Bosch Parts for Cordless Percussion Screwdriver GSB 18V-28

SKU: Bosch GSB 18V-28 - 3601JE7101
€46.30
VAT included

Bosch Parts for Cordless Percussion Screwdriver GSB 18V-28

Bosch genuine spare parts for to repair Cordless Percussion Screwdriver GSB 18V-28 - 3601JE710.

Bosch GSB 18V-28 - 3601JE710
Bosch Parts for Cordless Percussion Screwdriver GSB 18V-28
  • Bosch Parts for Cordless Percussion Screwdriver GSB 18V-28
  • Bosch Parts for Cordless Percussion Screwdriver GSB 18V-28 - Drawing
Bosch

Bosch Parts for Cordless Percussion Screwdriver GSB 18V-28

SKU: Bosch GSB 18V-28 - 3601JE7101 Condition: New
€46.30
VAT included

Bosch Parts for Cordless Percussion Screwdriver GSB 18V-28

Bosch genuine spare parts for to repair Cordless Percussion Screwdriver GSB 18V-28 - 3601JE710.

Bosch GSB 18V-28 - 3601JE710
settings 22 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:: BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
22 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 2609101483 Housing €39.19
4
 photo_cameraImage coming soon 160723359P Electronics Module €93.69
5
 photo_cameraImage coming soon 2609101484 Adjusting lever €2.51
9
 photo_cameraImage coming soon 160111C2F7 Manufacturer's nameplate €2.92
25
 photo_cameraImage coming soon 2609111944 Keyless Chuck €76.78
32
 photo_cameraImage coming soon 2609199812 Switchover Unit €2.92
45
 photo_cameraImage coming soon 1600A00S4H Gear Box €69.54
46
 photo_cameraImage coming soon 1609280477 Compression Spring €2.44
47
 photo_cameraImage coming soon 2609101486 Lens €1.23
101
 photo_cameraImage coming soon 2609110353 Torx Oval-Head Screw  €3.17
103
 photo_cameraImage coming soon 2609110835 Nut  €1.92
107
 photo_cameraImage coming soon 2603421229 Countersunk-Head Screw M6x23 €2.13
802
 photo_cameraImage coming soon 2609199841 DC motor €76.78
804
 photo_cameraImage coming soon 1609280478 Contact retainer €17.09
808
 photo_cameraImage coming soon 160111A5K3 Nameplate €2.92
851
 photo_cameraImage coming soon 1607A350BG Battery PackEU GBA 18V 2.0Ah Li SCM €117.04
851
 photo_cameraImage coming soon 1607A350BZ Battery Pack EU GBA 18V 1.5Ah Li SCM €85.38
851
 photo_cameraImage coming soon 2607336815 Slide-In Accu Package BBS MR 18V, 4,0Ah, LI €169.16
853
 photo_cameraImage coming soon 2607225321 Charger EU 230/10,8-18V, 30 MIN €93.69
853
 photo_cameraImage coming soon 2607225323 Charger GB 230/10,8-18V, 30 MIN €112.85
853
 photo_cameraImage coming soon 2607225423 Fast Charger EU 230/10,8-18V, 1h €102.13
853
 photo_cameraImage coming soon 2607225425 Fast Charger GB 230/10,8-18V, 1h €102.13

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Bosch Parts for Cordless Percussion Screwdriver GSB 18V-28

Bosch genuine spare parts for to repair Cordless Percussion Screwdriver GSB 18V-28 - 3601JE710.

In the following table, look for the model of the Percussion Drill and the respective parts of the code.
Bosch GSB 18V-28 - 3601JE710

Bosch Cordless Percussion Screwdriver GSB 18V-28 - 3601JE7101
# Part Num. Description
1 2609101483 Housing
4 160723359P Electronics Module
5 2609101484 Adjusting lever
9 160111C2F7 Manufacturer's nameplate
25 2609111944 Keyless Chuck
32 2609199812 Switchover Unit
45 1600A00S4H Gear Box
46 1609280477 Compression Spring
47 2609101486 Lens
101 2609110353 Torx Oval-Head Screw
103 2609110835 Nut
107 2603421229 Countersunk-Head Screw M6x23 LEFTHAND THREADS
802 2609199841 DC motor
804 1609280478 Contact retainer
808 160111A5K3 Nameplate
851 1607A350BG Battery Pack EU GBA 18V 2.0Ah Li SCM
851 1607A350BZ Battery Pack EU GBA 18V 1.5Ah Li SCM
851 2607336815 Battery Pack BBS MR 18V, 4,0Ah, 47 S
853 2607225321 Charger EU 230/14,4-18V, 30 40 S
853 2607225323 Charger GB 230/10,8-18V, 30 42 S
853 2607225423 Fast Charger EU AL 1820 CV 220V
853 2607225425 Fast Charger GB 230/10,8-18V, 1h

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch GSB 18V-28 - 3601JE7101
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:
BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS

Specific References

New

Download

Drawing Bosch GSB 18V-28

Drawing Bosch GSB 18V-28

Download (281.42KB)
