | Strain-Relief Clamp |
| 810 | 1609BP7209 | Carbon-Brush Set |
| 814 | 1609BP7386 | Handle |
| 821 | 1609BP7392 | Extension Stand |
| 822 | 1609BP7371 | Base |
| 823 | 1609BP7372 | Saw Table |
| 824 | 1609BP7377 | Mitre Fence |
| 825 | 1609BP7210 | Rubber Bushing |
| 826 | 1609BP7178 | Ball |
| 835 | 1609BP7393 | Support |
| 840 | 1609BP7378 | Wear Plate |
| 841 | 1609BP7379 | Pointer |
| 846 | 1609BP7381 | Bolt |
| 850 | 1609BP7375 | Support |
| 853 | 1609BP7376 | Stop Plate |
| 856 | 1609BP7383 | Shaft |
| 861 | 1609BP7384 | Pointer |
| 867 | 1609BP7373 | Lever |
| 869 | 1609BP7188 | Detent Pin |
| 871 | 1609BP7385 | Support Element |
| 873 | 1609BP7380 | Laser |
| 884 | 1609BP7191 | Torsion Spring |
| 885 | 1609BP7192 | Clamping Piece |
| 892 | 1609BP7193 | Locking Device |
| 896 | 1609BP7211 | Tapping Screw |
| 899 | 1609BP7194 | Locking Device |
| 8102 | 1609BP7387 | Baffle |
| 8103 | 1609BP7388 | Housing |
| 8107 | 1609BP7394 | Knob |
| 8111 | 1609BP7197 | Gear |
| 8121 | 1609BP7198 | Flange |
| 8123 | 1609BP7389 | Safety Cover |
| 8126 | 1609BP7200 | Trigger |
| 8127 | 1609BP7219 | Set Of Handles |
| 8142 | 1609BP7390 | Protective Cover |
| 8146 | 1609BP7391 | Linkage |
| 8149 | 1609BP7382 | Leaf Spring |
| 8151 | 1609BP7374 | Bearing |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Bosch websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Bosch brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch PCM 7 S - 3603M01300
