Bosch Spare Parts for Drill Screwdriver
€38.38
VAT included
Bosch Spare Parts for Drill Screwdriver GSR 6-45 TE 601 D40 300
Bosch genuine replacement parts for to replace broken parts for to fix Drill Screwdriver GSR 6-45 TE - 3601D40300.
Bosch Spare Parts for Drill Screwdriver
€38.38
VAT included
Bosch Spare Parts for Drill Screwdriver GSR 6-45 TE 601 D40 300
Bosch genuine replacement parts for to replace broken parts for to fix Drill Screwdriver GSR 6-45 TE - 3601D40300.
settings
27 spare parts
description
1 exploded view
verified_user
Original Product
Manufacturer warranty included
support_agent
Technical Support
Our team helps you choose
Secure and guaranteed payments
27 spare parts
Page 1
zoom_in View exploded
local_shipping Usually Ships in: 10 BUSYNESS DAYS
Informazioni sulle spedizioni e consegne saranno disponibili a breve.
Bosch Spare Parts for Drill Screwdriver GSR 6-45 TE 601 D40 300
Bosch genuine replacement parts for to replace broken parts for to fix Drill Screwdriver GSR 6-45 TE - 3601D40300.
In the following table, look for the model of the Drill Screwdriver and the respective parts of the code.
| Drill Screwdriver GSR 6-45 TE/3 601 D40 300. | ||
| 1 | 2605108083 | Motor Housing DARK BLUE |
| 2 | 2604220456 | Field 220-240V |
| 4 | 2607200638 | Switch |
| 6 | 2600703017 | Grommet Ø6,4-Ø7,2x76 MM |
| 7 | 2601035004 | Cable Clip |
| 9 | 2601115057 | Manufacturer's nameplate |
| 12 | 2607329151 | Suppression Filter |
| 16 | 2605807124 | Brush Plate |
| 19 | 2603490021 | Torx Oval-Head Screw 4x12 |
| 20 | 2601115265 | Reference Plate |
| 21 | 2605500196 | Switch Cover RED |
| 22 | 2910541050 | Countersunk-Head Screw DIN 7991 M3x8-8.8 |
| 26 | 2603490024 | Torx Oval-Head Screw 4x25 |
| 29 | 2601328078 | Cover Disc |
| 31 | 2602391004 | Rubber Buffer |
| 38 | 2603490023 | Torx Oval-Head Screw 4x20 |
| 47 | 2605132061 | Housing Cover DARK BLUE |
| 70 | 2601329113 | Belt holder clip |
| 803 | 2604011926 | Armature 220-240V |
| 805 | 1607000386 | Power supply cord EU 230V 4,15m 2 x 1,0mm H05 RN-F |
| 808 | 2601115215 | Marking Plate |
| 810 | 2604321943 | Carbon-Brush Set |
| 830 | 2606200237 | Gear Unit |
| 841 | 2601015097 | Seal |
| 870 | 2602025165 | Depth-Gauge |
| 870/78 | 3600290502 | Seal ring |
| 871 | 2602025166 | Depth-Gauge |
| 872 | 2602025167 | Depth-Gauge |
| 887 | 3603008500 | Toolholder 1/4" |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch GSR 6-45 TE - 3601D40300
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N BOSCH:
- BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
