Bosch

Bosch Spare Parts for Cordless Screw Driver EXACT 12

SKU: Bosch EXACT 12
€1.76
VAT included

Bosch Spare Parts for Cordless Screw Driver EXACT 12

Bosch genuine replacement parts for to replace broken parts for to fix Cordless Screw Driver EXACT 12/0 602 490 441.

Bosch Spare Parts for Cordless Screw Driver EXACT 12
  • Bosch Spare Parts for Cordless Screw Driver EXACT 12
  • Bosch Spare Parts for Cordless Screw Driver EXACT 12
Bosch

Bosch Spare Parts for Cordless Screw Driver EXACT 12

SKU: Bosch EXACT 12 Condition: New
€1.76
VAT included

Bosch Spare Parts for Cordless Screw Driver EXACT 12

Bosch genuine replacement parts for to replace broken parts for to fix Cordless Screw Driver EXACT 12/0 602 490 441.

settings 56 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:: BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
56 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 3605105016 Housing Section €26.51
4
 photo_cameraImage coming soon 3607200107 Electronic Assembly €330.51
10
 photo_cameraImage coming soon 3601099003 Switch Slide €2.01
20
 photo_cameraImage coming soon 3606328018 Pinion €3.69
29
 photo_cameraImage coming soon 2605719011 Intermediate Flange €2.85
30
 photo_cameraImage coming soon 3607030490 Planetary Gear Train €51.85
40
 photo_cameraImage coming soon 3607031535 Assembly kit €302.51
60
 photo_cameraImage coming soon 3601923022 Switching Element €3.69
61
 photo_cameraImage coming soon 3604611022 Compression Spring €2.85
62
 photo_cameraImage coming soon 3601923029 Pusher €2.85
71
 photo_cameraImage coming soon 3604460132 Light Conductor €1.73
80
 Torx Oval-Head Screw mm 3x18 for Cordless Drill Bosch 2603490018 Torx Oval-Head Screw mm 3x18 for Cordless Drill Bosch €0.93
101
 photo_cameraImage coming soon 3606445043 Clutch Element €114.91
102
 photo_cameraImage coming soon 3603124023 Output Shaft €76.21
106
 photo_cameraImage coming soon 3604610011 Compression Spring €2.01
109
 photo_cameraImage coming soon 3604619020 Compression Spring BLUE €4.46
110
 photo_cameraImage coming soon 3600224053 Retaining ring €1.31
113
 photo_cameraImage coming soon 3600499023 Clamp Bushing €14.05
114
 photo_cameraImage coming soon 3600921001 Plain bearing €7.68
115
 photo_cameraImage coming soon 3601023011 Sealing plate €2.01
116
 photo_cameraImage coming soon 3600134014 Setting Ring €30.01
117
 photo_cameraImage coming soon 1600101023 Plain Washer 0,5 MM THICK €1.31
119
 photo_cameraImage coming soon 3600190036 Support Disc €6.42
120
 photo_cameraImage coming soon 3603344046 Catch Disk €33.79
122
 photo_cameraImage coming soon 3600101052 Shim washer €6.42
125
 photo_cameraImage coming soon 3600202020 Backup ring €6.42
126
 photo_cameraImage coming soon 3600224006 Retaining ring €2.01
127
 photo_cameraImage coming soon 1903230006 Ball DIN 5401-3,5 MM-III-ST €1.73
129
 photo_cameraImage coming soon 1903230003 Ball DIN 5401-2,5MM-III-ST €1.73
140
 Locking Washer for Electric Chain Saw Bosch GKE 40 BCE 2916080012 Locking Washer for Electric Chain Saw Bosch GKE 40 BCE €1.67
143
 photo_cameraImage coming soon 3600210038 O-Ring 9,0x1,2 MM €2.01
145
 photo_cameraImage coming soon 3600210116 O-Ring €1.73
657
 photo_cameraImage coming soon 3607950027 Screwdriver €12.23
750
 photo_cameraImage coming soon 3601923024 Suspension Loop €8.73
751
 photo_cameraImage coming soon 3605500210 Protective Cap 5 PIECE €17.97
801
 photo_cameraImage coming soon 2607335683 Slide-In Accu Package 12V,2,6Ah,NiMh €389.71
802
 photo_cameraImage coming soon 3607031538 DC motor 12V €63.26
803
 photo_cameraImage coming soon 3609202764 Light-Emitting-Diode €17.97
804
 photo_cameraImage coming soon 3609202762 Microswitch €23.08
805
 photo_cameraImage coming soon 3609202766 Plug Set €5.02
806
 photo_cameraImage coming soon 3607200083 Switch €57.66
820
 photo_cameraImage coming soon 3603344047 Catch Disk €23.08
854
 photo_cameraImage coming soon 2607224435 Fast Charger J 100/7,2-24V, 1h  €144.63
854
 photo_cameraImage coming soon 2607225027 Fast Charger EU 230/7,2-24V, 30 MIN. €306.10
854
 photo_cameraImage coming soon 2607225029 Fast Charger GB 230/7,2-24V, 30 MIN. €129.88
854
 photo_cameraImage coming soon 2607225031 Fast Charger AUS 240/7,2-24V, 30 MIN. €129.88
854
 photo_cameraImage coming soon 2607225033 Fast Charger USA 120/7,2-24V, 30 MIN. €114.91
854
 photo_cameraImage coming soon 2607225039 Fast Charger ROK 220/7,2-24V, 30 MIN. €105.60
855
 photo_cameraImage coming soon 16070312A1 Nameplate €5.02
866
 photo_cameraImage coming soon 3601119210 Manufacturer's nameplate €5.02
890
 photo_cameraImage coming soon 3600106010 Parts Set 5 PCE., BLACK €17.97
890
 photo_cameraImage coming soon 3600106011 Parts Set 5 PCE., RED €17.97
890
 photo_cameraImage coming soon 3600106012 Parts Set 5 PCE,. LIGHT BLUE €17.97
890
 photo_cameraImage coming soon 3600106013 Parts Set 5 PCE,. LIGHT GREEN €17.97
890
 photo_cameraImage coming soon 3600106014 Parts Set 5 PCE., ORANGE €23.08
890
 photo_cameraImage coming soon 3600106015 Parts Set 5 PIECE €26.51

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Bosch Spare Parts for Cordless Screw Driver EXACT 12

Bosch genuine replacement parts for to replace broken parts for to fix Cordless Screw Driver EXACT 12/0 602 490 441.

In the following table, look for the model of the Cordless Screw Driver and the respective parts of the code.
Cordless Screw Driver EXACT 12/0 602 490 441

Cordless Screw Driver EXACT 12/0 602 490 441
# Part Num. Description
1 3605105016 Housing Section
4 3607200107 Electronic Assembly
10 3601099003 Switch Slide
20 3606328018 Pinion
29 2605719011 Intermediate Flange
30 3607030490 Planetary Gear Train
40 3607031535 Assembly kit
60 3601923022 Switching Element
61 3604611022 Compression Spring
62 3601923029 Pusher
71 3604460132 Light Conductor
80 2603490018 Torx Oval-Head Screw 3x18
82 2603414048 Torx SH cap screw M3x5-8.8-Z
101 3606445043 Clutch Element
102 3603124023 Output Shaft
106 3604610011 Compression Spring
109 3604619020 Compression Spring BLUE
110 3600224053 Retaining ring
113 3600499023 Clamp Bushing
114 3600921001 Plain bearing
115 3601023011 Sealing plate
116 3600134014 Setting Ring
117 1600101023 Plain Washer 0,5 MM THICK
119 3600190036 Support Disc
120 3603344046 Catch Disk
122 3600101052 Shim washer
125 3600202020 Backup ring
126 3600224006 Retaining ring
127 1903230006 Ball DIN 5401-3,5 MM-III-ST
128 1903230008 Ball 4,5 MM III DIN 5401-ST
129 1903230003 Ball DIN 5401-2,5MM-III-ST
140 2916080012 Locking Washer DIN 6799-9-FSt
143 3600210038 O-Ring 9,0x1,2 MM
145 3600210116 O-Ring
657 3607950027 Screwdriver
750 3601923024 Suspension Loop
751 3605500210 Protective Cap 5 PIECE
801 2607335683 Slide-In Accu Package 12V,2,6Ah,NiMh
802 3607031538 DC motor 12V
803 3609202764 Light-Emitting-Diode
804 3609202762 Microswitch
805 3609202766 Plug Set
806 3607200083 Switch
820 3603344047 Catch Disk
854 2607225027 Fast Charger EU 230/7,2-24V, 30 MIN.
854 2607225029 Fast Charger GB 230/7,2-24V, 30 MIN.
854 2607225031 Fast Charger AUS 240/7,2-24V, 30 MIN.
854 2607225033 Fast Charger USA 120/7,2-24V, 30 MIN.
854 2607225035 Fast Charger SAM 115/7,2-24V, 15 MIN.
854 2607224435 Fast Charger J 100/7,2-24V, 1h
854 2607225039 Fast Charger ROK 220/7,2-24V, 30 MIN.
855 16070312A1 Nameplate
866 3601119210 Manufacturer's nameplate
890 3600106010 Parts Set 5 PCE., BLACK
890 3600106011 Parts Set 5 PCE., RED
890 3600106012 Parts Set 5 PCE,. LIGHT BLUE
890 3600106013 Parts Set 5 PCE,. LIGHT GREEN
890 3600106014 Parts Set 5 PCE., ORANGE
890 3600106015 Parts Set 5 PIECE
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Bosch websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Bosch brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
