Bosch Spare Parts for Marble Cutting Saw GDC 125

SKU: Bosch GDC 125 - 3601E48000
€1.56
VAT included

Bosch Spare Parts for Marble Cutting Saw GDC 125

Bosch original spare parts for to replace broken parts for to fix Marble Cutting Saw Bosch GDC 125 - 3601E48000.



Bosch Spare Parts for Marble Cutting Saw GDC 125
  • Bosch Spare Parts for Marble Cutting Saw GDC 125
  • Bosch Spare Parts for Marble Cutting Saw GDC 125

Bosch Spare Parts for Marble Cutting Saw GDC 125

SKU: Bosch GDC 125 - 3601E48000 Condition: New
€1.56
VAT included

Bosch Spare Parts for Marble Cutting Saw GDC 125

Bosch original spare parts for to replace broken parts for to fix Marble Cutting Saw Bosch GDC 125 - 3601E48000.



settings 4 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 10 Business Days Approx

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:: BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

4 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Bosch Spare Parts for Marble Cutting Saw GDC 125

Bosch original spare parts for to replace broken parts for to fix Marble Cutting Saw Bosch GDC 125 - 3601E48000.

In the following table, look for the model of the Marble Cutting Saw and the respective parts of the code.
Bosch GDC 125 - 3601E48000

Marble Cutting Saw GDC 125/3 601 E48 000
2 F000607063 Field 220 V
3 F000605231 Armature With Fan 220V
8 F000616044 Supporting Disc
9 9618082293 Brake Disc
10 F000616134 Hex Socket Head Cap Screw
12 F000608414 Suppression Capacitor
13 2600905032 Ball Bearing 7x19x6
14 F000615004 groove ball bearing
16 F000612082 Brush Holder
25 F000618002 Cylindrical Gear
26 F000619026 Spindle
27 F000613083 Bearing
28 F000604013 Cover Disc
33 F000603061 Brush Holder
35 F000617024 Cylindrical Gear
36 F000613053 Motor Bearing
37 1600502011 Intermediate Ring
38 F000603029 Protective Guard
39 F000603027 Protective Cover
40 9618087099 Tapping Screw 4x16 MM
42 9618086615 Screw M 4x12 MM
44 F000600217 Tapping Screw
45 F000616166 Hex Socket Head Cap Screw
46 F000613064 Base Plate
48 F000603060 Sealing cap
49 F000615011 Needle bearing
50 F000616165 Hex Nut
52 F000640007 O-Ring
53 F000640008 O-Ring
54 1601025001 Wire Guide
56 2916012014 Plain Washer A 6,4 DIN 125-ST
58 F000616053 Knob
71 F000620013 Spring
72 F000616122 Detent Pin
73 2916080008 Locking Washer DIN 6799-5-FSt
74 F000600290 Time-Delay Switch
98 F000616394 Screw
99 F000616395 Toothed lock washer
650/6 F000630036 Low Pressure Hose
801 F000601323 Housing
804 F000608006 On-Off Switch
805 F000609274 Power supply cord BR 2,00m 2 x 1,00mm H05 VVF
806 3600703011 Grommet Ø9,2-Ø12x120 MM
816 F000611036 Carbon Brush
853 F000634146 Shut-Off Tap

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Bosch websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Bosch brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch GDC 125 - 3601E48000
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:
BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS

Specific References

New

Download

Diagram Bosch GDC 125

Diagram Bosch GDC 125

Download (152.45KB)
