Bosch GSB 183-LI Parts

SKU: Bosch GSB 183-LI - 3601JK91E1
€53.18
VAT included

Bosch Spare Parts for Cordless Percussion Drill GSB 183-LI

Bosch genuine spare parts for to repair Cordless Percussion Drill GSB 183-LI - 3601JK91E1.

Bosch GSB 183-LI
Bosch GSB 183-LI Parts
  • Out-of-Stock
  • Bosch GSB 183-LI Parts
  • Bosch GSB 183-LI Parts Drawing
Bosch

Bosch GSB 183-LI Parts

SKU: Bosch GSB 183-LI - 3601JK91E1 Condition: New
€53.18
VAT included

Bosch Spare Parts for Cordless Percussion Drill GSB 183-LI

Bosch genuine spare parts for to repair Cordless Percussion Drill GSB 183-LI - 3601JK91E1.

Bosch GSB 183-LI
settings 14 Spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Out-of-Stock

SHIPPING IN: ON DEMAND ONLY
CHECK ITEM CODE OR S/N: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH: BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
14 spare parts
Page 1 zoom_in View exploded local_shipping ON DEMAND ONLY
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
4
 Image coming soon 2607202535 Electronics Module €51.18
5
 Image coming soon 1600A026R5 Changeover Lever €1.16
25
 Image coming soon 1600A027W8 Keyless Chuck €45.08
32
 Image coming soon 1600A012MM Switchover Unit €1.16
45
 Image coming soon 1600A026R8 Gear Box €57.28
46
 Image coming soon 160461205J Compression Spring €23.12
91
 Image coming soon 1607A350MA Battery Pack GBA 18V 2.0AH €139.02
101
 Image coming soon 2609110201 Torx Flat-Head Screw 3x16 €2.38
107
 Countersunk-Head Screw M6x23 2603421229 Countersunk-Head Screw M6x23 €2.38
653
 Image coming soon 2607226289 Fast Charger LAM GAL18V-20 €102.42
653
 Image coming soon 2607226295 Fast Charger BR GAL18V-20, 127V–220V €112.18
653
 Image coming soon 2607226299 Fast Charger AR GAL18V-20 €102.42
801
 Image coming soon 16051082WH Motor Housing €0.00 Not available for order
802
 Image coming soon 16070226BW DC Motor €0.00 Not available for order

Shipping and delivery information will be available shortly.

Bosch Spare Parts for Cordless Percussion Drill GSB 183-LI

Bosch genuine spare parts for to repair Cordless Percussion Drill GSB 183-LI - 3601JK91E1.

In the following table, look for the model of the Percussion Drill and the respective parts of the code.
Bosch GSB 183-LI - 3601JK91E1
Cordl Perc Screwdr GSB 183-LI - 3601JK91E1
# Part Num Description
4 2607202535 Electronics Module
5 1600A026R5 Changeover Lever
25 1600A027W8 Keyless Chuck
32 1600A012MM Switchover Unit
45 1600A026R8 Gear Box
46 160461205J Compression Spring
91 1607A350MA Battery Pack GBA 18V 2.0AH
101 2609110201 Torx Flat-Head Screw 3X16
107 2603421229 Countersunk-Head Screw M6X23 LH THREADS
653 2607226289 Fast Charger LAM GAL18V-20
653 2607226295 Fast Charger BR GAL18V-20, 127V–220V
653 2607226299 Fast Charger AR GAL18V-20
801 16051082WH Motor Housing
802 16070226BW DC Motor
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
